10mm barb fitting made from nickel-coated brass with O-ring for PVC, PU ,PA, silicone or PE hoses with an inner diameter of 10mm. G1/4" outer threads. threads straight, SW 14. Note for watercooling beginners:The connectors for imperial hoses(7/16“, 3/8“, ½“) are provided with measurements in mm in our shop. These can differ by +-1mm, which is no problem as hose clamps have to be used for installation. If the hose is to be mounted without a clamp, a larger fitting should be chosen. With some fittings that tend to be larger, it is possible though that a hose with an inner diameter of 13mm actually does seal without a hose clamp. Overview:10mm (3/8“) hose clamp: up to 8mm none, from 10mm up required10mm (7/16“) hose clamp: up to 8mm none, from 10mm up required12mm (1/2“) hose clamp: up to 11mm none, from 12mm up required13mm (1/2“) hose clamp: up to 11mm none, from 13mm up required
Hochwertiger Schlauch aus Polyurethan (PUR) passend zu den Steckverbindern. Relativ enge Biegeradien sind möglich bei gleichzeitig guter Festigkeit. Dieser Schlauch wurde extra für Wasserkühlungen entwickelt, und speziell den Anforderungen angepasst. Farbe: glasklar Abmaße: Außendurchmesser: 8mm, Innendurchmesser 5,5mm Preis je Meter, Lieferung am Stück, Bestellmenge = Schlauchlänge in Metern.
Produktbeschreibung:Doppelnippel von G3/8" Aussengewinde auf G1/4" Innengewinde. Technische Daten:Höhe 19mm. Hinweis: Um diese Adapter 100%ig dicht zu bekommen empfehlen wir ihnen die verlinkte Dichtung. Dieses Produkt wurde für Sie getestet:OCReviews
This nipple can be used to connect two G1/4 inch threads together. Delivery includes O-rings Technical data Connecting element with 2x G1/4 external thread Material: nickel-plated brass Inner diameter: 8mm Total length: 19mm Inner length without thread: 7mm scope of delivery 1x double nipple G1/4 AG to G1/4 AG
Product description: L-connector with 1x G1/4 inch internal thread and 2x G1/4 inch external thread Technical data: Material: nickel-plated brass Dimensions: Upper T length: 50mm Left & bottom thread: 12mm Right internal thread: 15mm Height: 31mm Note: To make these adapters 100% leak-proof, we recommend using Phobya thread sealing tape.
Our trusted fittings are available in a whole new design! Robust high-quality reducing socket from G1/4" inner thread to G3/8" outer thread. Technical details: Material: Brass, black nickel coated Thread size: 1/4" inner thread to 3/8" outer thread Extent of delivery: Reducing socket
Double nipple for connecting 2x 1/4 inch internal threads. This double nipple can be used to connect different adapters to each other, for example. It can also be used to connect certain coolers together. This double nipple has an O-ring on both sides and therefore offers optimal security for your system. Since the thread length including the seal is only 4mm, this increases the area of application even further. The gap of just 3mm is edged and is therefore very suitable for assembly without tools. Technical details: Material: nickel-plated brass Total length: 11.5mm Thread length: 4mm Spacer: 3mm Scope of delivery: 1x double nipple G1/4 AG to G1/4 AG with O-ring - black nickel
This extension (G1/4" outer thread to G1/4" inner thread can be used to extend connection threads and therefore allows easier use of angled fittings. E.g. the output hose can therefore be mounted in the same direction as the hose for the Input as the fitting are at different heights. Color: Silver nickel coated Height without thread: 10,1mm Thread length: 4mm Extent of delivery: Extension G1/4" to G1/4" knured - silver nickel Please note: This knurled extesion is shipped with a seal
This different approach to thread manifolds offers even more possibilities in your system! Especially in smaller cases, systems with many waterblocks or other special applications space is often not sufficient to simply run the tubing in radiuses. Normal angled connectors also have the advantage to reduce flow. This is when this fitting option comes into play: Not narrowed internally this manifold offers great advantages especially when using High-Flow fittings. The cubic design also allows easy installation and fixation inside of the case. The thread depth of more than 8mm allows any fitting to be used without the use of spacer rings or special thread lengths. Technical specifications: Material: Silver nickel plated brassDimensions: (L x W x H): 30 x 21x 21mmThread size: 1/4"Number of threads: 3Thread depth: 8mmExtent of delivery: 1x Thread connector brass T-piece G1/4" MSV
This different approach to thread manifolds offers even more possibilities in your system! Especially in smaller cases, systems with many waterblocks or other special applications space is often not sufficient to simply run the tubing in radiuses. Normal angled connectors also have the advantage to reduce flow. This is when this fitting option comes into play: Not narrowed internally this manifold offers great advantages especially when using High-Flow fittings. The cubic design also allows easy installation and fixation inside of the case. The thread depth of more than 8mm allows any fitting to be used without the use of spacer rings or special thread lengths. Technical specifications: Material: Black nickel plated brassDimensions: (L x W x H): 30 x 21x 21mmThread size: 1/4"Number of threads: 3Thread depth: 8mmExtent of delivery: 1x Thread connector brass T-piece G1/4" MSV - black nickel
This G1/4" extension (male to female) allows an extension of a G1/4" thread which e.g. allows more universal application of angled fittings. When using this extension and angled fittings the tubing can be installed parallely as the threads are at different levels. Technical specifications: Colour: Silver nickel Threads: 1/4" outer thread to 1/4" inner thread Thread length: 4mm Length: 20mm Extent of delivery: 1x Phobya extension G1/4" to G1/4" revolvable - silver nickel plated
Connection element with G1/4" inner threads on both sides for endless application. Technical specifications: Inner thread G1/4" to inner thread G1/4" Material: Black nickel plated brass Length: 16,5mm Diameter: 17mm Extent of delivery: 1x Bushing G1/4 to G1/4" knurled
Our trusted fittings are available in a whole new design! Robust high-quality connector piece with three G1/4" inner threads. Technical specifications: Material: Brass, silvernickel coated Thread size: 3x 1/4" inner thread Extent of delivery: 1x Angled G1/4" connector piece 3x G1/4" inner threads Note: To ensure a perfect seal we recommend the use of Phobya thread sealing tape.
Our trusted fittings are available in a whole new design! Robust high-quality connector piece with three G1/4" inner threads. Technical specifications: Material: Brass, black nickel coated Thread size: 3x 1/4" inner thread Extent of delivery: 1x Angled G1/4" connector piece 3x G1/4" inner threads Note: To ensure a perfect seal we recommend the use of Phobya thread sealing tape.
This G1/4" extension can be used to extend a thread further out. This makes it possible to use angled connectors more versatile and offers many more possibilities! Technical specifications: Colour: Silver nickel Length: 20mm This adaptor is shipped with a seal!
This G1/4" extension can be used to extend a thread further out. This makes it possible to use angled connectors more versatile and offers many more possibilities! Technical specifications: Colour: Black nickel Length: 25mm This adaptor is shipped with a seal!
The extension with G1/4" inner thread and G1/4" outer thread can be used to extend a connection thread and allows more versatile use of angled fittings. With this extension it is possible to place angled fittings at different levels, allowing tubing to run in the same direction without blocking each other. Technical specifications: Material: Brass (matte black) Dimensions: 50x18,1mm Thread length: 4mm Extent of delivery: 1x Extension G1/4 to G1/4 50mm - knurled - matte black
Mit diesem günstigen Schlauchverbinder können Sie Systeme mit unterschiedlichen Innendurchmessern verbinden. Sie brauchen keinen Kabelbinder oder Schlauchschellen, der Schlauch dichtet auch so ab. Material: Polyamid, weiß Anschluss: 8/6mm auf 10/8mm (Di = 6mm auf Di = 8mm)>
8mm hose nozzle made of nickel-plated brass with O-ring for 10mm PVC, PU, PA, silicone or PE hoses with 7mm-9mm inner diameter. G1/4" external thread. Height 35.5mm. Connection inner diameter: 6.6mm Note for water cooling newbies: The connections for inch hoses (7/16", 3/8", ½") are provided with a mm specification in our shop. This can deviate by +-1mm, which is not a problem, as a hose clamp is required for assembly. If you want to install the hose without a hose clamp, you have to choose a larger connection. With some connections that tend to deviate upwards, it may also be possible that, for example, a 13mm connection actually seals on a hose with an inner diameter of 13mm without a hose clamp. Overview: 10mm (3/8") hose clamp: none up to 8mm, required from 10mm 10mm (7/16") hose clamp: none up to 8mm, required from 10mm 12mm (1/2") hose clamp: none up to 11mm, required from 12mm 13mm (1/2“) hose clamp: up to 11mm none, from 13mm required>
High-Flow barb fittings for hoses with an inner diameter of 11-13mm. Technical data:Thread: G1/4Overall length: 29mmInner diameter of hose: 11 bis 13mmInner diameter of fitting: 10mm Thread length: 8mm Note for watercooling beginners:The connectors for imperial hoses(7/16", 3/8", ½") are provided with measurements in mm in our shop. These can differ by +-1mm, which is no problem as hose clamps have to be used for installation. If the hose is to be mounted without a clamp, a larger fitting should be chosen. With some fittings that tend to be larger, it is possible though that a hose with an inner diameter of 13mm actually does seal without a hose clamp. Overview:10mm (3/8") hose clamp: up to 8mm none, from 10mm up required10mm (7/16") hose clamp: up to 8mm none, from 10mm up required12mm (1/2") hose clamp: up to 11mm none, from 12mm up required13mm (1/2") hose clamp: up to 11mm none, from 13mm up required
13mm barb fitting made from nickel coated brass with O-ring seal for PVC, PU, PA, silicone or PE hoses with an inner diameter of 11-13mm. G3/8" outer thread. The hose must be fixated with a zip tie or hose clamp. Inner diameter of fitting: 10mm. Note for watercooling beginners:The connectors for imperial hoses(7/16", 3/8", ½") are provided with measurements in mm in our shop. These can differ by +-1mm, which is no problem as hose clamps have to be used for installation. If the hose is to be mounted without a clamp, a larger fitting should be chosen. With some fittings that tend to be larger, it is possible though that a hose with an inner diameter of 13mm actually does seal without a hose clamp. Overview:10mm (3/8") hose clamp: up to 8mm none, from 10mm up required10mm (7/16") hose clamp: up to 8mm none, from 10mm up required12mm (1/2") hose clamp: up to 11mm none, from 12mm up required13mm (1/2") hose clamp: up to 11mm none, from 13mm up required
13mm barbed fitting made from nickel coated brass with O-ring seal for hoses with an inner diameter of 11-13mm . Inner diameter of connector: 13mm This hose connector was specially designed for Highflow systems. Note: For safety reasons we recommend the use of zip ties or hose clamps for additional hose fixation. Note for watercooling beginners:The connectors for imperial hoses(7/16", 3/8", ½") are provided with measurements in mm in our shop. These can differ by +-1mm, which is no problem as hose clamps have to be used for installation. If the hose is to be mounted without a clamp, a larger fitting should be chosen. With some fittings that tend to be larger, it is possible though that a hose with an inner diameter of 13mm actually does seal without a hose clamp. Overview:10mm (3/8") hose clamp: up to 8mm none, from 10mm up required10mm (7/16") hose clamp: up to 8mm none, from 10mm up required12mm (1/2") hose clamp: up to 11mm none, from 12mm up required13mm (1/2") hose clamp: up to 11mm none, from 13mm up required
High-flow barbed fitting for hoses with an inner diameter of 11mm to 13mm. This fitting was specially designed for High-flow systems. Technical data: Thread: 3/8" Compatible to hoses with an inner diameter of 11mm to 13mm Note for watercooling beginners:The connectors for imperial hoses(7/16", 3/8", ½") are provided with measurements in mm in our shop. These can differ by +-1mm, which is no problem as hose clamps have to be used for installation. If the hose is to be mounted without a clamp, a larger fitting should be chosen. With some fittings that tend to be larger, it is possible though that a hose with an inner diameter of 13mm actually does seal without a hose clamp. Overview:10mm (3/8") hose clamp: up to 8mm none, from 10mm up required10mm (7/16") hose clamp: up to 8mm none, from 10mm up required12mm (1/2") hose clamp: up to 11mm none, from 12mm up required13mm (1/2") hose clamp: up to 11mm none, from 13mm up required
Our trusted fittings are available in a whole new design! Robust high-quality barbed fitting with cylindrical thread (G3/8"). The fitting is suitable for PVC, OU, PA, silicone and PE hoses with an inner diameter of 13mm. With integrated 3/8" Perbunan(r) O-Ring seal. Technical details: Material: Brass, black nickel coated Hose size: 13 mm inner diameter Thread size: G3/8" Extent of delivery: Black nickel barbed fitting with O-ring seal Note for watercooling beginners: The connectors for hoses(7/16", 3/8",1/2") are provided with measurements in mm in our shop. These can differ by +-1mm, which is no problem as hose clamps have to be used for installation. If the hose is to be mounted without a clamp, a larger fitting should be chosen. With some fittings that tend to be larger, it is possible though that a hose with an inner diameter of 13mm actually does seal without a hose clamp. Overview: 10mm (3/8") hose clamp: up to 8mm none, from 10mm up required 10mm (7/16") hose clamp: up to 8mm none, from 10mm up required 12mm (1/2") hose clamp: up to 11mm none, from 12mm up required 13mm (1/2") hose clamp: up to 11mm none, from 13mm up required
Our trusted fittings are available in a whole new design! Robust high-quality barbed fitting with cylindrical thread (G1/8"). The fitting is suitable for PVC, OU, PA, silicone and PE hoses with an inner diameter of 13mm. With integrated 1/8" Perbunan(r) O-Ring seal. Technical details: Material: Brass, black nickel coated Hose size: 13m inner diameter Thread size: G1/8" Extent of delivery: Black nickel barbed fitting with O-ring seal Note for watercooling beginners: The connectors for hoses(7/16", 3/8",1/2") are provided with measurements in mm in our shop. These can differ by +-1mm, which is no problem as hose clamps have to be used for installation. If the hose is to be mounted without a clamp, a larger fitting should be chosen. With some fittings that tend to be larger, it is possible though that a hose with an inner diameter of 13mm actually does seal without a hose clamp. Overview: 10mm (3/8") hose clamp: up to 8mm none, from 10mm up required 10mm (7/16") hose clamp: up to 8mm none, from 10mm up required 12mm (1/2") hose clamp: up to 11mm none, from 12mm up required 13mm (1/2") hose clamp: up to 11mm none, from 13mm up required
Safely and quickly connects hoses. No zip ties or hose clamps are required, the hose seals safely on the connector. Angled by 90° to allow tight radiuses which would otherwise result in buckled hoses.Technical specifications: Material: Nickel plated brassSuitable for hoses with an inner diameter of 10mm Extent of delivery: 1x 10mm (3/8") 90° hose connector - Nickel plated brass Aquainfos hat dieses Produkt für Sie getestet
Safely and quickly connects hoses. No zip ties or hose clamps are required, the hose seals safely on the connector. This Y-piece allows the creation of a branch connection.Safely and quickly connects hoses made from PVC and others (e.g. Tygon, Masterkleer).Technical specifications: Material: Nickel plated brassSuitable for hoses with an inner diameter of 8mm Extent of delivery: 1x 8mm (10/8mm) Y hose connector - Nickel plated brass Aquainfos hat dieses Produkt für Sie getestet
Safely and quickly connects hoses. No zip ties or hose clamps are required, the hose seals safely on the connector. This Y-piece allows the creation of a branch connection.Safely and quickly connects hoses made from PVC and others (e.g. Tygon, Masterkleer).Technical specifications: Material: Black nickel plated brassSuitable for hoses with an inner diameter of 8mm Extent of delivery: 1x 8mm (10/8mm) Y hose connector - Black nickel plated brass Aquainfos hat dieses Produkt für Sie getestet
Safely and quickly connects hoses. No zip ties or hose clamps are required, the hose seals safely on the connector. This Y-piece allows the creation of a branch connection.Safely and quickly connects hoses made from PVC and others (e.g. Tygon, Masterkleer).Technical specifications: Material: Nickel plated brassSuitable for hoses with an inner diameter of 10mm Extent of delivery: 1x 10mm (3/8") Y hose connector - Nickel plated brass Aquainfos hat dieses Produkt für Sie getestet
Safely and quickly connects hoses. No zip ties or hose clamps are required, the hose seals safely on the connector. This Y-piece allows the creation of a branch connection.Safely and quickly connects hoses made from PVC and others (e.g. Tygon, Masterkleer).Technical specifications: Material: Black nickel plated brassSuitable for hoses with an inner diameter of 10mm Extent of delivery: 1x 10mm (3/8") Y hose connector - Black nickel plated brass Aquainfos hat dieses Produkt für Sie getestet
Safely and quickly connects hoses. No zip ties or hose clamps are required, the hose seals safely on the connector. This Y-piece allows the creation of a branch connection.Safely and quickly connects hoses made from PVC and others (e.g. Tygon, Masterkleer).Technical specifications: Material: Nickel plated brassSuitable for hoses with an inner diameter of 13mm Extent of delivery: 1x 13mm (1/2") Y hose connector - Nickel plated brass Aquainfos hat dieses Produkt für Sie getestet
Robust high-quality nickel plated barbed fitting with cylindrical thread (G1/4"). The fitting is suitable for PVC, PU, PA, silicone and PE hoses with an inner diameter of 10mm. With integrated 1/4" Perbunan(r) O-Ring seal. We recommend the use of hose clamps or zip ties for best possible safety! Note for watercooling beginners: The connectors for hoses(7/16", 3/8",1/2") are provided with measurements in mm in our shop. These can differ by +-1mm, which is no problem as hose clamps have to be used for installation. If the hose is to be mounted without a clamp, a larger fitting should be chosen. With some fittings that tend to be larger, it is possible though that a hose with an inner diameter of 13mm actually does seal without a hose clamp. Overview: 10mm (3/8") hose clamp: up to 8mm none, from 10mm up required 10mm (7/16") hose clamp: up to 8mm none, from 10mm up required 12mm (1/2") hose clamp: up to 11mm none, from 12mm up required 13mm (1/2") hose clamp: up to 11mm none, from 13mm up required
10mm 90° angled fitting, revolvable and made from black nickel plated brass. Complete with O-ring and suitable for use with PVC, PU, PA, silicone or PE tubing with an inner diameter of 10mm. Technical specifications: Material: Brass (matte black) Dimensions: 31,4x33x16,6mm Compatibility: Suitable for tubing with an inner diameter of 10mm Extent of delivery: 1x 10mm (3/8") barbed fitting 90°, revolvable G1/4" with O-ring - matte black
High quality hose connector made from high-grade brass. Eye candy for any cooling system, but not quite as cheap as the 90° plastic connectors. Both hose endings are stuck onto the fitting and tightly held in place by the union nuts. This system ensures maximum safety and ease of installation. For 8x1 hoses
