Kompakte Distro-Plate, für kleine Builds oder Server, kombinierbar, 14x G1/4-Zoll-Anschlüsse, aus schwarzem Acetal und vernickeltem Kupfer, variabel einsetzbar
Kompakte Distro-Plate, für kompakte Builds oder Server, kombinierbar, 22x G1/4-Zoll-Anschlüsse, aus schwarzem Acetal und vernickeltem Kupfer, variabel einsetzbar
The Alphacool ES 1-Slot Copper/Carbon water cooler with backplate was specially developed for the Alphacool Enterprise Series. Due to the positioning of the connections, the tubing of the cooler in the server rack is made much easier. The cooler top and the backplate are made of carbon. This makes the water cooler lighter compared to Alphacool's ice blocks with acetal or acrylic top. This cooler is 1U compatible! More performance! Alphacool succeeds in positioning the cooler as close as possible to the components to be cooled. To do this, the thermal pads used are reduced to a thickness of 1mm. The maximum possible reduction in the thickness of the copper block and the optimization of the water flow within the cooler allow all important components such as the GPU, voltage converter and VRAMs to be cooled much better and more effectively by the water. All of this ensures a significant increase in cooling performance. Chrome-plated copper The cooler is made entirely of chrome-plated copper. Chrome plating is much harder than nickel plating and is therefore less susceptible to acids, scratches and damage. The risk of nickel plating chipping off is completely eliminated. In addition, chrome plating looks much more homogeneous and offers a shine that cannot be achieved with nickel plating. Connections on the back? In order to save space in terms of width and height during installation, the inlet and outlet were moved to the rear of the cooling block. This positioning of the connections makes the tubing much easier and enables the GPU cooler to be easily integrated into the water circuit, even in the tightest server cases. Copper or aluminum? Alphacool uses only copper for all water-carrying parts. Copper has almost twice the thermal conductivity of aluminum and is therefore the much better choice of material for water cooling. The chrome-plated copper base is highly acid-resistant, which means that the chrome plating cannot chip off. Thermal paste & thermal pads The electrically non-conductive thermal paste is particularly well suited for high contact pressures, but can still be processed perfectly due to the viscosity of 850,000 TF. For the thermal pads, Alphacool uses soft pads that fit perfectly to the components to be cooled and are very durable. Compatibility: - Inno3D GeForce RTX 4090 iCHILL Black, 24GB GDDR6X (C4090-246XX-18330005) - Inno3D GeForce RTX 4090 iCHILL OC, 24GB GDDR6X (C4090-246XX-1833FB) - Inno3D GeForce RTX 4090 OC, 24GB GDDR6X (C40903-246XX-1833VA47) - Inno3D GeForce RTX 4090 X3 OC, 24GB GDDR6X (N40903-246XX-18332989) - KFA² GeForce RTX 4090 SG (1-Click OC), 24GB GDDR6X (49NXM5MD6DSK) Technical data cooler Dimensions (L x W x H) 234.21x119.69x19.29mm Height of the backplate 1 mm Weight (total) 1120g Radiator base material chrome-plated copper Material radiator top Carbon connections 2xG1/4" Maximum operating temperature 60°C Pressure tested 8 bars Color Black/Carbon Warranty: 3 years ? Warranty conditions
Schließe vier Lüfter am Hub an, Anschluss an Netzteil, PWM-Signal vom Mainboard, Warnsignale über Lautsprecher möglich, erhöhte Funktionalität mit CAN-Anschlüssen
Alphacool ES Laing DDC310 Pump - Single black plastic bottom
Tootekood: 13991GTIN: 4250197139915Pumps for water cooling
The Alphacool ES Solution Laing DDC310 pump serves as the foundation for various 1 to 4U server solutions from Alphacool. The unit is based around the very popular Alphacool DDC pump and has been coupled with a simple pump base to maintain compatibility with various Enterprise Solution reservoirs. Compact and powerful. The flat design of the Laing DDC310 pump saves space and fits with the corresponding Enterprise reservoirs from chassis as small as a 1U server rack. This results in a very powerful pump that can be used in the smallest of spaces. The DDC310 variant offers with a delivery height of 2.44m enough power to operate an extensive water loop. The performance is enough to operate a dual or quad socket system including reservoir and radiators. The performance of the pump is also sufficient to operate a render server with up to 4 graphics cards. Spherical Ceramic Bearing The pump uses a shaftless ball motor or spherical bearing. The motor is driven by magnets while the rotor is mounted on a ball-ceramic bearing. This makes the pump maintenance-free, as the bearing is self-adjusting and maintenance-free. The pump is lubricated by the coolant during operation. This makes the Alphacool ES Solution Laing DDC310 pump a so-called wet rotor pump. Due to its design, even small particles of dirt are no problem for the pump. Installation and Commissioning The pump is delivered with a classic plastic bottom which ensures a high compatibility to all Enterprise Solution products. However, the pump can also be mounted on all existing DDC pump tops from Alphacool. The pump comes with a corresponding O-ring, only the mounting screws must be used from the respective reservoir, as these may differ in length. The power is supplied via a 4-pin Molex connector, the speed can be read out via a 3-pin Molex connector. This is usually done via the 3-pin fan connector on the mainboard or via an appropriate fan controller. Technical data Dimensions (L x W x H) 62 x 62 x 30mm Material Stainless steel, Carbon (FH821Z2), Ceramic (Al2O3 99,5%), Luranyl KR 2403 GW T4 (PPE+PS) , Fortron 1140L4 (PPS) Weight 170g Speed 3250 rpm Max power consumption 8W Voltage 12V DC Power connector 4-Pin Molex PWM control n/a Tacho-Signal yes (3-Pin Molex) Max. working temperature ambiente 10°C - 50°C Max. working temperature water 10°C - 60°C Max. head of pump 2,28m Max. flow 200 l/h Color black Revision DDC4.CF-XTXXWX-01 BP54
Tootekood: 13879GTIN: 4250197138796Fittings for watercooling
The Alphacool ES quick-release connector is optimized for use in server and gaming systems. It is characterized by its precise manufacturing quality, excellent water flow, and a secure click mechanism for locking. Maximum flow in your system Other quick-release connectors can negatively affect water flow. Therefore, the quick coupling has been fundamentally revised to ensure water flow is barely disturbed, with a particular emphasis on minimal manufacturing tolerances. Quick and easy to connect Alphacool's ES quick-release connectors simplify the setup of server and workstation systems. Thanks to the comfortable operation, complex systems can be quickly and easily connected. To open the quick-release, the outer ring is pulled back. The seal closes immediately, preventing the coolant from leaking. To lock the quick-release connectors, it is enough to push them together. A click sound confirms the secure locking. Important: A quick-release connector always consists of two connections. Therefore, you always need the matching counterpart to get a complete quick-release. With this product, you only get half of the quick-release. Important: Note: To avoid damaging the O-ring, the quick-release should not be opened or closed in a dry state. Technical Details Color: Black, Silver Weight: 90 g Material: Nickel-plated brass, plastic Connections: G1/4 inch (AG)
The Alphacool ES RTX 4000 Ada Ge. GPU cooler was developed for the Enterprise Series, but not only impresses with its improved cooling performance and compact design, but also with its matt carbon look.Connections at the rear?By using a thin and extremely stable carbon plate, it was possible to design this as a single-slot cooler without having to compromise on the copper base. In combination with the connections positioned at the rear, several coolers can be stacked on top of each other with ease. This well thought-out design saves space, simplifies tubing and enables seamless integration into the water loop.More performance!Alphacool has given special attention to increasing cooling performance. In addition to optimising the water flow within the cooler and the thickness of the copper block, 1mm high-performance heat conducting pads are used. These measures ensure that the components to be cooled are closer to the cooler, which leads to significantly more effective cooling of all important components.Copper or aluminium?High-quality copper is used for all water-bearing parts, which offers almost twice the thermal conductivity of aluminium. The copper is also chrome-plated instead of nickel-plated, which provides additional protection for the cooler. The chrome plating is more resistant to acids, scratches and other damages, which effectively prevents coatings from flaking off.Thermal paste & thermal padsThe scope of delivery includes Apex thermal compound, which is the most durable thermal compound Alphacool offers with its low silicone content. This electrically non-conductive paste is ideal for high contact pressures and is easy to work with thanks to its viscosity. Soft, high-performance thermal pads are also supplied, which adapt perfectly to the components to be cooled. Compatibility:- Nvidia RTX 4000 Ada Generation, 20GB GDDR6, 4x DP, bulk (900-5G190-2270-000) Technical dataDimensions (L x W x H)241,25 x 96,70 x 17,50mmHeight of the backplate1mmWeight (total)1100gCooler base materialChome-plated copperCooler top materialCarbonThreads2 x G1/4"Maximum working temperature60 °CPressure tested8 BarColorBlackWarranty: 3 years???? Warranty Terms
Alphacool is expanding its Enterprise series with the latest 1-slot water coolers for the current Nvidia GeForce RTX generation. These solutions are specifically designed for use in server cases and workstations and enable efficient cooling, even in densely populated systems. By using a thin and extremely stable carbon plate, this cooler could be designed as a single-slot cooler without compromising on the copper block. Combined with the rear-mounted brass connectors, multiple coolers can be easily stacked on top of each other or side by side in the server case. This sophisticated design saves space, simplifies piping, and enables seamless integration into the water loop. High-quality copper is used for all water-carrying parts, which offers almost twice the thermal conductivity of aluminum. Furthermore, the copper is chrome-plated instead of nickel-plated, providing additional protection for the cooler. Chrome plating is more resistant to acids, scratches, and other damage, effectively preventing coatings from chipping. Technically, the GPU water cooler has been completely redesigned. To optimize cooling performance, the gaps between the cooler and the PCB components were redefined and tested. The water flow was simulated using state-of-the-art software and verified in practical tests. These extensive tests enabled improvements to the cooler base and nozzle to ensure the best possible cooling performance for the new Nvidia GeForce RTX generation. Compatibility: - MSI GeForce RTX™ 5070 Ti 16G INSPIRE 3X OC - MSI GeForce RTX™ 5070 Ti 16G SHADOW 3X OC - MSI GeForce RTX™ 5070 Ti 16G VENTUS 3X OC (V531-092R) - Inno3D GeForce RTX™ 5080 iChill Frostbite (C50803-16D7X-1760FB) - Inno3D GeForce RTX™ 5080 iChill X3 (C50803-16D7X-176069H) - Inno3D GeForce RTX™ 5080 X3 (N50803-16D7-176068N) - Inno3D GeForce RTX™ 5080 X3 OC (N50803-16D7X-17603930) - Inno3D GeForce RTX™ 5080 X3 OC White (N50803-16D7X-17605211) - MSI GeForce RTX™ 5080 16G SHADOW 3X OC (G5080-16S3C) - MSI GeForce RTX™ 5080 16G VENTUS 3X OC (V531-095R) - MSI GeForce RTX™ 5080 16G VENTUS 3X OC Plus (V531-001R) Technical data cooler Complete dimensions (L x W x H) 186.50 x 95.75 x 21.19 mm Radiator base material chrome-plated copper Material radiator top Acrylic Material Terminal Brass Material connection thread Brass Maximum working temperature 60°C Pressure tested 0.8 bar Connections 2 x G1/4" Thickness of radiator base 3.25 mm Thick cooling fins 0.4 mm Distance between cooling fins 0.4 mm Color transparent Technical data backplate Dimensions (L x W x H) 171.50 x 95.75 x 3 mm Thick backplate without spacers 1 mm Material aluminum Warranty: 3 years
Tootekood: 17635GTIN: 4250197176354Liquids for water cooling
Reinstwasser für Wasserkühlungen, frei von organischen und anorganischen Stoffen, demineralisiert und deionisiert, verhindert das Bilden von Rückständen
Tootekood: 18674GTIN: 4250197186742Internal power cables and adapters
An extension cable for 4-pin PWM fans. Available in various lengths. Sleeving provides additional protection, stability and increased lifetime. Technical detailsLength30cmConnections4-pin to 4-pinMaterialPlastic, sleevedColorblack
Tootekood: 18675GTIN: 4250197186759Internal power cables and adapters
An extension cable for 4-pin PWM fans. Available in various lengths. Sleeving provides additional protection, stability and increased lifetime. Technical detailsLength60cmConnections4-pin to 4-pinMaterialPlastic, sleevedColorblack
The ideal supplement for cooling of Mosfet or RAM modules on graphics cards. For sufficient cooling of these components, heatsinks such as this one are required. As a result, lower temperatures and better overclocking performance can be achieved. Being made completely from Aluminum, these heatsinks allow very efficient cooling of the cooled components. A low height of only 15mm allows installation even under large graphics card coolers. Technical specifications: Dimensions: 15x15x15mm (LxWxH) Material: Black anodized Aluminium Weight: 4g each This is a kit of 10 Alphacool GPU heatsinks 15x15mm Download 3D-file (.stp)
The ideal supplement for cooling of Mosfet or RAM modules on graphics cards. For sufficient cooling of these components, heatsinks such as this one are required. As a result, lower temperatures and better overclocking performance can be achieved. Being made completely from Aluminum, these heatsinks allow very efficient cooling of the cooled components. A low height of only 15mm allows installation even under large graphics card coolers. Technical specifications: Dimensions: 7x7x15mm (LxWxH) Material: Black anodized Aluminium Weight: 2g each This is a kit of 10 Alphacool GPU heatsinks 7x7mm Download 3D-file (.stp)
The small heat sinks are the perfect addition for cooling various electronic components such as the graphics card VRam, the voltage transformer on a motherboard, or even in a power amplifier or in RC vehicles. To ensure maximum heat capacity and cooling performance, the coolers are made of copper. Alphacool uses a special coating to prevent the infamous greenish discolouration on copper as much as possible. This increases the lifespan of the cooler and ensures steady cooling performance. The coolers can be installed onto the desired components with optional thermal paste or self-adhesive thermal pads. Technical Data Dimensions: 10 x 10mm Material: Fullcopper Scope of Delivery Alphacool GPU RAM Copper Heatsinks 10x10mm - 10pcs
The small heat sinks are the perfect addition for cooling various electronic components such as the graphics card VRam, the voltage transformer on a motherboard, or even in a power amplifier or in RC vehicles. To ensure maximum heat capacity and cooling performance, the coolers are made of copper. Alphacool uses a special coating to prevent the infamous greenish discolouration on copper as much as possible. This increases the lifespan of the cooler and ensures steady cooling performance. The coolers can be installed onto the desired components with optional thermal paste or self-adhesive thermal pads. Technical Data Dimensions: 14 x 14mm Material: Fullcopper Scope of Delivery Alphacool GPU RAM Copper Heatsinks 14x14mm - 10pcs
The small heat sinks are the perfect addition for cooling various electronic components such as the graphics card VRam, the voltage transformer on a motherboard, or even in a power amplifier or in RC vehicles. To ensure maximum heat capacity and cooling performance, the coolers are made of copper. Alphacool uses a special coating to prevent the infamous greenish discolouration on copper as much as possible. This increases the lifespan of the cooler and ensures steady cooling performance. The coolers can be installed onto the desired components with optional thermal paste or self-adhesive thermal pads. Technical Data Dimensions: 6,5 x 6,5mm Material: Fullcopper Scope of Delivery Alphacool GPU RAM Copper Heatsinks 6,5x6,5mm - 10pcs
Connect your graphics cards with the new Alphacool GPX SLI Connector and embrace the power! You get optimal cooling performance thanks to the serial water flow and your system looks great. ARGB - Stay in Control of Your LightingLight your system the way you want to. Thanks to addressable RGB you retain full control over your lighting. The high-quality acrylic allows the the ARGB LED's shine in rich, vibrant colours. These can be easily controlled by the Alphacool Aurora Eiscontrol. Mounting - Easier Than Ever BeforeThanks to the ¼" thread, installation is simple using the included fittings. Simply install them into your Alphacool EisBlock GPX Cooler and plug your Alphacool GPX SLI Connector onto it. Thanks to the double secured O-ring, you can even plug it on already mounted coolers. Expand the system - Make It YOUR ProjectThe Alphacool GPX SLI connectors are compatible with all new models of the Alphacool Eisblock series from 2080/2080Ti M02. All previous models can easily be upgraded with the Alphacool GPX SLI Upgrade Kit (1015976). The SLI Connectorl is available in 3 PCI-E Space and 4 PCI-E Space. Technical details Dimensions (LxWxH): 58 x 93,96 x 23mm Net weight: 195g Working temperature: Max 60°C Voltage: 5 VDC Certificates: CE, FC, ROHS Scope of delivery 1x GPX SLI Connector Plexi aRGB X3 4x SLI Adapter G 1/4“ Manual for download here Datasheet for download here
Alphacool HardTube 12/10mm Acrylic (PMMA) Clear 80cm - Set of 4 (320cm)
Tootekood: 18527GTIN: 4250197185271Tubing for water cooling
The HardTube Project has become a reality! Alphacool is breaking new ground and setting a new standard! Up till now, the most commonly used method for connecting water cooling systems was normal PVC tubing - but now, Alphacool is offering another way to set up your system. HardTubes provide more organisation for a system, giving it a distinctly more structured appearance. The plexiglass tubes can be fitted to a system easily with the right bending tools, without requiring extra angled pieces. In order to install the tubes into a system, they must be cut to the correct length. The following variants are available HardTube 13/10mm Plexi Clear 20cm, 40cm, 60cm, and 80cm HardTube 16/12mm Plexi Clear 20cm, 40cm, 60cm, and 80cm (now available as a 4-pack) Components can be attached to the tubes, cut to the correct length, with a little effort. Scope of delivery Alphacool HardTube 12/10mm Plexi (PMMA) Clear 80cm - 4 pcs. Please note: not compatible with Monsoon fittings
Tootekood: ROH1020314GTIN: 4250197184960Tubing for water cooling
Transparente 600-mm-Tube von Alphacool, aus Borosilikatglas, besonders kratzfest und langlebig, zum Verbinden von Wakü-Komponenten, 16/11mm (Außen-/Innendurchmesser), klar
With the Alphacool HardTube Bending Kit Basic you everything you need to cut, deburr and bend your 10mm and 13mm inner diameter PETG tubes. Deburring made easyEveryone who works with HardTubes knows that they must deburr all ends of the tubes. The classic deburrer from Alphacool offers the ability to deburr HardTubes inside and outside. The external deburring is extremely important so that the HardTubes fit perfectly and do not damage any O-rings. The inner deburring is only used to remove cutting residue. For clean deburring, the deburrer has three steel blades with sharpened edges. The deburrer fits perfectly in the hand due to its large round shape. Cutting PETG tubesThe Eistools Modding Cutter works like scissors and is ideal for cutting PETG HardTube . Please note that acrylic HardTube cannot be cut with this tool as they would shatter when cut. Of course, you can also use it to cut cables and other soft components. If you want to cut angles, the integrated protractor can be used. Bending tool and silicone insertsA silicone insert is absolutely necessary for bending HardTubes. The Silicone Insert prevents the tube from collapsing at the bends. To help the insert glide better, use a waterbased lubricant or similar. Oil based Lubricant and too much soap should be avoided and never use alcohol as this can damage plastics such as PETG . With the small but practical bending tool you can easily bend simple angles. The tube is pushed into the bending tool, heated with a heat gun and can then be bent very easily. The only additional items you will need are the HardTubes and a heatgun that can produce low emperatures. With this simple combination you can make the liquid cooled PC of your dreams. Scope of delivery:1 x Silicon Bending Insert 100cm HardTubes with 13mm inner diameter1 x Silicon Bending Insert 100cm HardTubes with 10mm inner diameter1 x PETG and Acrylrohr Deburrer - Light Version1 x Double Bending Tool for 12-14 und 16mm HardTubes1 x Eistools Modding Cutter for PETG HardTubes Data sheet PDF: Alphacool HardTube Bending Kit Basic
