EK-Quantum Vector Strix RTX 3080/3090 Backplate - Black is a CNC-milled backplate made of black anodised aluminium that fits all EK-Quantum Vector Strix RTX 3080/3090 water blocks. The backplate covers the full length of the graphics card PCB, serves as an aesthetic addition and also provides passive cooling for the back of the voltage regulator module (VRM), the GPU core and the VRAM on the 3090 cards. Enclosed: EK-Quantum Vector Strix RTX 3070/3080/3090 back plate - Black Assembly mechanism Thermal pads
EK-Quantum Vector Trinity RTX 3080/3090 Active Backplate D-RGB - Acryl is a cutting-edge addition to the EK® Quantum Line. It is made to complement the existing EK-Quantum Vector Trinity RTX 3080/3090 water blocks and actively cool the backside of all ZOTAC® GeForce RTX™ 3080 and 3090 Trinity GPU. EK-Quantum Vector Trinity RTX 3080/3090 Active BackplateEK-Quantum Vector Trinity RTX 3080/3090 active backplate links the water block and the active backplate part with a new terminal, which replaces the stock terminal coming with your water block. This way the whole enclosure requires only one inlet and one outlet, removing any unneeded additional tubing and reducing clutter. It is the ultimate aesthetic and performance solution that finds your GPU sandwiched between two water blocks allowing maximum cooling. The Vector Active Backplate directly cools the PCB hotspots that are found on the backside of the GPU core and the VRM (voltage regulation module). On the RX 3090, the VRAM located on the backside is cooled, while the RTX 3080 gets cooling for the PCB located around the front-mounted VRAM. Cooling liquid is channeled over all these critical areas. These newly developed active backplates feature a fin array with 6 wide channels allowing for very low flow restriction. This in turn allows overall lower temperatures, while the active backplate gets more than sufficient surface area for heat transfer. The base of the active backplate is CNC-machined out of nickel-plated electrolytic copper, while its top is CNC-machined out of glass-like cast Acrylic. The rest of the backplate is made of nickel-plated aluminum and it does not come in contact with the liquid. These Vector Active Backplates also feature acrylic terminals that match the top cover. The watertight sealing is ensured by high-quality EPDM O-rings. D-RGB lighting on EK-Quantum Vector Trinity RTX 3080/3090 Active Backplate D-RGB water blockThe aesthetic end-piece is housing the addressable D-RGB LED strip. This water block boasts a total of 8 individually addressable RGB LEDs, and it is compatible with popular RGB sync technologies from all major motherboard manufacturers. The arrow marking on the 3-pin D-RGB LED connector is to be aligned with the +5V marking on the D-RGB (addressable) header. Technical Specification Dimensions: (LxHxW) - 231x124x15mm D-RGB cable length: 500mm D-RGB LED count: 8 D-RGB connector standard 3-pin (+5V, Data, Blocked, Ground) Enclosed EK-Quantum Vector Trinity RTX 3080/3090 Active Backplate D-RGB - Acryl Necessary mounting screws, nuts, and washers 1x Nickel plated brass plug G1/4” EK-Loop Multi Allen Key (6mm, 8mm, 9mm) Thermal pads Warning: EK only guarantees compatibility with included EK-brand thermal pads. Installation process, cooling performance and block contacts are tested exclusively with EK-brand thermal pads. Listed thermal pad thicknesses apply only to EK thermal pads which are included in the package. EK does not guarantee compatibility with aftermarket alternatives for thermal interface material.
The EK Water Blocks EK-Quantum Vector Trio RTX 3080/3090 Backplate - Black Backplate is made of aluminum. This ensures improved cooling. Technical specifications: Material: aluminum Color: Black Weight: Dimensions: 307.62 x 128 x 5.2mm Scope of delivery: EK Water Blocks EK-Quantum Vector Trio RTX 3080/3090 Backplate - Black
The EK Water Blocks EK-Quantum Vector Trio RTX 3080/3090 Backplate - Nickel Backplate is made of aluminum. This ensures improved cooling. Technical specifications: Material: aluminum Silver Weight: Dimensions: 307.62 x 128 x 5.2mm Scope of delivery: EK Water Blocks EK-Quantum Vector Trio RTX 3080/3090 Backplate - Nickel
EK-Quantum Vector XC3 RTX 3080/3090 Active Backplate - Acetal is a cutting-edge addition to the EK® Quantum Line. It is made to complement the existing EK-Quantum Vector XC3 RTX 3080/3090 water blocks and actively cool the backside of all EVGA® GeForce RTX™ 3080 and 3090 XC3 GPU. EK-Quantum Vector XC3 RTX 3080/3090 Active BackplateEK-Quantum Vector XC3 RTX 3080/3090 active backplate links the water block and the active backplate part with a new terminal, which replaces the stock terminal coming with your water block. This way the whole enclosure requires only one inlet and one outlet, removing any unneeded additional tubing and reducing clutter. It is the ultimate aesthetic and performance solution that finds your GPU sandwiched between two water blocks allowing maximum cooling. The Vector Active Backplate directly cools the PCB hotspots that are found on the backside of the GPU core and the VRM (voltage regulation module). On the RX 3090, the VRAM located on the backside is cooled, while the RTX 3080 gets cooling for the PCB located around the front-mounted VRAM. Cooling liquid is channeled over all these critical areas. These newly developed active backplates feature a fin array with 6 wide channels allowing for very low flow restriction. This in turn allows overall lower temperatures, while the active backplate gets more than sufficient surface area for heat transfer. The base of this stealthy active backplate is CNC-machined out of nickel-plated electrolytic copper, while its top is CNC-machined out of durable Black POM acetal. The rest of the backplate is made of anodized aluminum and it does not come in contact with the liquid. These Vector Active Backplates also feature acetal terminals that match the top cover. The watertight sealing is ensured by high-quality EPDM O-rings. Technical Specification Dimensions: (LxHxW) - 274x124x15mm Enclosed EK-Quantum Vector XC3 RTX 3080/3090 Active Backplate - Acetal Necessary mounting screws, nuts, and washers 1x Nickel plated brass plug G1/4” EK-Loop Multi Allen Key (6mm, 8mm, 9mm) Thermal pads Warning: EK only guarantees compatibility with included EK-brand thermal pads. Installation process, cooling performance and block contacts are tested exclusively with EK-brand thermal pads. Listed thermal pad thicknesses apply only to EK thermal pads which are included in the package. EK does not guarantee compatibility with aftermarket alternatives for thermal interface material.
EK-Quantum Vector Xtreme RTX 3080/3090 Backplate - Nickel is a CNC machined retention backplate made from nickel-plated aluminum, that fits all EK-Quantum Vector Xtreme RTX 3080/3090 water blocks. The backplate covers the whole length of the graphics card's PCB, serves as an aesthetic add-on, and also provides passive cooling for the backside of the voltage regulation module (VRM), the GPU core, and rear-mounted VRAM on the 3090 cards. Enclosed EK-Quantum Vector Xtreme RTX 3080/3090 Backplate - Nickel Mounting mechanism (the backplate screws are on the other side - separate compartment)* Thermal pads
This is the 2nd generation Vector GPU water block from the EK® Quantum Line, designed for AORUS® Xtreme and Master RTX 3080 and 3090 graphics cards based on the latest NVIDIA® Ampere™ architecture. An EK water block for Xtreme and Master RTX 3080 and 3090EK-Quantum Vector Xtreme 3080/3090 D-RGB - Nickel + Acetal water block is compatible with Aorus Xtreme and Master RTX 3080 and RTX 3090 graphics cards. The Vector water block actively cools the GPU, VRAM (on the front), power stages, and chokes in the VRM (voltage regulation module). These newly developed water blocks feature optimized flow paths that reduce hydrodynamic instabilities and vortexing (dead spots) inside of them. The EK-Quantum Vector Series water blocks use an Open Split-Flow cooling engine design, which proved to be a superior solution for GPU water blocks. It is characterized by low hydraulic flow restriction, meaning it can be used with weaker water pumps or pumps running on low-speed settings, and still achieve top performance. The jet plate and fin structure geometry have been optimized to provide even flow distribution with minimal losses and optimal performance when used in any given coolant flow orientation. The base of the block is CNC-machined out of nickel-plated high-grade copper, while its top is CNC-machined out of durable black POM Acetal. These 2nd generation Vector GPU water blocks also feature Acetal terminals. The watertight sealing is ensured by high-quality EPDM O-rings, while brass standoffs are already pre-installed and allow for a safe and easy installation procedure. D-RGB lighting on EK-Quantum Vector Xtreme RTX 3080/3090 D-RGB water blockThe aesthetic corner end-piece is housing the addressable D-RGB LEDs. This water block boasts a total of 8 individually addressable RGB LEDs, and it is compatible with popular RGB sync technologies from all major motherboard manufacturers. The arrow marking on the 3-pin D-RGB LED connector is to be aligned with the +5V marking on the D-RGB (addressable) header. Backplate for the EK-Quantum Vector Xtreme 3080/3090 water blockEK recommends the purchase of a retention backplate, especially for the 3090 models of graphics cards. The backplate improves the overall aesthetics of your graphics cards and also provides additional passive cooling for the GPU core, VRAM on the 3090 cards, and backside of the printed circuit board VRM section. Technical Specification Dimensions: (LxHxW) - 295x150.5x20.5mm Enclosed EK-Quantum Vector Xtreme RTX 3080/3090 D-RGB series high-performance water block Mounting mechanism with screw-in brass standoffs Necessary mounting screws, nuts, and washers 2x Nickel plated brass plug G1/4” EK-Loop Multi Allen Key (6mm, 8mm, 9mm) Thermal pads Thermal grease EK-TIM Ectotherm (1g)
Full-Cover-Waterblock von EK Water Blocks, für ROG Strix und ASUS TUF RTX 3090 Ti, vernickelter Kupferboden, Acryl-Deckel, adressierbare RGB-Beleuchtung
Backplate mit aktiver Kühlung von EK Water Blocks, für MSI Trio und Suprim 3080 / 3080 Ti und 3090, vernickelter Kupferboden, Acetal-Deckel, adressierbare RGB-Beleuchtung
Backplate mit aktiver Kühlung von EK Water Blocks, für EVGA XC3 RTX 3080 / 3080 Ti und 3090, vernickelter Kupferboden, Acetal-Deckel, adressierbare RGB-Beleuchtung
Backplate mit aktiver Kühlung von EK Water Blocks, für EVGA XC3 RTX 3080 / 3080 Ti und 3090, vernickelter Kupferboden, Acryl-Deckel, adressierbare RGB-Beleuchtung
Kühlblock und Backplate mit aktiver Kühlung von EK Water Blocks, für EVGA XC3 RTX 3080 / 3080 Ti und 3090, vernickelter Kupferboden, Acetal-Deckel, adressierbare RGB-Beleuchtung
Kühlblock und Backplate mit aktiver Kühlung von EK Water Blocks, für EVGA XC3 RTX 3080 / 3080 Ti und 3090, vernickelter Kupferboden, Acryl-Deckel, adressierbare RGB-Beleuchtung
Full-Cover-Waterblock von EK Water Blocks, für EVGA XC3 RTX 3080 / 3080 Ti und 3090, vernickelter Kupferboden, Acetal-Deckel, adressierbare RGB-Beleuchtung
Full-Cover-Waterblock von EK Water Blocks, für EVGA XC3 RTX 3080 / 3080 Ti und 3090, vernickelter Kupferboden, Acryl-Deckel, adressierbare RGB-Beleuchtung
Full-Block-Wasserkühler von EK Water Blocks, für RTX 3080 und 3090-Grafikkarten im Referenz-Design, schwarzer Acetal-Deckel, Kühlkörper aus hochreinem Kupfer
