EK Water Blocks EK-AC GeForce RTX 3090 – Backplate – CNC-machined backplate for EK-AC water blocks EK Water Blocks EK-AC GeForce RTX 3090 – Backplate is a CNC-machined retention backplate made from anodised aluminium and designed for the matching EK-AC water blocks. It covers the entire length of the graphics card PCB, acts as an aesthetic upgrade, and additionally provides passive cooling for the backside of the voltage regulation module (VRM) and the GPU core. The part is CNC-machined from anodised aluminium, which is more rigid and more scratch-resistant than painted plastic. Key Features GPU, VRAM and VRM in one block: Coolant flows directly over the graphics chip, memory, and voltage regulation module – not just the core. Anodised aluminium: The anodised surface is more scratch-resistant than paint and keeps its colour over time. Passive additional cooling: Thermal pads transfer heat from the back of the PCB to the surrounding air. Full PCB coverage: Covering the entire length of the PCB protects the card mechanically and prevents sagging. Technical Specifications TypeEK Water Blocks EK-AC GeForce RTX 3090 – Backplate ManufacturerEK Water Blocks Manufacturer P/N3831109833674 SeriesEK-AC GPU PlatformNVIDIA GeForce Scope of Delivery EK-AC GeForce RTX 3090 – Backplate All necessary mounting screws EK Water Blocks EK-AC GeForce RTX 3090 – Backplate adds a carefully manufactured component to your custom loop.
EK Water Blocks EK-AC Trinity RTX 3090 – Backplate – CNC-machined backplate for EK-AC water blocks EK Water Blocks EK-AC Trinity RTX 3090 – Backplate is a CNC-machined retention backplate made from anodised aluminium and designed for the matching EK-AC water blocks. It covers the entire length of the graphics card PCB, acts as an aesthetic upgrade and additionally provides passive cooling for the backside of the voltage regulation module (VRM) and the GPU core. The part is CNC-machined from anodised aluminium, which is more rigid and more scratch-resistant than painted plastic. Key Features GPU, VRAM and VRM in one block: Coolant flows directly over the graphics chip, memory and voltage regulation module – not just the core. Anodised aluminium: The anodised surface is more scratch-resistant than paint and keeps its colour over time. Passive additional cooling: Thermal pads transfer heat from the back of the PCB to the surrounding air. Full PCB coverage: Covering the entire length of the PCB protects the card mechanically and prevents sagging. Technical Specifications TypeEK Water Blocks EK-AC Trinity RTX 3090 – Backplate ManufacturerEK Water Blocks Manufacturer P/N3831109833681 SeriesEK-AC GPU PlatformNVIDIA GeForce Scope of Delivery EK-AC GeForce RTX 3090 – Backplate All necessary mounting screws EK Water Blocks EK-AC Trinity RTX 3090 – Backplate adds a carefully manufactured component to your custom loop.
EK-Quantum Vector FE RTX 3090 Backplate - Black is a CNC machined retention backplate made from black anodized aluminum for the EK-Quantum Vector FE RTX 3090 - Special Edition water block. The backplate covers the backside of the graphics card's PCB and serves as an aesthetic add-on. It provides additional passive cooling for the GPU core, rear-mounted VRAM and backside of the printed circuit board VRM section. Due to the small size of both the card and the water block, the backplate boasts a ribbed design for additional passive cooling power and touches the active part of the water block for true hybrid cooling. Enclosed EK-Quantum Vector FE RTX 3090 Backplate - Black Mounting screws Thermal pads
EK-Quantum Vector FE RTX 3090 Backplate - Silver is a CNC machined retention backplate made from silver anodized aluminum for the EK-Quantum Vector FE RTX 3090 - Special Edition water block. The backplate covers the backside of the graphics card's PCB and serves as an aesthetic add-on. It provides additional passive cooling for the GPU core, rear-mounted VRAM and backside of the printed circuit board VRM section. Due to the small size of both the card and the water block, the backplate boasts a ribbed design for additional passive cooling power and touches the active part of the water block for true hybrid cooling. Enclosed EK-Quantum Vector FE RTX 3090 Backplate - Silver Mounting screws Thermal pads
EK-Quantum Vector FE RTX 3090 D-RGB Active Backplate - Black SE is a cutting-edge addition to the EK® Quantum Line. It is made to complement the existing EK-Quantum Vector FE RTX 3090 – Special Edition water blocks and actively cool the backside of a Founders Edition NVIDIA® GeForce RTX™ 3090 GPUs. These newly developed active backplates require at least one slot above them to be empty as they stand 16.8mm tall from the PCB across the whole GPU. EK-Quantum Vector FE RTX 3090 D-RGB Active Backplate The EK-Quantum Vector FE RTX 3090 D-RGB Active Backplate links the water block and active backplate with a new terminal, which replaces the original terminal that comes with your water block. As a result, the whole enclosure requires only one inlet and one outlet, which removes unnecessary additional tubing and reduces clutter. It is the ultimate aesthetic and performance solution that sandwiches your GPU between two water blocks, allowing for maximum cooling. The brand new Vector Active Backplate directly cools all PCB hotspots found on the backside of the GPU core and VRM, but especially the rear-mounted VRAM. Cooling liquid is channeled over all these critical areas. The inside of the water block follows the stock backplate aesthetics with ribs that span the entirety of the block. The new terminal has 4 ports, two direct (end ports) and two through port-style (either on the bottom or top of the terminal). It can be flipped to have the through ports either on the side of the water block or active backplate, but the flow cannot be reversed. The base of the active backplate is CNC-machined out of nickel-plated electrolytic copper, while the top is CNC-machined out of glass-like cast acrylic. Just like on the water block itself, the external enclosure does not have any contact with the coolant. It is machined out of a thick solid piece of aluminum, which is afterward anodized into black. The watertight seal is ensured by high-quality EPDM O-rings. D-RGB lighting on EK-Quantum Vector FE RTX 3090 D-RGB Active BackplateThis active backplate boasts a whopping 22 individually addressable D-RGB LEDs that illuminate both the water block’s interior and the terminal itself. It is compatible with all popular RGB Sync technologies from major motherboard manufacturers. The arrow symbol on the 3-pin D-RGB LED connector is to be aligned with the +5V marking on the D-RGB (addressable) motherboard header. Technical Specification: Dimensions: (LxHxW) - 212,5x121,5x40mm (thickness excluding the terminal = 16.8mm from the PCB) D-RGB cable length: 500mm D-RGB LED count: 22 D-RGB connector standard 3-pin (+5V, Data, Blocked, Ground) Enclosed: EK-Quantum Vector FE RTX 3090 Active Backplate D-RGB - Black SE Necessary mounting screws, nuts, and washers Thermal pads Warning: EK only guarantees compatibility with included EK-brand thermal pads. Installation process, cooling performance and block contacts are tested exclusively with EK-brand thermal pads. Listed thermal pad thicknesses apply only to EK thermal pads which are included in the package. EK does not guarantee compatibility with aftermarket alternatives for thermal interface material.
EK Water Blocks EK-Quantum Vector FE RTX 3090 Ti D-RGB - Silver Special Edition – Full-cover water block for graphics cards EK Water Blocks EK-Quantum Vector FE RTX 3090 Ti D-RGB - Silver Special Edition is a full-cover water block that spans the entire length of the graphics card. Coolant is channelled directly over the GPU core, memory and voltage regulation module (VRM), so all critical components are cooled within a single loop. The cold plate is CNC-machined from nickel-plated electrolytic copper. The dimensions are 212.5x121.5x29 mm. Key Features Open Split-Flow cooling engine: The flow is split across the fin structure. This keeps flow restriction low, so weaker or slow-running pumps are sufficient as well. GPU, VRAM and VRM in one block: Coolant flows directly over the graphics chip, memory and voltage regulation module – not just the core. Addressable D-RGB lighting: Connects to a 3-pin 5V D-RGB header and works with the common motherboard sync technologies. Nickel-plated surface: The nickel plating protects the base material and provides an even, long-lasting appearance. Anodised aluminium: The anodised surface is more scratch-resistant than paint and keeps its colour over time. CNC-machined cold plate: The electrolytic copper base ensures rapid heat transfer. Silver Special Edition version: Matches fittings and components with the same finish. Technical Specifications TypeEK Water Blocks EK-Quantum Vector FE RTX 3090 Ti D-RGB - Silver Special Edition ManufacturerEK Water Blocks Manufacturer P/N3831109896877 SeriesEK-Quantum Vector FinishSilver Special Edition Dimensions212.5 x 121.5 x 29 mm Cable Length500 mm ThreadG1/4" GPU PlatformNVIDIA GeForce ManufacturingMade in Slovenia – Europe Important notes Do not run together with aluminium components in the same loop – mixing different metals causes corrosion. Use coolants containing corrosion, scale and biological inhibitors to avoid damaging the nickel-plated surfaces. The factory backplate of the graphics card cannot be reused. Given the variety on the market, EK guarantees fit only for fittings from its own range.
Backplate für GPU-Wasserkühlung, für EK-Quantum Vector FTW3 RTX 3080/3090, aus POM Acetal, bietet erhöhte Stabilität, mit Wärmeleitpads, für aktive Kühlung des PCBs
EK-Quantum Vector FTW3 RTX 3080/3090 Active Backplate D-RGB - Acryl is a cutting-edge addition to the EK® Quantum Line. It is made to complement the existing EK-Quantum Vector FTW3 RTX 3080/3090 water blocks and actively cool the backside of all EVGA® GeForce RTX™ 3080 and 3090 FTW3 GPU. EK-Quantum Vector FTW3 RTX 3080/3090 Active BackplateThe EK-Quantum Vector FTW3 RTX 3080/3090 Active Backplate comes with a new terminal that replaces the stock terminal arriving with the Vector water block and links the water block and Vector Active Backplate into a single unit. This way, the whole enclosure requires only one inlet and one outlet, removing unnecessary additional tubing and reducing clutter. It is the ultimate aesthetic and performance solution that finds your GPU sandwiched between two water blocks, allowing maximum cooling. The Vector Active Backplate directly cools the PCB hotspots that are found on the backside of the GPU core and the VRM (voltage regulation module). On the RX 3090, the VRAM located on the backside is cooled, while the RTX 3080 gets cooling for the PCB located around the front-mounted VRAM. Cooling liquid is channeled over all these critical areas. These newly developed active backplates feature a fin array with 8 wide channels allowing for very low flow restriction. This in turn allows overall lower temperatures, while the active backplate gets more than sufficient surface area for heat transfer. The base of the active backplate is CNC-machined out of nickel-plated electrolytic copper, while its top is CNC-machined out of glass-like cast Acrylic. The rest of the backplate is made of nickel-plated aluminum and it does not come in contact with the liquid. These Vector Active Backplates also feature acrylic terminals that match the top cover. The watertight sealing is ensured by high-quality EPDM O-rings. D-RGB lighting on EK-Quantum Vector FTW3 RTX 3080/3090 Active Backplate D-RGB water blockThe aesthetic end-piece is housing the addressable D-RGB LED strip. This water block boasts a total of 8 individually addressable RGB LEDs, and it is compatible with popular RGB sync technologies from all major motherboard manufacturers. The arrow marking on the 3-pin D-RGB LED connector is to be aligned with the +5V marking on the D-RGB (addressable) header. Technical Specification Dimensions: (LxHxW) - 303x151x37.8mm D-RGB cable length: 500mm D-RGB LED count: 8 D-RGB connector standard 3-pin (+5V, Data, Blocked, Ground) Enclosed EK-Quantum Vector FTW3 RTX 3080/3090 Active Backplate D-RGB - Acryl Necessary mounting screws, nuts, and washers 1x Nickel plated brass plug G1/4” EK-Loop Multi Allen Key (6mm, 8mm, 9mm) Thermal pads Warning: EK only guarantees compatibility with included EK-brand thermal pads. Installation process, cooling performance and block contacts are tested exclusively with EK-brand thermal pads. Listed thermal pad thicknesses apply only to EK thermal pads which are included in the package. EK does not guarantee compatibility with aftermarket alternatives for thermal interface material.
The EK-Quantum Vector FTW3 RTX 3080/3090 backplate is intended for the EK-Quantum Vector FTW3 RTX 3080/3090 graphics card cooler of the same name. A backplate is particularly suitable for giving the graphics card more stability. As the backplate is kept very simple, it is rounded off by a small but elegant EK logo. Technical Data Material: Nickel-Plated Aluminium Color: Nickel Scope of Delivery EK-Quantum Vector FTW3 RTX 3080/3090 Backplate - Nickel Mounting mechanism (the backplate screws are on the other side - separate compartment) Thermal pads
EK-Quantum Vector RE RTX 3080/3090 Active Backplate - Acetal is a cutting-edge addition to the EK® Quantum Line. It is made to complement the existing EK-Quantum Vector RE RTX 3080/3090 water blocks and actively cool the backside of a reference design NVIDIA® GeForce RTX™ 3080 and 3090 GPU. EK-Quantum Vector RE RTX 3080/3090 Active BackplateEK-Quantum Vector RE RTX 3080/3090 active backplate links the water block and the active backplate part with a new terminal, which replaces the stock terminal coming with your water block. This way the whole enclosure requires only one inlet and one outlet, removing any unneeded additional tubing and reducing clutter. It is the ultimate aesthetic and performance solution that finds your GPU sandwiched between two water blocks allowing maximum cooling. The Vector Active Backplate directly cools the PCB hotspots that are found on the backside of the GPU core and the VRM (voltage regulation module). On the RX 3090, the VRAM located on the backside is cooled, while the RTX 3080 gets cooling for the PCB located around the front-mounted VRAM. Cooling liquid is channeled over all these critical areas. These newly developed active backplates feature a fin array with 6 wide channels allowing for very low flow restriction. This in turn allows overall lower temperatures, while the active backplate gets more than sufficient surface area for heat transfer. The base of this stealthy active backplate is CNC-machined out of nickel-plated electrolytic copper, while its top is CNC-machined out of durable Black POM acetal. The rest of the backplate is made of anodized aluminum and it does not come in contact with the liquid. These Vector Active Backplates also feature acetal terminals that match the top cover. The watertight sealing is ensured by high-quality EPDM O-rings. Technical Specification: Dimensions: (LxHxW) - 223x124x15mm Enclosed: EK-Quantum Vector RE RTX 3080/3090 Active Backplate - Acetal Necessary mounting screws, nuts, and washers 1x Nickel plated brass plug G1/4” EK-Loop Multi Allen Key (6mm, 8mm, 9mm) Thermal pads Warning: EK only guarantees compatibility with included EK-brand thermal pads. Installation process, cooling performance and block contacts are tested exclusively with EK-brand thermal pads. Listed thermal pad thicknesses apply only to EK thermal pads which are included in the package. EK does not guarantee compatibility with aftermarket alternatives for thermal interface material.
EK-Quantum Vector RE RTX 3080/3090 Active Backplate D-RGB - Acryl is a cutting-edge addition to the EK® Quantum Line. It is made to complement the existing EK-Quantum Vector RE RTX 3080/3090 water blocks and actively cool the backside of a reference design NVIDIA® GeForce RTX™ 3080 and 3090 GPU. EK-Quantum Vector RE RTX 3080/3090 Active BackplateEK-Quantum Vector RE RTX 3080/3090 active backplate links the water block and the active backplate part with a new terminal, which replaces the stock terminal coming with your water block. This way the whole enclosure requires only one inlet and one outlet, removing any unneeded additional tubing and reducing clutter. It is the ultimate aesthetic and performance solution that finds your GPU sandwiched between two water blocks allowing maximum cooling. The Vector Active Backplate directly cools the PCB hotspots that are found on the backside of the GPU core and the VRM (voltage regulation module). On the RX 3090, the VRAM located on the backside is cooled, while the RTX 3080 gets cooling for the PCB located around the front-mounted VRAM. Cooling liquid is channeled over all these critical areas. These newly developed active backplates feature a fin array with 6 wide channels allowing for very low flow restriction. This in turn allows overall lower temperatures, while the active backplate gets more than sufficient surface area for heat transfer. The base of the active backplate is CNC-machined out of nickel-plated electrolytic copper, while its top is CNC-machined out of glass-like cast Acrylic. The rest of the backplate is made of nickel-plated aluminum and it does not come in contact with the liquid. These Vector Active Backplates also feature acrylic terminals that match the top cover. The watertight sealing is ensured by high-quality EPDM O-rings. D-RGB lighting on EK-Quantum Vector RE RTX 3080/3090 Active Backplate D-RGB water blockThe aesthetic end-piece is housing the addressable D-RGB LED strip. This water block boasts a total of 8 individually addressable RGB LEDs, and it is compatible with popular RGB sync technologies from all major motherboard manufacturers. The arrow marking on the 3-pin D-RGB LED connector is to be aligned with the +5V marking on the D-RGB (addressable) header. Technical Specification Dimensions: (LxHxW) - 223x124x15mm D-RGB cable length: 500mm D-RGB LED count: 8 D-RGB connector standard 3-pin (+5V, Data, Blocked, Ground) Enclosed EK-Quantum Vector RE RTX 3080/3090 Active Backplate D-RGB - Acryl Necessary mounting screws, nuts, and washers 1x Nickel plated brass plug G1/4” EK-Loop Multi Allen Key (6mm, 8mm, 9mm) Thermal pads Warning: EK only guarantees compatibility with included EK-brand thermal pads. Installation process, cooling performance and block contacts are tested exclusively with EK-brand thermal pads. Listed thermal pad thicknesses apply only to EK thermal pads which are included in the package. EK does not guarantee compatibility with aftermarket alternatives for thermal interface material.
EK-Quantum Vector RTX 3080/3090 Backplate - Black is a CNC-milled backplate made of black anodised aluminium that fits all EK-Quantum Vector RTX 3080/3090 water blocks. The backplate covers the full length of the graphics card PCB, serves as an aesthetic addition and also provides passive cooling for the back of the voltage regulator module (VRM), the GPU core and the VRAM on the 3090 cards. Enclosed: EK-Quantum Vector RTX 3080/3090 rear panel - Black Assembly mechanism Thermal pads
EK Water Blocks EK-Quantum Vector Strix RTX 3080/3090 Active Backplate D-RGB - Acrylic – Active, water-cooled backplate for EK-Quantum Vector water blocks EK Water Blocks EK-Quantum Vector Strix RTX 3080/3090 Active Backplate D-RGB - Acrylic is an active backplate that does not just cover the back of the graphics card but is connected directly to the custom loop. Together with the matching EK-Quantum Vector water block, it actively cools the back of the PCB and the components located there. The cold plate is CNC-machined from nickel-plated electrolytic copper, while the top is made of transparent acrylic. The dimensions are - 281x154x33 mm. Lighting is provided by 8 addressable D-RGB LEDs, connected via a 500 mm cable. Key Features Addressable D-RGB lighting: Connects to a 3-pin 5V D-RGB header and works with the common motherboard sync technologies. Nickel-plated surface: The nickel plating protects the base material and provides an even, long-lasting appearance. Transparent acrylic top: The clear top reveals the coolant inside and showcases the lighting. EPDM gasket: The internal EPDM gasket grips the tube and keeps the connection permanently sealed. Check compatibility: EK recommends checking the exact fit for your graphics card in the EK Cooling Configurator beforehand. Active liquid cooling of the backside: The backplate is plumbed into the loop and cools the back of the PCB with coolant. Used only together with the water block: The active backplate is exclusively used in combination with the corresponding GPU water block. Technical Specifications TypeEK Water Blocks EK-Quantum Vector Strix RTX 3080/3090 Active Backplate D-RGB - Acrylic ManufacturerEK Water Blocks Manufacturer P/N3831109836538 SeriesEK-Quantum Vector FinishAcrylic Dimensions- 281x154x33 mm Cable Length500 mm D-RGB LEDs8 ThreadG1/4" GPU PlatformNVIDIA GeForce ManufacturingMade in Slovenia – Europe Scope of Delivery EK-Quantum Vector Strix RTX 3080/3090 Active Backplate D-RGB - Plexi All necessary mounting screws, nuts and washers EK-Loop Multi Allen Key (6 mm, 8 mm, 9 mm) Thermal pads Important notes Do not run together with aluminium components in the same loop – mixing different metals causes corrosion. Use coolants containing corrosion, scale and biological inhibitors to avoid damaging the nickel-plated surfaces. Given the variety on the market, EK guarantees fit only for fittings from its own range. With EK Water Blocks EK-Quantum Vector Strix RTX 3080/3090 Active Backplate D-RGB - Acrylic you extend your GPU water block with an actively cooled backplate in Acrylic.
EK-Quantum Vector Strix RTX 3080/3090 Backplate - Nickel is a CNC-milled backplate made of nickel-plated aluminium that fits all EK-Quantum Vector Strix RTX 3070/3080/3090 water blocks. The backplate covers the full length of the graphics card PCB, serves as an aesthetic addition and also provides passive cooling for the back of the voltage regulator module (VRM), the GPU core and the VRAM on the 3090 cards. Enclosed: EK-Quantum Vector Strix RTX 3070/3080/3090 back plate - nickel Assembly mechanism Thermal pads
EK-Quantum Vector Strix RTX 3080/3090 Backplate - Black is a CNC-milled backplate made of black anodised aluminium that fits all EK-Quantum Vector Strix RTX 3080/3090 water blocks. The backplate covers the full length of the graphics card PCB, serves as an aesthetic addition and also provides passive cooling for the back of the voltage regulator module (VRM), the GPU core and the VRAM on the 3090 cards. Enclosed: EK-Quantum Vector Strix RTX 3070/3080/3090 back plate - Black Assembly mechanism Thermal pads
EK Water Blocks EK-Quantum Vector Trinity RTX 3080/3090 Active Backplate - Acetal: Active, Water-Cooled Backplate for Additional Cooling Performance EK-Quantum Vector Trinity RTX 3080/3090 Active Backplate - Acetal is designed for graphics cards of the Trinity RTX 3080/3090 Active Backplate series. Unlike a passive backplate, the active backplate has coolant flowing directly through it, measurably contributing to the cooling of rear-mounted components. Key Features: Nickel-Plated Copper Cold Plate: Ensures efficient heat transfer from the GPU and memory chips. Acetal Components: Combine an appealing look with high-quality workmanship. Addressable D-RGB Lighting: Individually controllable lighting for a cohesive look in the loop. G1/4" Ports: Compatible with all common water cooling components with a standard G1/4" port. Technical Specifications: Type: EK-Quantum Vector Trinity RTX 3080/3090 Active Backplate - Acetal Compatibility: Trinity RTX 3080/3090 Active Backplate Material: Acetal Ports: G1/4" Ideal for: EK-Quantum Vector Trinity RTX 3080/3090 Active Backplate - Acetal is ideal for: owners of a compatible Trinity RTX 3080/3090 Active Backplate graphics card switching to water cooling users seeking maximum cooling performance with minimal noise With EK-Quantum Vector Trinity RTX 3080/3090 Active Backplate - Acetal, you get a high-quality cooling solution for your Trinity RTX 3080/3090 Active Backplate graphics card.
EK-Quantum Vector Trinity RTX 3080/3090 Active Backplate D-RGB - Acryl is a cutting-edge addition to the EK® Quantum Line. It is made to complement the existing EK-Quantum Vector Trinity RTX 3080/3090 water blocks and actively cool the backside of all ZOTAC® GeForce RTX™ 3080 and 3090 Trinity GPU. EK-Quantum Vector Trinity RTX 3080/3090 Active BackplateEK-Quantum Vector Trinity RTX 3080/3090 active backplate links the water block and the active backplate part with a new terminal, which replaces the stock terminal coming with your water block. This way the whole enclosure requires only one inlet and one outlet, removing any unneeded additional tubing and reducing clutter. It is the ultimate aesthetic and performance solution that finds your GPU sandwiched between two water blocks allowing maximum cooling. The Vector Active Backplate directly cools the PCB hotspots that are found on the backside of the GPU core and the VRM (voltage regulation module). On the RX 3090, the VRAM located on the backside is cooled, while the RTX 3080 gets cooling for the PCB located around the front-mounted VRAM. Cooling liquid is channeled over all these critical areas. These newly developed active backplates feature a fin array with 6 wide channels allowing for very low flow restriction. This in turn allows overall lower temperatures, while the active backplate gets more than sufficient surface area for heat transfer. The base of the active backplate is CNC-machined out of nickel-plated electrolytic copper, while its top is CNC-machined out of glass-like cast Acrylic. The rest of the backplate is made of nickel-plated aluminum and it does not come in contact with the liquid. These Vector Active Backplates also feature acrylic terminals that match the top cover. The watertight sealing is ensured by high-quality EPDM O-rings. D-RGB lighting on EK-Quantum Vector Trinity RTX 3080/3090 Active Backplate D-RGB water blockThe aesthetic end-piece is housing the addressable D-RGB LED strip. This water block boasts a total of 8 individually addressable RGB LEDs, and it is compatible with popular RGB sync technologies from all major motherboard manufacturers. The arrow marking on the 3-pin D-RGB LED connector is to be aligned with the +5V marking on the D-RGB (addressable) header. Technical Specification Dimensions: (LxHxW) - 231x124x15mm D-RGB cable length: 500mm D-RGB LED count: 8 D-RGB connector standard 3-pin (+5V, Data, Blocked, Ground) Enclosed EK-Quantum Vector Trinity RTX 3080/3090 Active Backplate D-RGB - Acryl Necessary mounting screws, nuts, and washers 1x Nickel plated brass plug G1/4” EK-Loop Multi Allen Key (6mm, 8mm, 9mm) Thermal pads Warning: EK only guarantees compatibility with included EK-brand thermal pads. Installation process, cooling performance and block contacts are tested exclusively with EK-brand thermal pads. Listed thermal pad thicknesses apply only to EK thermal pads which are included in the package. EK does not guarantee compatibility with aftermarket alternatives for thermal interface material.
EK Water Blocks EK-Quantum Vector Trinity RTX 3080/3090 Backplate - Black – CNC-machined backplate for EK-Quantum Vector water blocks EK Water Blocks EK-Quantum Vector Trinity RTX 3080/3090 Backplate - Black is a CNC-machined retention backplate made from anodised aluminium and designed for the matching EK-Quantum Vector water blocks. It covers the entire length of the graphics card PCB, acts as an aesthetic upgrade, and additionally provides passive cooling for the backside of the voltage regulation module (VRM) and the GPU core. The part is CNC-machined from anodised aluminium, which is more rigid and more scratch-resistant than painted plastic. Key Features GPU, VRAM and VRM in one block: Coolant flows directly over the graphics chip, memory and voltage regulation module – not just the core. Anodised aluminium: The anodised surface is more scratch-resistant than paint and keeps its colour over time. Passive additional cooling: Thermal pads transfer heat from the back of the PCB to the surrounding air. Full PCB coverage: Covering the entire length of the PCB protects the card mechanically and prevents sagging. Black finish: Matched to the water blocks and fittings of the same finish. Technical Specifications TypeEK Water Blocks EK-Quantum Vector Trinity RTX 3080/3090 Backplate - Black ManufacturerEK Water Blocks Manufacturer P/N3831109833087 SeriesEK-Quantum Vector FinishBlack ManufacturingMade in Slovenia – Europe Scope of Delivery EK-Quantum Vector Trinity RTX 3080/3090 Backplate - Black Mounting mechanism (the backplate screws are in a separate compartment) Thermal pads
EK Water Blocks EK-Quantum Vector Trinity RTX 3080/3090 Backplate - Nickel – CNC-machined backplate for EK-Quantum Vector water blocks EK Water Blocks EK-Quantum Vector Trinity RTX 3080/3090 Backplate - Nickel is a CNC-machined retention backplate made from anodised aluminium and designed for the matching EK-Quantum Vector water blocks. It covers the full length of the graphics card PCB, acts as an aesthetic upgrade, and additionally provides passive cooling for the backside of the voltage regulation module (VRM) and the GPU core. The part is CNC-machined from nickel-plated aluminium, which is more rigid and more scratch-resistant than painted plastic. Key Features GPU, VRAM and VRM in one block: Coolant flows directly over the graphics chip, memory and voltage regulation module – not just the core. Nickel-plated surface: The nickel plating protects the base material and provides an even, long-lasting appearance. CNC-machined aluminium backplate: Made from anodised aluminium for a rigid, durable construction. Passive additional cooling: Thermal pads transfer heat from the back of the PCB to the surrounding air. Full PCB coverage: Covering the entire length of the PCB protects the card mechanically and prevents sagging. Nickel finish: Matched to the water blocks and fittings of the same finish. Technical Specifications TypeEK Water Blocks EK-Quantum Vector Trinity RTX 3080/3090 Backplate - Nickel ManufacturerEK Water Blocks Manufacturer P/N3831109833094 SeriesEK-Quantum Vector FinishNickel ManufacturingMade in Slovenia – Europe Scope of Delivery EK-Quantum Vector Trinity RTX 3080/3090 Backplate - Nickel Mounting mechanism (the backplate screws are in a separate compartment) Thermal pads
EK-Quantum Vector TRIO RTX 3080/3090 Active Backplate - Acetal is a state-of-the-art addition to the EK® Quantum Line. It complements the existing EK-Quantum Vector TRIO RTX 3080/3090 water blocks and actively cools the back of all MSI® TRIO and SUPRIM GeForce RTX™ 3080 and 3090 GPUs. The EK-Quantum Vector TRIO RTX 3080/3090 Active Backplate comes with a new connector that replaces the stock connector on the Vector water block, connecting the water block and Vector Active Backplate into one unit. This way, the entire case only needs one inlet and one outlet, eliminating unnecessary extra tubing and reducing clutter. It is the ultimate aesthetic and performance solution where your GPU is sandwiched between two water blocks, allowing for maximum cooling. Technical specification: Dimensions: (LxHxW) - 307x153x38mm Scope of delivery: EK-Quantum Vector TRIO RTX 3080/3090 Active Backplate - Plexi Required mounting screws, nuts and washers 1x nickel-plated brass connector G1/4" EK-Loop Multi Allen key (6mm, 8mm, 9mm) Thermal Pads
The EK Water Blocks EK-Quantum Vector Trio RTX 3080/3090 Backplate - Black Backplate is made of aluminum. This ensures improved cooling. Technical specifications: Material: aluminum Color: Black Weight: Dimensions: 307.62 x 128 x 5.2mm Scope of delivery: EK Water Blocks EK-Quantum Vector Trio RTX 3080/3090 Backplate - Black
The EK Water Blocks EK-Quantum Vector Trio RTX 3080/3090 Backplate - Nickel Backplate is made of aluminum. This ensures improved cooling. Technical specifications: Material: aluminum Silver Weight: Dimensions: 307.62 x 128 x 5.2mm Scope of delivery: EK Water Blocks EK-Quantum Vector Trio RTX 3080/3090 Backplate - Nickel
EK-Quantum Vector XC3 RTX 3080/3090 Active Backplate - Acetal is a cutting-edge addition to the EK® Quantum Line. It is made to complement the existing EK-Quantum Vector XC3 RTX 3080/3090 water blocks and actively cool the backside of all EVGA® GeForce RTX™ 3080 and 3090 XC3 GPU. EK-Quantum Vector XC3 RTX 3080/3090 Active BackplateEK-Quantum Vector XC3 RTX 3080/3090 active backplate links the water block and the active backplate part with a new terminal, which replaces the stock terminal coming with your water block. This way the whole enclosure requires only one inlet and one outlet, removing any unneeded additional tubing and reducing clutter. It is the ultimate aesthetic and performance solution that finds your GPU sandwiched between two water blocks allowing maximum cooling. The Vector Active Backplate directly cools the PCB hotspots that are found on the backside of the GPU core and the VRM (voltage regulation module). On the RX 3090, the VRAM located on the backside is cooled, while the RTX 3080 gets cooling for the PCB located around the front-mounted VRAM. Cooling liquid is channeled over all these critical areas. These newly developed active backplates feature a fin array with 6 wide channels allowing for very low flow restriction. This in turn allows overall lower temperatures, while the active backplate gets more than sufficient surface area for heat transfer. The base of this stealthy active backplate is CNC-machined out of nickel-plated electrolytic copper, while its top is CNC-machined out of durable Black POM acetal. The rest of the backplate is made of anodized aluminum and it does not come in contact with the liquid. These Vector Active Backplates also feature acetal terminals that match the top cover. The watertight sealing is ensured by high-quality EPDM O-rings. Technical Specification Dimensions: (LxHxW) - 274x124x15mm Enclosed EK-Quantum Vector XC3 RTX 3080/3090 Active Backplate - Acetal Necessary mounting screws, nuts, and washers 1x Nickel plated brass plug G1/4” EK-Loop Multi Allen Key (6mm, 8mm, 9mm) Thermal pads Warning: EK only guarantees compatibility with included EK-brand thermal pads. Installation process, cooling performance and block contacts are tested exclusively with EK-brand thermal pads. Listed thermal pad thicknesses apply only to EK thermal pads which are included in the package. EK does not guarantee compatibility with aftermarket alternatives for thermal interface material.
EK-Quantum Vector XC3 RTX 3080/3090 Active Backplate D-RGB - Acryl is a cutting-edge addition to the EK® Quantum Line. It is made to complement the existing EK-Quantum Vector XC3 RTX 3080/3090 water blocks and actively cool the backside of all EVGA® GeForce RTX™ 3080 and 3090 XC3 GPU. EK-Quantum Vector XC3 RTX 3080/3090 Active BackplateEK-Quantum Vector XC3 RTX 3080/3090 active backplate links the water block and the active backplate part with a new terminal, which replaces the stock terminal coming with your water block. This way the whole enclosure requires only one inlet and one outlet, removing any unneeded additional tubing and reducing clutter. It is the ultimate aesthetic and performance solution that finds your GPU sandwiched between two water blocks allowing maximum cooling. The Vector Active Backplate directly cools the PCB hotspots that are found on the backside of the GPU core and the VRM (voltage regulation module). On the RX 3090, the VRAM located on the backside is cooled, while the RTX 3080 gets cooling for the PCB located around the front-mounted VRAM. Cooling liquid is channeled over all these critical areas. These newly developed active backplates feature a fin array with 6 wide channels allowing for very low flow restriction. This in turn allows overall lower temperatures, while the active backplate gets more than sufficient surface area for heat transfer. The base of the active backplate is CNC-machined out of nickel-plated electrolytic copper, while its top is CNC-machined out of glass-like cast Acrylic. The rest of the backplate is made of nickel-plated aluminum and it does not come in contact with the liquid. These Vector Active Backplates also feature acrylic terminals that match the top cover. The watertight sealing is ensured by high-quality EPDM O-rings. D-RGB lighting on EK-Quantum Vector XC3 RTX 3080/3090 Active Backplate D-RGB water blockThe aesthetic end-piece is housing the addressable D-RGB LED strip. This water block boasts a total of 8 individually addressable RGB LEDs, and it is compatible with popular RGB sync technologies from all major motherboard manufacturers. The arrow marking on the 3-pin D-RGB LED connector is to be aligned with the +5V marking on the D-RGB (addressable) header. Technical Specification: Dimensions: (LxHxW) - 274x124x15mm D-RGB cable length: 500mm D-RGB LED count: 8 D-RGB connector standard 3-pin (+5V, Data, Blocked, Ground) Enclosed: EK-Quantum Vector XC3 RTX 3080/3090 Active Backplate D-RGB - Acryl Necessary mounting screws, nuts, and washers 1x Nickel plated brass plug G1/4” EK-Loop Multi Allen Key (6mm, 8mm, 9mm) Thermal pads Warning: EK only guarantees compatibility with included EK-brand thermal pads. Installation process, cooling performance and block contacts are tested exclusively with EK-brand thermal pads. Listed thermal pad thicknesses apply only to EK thermal pads which are included in the package. EK does not guarantee compatibility with aftermarket alternatives for thermal interface material.
EK-Quantum Vector Xtreme RTX 3080/3090 Backplate - Black is a CNC machined retention backplate made from black anodized aluminum, that fits all EK-Quantum Vector Xtreme RTX 3080/3090 water blocks. The backplate covers the whole length of the graphics card's PCB, serves as an aesthetic add-on, and also provides passive cooling for the backside of the voltage regulation module (VRM), the GPU core, and rear-mounted VRAM on the 3090 cards. Enclosed EK-Quantum Vector Xtreme RTX 3080/3090 Backplate - Black Mounting mechanism (the backplate screws are on the other side - separate compartment)* Thermal pads
EK-Quantum Vector Xtreme RTX 3080/3090 Backplate - Nickel is a CNC machined retention backplate made from nickel-plated aluminum, that fits all EK-Quantum Vector Xtreme RTX 3080/3090 water blocks. The backplate covers the whole length of the graphics card's PCB, serves as an aesthetic add-on, and also provides passive cooling for the backside of the voltage regulation module (VRM), the GPU core, and rear-mounted VRAM on the 3090 cards. Enclosed EK-Quantum Vector Xtreme RTX 3080/3090 Backplate - Nickel Mounting mechanism (the backplate screws are on the other side - separate compartment)* Thermal pads
