UDC-3 cables for uplinks between the UniFi switch and the SFP ports.1Gbps or 10Gbps capacitiesThe cable is copper and incorporates SFP modules.Designed for UniFi switches to chain between communication cabinets/boxes.SFP+ 10G passive copper cables can be used for short distance 10Gbps transmission. Transceiver cables are perfect solution for a server room applications.
The Switch Enterprise 24 PoE (USW Enterprise 24 PoE) is a fully managed Layer 3 switch with (12) 2.5GbE 802.3at PoE+ RJ45 ports (12) GbE 802.3at PoE+ RJ45 ports (2) 10G SFP+ ports and a 400W total PoE supply. The USW Enterprise 24 PoE also features a 1.3" LCM color touchscreen that concisely displays key system and connection insights.Additionally the USW Enterprise 24 PoE offers enhanced power supply failure protection when connected to the SmartPower Redundant Power System (USP RPS sold separately). This switch can be monitored or configured from anywhere with the powerful intuitive UniFi Network web application and mobile app.Managed with the UniFi Network application: Version 5.14.12 and later.
UniFi Switch Enterprise 48 PoE is a reliable manageable 2.5-Gigabit L3 Switch with a switching capacity of 320 Gbps (48) 2.5-Gigabit LAN ports and four SFP+ (10 Gbps) slots. All Ethernet ports support 802.3af/at PoE-Out with an output power of 30 W/port and total PoE budget of 720 W. In addition to the standard equipment the switch also has a 1.3" touch screen for providing information about the system temperature port statistics PoE power supply and much more. The switch can be powered via standard 230 V but also via UniFi SmartPower RPS which rather backs up power in the event of an internal power failure.USW-Enterprise-48-PoE does not have web management but is managed centrally by UniFi Controller with support for the UniFi mobile application. It offers an extensive set of advanced switching protocols and L2 functions including operating mode (switching mirroring or aggregation) per port. UniFi Network Controller and mobile applications allow administrators to configure and monitor virtually all graphical user interface functions from anywhere.This generation of switches supports redundant power supply via a special connector to the UniFi SmartPower unit in the event of a failure of the primary power supply at the switch.
The Switch Enterprise 8 PoE (USW Enterprise 8 PoE) is a fully managed Layer 3* switch with (8) 2.5GbE 802.3at PoE+ RJ45 ports and (2) 10G SFP+ ports.The USW Enterprise 8 PoE also features a 1.3" LCM color touchscreen that concisely displays key system and connection insights. This switch can be monitored or configured from anywhere with the powerful intuitive UniFi Network web application and mobile app.* Layer 3 switching will become available in a future firmware update.
The Switch Enterprise XG 24 (USW Enterprise XG 24) is a fully managed mult-gigabit Layer 3 switch with (24) 10GbE RJ45 ports and (2) 25G SFP28 ports. The USW Enterprise XG 24 also features a 1.3" LCM color touchscreen that concisely displays key system and connection insights.Additionally the USW Enterprise XG 24 offers enhanced power supply failure protection when connected to the SmartPower Redundant Power System (USP RPS sold separately). This switch can be monitored or configured from anywhere with the powerful intuitive UniFi Network web application and mobile app.
The Switch Flex XG (USW Flex XG) is a fully managed mult-gigabit Layer 2 switch with (4) 10GbE RJ45 ports and (1) GbE PoE input. The USW Flex XG sports slim compact housing and can be mounted on a desktop*. This switch can also be monitored or configured from anywhere with the powerful intuitive UniFi Network web application and mobile app.Do not stack other hardware on the USW Flex XG.
USW-Flex-MiniUniFi Compact 5Port Gigabit Desktop SwitchBuild and expand your network with the UniFi Switch part of the Ubiquiti Networks UniFi Enterprise System. The UniFi Switch model USW-Flex-Mini is a smart managed Gigabit switch. It offers 5 RJ45 Ethernet ports providing 1 Gigabit links to your devices. Power up the USW-Flex-Mini with the included USB Type-C power adapter or with 802.3af PoE Ethernet in port 1.
Unifi Switch FlexBuild and expand your network with the UniFi® Switch part of the UniFi Enterprise System. The UniFi Switch model USW-Flex is a configurable Layer 2 Gigabit switch with auto-sensing 802.3af PoE. It offers 5 RJ45 Gigabit Ethernet ports providing 1 PoE input and 4 PoE output links to your devices.The UniFi Switch Flex features a single PoE In port for power and four PoE ports that provide up to 15W PoE output to power a UniFi access point or other PoE devices. With 802.3bt rated PoE switches (USW-Pro-48-PoE USW-Pro-24-PoE and USW-Industrial switches sold separately) as power source USW-Flex supports maximum 46W PoE output budget. It has weatherproof housing and offers versatile mounting options.Managed and configured by the UniFi Controller or UniFi Mobile app the UniFi Switch Flex offers basic Layer 2 switching protocols and features. The UniFi Controller and mobile app allow admins to configure and monitor virtually all of the switch features using a graphical user interface from anywhere. PoE Flexibility The USW-Flex supports a maximum PoE output budget of 46W when powered by 60W 802.3bt PoE++. Four ports offer auto-sensing 802.3af PoE output to power multiple devices on the network. Versatile Mounting The USW-Flex can be installed horizontally or vertically making it ideal for desktop magnetic wall-mount and pole-mount installations. Indoor/Outdoor Design The USW-Flex is designed for indoor or outdoor use. With its weatherproof housing and versatile mounting options the USW-Flex provides both flexibility and durability for environments with extreme temperature variations. Compatible Products The USW-Flex powers a variety of products including the UniFi Video Camera G3 Flex UniFi Video Camera G4 Pro and UniFi AC Mesh AP which use 802.3af PoE. To enable its maximum power budget of 46W the USW-Flex can be powered by the USW-Industrial switch which provides 60W of 802.3bt PoE++. Seamless Integration A single instance of the UniFi Controller running in the cloud can manage multiple UniFi sites within a centralized interface. Each site is logically separated and has its own network monitoring configuration maps statistics and admin accounts.
The USW-Lite-16-PoE is a fully managed Layer 2 switch with 16x Gigabit Ethernet ports for your RJ45 Ethernet devices. Eight ports also offer auto-sensing 802.3at PoE+ that provide up to a total PoE wattage of 45W for UniFi Access Points or other PoE devices.Managed and configured by the UniFi Network Controller with UniFi mobile app support the USW-Lite-16-PoE offers Layer 2 switching protocols and features. The UniFi Network Controller and mobile app allow admins to configure and monitor virtually all of the switch features in a graphical user interface from anywhere.
The USW-Pro-48-POE is a configurable Gigabit Layer2 and Layer3 switch with auto-sensing 802.3at PoE+ and 802.3bt PoE++. Forty PoE+ and eight PoE++ RJ45 ethernet ports have total 600W PoE budget and four SFP+ ports offer 10Gbps uplink options. Near-silent cooling and a 1.3" touch LCM. Note: Layer3 will be included in later software release.
The UniFi Switch Pro 48 features a rich set of Layer 2 capabilities and integrates Layer 3 functionality such as inter-VLAN routing static routing and DHCP server. The UniFi Switch Pro 48 is an ideal aggregation and access layer switch for any UniFi solution – it combines innovative near-silent cooling with UniFi SmartPower RPS power redundancy. UniFi Network Controller and UniFi Network mobile app allow admins to configure and monitor virtually all of the switch features in an intuitive graphical user interface from anywhere. Features: (48) Gigabit RJ45 ports (4) 10G SFP+ ports Layer 2 and Layer 3* features UniFi SmartPower RPS DC input Near-silent cooling 1.3" touchscreen display Managed by UniFi Network Controller
The USW-16-POE is a configurable Gigabit Layer 2 switch with sixteen Gigabit Ethernet ports including eight auto-sensing 802.3at PoE+ ports and two SFP ports. It provides Gigabit PoE links to your RJ45 Ethernet devices and Gigabit fiber uplink options to your enterprise network. The USW-16-POE features a 1.3" touch LCM to provide status information. With a depth of 7.9" the compact fanless design can be easily installed in a SOHO rack cabinet. Managed and configured by the UniFi Network Controller with UniFi mobile app support the USW-16-POE offers an extensive suite of advanced Layer 2 switching protocols and features including operation mode (switching mirroring or aggregate) per port. The UniFi Network Controller and mobile app allow admins to configure and monitor virtually all of the switch features in a graphical user interface from anywhere.
The USW-24-POE is a configurable Gigabit Layer 2 switch with twenty four Gigabit Ethernet ports including sixteen auto-sensing 802.3at PoE+ ports and two SFP ports. It provides Gigabit PoE links to your RJ45 Ethernet devices and Gigabit fiber uplink options to your enterprise network. The USW-24-POE features a 1.3" touch LCM to provide status information. With a depth of 7.9" the compact fanless design can be easily installed in a SOHO rack cabinet. Managed and configured by the UniFi Network Controller with UniFi mobile app support the USW-24-POE offers an extensive suite of advanced Layer 2 switching protocols and features including operation mode (switching mirroring or aggregate) per port. The UniFi Network Controller and mobile app allow admins to configure and monitor virtually all of the switch features in a graphical user interface from anywhere.
The USW-24 is a configurable Layer 2 switch with 24 Gigabit Ethernet ports and 2 SFP ports. The SFP ports provide 1 Gbps fiber uplink options to your enterprise network. The USW-24 features a 1.3" touchscreen compact size and fanless design. The touchscreen displays the current switch state and information for quick diagnosis. Managed and configured by the UniFi Network Controller with UniFi mobile app support the USW-24 switch offers an extensive suite of advanced Layer 2 switching protocols and features including operating mode (switching mirroring or aggregate) per port.Managed by UniFi Network Controller version: 5.12.32 or higher.
The USW-48-PoE is a configurable Gigabit Layer 2 switch with 48 Gigabit Ethernet ports including 32 auto-sensing 802.3at PoE+ ports and 4 SFP ports. It provides Gigabit PoE links to your RJ45 Ethernet devices and Gigabit fiber uplink options to your enterprise network. The USW-48-PoE features a 1.3" touch LCM to provide statusManaged and configured by the UniFi Network Controller with UniFi mobile app support the USW-48-PoE offers an extensive suite of advanced Layer 2 switching protocols and features including operation mode (switching mirroring or aggregate) per port. The UniFi Network Controller and mobile app allow admins to configure and monitor virtually all of the switch features in a graphical user interface from anywhere.
UniFi Switch 48 is a fully managed Layer 2 switch with (48) Gigabit Ethernet ports and (4) 1G SFP ports for fiber connectivity.The UniFi Switch 48 features a rich set of Layer 2 capabilities and fanless silent cooling for use as an access layer switch. UniFi Network Controller and UniFi Network mobile app allow admins to configure and monitor virtually all of the switch features in an intuitive graphical user interface from anywhere.
