To attach DIN rail adapter to the device: Locate the groove for attaching adapter on the bottom of the device Line up smaller holes in the middle of DIN rail adapter with the groove on the device Secure adapter with two self-tapping screws.

Parameters Rated Value Single output power 20 W Input voltage range 100-240 VAC 50/60 Hz DC output voltage 12 V DC output current 0~1.67 A Output ripple and noise 120 mVp-p Line regulation ±1 % Load regulation ±1 % Efficiency 80 % Adjustable range for DC voltage ±1 % Test standard EN60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013EN55022:2010EN61000-3-2:2014EN61000-3-3:2013EN55024:2010/A1:2015 Inrush current Cold start current 20 A/ 115 VAC; 40 A/ 230 VAC Overload protection 105 % ~ 160 % cut off the output automatic recovery Over voltage protection 120 % ~ 140 % shut down O/P voltage re-power on to recover Setup rise hold up time 500 ms; 30 ms/ 230 VAC at full load; 1000 ms; 30 ms/ 115 VAC at full load Withstand voltage I/P-O/P: 1.5 kV; I/P-FG: 1.5 kV; O/P-FG: 0.5 kV 1 minute Isolation resistance I/P-O/P I/P-FG O/P-FG: 500 VDC/ 1000 MΩ Working temperature -10 °C ~ +50 °C Mounting options 35 mm DIN Rail Dimensions 22.5 x 90 x 100 mm Weight 190 g

To attach DIN rail adapter to the device: 1. Locate the groove for attaching adapter on the bottom of the device. 2. Line up smaller holes in the middle of DIN rail adapter with the groove on the device. 3. Secure adapter with two screws.

* - Teltonika devices are shown for demonstration purposes only and sold separately!

License Coverage: If You have 12 licenses and 1 monitored devices you will see license coverage for 12 monthsIf You have 12 licenses and 2 monitored devices you will see license coverage for 6 months 1 License cover: 1 device per months To generate the license please write in order comment your Teltonika ID (login) and license will be transferred to your account. Remote Management System (RMS) is designed to conveniently monitor and manage all your Teltonika networking devices including RUT2XX RUT8XX and RUT9XX routers.The system allows to securely gather status information of your devices and to change their configuration even if the devices do not have public IP addresses. Try RMS for free by clicking this link and registering your free demo account! Centralized system Access monitor and control whole router fleet from within a single web browser-based interface. Compatible with browsers across all platforms requires no installation or additional plug-ins.Firmware and configuration updates Deploy your desired con­figuration ­template or new ­firmware version to multiple units or groups of units at the same time. Over-the-air bulk upgrade and con­figuration signif­icantly reduces the costs of system maintenance.Accessibility and security Your routers will not be dependent on having a public IP address for remote access decreasing maintenance costs and increasing effectiveness. Communication between routers and main server is secured by hardcoded OpenVPN connection which requires no configuration and protects communication channel from tampering.Maintenance and diagnostics Users receive information that helps them to visualize the unit’s location and check performance indicators like temperature signal strength and all device details. For proactive diagnostics – remotely reboot devices download troubleshooting or system event files for in-depth health analysis.Statistics Improve overall performance and efficiency of your whole network based on conclusions of reporting tools that allow creation of custom reports related to device availability performance and exceptions. Actively know how your network is behaving.
