Alphacool ES 80mm

The Alphacool ES 80mm 800-6,000rpm Fan 80x80x25mm was specially developed for use in servers and workstations and, unlike usual, does not offer a 2 or 3-pin DC power connection, but a 4-pin PWM control. The fan always receives full voltage via the 4-pin PWM connection and is controlled by pulse width modulation. This mEAN Code s that the fan can be controlled over a much larger speed range. A considerable amount of energy can be saved by controlling the fans in server racks. The Alphacool ES fan has a double ball bearing for an increased service life under full load. Double ball bearings are generally considered to be the highest quality bearings in terms of durability and quality. The Alphacool ES fans for servers and workstations offer an extremely high air flow and a very high static pressure. They are therefore ideal for operation on radiators or as particularly powerful case fans.Article no.: 1833502 Fan type EAN Code 4250197248297 Manufacturer part number: 24829 Type Case Fan Use for PC cases, suitable for servers Fastening screwed Volume 50 dB Speed 800 to 6,000 rpm Fan bearing ball bearing double Volume flow 130.93 m3/h Air pressure Up to 14.29 mm/H2O Power connector 4-pin PWM Voltage range 7 - 14 volts Power consumption 7.92 - 10.2 watts Note: The speed information on the fan stickers is unfortunately currently incorrect. The 1000-4000 rpm information on the fans is not correct. It is 800-6000 rpm. Dimensions Fan1 Quantity: 1 piece, Width: 80 mm, Height: 80 mm, Depth: 25 mm
