The ZOTAC ZBOX CI649 nano is a compact Barebone computer designed for offices, workstations and other space-conscious environments. Its 1,8-liter case has a modern black/white design and a fanless, passively cooled construction, providing silent operation without sacrificing the performance of the Intel® Core™ i5-1335U processor. The installed Intel® Core™ i5-1335U processor uses the Raptor Lake architecture and offers 10 cores and 12 threads, with a boost clock of 4,6 GHz. The configuration includes 2 Performance cores with 4 threads and a boost clock of 4,6 GHz, plus 8 Efficiency cores with 8 threads and a boost clock of 3,4 GHz, making the system suitable for office applications, multitasking, web work and digital content playback. The computer provides 2 SO-DIMM memory slots for DDR5 RAM and supports up to 64 GB. DDR5 modules with 5200 and 4800 MHz are supported. The integrated Intel® Iris® Xe Graphics are available when the system is configured with dual-channel memory; with single-channel memory, only Intel® UHD Graphics functions are available. For storage expansion, the Barebone system has 1 M.2 slot for an SSD, 1 SATA 6 Gb/S interface and an internal 2,5" drive bay for an HDD or SSD. Memory, SSD or hard drive, CD/DVD drive and operating system are not included, allowing the configuration to be adapted to the intended use. The ZBOX nano supports wired networking through LAN 10/100/1000 MBit/s and 2,5-Gigabit LAN, as well as wireless connections through Wi-Fi 6 (802.11ax) and Bluetooth 5.2. Five USB ports and a Thunderbolt 4 port provide connectivity for peripherals and compatible accessories. HDMI, DisplayPort and the DisplayPort-enabled Thunderbolt 4 port allow connection of up to 3 displays, while Thunderbolt 4 supports DisplayPort 1.4 with a resolution of up to 4096x2160@60Hz. The device includes an SD, SDHC, SDXC card reader, microphone and headphone connections, and digital 8-channel audio through HDMI. The external 65 Watt power supply, VESA Mount compatibility and Kensington cable lock socket support flexible installation in offices and multimedia workspaces. The package includes a Wi-Fi antenna, AC adapter, power cable, quick installation guide, VESA Mount with 4 screws and a USB drive with O/S driver. Product type: Barebone Color: black/white EAN: 4895173627521 Manufacturer code: ZBOX-CI649NANO-BE Series: ZBOX nano Processor: Intel® Core™ i5-1335U Processor architecture: Raptor Lake Core and thread count: 10 cores / 12 threads Processor boost clock: 4,6 GHz Memory type: DDR5 Memory slots: 2 SO-DIMM slots Maximum memory: up to 64 GB Supported memory speeds: 5200 and 4800 MHz Graphics: Intel® Iris® Xe Graphics PCIe slot: 1x PCIe x4 (Version 4.0) Storage interfaces: 1x M.2, 1x SATA 6 Gb/S Internal drive bay: 2,5" Card reader: SD, SDHC, SDXC Wired networking: LAN 10/100/1000 MBit/s, LAN 2,5-Gigabit Wireless networking: Wi-Fi 6 (802.11ax) Bluetooth: Bluetooth 5.2 Display support: up to 3 displays Audio: 1x microphone, 1x headphone, digital 8-channel audio via HDMI Operating system: without operating system Cooling: fanless, passively cooled design Power supply: external, 65 Watt Case form factor: HTPC Case volume: 1,8-liter Dimensions: 204 mm width x 68 mm height x 129 mm depth/length Security: Kensington cable lock socket Mounting: VESA Mount Ready
