UF-InstantUFiber Instant Optical TransceiverGigabit Passive Optical Network CPEFeatures: High-Performance GPON CPE Up to 2.4 Gbps Downstream and 1.2 Gbps Upstream GPON structure Supports up to 20 km GPON Links Powerful Layer 2/3 Management Features (1) GPON WAN Port SC/APC (1) 1Gbps SFP interface

GPON Optical Line Terminal Configuring a fiber network just became as easy as setting up a smartphone. Say goodbye to command lines manuals and paid support licenses. Introducing the UFiber OLT – a fiber solution that anyone can deploy. Features: 8 Gigabit Passive Optical Network PortsSupports up to 1024 Clients (128 per PON Port)Up to 2.488 Gbps TX and 1.244 Gbps RXTwo 1G/10G SFP+ Ethernet PortsFlexible Layer 2/3 Management FeaturesFastEthernet port for managementConsole serial port for management Centralized Management Easily configure the OLT and manage multiple sites using the comprehensive UNMS™ (Ubiquiti® Network Management System) software.Rackmount Design The 1U-high metal chassis allows for convenient mounting in a standard-sized 19"‑wide rack. Client and Uplink Connectivity The OLT features eight PON ports to connect up to 1024 Nano G devices and two SFP+ ports deliver up to 20 Gbps of uplink connectivity. Power Versatility Featuring low power consumption the OLT offers two modular power bays. The first bay includes an AC/DC power module. The second bay can house an optional power module either an AC/DC backup or a DC/DC power module.

Sporting a sleek industrial design the U Fiber WiFi is a robust high‑performance GPON CPE that features an informational LED display with 4 Ethernet ports and WiFi. Features: High-Performance GPON CPELED diodes for easy diagnosticsUp to 2.4 Gbps Downstream and 1.2 Gbps UpstreamSupports up to 20 km GPON LinksPowerful Layer 2/3 Management FeaturesGPON WAN Port4x RJ45 Gigabit LAN PortSC/APC Fiber Connector802.11n Wi‑Fi Status LEDs The easy-to-read LEDs provide status information: Ethernet connection signal strength and power.Versatile Power The 4 Ethernet LAN ports support 10/100/1000 Mbps connections. The UFiber WiFi can be powered using 24V passive PoE on Port 1 or by 24VDC. Designed for Integration Up to 128 UFiber WiFi devices can be connected to a single GPON port. Supporting GPON links of up to 20 km the UFiber WiFi integrates with the UFiber OLT and third-party OLT devices.

The UFiber splitter carries data from a UFiber OLT’s long-haul cable and shares it with multiple UFiber ONUs. Available with 4 8 16 or 32 outputs. PLC Splitters UF-SPLITTER-4 UF-SPLITTER-8 UF-SPLITTER-16 UF-SPLITTER-32 Input (1) SC/APC (1) SC/APC (1) SC/APC (1) SC/APC Outputs (4) SC/APC (8) SC/APC (16) SC/APC (32) SC/APC Insertion Loss with Connectors 7.4 dB 10.5 dB 13.7 dB 17.0 dB Uniformity Loss 0.6 dB 0.8 dB 1.2 dB 1.5 dB Polarization Dependent Loss 0.3 dB 0.3 dB 0.3 dB 0.3 dB Wavelength Bandwidth 1260-1650 nm 1260-1650 nm 1260-1650 nm 1260-1650 nm Return Loss (All Ports) 50 dB 50 dB 50 dB 50 dB Directivity 55 dB 55 dB 55 dB 55 dB Fiber Type G657A1 G657A1 G657A1 G657A1 Operating Temperature -40 to 85° C (-40 to 185° F) -40 to 85° C (-40 to 185° F) -40 to 85° C (-40 to 185° F) -40 to 85° C (-40 to 185° F) Total Length 4.06m (13.32') 4.06 m (13.32') 4.06 m (13.32') 4.08 m (13.39') Weight 58 g (2.0 oz) 62 g (2.2 oz) 110 g (3.9 oz) 160 g (5.6 oz)

The UFiber splitter carries data from a UFiber OLT’s long-haul cable and shares it with multiple UFiber ONUs. Available with 4 8 16 or 32 outputs. PLC Splitters UF-SPLITTER-4 UF-SPLITTER-8 UF-SPLITTER-16 UF-SPLITTER-32 Input (1) SC/APC (1) SC/APC (1) SC/APC (1) SC/APC Outputs (4) SC/APC (8) SC/APC (16) SC/APC (32) SC/APC Insertion Loss with Connectors 7.4 dB 10.5 dB 13.7 dB 17.0 dB Uniformity Loss 0.6 dB 0.8 dB 1.2 dB 1.5 dB Polarization Dependent Loss 0.3 dB 0.3 dB 0.3 dB 0.3 dB Wavelength Bandwidth 1260-1650 nm 1260-1650 nm 1260-1650 nm 1260-1650 nm Return Loss (All Ports) 50 dB 50 dB 50 dB 50 dB Directivity 55 dB 55 dB 55 dB 55 dB Fiber Type G657A1 G657A1 G657A1 G657A1 Operating Temperature -40 to 85° C (-40 to 185° F) -40 to 85° C (-40 to 185° F) -40 to 85° C (-40 to 185° F) -40 to 85° C (-40 to 185° F) Total Length 4.06m (13.32') 4.06 m (13.32') 4.06 m (13.32') 4.08 m (13.39') Weight 58 g (2.0 oz) 62 g (2.2 oz) 110 g (3.9 oz) 160 g (5.6 oz)

The UFiber splitter carries data from a UFiber OLT’s long-haul cable and shares it with multiple UFiber ONUs. Available with 4 8 16 or 32 outputs. PLC Splitters UF-SPLITTER-4 UF-SPLITTER-8 UF-SPLITTER-16 UF-SPLITTER-32 Input (1) SC/APC (1) SC/APC (1) SC/APC (1) SC/APC Outputs (4) SC/APC (8) SC/APC (16) SC/APC (32) SC/APC Insertion Loss with Connectors 7.4 dB 10.5 dB 13.7 dB 17.0 dB Uniformity Loss 0.6 dB 0.8 dB 1.2 dB 1.5 dB Polarization Dependent Loss 0.3 dB 0.3 dB 0.3 dB 0.3 dB Wavelength Bandwidth 1260-1650 nm 1260-1650 nm 1260-1650 nm 1260-1650 nm Return Loss (All Ports) 50 dB 50 dB 50 dB 50 dB Directivity 55 dB 55 dB 55 dB 55 dB Fiber Type G657A1 G657A1 G657A1 G657A1 Operating Temperature -40 to 85° C (-40 to 185° F) -40 to 85° C (-40 to 185° F) -40 to 85° C (-40 to 185° F) -40 to 85° C (-40 to 185° F) Total Length 4.06m (13.32') 4.06 m (13.32') 4.06 m (13.32') 4.08 m (13.39') Weight 58 g (2.0 oz) 62 g (2.2 oz) 110 g (3.9 oz) 160 g (5.6 oz)

The UFiber splitter carries data from a UFiber OLT’s long-haul cable and shares it with multiple UFiber ONUs. Available with 4 8 16 or 32 outputs. PLC Splitters UF-SPLITTER-4 UF-SPLITTER-8 UF-SPLITTER-16 UF-SPLITTER-32 Input (1) SC/APC (1) SC/APC (1) SC/APC (1) SC/APC Outputs (4) SC/APC (8) SC/APC (16) SC/APC (32) SC/APC Insertion Loss with Connectors 7.4 dB 10.5 dB 13.7 dB 17.0 dB Uniformity Loss 0.6 dB 0.8 dB 1.2 dB 1.5 dB Polarization Dependent Loss 0.3 dB 0.3 dB 0.3 dB 0.3 dB Wavelength Bandwidth 1260-1650 nm 1260-1650 nm 1260-1650 nm 1260-1650 nm Return Loss (All Ports) 50 dB 50 dB 50 dB 50 dB Directivity 55 dB 55 dB 55 dB 55 dB Fiber Type G657A1 G657A1 G657A1 G657A1 Operating Temperature -40 to 85° C (-40 to 185° F) -40 to 85° C (-40 to 185° F) -40 to 85° C (-40 to 185° F) -40 to 85° C (-40 to 185° F) Total Length 4.06m (13.32') 4.06 m (13.32') 4.06 m (13.32') 4.08 m (13.39') Weight 58 g (2.0 oz) 62 g (2.2 oz) 110 g (3.9 oz) 160 g (5.6 oz)

The UVC-G4-Doorbell-PS is an optional power adapter for the UVC-G4-Doorbell. Instead of using existing electrical wiring one end connects to the doorbell and the other end plugs into a standard EU electrical outlet. Maximum distance: 6 m (19' 8")

Specifications Output Voltage 24V Output Rating 0.5A (12W) Input Voltage AC 100~240V Input Frequency 50~60Hz Operating Temperature 0C~+40C Storage Temperature -20C~+85C

Specifications Output Voltage 24 V Output Rating 1A (24W) Input Voltage AC 100~240V Input Frequency 50~60Hz Operating Temperature 0C~+40C Storage Temperature -20C~+85C

Specifications Output Voltage 24 V Output Rating 1A (24W) Input Voltage AC 100~240V Input Frequency 50~60Hz Operating Temperature 0C~+40C Storage Temperature -20C~+85C

Ubiquiti POE-24-30W-G-WHis a PoE adapter designed to power various Ubiquiti devices. Compatible with most products (check the device specification before determining compatibility): airFiber airMAX EdgeMAX mFi UniFi AP UniFi Video / airVision. Protection Ubiquiti PoE Adapters provide a variety of features to help protect your PoE devices: Surge protection Clamping protection Maximum surge discharge Peak pulse current AC cable with earth ground Electrostatic discharge (ESD) is the leading cause for outdoor device failures. You can effectively protect against ESD damage using a grounded Ubiquiti PoE Adapter TOUGHCable™ and TOUGHCable Connectors. Ubiquiti PoE Adapter Compatibility with the airGateway™ Specific PoE Adapter models are designed to work with the airGateway. The airGateway is a compact CPE (consumer premises equipment) gateway with built-in Wi-Fi used to connect the subscriber’s local network to the WISP network. The airGateway is available in three models: airGateway Standard model with an internal antenna airGateway Pro Dual-Band Wi-Fi model with an internal antenna airGateway-LR Long-range Wi-Fi model with an external antenna for extended range The airGateway plugs into any of these PoE Adapters: Model Number Compatibility POE-15-12W ✓ POE-24-12W ✓ POE-24-12W-G ✓* POE-24-7W ✓* POE-24-12W-G-WH ✓* * airGateway maximum LAN port speed: 100 Mbps

Ubiquiti POE-24-7W is a PoE adapter designed to power various Ubiquiti devices.Compatible with most products (check the device specification before determining compatibility):airFiberairMAXEdgeMAXmFiUniFi APUniFi Video / airVision.Protection Ubiquiti PoE Adapters provide a variety of features to help protect your PoE devices: Surge protectionClamping protectionMaximum surge dischargePeak pulse currentAC cable with earth ground Electrostatic discharge (ESD) is the leading cause for outdoor device failures. You can effectively protect against ESD damage using a grounded Ubiquiti PoE Adapter TOUGHCable™ and TOUGHCable Connectors. Ubiquiti PoE Adapter Compatibility with the airGateway™ Specific PoE Adapter models are designed to work with the airGateway. The airGateway is a compact CPE (consumer premises equipment) gateway with built-in Wi-Fi used to connect the subscriber’s local network to the WISP network. The airGateway is available in three models: airGateway Standard model with an internal antennaairGateway Pro Dual-Band Wi-Fi model with an internal antennaairGateway-LR Long-range Wi-Fi model with an external antenna for extended range The airGateway plugs into any of these PoE Adapters: Model Number CompatibilityPOE-15-12W ✓POE-24-12W ✓POE-24-12W-G ✓*POE-24-7W ✓*POE-24-12W-G-WH ✓* * airGateway maximum LAN port speed: 100 Mbps

Specifications Output Voltage 48 V Output Rating 0.5A (24W) Input Voltage AC 100~240V Input Frequency 50~60Hz Operating Temperature 0C~+40C Storage Temperature -20C~+85C

Specifications Output Voltage 48-56V Output Rating 1.2A Input Voltage AC 100~240V Input Frequency 50~60Hz Operating Temperature 0C~+40C Storage Temperature -20C~+85C

Specifications Output Voltage 54V Output Rating 1.5A Input Voltage AC 100~240V Input Frequency 50~60Hz Operating Temperature 0C~+40C Storage Temperature -20C~+85C

The UF-GP-B+ SFP module is designed to be used with the ports on the UF-OLT. It is a Single-Mode SC/UPC module offering an upstream data rate of up to 1.25Gbps and a downstream rate of up to 2.5Gbps. Supported Media: Single-Mode FibreConnector Type: SC/UPCTX Wavelength: 1490nmRX Wavelength: 1310nmDownstream Data Rate: 2.5GbpsUpstream Data Rate: 1.25GbpsCable Distance: 20km

The UF-GP-C+ SFP module is designed to be used with the ports on the UF-OLT. It is a Single-Mode SC/UPC module offering an upstream data rate of up to 1.25Gbps and a downstream rate of up to 2.5Gbps. Supported Media: Single-Mode FibreConnector Type: SC/UPCTX Wavelength: 1490nmRX Wavelength: 1310nmDownstream Data Rate: 2.5GbpsTx power range: 3 to 7 dBmRx power range: -12 to -30 dBmUpstream Data Rate: 1.25GbpsCable Distance: 20km

PoE Switch Compatibility The Instant 802.3af Gigabit PoE Converter integrates seamlessly with a variety of auto-sensing 802.3af PoE switches for remote power control applications. As you manage and monitor your network you can conveniently power or power cycle your remote devices using your 802.3af switch. For ease of power management you can centralize the 802.3af switch and power source and you can include a UPS (Uninterruptible Power Supply) as a backup. This way your network continues to run even during a temporary power outage.
