The NVR supports ePoE and EoC technology for use in a broad range of application scenarios. ePoE technology simplifies the network structure of long-range surveillance projects, eliminating the requirement for extra network repeater devices, making the system more reliable and easy to deploy. EoC technology makes it possible to upgrade existing systems to high definition IP surveillance while using existing coax cables. •8 IP channel max, up to 12MP resolution •Max 12MP, Record Rate up to 20Mbps Per Channel •VGA/HDMI up to 3840x2160 output •Dual-stream, 8-ch synchronous playback •2 SATA interface up to 20TB total, Gigabit LAN •PoE: 8 ports (IEEE802.3af/at), All ports support ePoE & EoC, 25.5W for single port, 130W total rated power •No front panel controls, 4/2 alarm I/O, RS232, RS485, 2 USB •1U 19” chassis, mouse included •Free IP monitoring software available •Other brands IP cameras supported: Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, etc., ONVIF Version 2.4 conformance
Capture every detail with the 4K resolution G4-PRO camera. The G4-PRO is our most powerful camera yet, with a large 1/2" image sensor, 3X powered optical zoom lens, and integrated high-power infrared LEDs for night vision. The adjustable base can be mounted to a flat surface or a pole with the included mounting hardware.UniFi Video G4-PRO CameraDimensionsLength: 153mm (6.02") Diameter: 86mm (3.39")Weight0.7kg (1.54lb)EnclosurePC/TPE/Aluminum Alloy(ADC-12 + Liquid Coating)Networking Interface(1) 10/100/1000 Mbps Ethernet PortSensorOS08A10, 1/2"LensF 4.1mm - 12.3mm; f/1.53 -f/3.3LEDLED RingField of View Wide Tele 108° (H), 58° (V), 125° (D) 37° (H), 20° (V), 43° (D)Night ModeIR LEDs with Mechanical IR Cut FilterVideo CompressionH.264Resolution4K2K (3840 x 2160)Max. Frame Rate24 FPSImage SettingsFlip, Brightness, Contrast, WDR, Hue, Infrared, Sharpness, Saturation, Denoise, 50/60 Hz Flicker ReductionManagement Interface Managed Mode Standalone Mode UniFi Protect Camera Integrated Web UIMicrophoneYesMax. Power Consumption12.5WPower MethodIEEE 802.3af/atPower Supply802.3af/802.3at or UniFi PoE SwitchButtonsFactory Reset ButtonMountingWall, Ceiling, Pole (Kits Included)Operating Temperature-20 to 50° C (-4 to 122° F)Operating Humidity0 to 90% NoncondensingWeatherproofingIP67
Type Fixed Dome/HDTV/Megapixel | Pixel Resolution 3 Mega Pixel | Sensor size 1/2.5” progressive scan RGB CMOS | Min. Illumination 0.26 Lux | Electronic Shutter Speed 1/10000 s to 1/5 s | 1xHDMI Micro (D) | 1xMicroSD Card Slot | 1xRJ45 | Power options PoE | Power supply requirements Power over Ethernet (PoE) IEEE 802.3af/802.3at Type 1 Class 3 | Operating temperature range °C to 45 °C (32 °F to 113 °F) | Included Accessories Installation guide, Windows decoder 1-user license | Dimensions Height: 71 mm ø121 mm
Focal Length 3.7 mm|Sensor size 1/3”|Min. Illumination 0.25 Lux|Electronic Shutter Speed 1/32500 s to 1/25 s with 50 Hz, 1/32500 s to 1/30 s with 60 Hz|Operating temperature range -20 °C to 50 °C|Included Accessories Installation Guide,8-m (26 ft) bl
Mini HDTV PTZ with wireless I/O AXIS M5065 PTZ Network Camera is an ultra-discreet, palm-sized, pan-tilt-zoom camera for remote indoor monitoring. With its support for wireless input/output connectivity, the camera can communicate wirelessly with connected Z-Wave Plus® devices, creating a small security solution with less cabling. AXIS M5065 is a ceiling-mount camera that provides coverage over a 500 m² (4300 sq. ft) area with ±180° pan, 90° tilt, and 5x optical zoom. The IP51 rating ensures protection against dust and dripping water, enabling camera operation even when a sprinkler system is activated. HDTV 1080p and 5x optical zoom Z-wave Plus® compatibility IP51-rated Power over Ethernet (IEEE 802.3af) Built-in analytics
Description: AXIS P5655-E PTZ Network Camera is a cost-effective, high performance PTZ with HDTV 1080p and 32x optical zoom. It features Forensic WDR for clarity even when there’s both dark and light areas in the scene. And, Lightfinder 2.0 to capture low-light images with more saturated colors and sharper images of moving objects. It offers electronic image stabilization and enhanced security features including signed firmware and secure boot. With IP66, NEMA 4X and IK10 ratings it’s resistant to both harsh weather conditions and impacts. Plus, you get two-way audio, I/O ports and extended capabilities for advanced analytics. > HDTV 1080p with 32x optical zoom > Forensic WDR and Lightfinder 2.0 > Signed firmware and secure boot > Focus recall and EIS > Zipstream with support for H.264 and H.265Vendor Homepage: www.axis.com/products/axis-p5655-eUnit Gross Weight: 3.26Unit Net Weight: 2.5Shipping box quantity: 1Audio-In: 1Audio-Out: 1Optical Zoom: 32 xRJ45: 1Unit Brutto Volume: 0.01974SD Card Slot: 1Dimensions: 217xø188 mm Power consumption: 10Power supply requirements: IEEE 802.3at, Type 2 Class 4Sensor size: 1/2.8” progressive scan RGB CMOSMin. Illumination: 0.1Operating temperature range: -30 °C to 50 °CFocal Length: 4.3-137.6 mmElectronic Shutter Speed: 1/66500 s to 2 sShipping Box Width: 22.5Shipping Box Depth: 22.5Shipping Box Height: 39Shipping Box Weight: 3.26Network Camera Type: Fixed Dome, HDTV/Megapixel, Outdoor, PTZEnvironment: OutdoorPower options: PoE
