A special version of the Acar S8 dedicated to rack cabinet 19".Acar S8 protects against overvoltage up to 8 devices installed in the rack cabinet. The ACAR-S8/FA/RACK has the power switch with light indicator built-in, which inform about the power voltage in outlets. Fuses protect against any short-circuits and power surges. It is equipped with black housing designed to mount in RACK 19" cabinets. Power charge 10A.

Pikendusjuhe ACAR S8 FA Rack 3m

<p>Description:</p><p>A special version of the Acar S8 dedicated to rack cabinet 19".<br />Acar S8 protects against overvoltage up to 8 devices installed in the rack cabinet. The ACAR-S8/FA/RACK has the power switch with light indicator built-in, which inform about the power voltage in outlets. Fuses protect against any short-circuits and power surges. It is equipped with black housing designed to mount in RACK 19" cabinets. <br />Power charge 10A.</p><p>Dimensions:</p><p>445 x 54 x 55mm</p><p>Other features:</p><p>- Rated voltage of the device 230 V<br />- Rated frequency 50Hz<br />- Rated current load ΣIN = 10 A<br />- 1 circuit breaker 10A / 250V<br />- Leakage current &lt;0.5 mA; The response time of the surge protector &lt;25ns<br />- Rated voltage of the surge protector 250V 50Hz UC<br />- The level of UP protection ≤1,3kV (L / N)<br />- Nominal discharge current iN 2kA (L / N) - 8 / 20μs<br />- Maximum discharge current iMAX 6,5kA (L / N) - 8 / 20μs<br />- Protection against electric shock: protective pins connected to the grounded conductor (2P+Z)<br />- Housing made of self-extinguishing plastic<br />- 8 bipolar electrical sockets with protective contact 10A / 250V</p><p>Designation:</p>CE+WEEE
