Alphacool ES G1/4 90° rotatable barbed fitting for 6mm tube
Tootekood: 14639GTIN: 4250197146395Fittings for watercooling
The Alphacool ES G1/4 90° rotatable Fitting with Barbed Fitting for Tubes ID 6mm is part of Alphacool’s professional ES series and sets new standards in design, functionality, and reliability for water cooling systems in servers, workstations, and industrial applications. With its precisely machined barbed fitting and solid brass construction, this connector ensures a secure and leak-proof connection for 6mm tubing. The internal diameter is optimized for minimal flow resistance, supporting effective coolant circulation even in complex system configurations. Hose barb fittings offer a compact and straightforward alternative to compression fittings, highlighting more of the tubing and saving space — especially useful in tight installations or specialized setups. Despite their minimal form factor, they provide secure hose grip and high flow capacity. Thanks to the 90° rotatable design, tubing can be routed with exceptional flexibility. The fitting simplifies clean loop layout, reduces mechanical stress on the tubing, and enables space-saving installations — ideal for compact cases or densely packed rack systems. ES Series – developed for professionals Each component in Alphacool’s ES line is engineered for professional-grade reliability and performance. Whether in a high-performance workstation or industrial cooling setup, these fittings deliver consistent performance and robust build quality. Technical data Type: 90° rotatable fitting for low flow rates Dimensions: 30.50 mm x 26.35 mm x 15.80 mm Nominal diameter: 6.5 mm Connection type: barbed fitting for tube Material: brass (CuZn39Pb3) Seal material: EPDM Shore A 70 Clamping spring material: stainless steel (X10CrNi18-8) Working pressure: 2bar Burst pressure: 8bar Working temperature: -20℃ ~ +100℃ Recommended liquids: water, deionized water, glycol water, propanediol water etc. Thread type: G1/4” 6 mm outer thread Threaded fastening: Open-end wrench width across flats 16 mm Weight: 21g Color: brass, raw
Alphacool ES G1/4 90° Rotatable Barbed Fitting for TPV Tubes 12.7/7.6mm
Tootekood: 14640GTIN: 4250197146401Fittings for watercooling
The Alphacool ES G1/4 90° rotatable Fitting with Barbed Fitting for TPV Tubes 12.7/7.6mm is part of Alphacool’s professional ES series and sets new standards in design, functionality, and reliability for water cooling systems in servers, workstations, and industrial applications. With its precisely machined barbed fitting and solid brass construction, this connector ensures a secure and leak-proof connection for 12.7/7.6mm tubing. The internal diameter is optimized for minimal flow resistance, supporting effective coolant circulation even in complex system configurations. Hose barb fittings offer a compact and straightforward alternative to compression fittings, highlighting more of the tubing and saving space — especially useful in tight installations or specialized setups. Despite their minimal form factor, they provide secure hose grip and high flow capacity. Thanks to the 90° rotatable design, tubing can be routed with exceptional flexibility. The fitting simplifies clean loop layout, reduces mechanical stress on the tubing, and enables space-saving installations — ideal for compact cases or densely packed rack systems. ES Series – developed for professionals Each component in Alphacool’s ES line is engineered for professional-grade reliability and performance. Whether in a high-performance workstation or industrial cooling setup, these fittings deliver consistent performance and robust build quality. Technical data Type: 90° rotatable fitting for low flow rates Dimensions: 26.35 mm x 29.15 mm x 15.80 mm Nominal diameter: 10.20 mm Connection type: barbed fitting for tube Material: Brass (CuZn39Pb3) Seal material: EPDM Shore A 70 Clamping spring material: stainless steel (X10CrNi18-8) Working pressure: 2bar Burst pressure: 8bar Working temperature: -20℃ ~ +100℃ Recommended liquids: water, deionized water, glycol water, propanediol water etc. Thread type: G1/4” 6 mm outer thread Threaded fastening: Open-end wrench width across flats 16 mm Weight: 23g Color: brass, raw
Alphacool ES G1/4 barbed fitting (short) for 12.7/7.6mm tubing
Tootekood: 14643GTIN: 4250197146432Fittings for watercooling
The Alphacool ES G1/4 barbed fitting (short) for 12.7/7.6mm is part of Alphacool’s professional ES series and sets new standards in design, functionality, and reliability for water cooling systems in servers, workstations, and industrial applications. With its precisely machined barbed fitting and solid brass construction, this connector ensures a secure and leak-proof connection for 12.7/7.6mm tubing. The internal diameter is optimized for minimal flow resistance, supporting effective coolant circulation even in complex system configurations. Hose barb fittings offer a compact and straightforward alternative to compression fittings, highlighting more of the tubing and saving space — especially useful in tight installations or specialized setups. Despite their minimal form factor, they provide secure hose grip and high flow capacity. ES Series – developed for professionals Each component in Alphacool’s ES line is engineered for professional-grade reliability and performance. Whether in a high-performance workstation or industrial cooling setup, these fittings deliver consistent performance and robust build quality. Technical dataType:fitting for low flow ratesDimensions:23,00 mm x 15,91 mmNominal diameter:10,20 mmConnection type:barbed fitting for tubeMaterial:brass (CuZn39Pb3)Seal material:EPDM Shore A 70Working pressure:2barBurst pressure:8barWorking temperature (in degrees Celcius):-20 ~ +100Recommended liquids:water, deionized water, glycol water, propanediol water etc.Thread type:G1/4” 6 mm outer threadThreaded fastening:Open-end wrench width across flats 13 mmWeight:12gColor:brass, raw
Alphacool ES G1/4 barbed fitting for 12.7/7.6mm tubing
Tootekood: 14641GTIN: 4250197146418Fittings for watercooling
The Alphacool ES G1/4 barbed fitting for 12.7/7.6mm is part of Alphacool’s professional ES series and sets new standards in design, functionality, and reliability for water cooling systems in servers, workstations, and industrial applications. With its precisely machined barbed fitting and solid brass construction, this connector ensures a secure and leak-proof connection for 12.7/7.6mm tubing. The internal diameter is optimized for minimal flow resistance, supporting effective coolant circulation even in complex system configurations. Hose barb fittings offer a compact and straightforward alternative to compression fittings, highlighting more of the tubing and saving space — especially useful in tight installations or specialized setups. Despite their minimal form factor, they provide secure hose grip and high flow capacity. ES Series – developed for professionals Each component in Alphacool’s ES line is engineered for professional-grade reliability and performance. Whether in a high-performance workstation or industrial cooling setup, these fittings deliver consistent performance and robust build quality. Technical dataType:fitting for low flow ratesDimensions:31,30 mm x 17,50 mmNominal diameter:10,20 mmConnection type:barbed fitting for tubeMaterial:brass (CuZn39Pb3)Seal material:EPDM Shore A 70Working pressure:2barBurst pressure:8barWorking temperature (in degrees Celcius):-20 ~ +100Recommended liquids:water, deionized water, glycol water, propanediol water etc.Thread type:G1/4” 6 mm outer threadThreaded fastening:Open-end wrench width across flats 13 mmWeight:12gColor:brass, raw
The Alphacool ES 1-Slot Copper/Carbon water cooler with backplate was specially developed for the Alphacool Enterprise Series. Due to the positioning of the connections, the tubing of the cooler in the server rack is made much easier. The cooler top and the backplate are made of carbon. This makes the water cooler lighter compared to Alphacool's ice blocks with acetal or acrylic top. This cooler is 1U compatible! More performance! Alphacool succeeds in positioning the cooler as close as possible to the components to be cooled. To do this, the thermal pads used are reduced to a thickness of 1mm. The maximum possible reduction in the thickness of the copper block and the optimization of the water flow within the cooler allow all important components such as the GPU, voltage converter and VRAMs to be cooled much better and more effectively by the water. All of this ensures a significant increase in cooling performance. Chrome-plated copper The cooler is made entirely of chrome-plated copper. Chrome plating is much harder than nickel plating and is therefore less susceptible to acids, scratches and damage. The risk of nickel plating chipping off is completely eliminated. In addition, chrome plating looks much more homogeneous and offers a shine that cannot be achieved with nickel plating. Connections on the back? In order to save space in terms of width and height during installation, the inlet and outlet were moved to the rear of the cooling block. This positioning of the connections makes the tubing much easier and enables the GPU cooler to be easily integrated into the water circuit, even in the tightest server cases. Copper or aluminum? Alphacool uses only copper for all water-carrying parts. Copper has almost twice the thermal conductivity of aluminum and is therefore the much better choice of material for water cooling. The chrome-plated copper base is highly acid-resistant, which means that the chrome plating cannot chip off. Thermal paste & thermal pads The electrically non-conductive thermal paste is particularly well suited for high contact pressures, but can still be processed perfectly due to the viscosity of 850,000 TF. For the thermal pads, Alphacool uses soft pads that fit perfectly to the components to be cooled and are very durable. Compatibility: - Inno3D GeForce RTX 4090 iCHILL Black, 24GB GDDR6X (C4090-246XX-18330005) - Inno3D GeForce RTX 4090 iCHILL OC, 24GB GDDR6X (C4090-246XX-1833FB) - Inno3D GeForce RTX 4090 OC, 24GB GDDR6X (C40903-246XX-1833VA47) - Inno3D GeForce RTX 4090 X3 OC, 24GB GDDR6X (N40903-246XX-18332989) - KFA² GeForce RTX 4090 SG (1-Click OC), 24GB GDDR6X (49NXM5MD6DSK) Technical data cooler Dimensions (L x W x H) 234.21x119.69x19.29mm Height of the backplate 1 mm Weight (total) 1120g Radiator base material chrome-plated copper Material radiator top Carbon connections 2xG1/4" Maximum operating temperature 60°C Pressure tested 8 bars Color Black/Carbon Warranty: 3 years ? Warranty conditions
Schließe vier Lüfter am Hub an, Anschluss an Netzteil, PWM-Signal vom Mainboard, Warnsignale über Lautsprecher möglich, erhöhte Funktionalität mit CAN-Anschlüssen
The Alphacool ES 1-Slot GPU water cooler for the Nvidia H200 141GB is specifically designed for professional use in performance-optimized server environments. With its compact 1-slot design and strategically positioned connectors, it meets the highest standards in cooling performance, reliability, and ease of installation – particularly in dense rack setups where space is at a premium. Both the top and bottom of the cooler are made from lightweight yet durable carbon. This significantly reduces the overall weight compared to conventional solutions, while the matte carbon finish adds a subtle and refined aesthetic – functional and elegant at the same time. The cooling block itself is made entirely of chrome-plated copper. This plating is significantly harder and more resilient than traditional nickel coatings, offering long-term protection against corrosion, scratches, and mechanical stress – ideal for continuous 24/7 operation. The cooler’s inlet and outlet ports are placed at the rear of the block to save space. This connector layout simplifies tubing and integration into existing cooling loops, even within the tightest server chassis. The optimized internal channel structure ensures highly efficient heat dissipation from GPU, VRAM, and power delivery components. A precise flow path within the cooler ensures consistent water distribution across all critical areas. The solid copper base guarantees maximum thermal absorption and transfer. The robust chrome plating prevents flaking or damage, even under sustained thermal loads. The Alphacool ES 1-Slot GPU water cooler for Nvidia H200 141GB is the ideal solution for enterprise applications where performance, reliability, and efficient space utilization are key. Compatibility: - Nvidia H200 NVL, 141GB HBM3 (900-21010-0040-000) Technical dataDimensions (L x W x H)268.59 x 94.45 x 20.67 mmSlot size1Material coolerChrome-plated copperMaterial cooler topCarbonThreads2 x G1/4"Pressure tested8 BarMaximum working temperature60 °CColorblack, carbonTechnical data backplateDimensions (L x W x H)268.59 x 94.45 x 1.10 mmMaterialAluminumColorblackWarranty: 3 years???? Warranty Terms
As the only manufacturer worldwide, Alphacool is uncompromising in its choice of materials and uses only copper for all water-carrying components in the radiator. The chambers, cooling fins, and cooling channels are made of pure copper. Only the connection threads (made of brass) and the outer housing of the radiator (made of sheet steel) are made from other materials.The HPE radiators are based on the NexXxoS series. But what’s new? The HPE version features additional cooling channels and a very high fin density. Due to its technical design, cooling performance is significantly increased without restricting water flow within the radiator. When fans are mounted on both sides in push/pull configuration, a noticeable drop in water temperature can be achieved compared to standard radiators.The Radiators are designed specifically for industrial and server environments. Thanks to thicker cooling channels and reinforced welds, they are built to withstand operating pressures of up to 5 Bar, ensuring maximum reliability in demanding industrial use.In traditional PC radiators, water flows in a U-shape, meaning the inlet and outlet are on the same side. This has certain advantages in typical PC setups. However, creating a proper water loop in an extremely flat server is difficult this way. Thanks to X-Flow technology, the inlet and outlet are on opposite sides. This makes it easy to implement a circular water flow in a server rack: exiting one side directly into a CPU, possibly then through one or more graphics cards, and returning on the other side to the radiator.To maximize the radiator’s performance, Alphacool uses pure copper for the cooling fins, cooling channels, and chambers due to its high thermal conductivity of 400 W/mK (by comparison: aluminum has 236 W/mK). The radiator’s high fin density with a spacing of 15 FPI allows for optimal airflow. All cooling fins are also equipped with small flaps—tiny wings that guide the airflow in the desired direction and create controlled turbulence. This increases cooling performance and reduces potential flow noise.In the area of the pre-chambers, each side features three IN or OUT ports with G1/4" threads. All screws required for mounting the radiator in a case and for attaching the fans are included. Additional screws are usually not necessary.A special protective feature ensures that fan or mounting screws cannot be driven in too deeply. Protective plates have been placed beneath all mounting holes to prevent over-tightening. This protects the cooling fins and water channels underneath from damage.All NexXxoS HPE X-Flow radiators use Alphacool's patented sealing plugs. Anyone who has ever mounted a radiator to the front or top of a case knows that protruding sealing plugs can prevent the radiator from sitting flush. With Alphacool’s patented sealing plugs, this issue is solved. The sealing plugs are completely recessed and sit flush with the surface of the radiator. This ensures a clean installation. Of course, the radiators also look significantly more refined with these flat plugs. Technical data radiatorL x W x H287 x 80 x 60 mm (+/- 3% tolerance in the range of the prechamber)Quantity of cooling channels24Material cooling fins, pre-chambers & channelscopperMaterial threadsbrassMaterial outer housingstainless steelThreads6x G1/4" IN/OUT (max. 5mm thread length)Possible fan size80mmPossible fan assembly3x one-sided / 6x both-sidedThread size fan mountingM3Pressure tested5.0 BarMaximum working temperature60°CFin density15 FPIWeight1035gColorblackWarranty: 10 years???? Warranty Terms
As the only manufacturer worldwide, Alphacool is uncompromising in its choice of materials and uses only copper for all water-carrying components in the radiator. The chambers, cooling fins, and cooling channels are made of pure copper. Only the connection threads (made of brass) and the outer housing of the radiator (made of sheet steel) are made from other materials.The HPE radiators are based on the NexXxoS series. But what’s new? The HPE version features additional cooling channels and a very high fin density. Due to its technical design, cooling performance is significantly increased without restricting water flow within the radiator. When fans are mounted on both sides in push/pull configuration, a noticeable drop in water temperature can be achieved compared to standard radiators.The Radiators are designed specifically for industrial and server environments. Thanks to thicker cooling channels and reinforced welds, they are built to withstand operating pressures of up to 5 Bar, ensuring maximum reliability in demanding industrial use.In traditional PC radiators, water flows in a U-shape, meaning the inlet and outlet are on the same side. This has certain advantages in typical PC setups. However, creating a proper water loop in an extremely flat server is difficult this way. Thanks to X-Flow technology, the inlet and outlet are on opposite sides. This makes it easy to implement a circular water flow in a server rack: exiting one side directly into a CPU, possibly then through one or more graphics cards, and returning on the other side to the radiator.To maximize the radiator’s performance, Alphacool uses pure copper for the cooling fins, cooling channels, and chambers due to its high thermal conductivity of 400 W/mK (by comparison: aluminum has 236 W/mK). The radiator’s high fin density with a spacing of 15 FPI allows for optimal airflow. All cooling fins are also equipped with small flaps—tiny wings that guide the airflow in the desired direction and create controlled turbulence. This increases cooling performance and reduces potential flow noise.In the area of the pre-chambers, each side features three IN or OUT ports with G1/4" threads. All screws required for mounting the radiator in a case and for attaching the fans are included. Additional screws are usually not necessary.A special protective feature ensures that fan or mounting screws cannot be driven in too deeply. Protective plates have been placed beneath all mounting holes to prevent over-tightening. This protects the cooling fins and water channels underneath from damage.All NexXxoS HPE X-Flow radiators use Alphacool's patented sealing plugs. Anyone who has ever mounted a radiator to the front or top of a case knows that protruding sealing plugs can prevent the radiator from sitting flush. With Alphacool’s patented sealing plugs, this issue is solved. The sealing plugs are completely recessed and sit flush with the surface of the radiator. This ensures a clean installation. Of course, the radiators also look significantly more refined with these flat plugs. Technical dataL x W x H367 x 80 x 60 mm (+/- 3% tolerance in the range of the prechamber)Quantity of cooling channels24Material cooling fins, pre-chambers & channelscopperMaterial threadsbrassMaterial outer housingstainless steelThreads6x G1/4" IN/OUT (max. 5mm thread length)Possible fan size80mmPossible fan assembly4x one-sided / 8x both-sidedThread size fan mountingM3Pressure tested5.0 BarMaximum working temperature60°CFin density15 FPIWeight1294gColorblackWarranty: 10 years???? Warranty Terms
Alphacool ES Laing DDC310 Pump - Single black plastic bottom
Tootekood: 13991GTIN: 4250197139915Pumps for water cooling
The Alphacool ES Solution Laing DDC310 pump serves as the foundation for various 1 to 4U server solutions from Alphacool. The unit is based around the very popular Alphacool DDC pump and has been coupled with a simple pump base to maintain compatibility with various Enterprise Solution reservoirs. Compact and powerful. The flat design of the Laing DDC310 pump saves space and fits with the corresponding Enterprise reservoirs from chassis as small as a 1U server rack. This results in a very powerful pump that can be used in the smallest of spaces. The DDC310 variant offers with a delivery height of 2.44m enough power to operate an extensive water loop. The performance is enough to operate a dual or quad socket system including reservoir and radiators. The performance of the pump is also sufficient to operate a render server with up to 4 graphics cards. Spherical Ceramic Bearing The pump uses a shaftless ball motor or spherical bearing. The motor is driven by magnets while the rotor is mounted on a ball-ceramic bearing. This makes the pump maintenance-free, as the bearing is self-adjusting and maintenance-free. The pump is lubricated by the coolant during operation. This makes the Alphacool ES Solution Laing DDC310 pump a so-called wet rotor pump. Due to its design, even small particles of dirt are no problem for the pump. Installation and Commissioning The pump is delivered with a classic plastic bottom which ensures a high compatibility to all Enterprise Solution products. However, the pump can also be mounted on all existing DDC pump tops from Alphacool. The pump comes with a corresponding O-ring, only the mounting screws must be used from the respective reservoir, as these may differ in length. The power is supplied via a 4-pin Molex connector, the speed can be read out via a 3-pin Molex connector. This is usually done via the 3-pin fan connector on the mainboard or via an appropriate fan controller. Technical data Dimensions (L x W x H) 62 x 62 x 30mm Material Stainless steel, Carbon (FH821Z2), Ceramic (Al2O3 99,5%), Luranyl KR 2403 GW T4 (PPE+PS) , Fortron 1140L4 (PPS) Weight 170g Speed 3250 rpm Max power consumption 8W Voltage 12V DC Power connector 4-Pin Molex PWM control n/a Tacho-Signal yes (3-Pin Molex) Max. working temperature ambiente 10°C - 50°C Max. working temperature water 10°C - 60°C Max. head of pump 2,28m Max. flow 200 l/h Color black Revision DDC4.CF-XTXXWX-01 BP54
The Alphacool ES Pressure Valve is designed to manage pressure fluctuations in closed-loop water cooling systems. Developed for use in servers, workstations, and industrial environments, it safeguards individual components from excessive pressure build-up. Thanks to its compact dimensions—just 20.0 mm in height and 16.0 mm in diameter—the valve is well-suited for installations where space is limited. The G1/4" thread ensures straightforward integration into existing cooling circuits. Installation is versatile, allowing the valve to be positioned where it most effectively contributes to system reliability. Engineered for continuous use under demanding conditions, the valve features a durable housing that resists both thermal and mechanical stress. Its precision valve mechanism guarantees reliable performance throughout its entire operational lifespan. Technical specifications Type: Pressure equalizing valve to limit the pressure increase in the closed system Dimensions: 20.0 mm x 16.0 mm Material Valve body: brass (CuZn39Pb3) Compression spring material: stainless steel (X10CrNi18-8) Material O-ring: NBR Shore 70 Working pressure: 2bar Burst pressure: 4bar Working temperature (in degrees Celsius): -20 ~ +100 Recommended liquids: water, deionized water, glycol water, propanediol water etc. Thread type: G1/4’, external thread 5mm Weight: 18g Color: silver/black
The Alphacool ES RTX 4000 Ada Ge. GPU cooler was developed for the Enterprise Series, but not only impresses with its improved cooling performance and compact design, but also with its matt carbon look.Connections at the rear?By using a thin and extremely stable carbon plate, it was possible to design this as a single-slot cooler without having to compromise on the copper base. In combination with the connections positioned at the rear, several coolers can be stacked on top of each other with ease. This well thought-out design saves space, simplifies tubing and enables seamless integration into the water loop.More performance!Alphacool has given special attention to increasing cooling performance. In addition to optimising the water flow within the cooler and the thickness of the copper block, 1mm high-performance heat conducting pads are used. These measures ensure that the components to be cooled are closer to the cooler, which leads to significantly more effective cooling of all important components.Copper or aluminium?High-quality copper is used for all water-bearing parts, which offers almost twice the thermal conductivity of aluminium. The copper is also chrome-plated instead of nickel-plated, which provides additional protection for the cooler. The chrome plating is more resistant to acids, scratches and other damages, which effectively prevents coatings from flaking off.Thermal paste & thermal padsThe scope of delivery includes Apex thermal compound, which is the most durable thermal compound Alphacool offers with its low silicone content. This electrically non-conductive paste is ideal for high contact pressures and is easy to work with thanks to its viscosity. Soft, high-performance thermal pads are also supplied, which adapt perfectly to the components to be cooled. Compatibility:- Nvidia RTX 4000 Ada Generation, 20GB GDDR6, 4x DP, bulk (900-5G190-2270-000) Technical dataDimensions (L x W x H)241,25 x 96,70 x 17,50mmHeight of the backplate1mmWeight (total)1100gCooler base materialChome-plated copperCooler top materialCarbonThreads2 x G1/4"Maximum working temperature60 °CPressure tested8 BarColorBlackWarranty: 3 years???? Warranty Terms
Alphacool is expanding its Enterprise series with the latest 1-slot water coolers for the current Nvidia GeForce RTX generation. These solutions are specifically designed for use in server cases and workstations and enable efficient cooling, even in densely populated systems. By using a thin and extremely stable carbon plate, this cooler could be designed as a single-slot cooler without compromising on the copper block. Combined with the rear-mounted brass connectors, multiple coolers can be easily stacked on top of each other or side by side in the server case. This sophisticated design saves space, simplifies piping, and enables seamless integration into the water loop. High-quality copper is used for all water-carrying parts, which offers almost twice the thermal conductivity of aluminum. Furthermore, the copper is chrome-plated instead of nickel-plated, providing additional protection for the cooler. Chrome plating is more resistant to acids, scratches, and other damage, effectively preventing coatings from chipping. Technically, the GPU water cooler has been completely redesigned. To optimize cooling performance, the gaps between the cooler and the PCB components were redefined and tested. The water flow was simulated using state-of-the-art software and verified in practical tests. These extensive tests enabled improvements to the cooler base and nozzle to ensure the best possible cooling performance for the new Nvidia GeForce RTX generation. Compatibility: - MSI GeForce RTX™ 5070 Ti 16G INSPIRE 3X OC - MSI GeForce RTX™ 5070 Ti 16G SHADOW 3X OC - MSI GeForce RTX™ 5070 Ti 16G VENTUS 3X OC (V531-092R) - Inno3D GeForce RTX™ 5080 iChill Frostbite (C50803-16D7X-1760FB) - Inno3D GeForce RTX™ 5080 iChill X3 (C50803-16D7X-176069H) - Inno3D GeForce RTX™ 5080 X3 (N50803-16D7-176068N) - Inno3D GeForce RTX™ 5080 X3 OC (N50803-16D7X-17603930) - Inno3D GeForce RTX™ 5080 X3 OC White (N50803-16D7X-17605211) - MSI GeForce RTX™ 5080 16G SHADOW 3X OC (G5080-16S3C) - MSI GeForce RTX™ 5080 16G VENTUS 3X OC (V531-095R) - MSI GeForce RTX™ 5080 16G VENTUS 3X OC Plus (V531-001R) Technical data cooler Complete dimensions (L x W x H) 186.50 x 95.75 x 21.19 mm Radiator base material chrome-plated copper Material radiator top Acrylic Material Terminal Brass Material connection thread Brass Maximum working temperature 60°C Pressure tested 0.8 bar Connections 2 x G1/4" Thickness of radiator base 3.25 mm Thick cooling fins 0.4 mm Distance between cooling fins 0.4 mm Color transparent Technical data backplate Dimensions (L x W x H) 171.50 x 95.75 x 3 mm Thick backplate without spacers 1 mm Material aluminum Warranty: 3 years
Alphacool expands its Enterprise series with the latest 1-slot water coolers for the current Nvidia GeForce RTX generation. These solutions are specifically designed for use in server enclosures and workstations, enabling efficient cooling even in densely packed systems. By employing a thin yet extremely robust carbon plate, these coolers have been designed as 1-slot units without compromising the integrity of the copper block. Paired with rear-placed brass connectors, multiple coolers can be easily stacked on top of each other or side by side within a server case. This thoughtful design saves space, simplifies tubing, and allows for seamless integration into the water circuit. All water-bearing parts are made from high-quality copper, which offers nearly twice the thermal conductivity of aluminum. Additionally, the copper is chrome-plated rather than nickel-plated, providing extra protection for the cooler. Chrome plating is more resistant to acids, scratches, and other damage, effectively preventing the chipping of coatings. The GPU water cooler has undergone a complete technical overhaul. To optimize cooling performance, the spacing between the cooler and the components on the PCB was redefined and tested. The water flow was simulated using state-of-the-art software and validated through practical trials. These extensive tests led to improvements in the cooler base and nozzle, ensuring the best possible cooling performance for the new Nvidia GeForce RTX generation. Note: The ES RTX 5090 Reference 1-slot design REV1 with backplate has been redesigned to offer greater compatibility with other graphics cards. Compatibility: - Inno3D GeForce RTX™ 5090 iChill Frostbite (C50903-32D7X-1759FB) - Inno3D GeForce RTX™ 5090 iCHILL X3 (C50903-32D7X-175967H) - Inno3D GeForce RTX™ 5090 X3 (N50903-32D7-17593928) - Inno3D GeForce RTX™ 5090 X3 OC (N50903-32D7X-17593928) - MSI GeForce RTX™ 5090 32G VENTUS 3X OC (MS-V530 VER:1.1) - PNY GeForce RTX™ 5090 ARGB EPIC-X RGB™ Overclocked Triple Fan GPU - PNY GeForce RTX™ 5090 ARGB EPIC-X RGB™ Triple Fan GPU - PNY GeForce RTX™ 5090 Overclocked Triple Fan GPU - PNY GeForce RTX™ 5090 Triple Fan GPU Technical data cooler Dimensions total (L x W x H): 235.29 x 119.32 x 21.13mm Material cooler: chrome-plated copper Material cooler top: Carbon Material terminal: Brass Material Connection thread: Brass Max working temperature: 60°C Pressure tested: 2.0 bar Threads: 2 x G1/4" Thickness cooler bottom: 3.25mm Thickness cooling fins: 0.4mm Distance cooling fins: 0.4mm Technical data backplate Dimensions (L x W x H): 224.79 x 119.32 x 3mm Thick backplate without spacers: 1mm Material: Carbon Warranty: 3 years ???? Warranty Terms
Alphacool expands its Enterprise series with the latest 1-slot water coolers for the current Nvidia GeForce RTX generation. These solutions are specifically designed for use in server enclosures and workstations, enabling efficient cooling even in densely packed systems.By employing a thin yet extremely robust carbon plate, these coolers have been designed as 1-slot units without compromising the integrity of the copper block. Paired with rear-placed brass connectors, multiple coolers can be easily stacked on top of each other or side by side within a server case. This thoughtful design saves space, simplifies tubing, and allows for seamless integration into the water circuit.All water-bearing parts are made from high-quality copper, which offers nearly twice the thermal conductivity of aluminum. Additionally, the copper is chrome-plated rather than nickel-plated, providing extra protection for the cooler. Chrome plating is more resistant to acids, scratches, and other damage, effectively preventing the chipping of coatings.The GPU water cooler has undergone a complete technical overhaul. To optimize cooling performance, the spacing between the cooler and the components on the PCB was redefined and tested. The water flow was simulated using state-of-the-art software and validated through practical trials. These extensive tests led to improvements in the cooler base and nozzle, ensuring the best possible cooling performance for the new Nvidia GeForce RTX generation. Compatibility:- Inno3D GeForce RTX™ 5090 iChill Frostbite (C50903-32D7X-1759FB)- Inno3D GeForce RTX™ 5090 iChill X3 (C50903-32D7X-175967H)- Inno3D GeForce RTX™ 5090 X3 (N50903-32D7-17593928)- Inno3D GeForce RTX™ 5090 X3 OC (N50903-32D7X-17593928)- MSI GeForce RTX™ 5090 32G VENTUS 3X OC (MS-V530 VER:1.1) Technical data coolerDimensions total (L x W x H)224,29 x 119,32 x 21,34mmMaterial coolerchrome-plated copperMaterial cooler topCarbonMaterial terminalBrassMaterial Connection threadBrassMax working temperature60°CPressure tested2,0 barThreads2 x G1/4"Thickness cooler bottom3,25mmThickness cooling fins0,4mmDistance cooling fins0,4mmTechnical data backplateDimensions (L x W x H)224,29 x 119,32 x 3mmThick backplate without spacers1mmMaterialCarbonWarranty: 3 years???? Warranty Terms
Tootekood: 18674GTIN: 4250197186742Internal power cables and adapters
An extension cable for 4-pin PWM fans. Available in various lengths. Sleeving provides additional protection, stability and increased lifetime. Technical detailsLength30cmConnections4-pin to 4-pinMaterialPlastic, sleevedColorblack
Tootekood: 18720GTIN: 4250197187206Internal power cables and adapters
An extension cable for 4-pin PWM fans. Available in various lengths. Sleeving provides additional protection, stability and increased lifetime. Technical detailsLength30cmConnections4-pin to 4-pinMaterialPlastic, sleevedColorwhite
Tootekood: 18675GTIN: 4250197186759Internal power cables and adapters
An extension cable for 4-pin PWM fans. Available in various lengths. Sleeving provides additional protection, stability and increased lifetime. Technical detailsLength60cmConnections4-pin to 4-pinMaterialPlastic, sleevedColorblack
The ideal supplement for cooling of Mosfet or RAM modules on graphics cards. For sufficient cooling of these components, heatsinks such as this one are required. As a result, lower temperatures and better overclocking performance can be achieved. Being made completely from Aluminum, these heatsinks allow very efficient cooling of the cooled components. A low height of only 15mm allows installation even under large graphics card coolers. Technical specifications: Dimensions: 15x15x15mm (LxWxH) Material: Black anodized Aluminium Weight: 4g each This is a kit of 10 Alphacool GPU heatsinks 15x15mm Download 3D-file (.stp)
The ideal supplement for cooling of Mosfet or RAM modules on graphics cards. For sufficient cooling of these components, heatsinks such as this one are required. As a result, lower temperatures and better overclocking performance can be achieved. Being made completely from Aluminum, these heatsinks allow very efficient cooling of the cooled components. A low height of only 15mm allows installation even under large graphics card coolers. Technical specifications: Dimensions: 7x7x15mm (LxWxH) Material: Black anodized Aluminium Weight: 2g each This is a kit of 10 Alphacool GPU heatsinks 7x7mm Download 3D-file (.stp)
The small heat sinks are the perfect addition for cooling various electronic components such as the graphics card VRam, the voltage transformer on a motherboard, or even in a power amplifier or in RC vehicles. To ensure maximum heat capacity and cooling performance, the coolers are made of copper. Alphacool uses a special coating to prevent the infamous greenish discolouration on copper as much as possible. This increases the lifespan of the cooler and ensures steady cooling performance. The coolers can be installed onto the desired components with optional thermal paste or self-adhesive thermal pads. Technical Data Dimensions: 10 x 10mm Material: Fullcopper Scope of Delivery Alphacool GPU RAM Copper Heatsinks 10x10mm - 10pcs
The small heat sinks are the perfect addition for cooling various electronic components such as the graphics card VRam, the voltage transformer on a motherboard, or even in a power amplifier or in RC vehicles. To ensure maximum heat capacity and cooling performance, the coolers are made of copper. Alphacool uses a special coating to prevent the infamous greenish discolouration on copper as much as possible. This increases the lifespan of the cooler and ensures steady cooling performance. The coolers can be installed onto the desired components with optional thermal paste or self-adhesive thermal pads. Technical Data Dimensions: 14 x 14mm Material: Fullcopper Scope of Delivery Alphacool GPU RAM Copper Heatsinks 14x14mm - 10pcs
Connect your graphics cards with the new Alphacool GPX SLI Connector and embrace the power! You get optimal cooling performance thanks to the serial water flow and your system looks great. ARGB - Stay in Control of Your LightingLight your system the way you want to. Thanks to addressable RGB you retain full control over your lighting. The high-quality acrylic allows the the ARGB LED's shine in rich, vibrant colours. These can be easily controlled by the Alphacool Aurora Eiscontrol. Mounting - Easier Than Ever BeforeThanks to the ¼" thread, installation is simple using the included fittings. Simply install them into your Alphacool EisBlock GPX Cooler and plug your Alphacool GPX SLI Connector onto it. Thanks to the double secured O-ring, you can even plug it on already mounted coolers. Expand the system - Make It YOUR ProjectThe Alphacool GPX SLI connectors are compatible with all new models of the Alphacool Eisblock series from 2080/2080Ti M02. All previous models can easily be upgraded with the Alphacool GPX SLI Upgrade Kit (1015976). The SLI Connectorl is available in 3 PCI-E Space and 4 PCI-E Space. Technical details Dimensions (LxWxH): 58 x 93,96 x 23mm Net weight: 195g Working temperature: Max 60°C Voltage: 5 VDC Certificates: CE, FC, ROHS Scope of delivery 1x GPX SLI Connector Plexi aRGB X3 4x SLI Adapter G 1/4“ Manual for download here Datasheet for download here
Tootekood: ROH1020311GTIN: 4250197184991Fittings for watercooling
Transparente Tube von Alphacool, mit 90°-Winkel, 10/30 cm, aus Borosilikatglas, besonders kratzfest und langlebig, zum Verbinden von Wakü-Komponenten, 16/11mm (Außen-/Innendurchmesser), klar
Tootekood: ROH1020312GTIN: 4250197185004Fittings for watercooling
Transparente Tube von Alphacool, mit 90°-Winkel, 20/40 cm, aus Borosilikatglas, besonders kratzfest und langlebig, zum Verbinden von Wakü-Komponenten, 16/11mm (Außen-/Innendurchmesser), klar
Tootekood: ROH1020313GTIN: 4250197184953Tubing for water cooling
Transparente 400-mm-Tube von Alphacool, aus Borosilikatglas, besonders kratzfest und langlebig, zum Verbinden von Wakü-Komponenten, 16/11mm (Außen-/Innendurchmesser), klar
Tootekood: ROH1020314GTIN: 4250197184960Tubing for water cooling
Transparente 600-mm-Tube von Alphacool, aus Borosilikatglas, besonders kratzfest und langlebig, zum Verbinden von Wakü-Komponenten, 16/11mm (Außen-/Innendurchmesser), klar
