The new Eiszapfen PRO hard tube fittings from Alphacool are the next step in development for the familiar Eiszapfen fittings. In the development of the fittings Alphacool concentrated on a specific problem, deforming PETG hard tubes at high temperatures. PETG can start to deform at 60°C. Although such a temperature is usually rarely reached, it can still occur. The Eiszapfen PRO fittings prevent this problem from the outset and hold the tubes in position. The deformation is prevented by the new nylon inserts inside and stabilizes the hard tubes. Furthermore, the fitting still has an O-ring and a compression seal. However, the contact area is much larger than with normal O-rings, which provides a better grip. With the insert and the compression seal, the tube is strengthened from the inside and outside. Even under heavy loads the HardTube does not slip. Alphacool has tested the tensile strength of up to over 8kg, so there is no need to worry about loose tubing. Technical details: Material: brass Colour: chrome Diameter: 22 mm Height: 20 mm Thread: G1/4" Thread length: 5 mm HardTube size: 13 mm Compatibility: PETG, acrylic, brass and glass tubes Weight: 0,023 kg Scope of supply: 1x Alphacool Eiszapfen PRO 13mm HardTube Fitting G1/4 - Chrome Notice: Attention: The manufacturer Mayhems advises that Mayhems fluids, especially the Aurora line of products, have been manufactured and distributed solely for show and modding purposes. These should not be utilized in the system for more than 14 days. We would also like to advise that Mayhems fluids can damage water cooling products, and using Mayhems fluids can thereby void the warranties offered by the following manufacturers: Koolance, Phobya, Alphacool, Aqua Computer, Watercool. Damages such as: clogging, corrosion of aluminium radiators, deterioration of glued containers, etc., are a consequence of the use of Mayhems, but will not be reimbursed by Mayhems. Use is therefore at one’s own risk.
Alphacool's Eiszapfen is the high-end version of the already proven connectors and meets all the requirements placed on a connector with its high-flow, shape, processing and colour. Compatibility This 90° angled adapter has a rotatable 1/4" external thread on one side and a 1/4" internal thread on the other. This 90° angled connection is mostly used where space is limited and a special solution is required. For maximum flexibility, the adapter can be rotated on the external thread. Design With brilliant chrome, deep matt black and decent matt white, three colour variants are available that fit perfectly into any system. Thanks to special processes, the coatings are firmly bonded to the substrate. This ensures a high longevity of the colours and prevents the coating from flaking off. The connector now also has the Alphacool logo, which makes it unique in addition to its special shape! Technical details Material Brass Colour White Length 34 mm Diameter 18 mm Thread G1/4“ Thread length 5 mm Weight 38 g Download Datasheet PDF: Alphacool Eiszapfen L-connector rotatable G1/4 outer thread to G1/4 inner thread - White Fitting Map: You can find an interactive map of all Alphacool fittings here.
The two clamp set is suitable for the equalizing tanks of the Z-series from Bitspower. They make it possible to mount the expansion tank individually inside or outside the case, also with the corresponding pump. The set contains two clamps each with four screws and nuts. The holders have an 80mm, 5mm high and 15mm deep base. The clamps themselves are 10mm wide, have an inside diameter of 60mm and an outside diameter of 66mm. Technical Data: Dimensions: 80 x 70 x 15 mm (W x H x D) Inner Diameter Clamps: 60 mm Outer Diameter Clamps: 66mm Material: Plastic Color: Black Compatibility: Bitspower water tanks of the Z-series
Visual appearance combined with functionality. After the successful launch of the “Lian Li 011D Mini MK1“, now the Lian Li Mini is followed by the “MK2” front distro plate. It is made of high-quality and transparent acrylic glass. Despite the small case, our distro plate MK2 allows all radiators as well as GPU and CPU to be connected in the circuit. This is rendered possible by a large chamber and 5 channels with a total of 12 ports (incl. fill port & drain port). The “MK2” will replace the original tempered glass pane. The distro plate is made of high-quality acrylic and the accuracy of fit is assured. Additionally, we use EPDM seals to guarantee leak tightness. After the leak test, a test seal is glued on the back of the plate. The screw-fitting points provided by Lian Li are used for fixation. To mount the distro plate safely, 4 screws with sealing disc are included in the scope of delivery. It is important to ensure that only (!) “ECWB SE360 (2x) “ & “ ECA SE240 (1x)“ radiators are usable because the accuracy of fit can only be assured in this case. A frame sticker (you may choose between black or white) decorates the sides of the front. Thereby, mounting strips that are glued on the rear side of the distro are covered. Overview of Features smallest distro plate of the Lian Li series frame sticker, selectable in black or white clever plug-in system for effortless installation adapter allows perfect fit of a D5 pump compatible with EK-CoolStream SE360 2x and 1x SE240mm (radiators) Technical details Material: high-quality acrylic glass, plastic Manufacturing: CNC machining of the acrylic, assembly by hand Dimensions: without pump (W x H x D): 487 x 211 x 21 mm, with pump (W x H x D): 487 x 211 x 90 mm Colour: transparent Connections: 12x G1/4" Capacity: 435 ml Compatibility: 3x360mm fan space Scope of Delivery Lian Li Mini MK2 4x M3 screws
High-End-CPU-Wasserkühler in Schwarz, passend für viele Intel-Sockel, Deckel aus transparentem Acryl, Kühlerboden aus Kupfer, schwarze Halterung aus Aluminium, integrierte aRGB-Beleuchtung
The vertical bracket from Singularity can be used to mount a Protium series reservoir or pump attachment vertically on a 120 or 140 fan slot of a radiator. It is even possible to mount two reservoirs or pump attachments. Technical Data Colour: Silver Material: Aluminium (mounting plates), Stainless Steel (screws) Scope of Delivery: 2x SC Universal 120/140 Back Plate Mounting Plate 2x Vertical mounting plate 4x M4 Button Head Hex (10 mm) 4x M4 Countersunk Hex (10 mm) 4x M4 Washers 4x M4 Nut
The transparent acrylic lid fits all Protium reservoirs from Singularity. It has four G1/4" connections and, due to its design, can be integrated into the water cooling circuit in a variety of ways. Technical Data Colour: Transparent Material: Acryl Thread: 4x G1/4" Compatibility: Protium reservoir
Schicker zylindrischer Ausgleichsbehälter, Röhre und Aufsätze aus transparentem Acryl, drei Aufsätze für flexible Anschlussmöglichkeiten, silberne Sicherungsringe aus Aluminium
The nickel-plated adapter from Bitspower in the color shiny black, has an angle of up to 90 degrees, a G1/4" internal thread and a G1/4" external thread. The special feature of this adapter are the three swivel joints, so that the alignment of e.g. tubes becomes even easier and more flexible. Technical Data: Material: Nickel-Plated Brass Main Color: Shiny Black Angle: up to 90° Thread: 1x G1/4", 1x Inner G1/4" Thread Length: 5 mm
The adapter in white from Bitspower has a G1/4" external thread and a G1/4" internal thread. It has a 90 degree angle and can be rotated on the thread for easier tube alignment. Technical Data: Material: Brass Colour: White Angle: 90 ° Thread: G1/4" and inner G1/4" Thread Length : 5 mm
The nickel-plated adapter from Bitspower in matt black has a 90 degree angle and is rotatable. One side is designed for mounting hard tubes with an outside diameter of 12mm and the other side has a G1/4" external thread for mounting on radiators and Co. The two rubber rings seal the sides. Technical Data: Material: Nickel-Plated Brass Colour: Matt Black Angle: 90° Thread: G1/4 inch Connection: 1x Ø 12 mm
The Alphacool Eisbaer Pro Aurora CPU AIO water cooler is a special development for processors with particularly large CPU dies. These include the AMD Threadripper and Epyc processors and the Intel CPUs for the LGA 3647 and LGA 4189 socket. With the optional XPX Pro AM4 mounting bracket, the Alphacool Eisbaer Pro CPU cooler can also be used on AMD Ryzen processors. Large cooling surface The cold plate bottom covers the entire surface of the respective processors. The area of the cooling fins exceeds all known processor cores with an area of around 55 x 42 mm. This ensures that all hotspots of a CPU are directly covered and thus optimally cooled. With the additionally available AM4 bracket, cooling an AMD Ryzen processor is also child's play. The cooling fins are 0.4 mm thick and also have an optimal distance of 0.4 mm between them. In total there are 58 cooling fins on the bottom of the cooler. The bottom of the cooler is only 3 mm thick, which allows the heat to reach the water and be dissipated as quickly as possible. Copper radiator As per usual with Alphacool, the radiators are made of copper. Alphacool is the first manufacturer worldwide to use copper for all water bearing components such as the antechambers, the cooling fins and the cooling channels to which the fins are soldered. The connection threads are made of brass for strength reasons. In addition, the cooling fins are only lightly painted. On closer inspection the copper shimmers through a little. A thick lacquer coating would result in a reduction of the cooling capacity. The fin density is at optimal 15FPI. Therefore the radiator works perfectly even at low airflow. A too high fin density would require fans with higher speed to achieve the same cooling capacity. A lower fin density would no longer benefit from fast rotating fans. So the golden mean was chosen. Real water cooling The Eisbaer Pro Aurora consists almost entirely of actual water cooling components. The extremely robust and durable TPV hoses are used in the enterprise products for servers and workstations. The hose connections also come from the Enterprise series from Alphacool and use the standard G1/4". This makes the Eisbaer Pro Aurora fully compatible with all common water cooling products. The quick-release fastener allows easy expansion of the AIO with additional components. The most important of these are the prefilled radiators and the Eiswolf GPU AIO water cooling system. Fan and lighting The entire Eisbaer Aurora Pro cooler is equipped with addressable digital RGB LEDs. This gives a real eye-catcher in the Case. The fan used is the Aurora Rise with 140mm. Due to the special blade design, the fan is extremely quiet and the addressable RGB LEDs provide brilliant illumination. The Alphacool Aurora Rise fan convinces with a max. statistical pressure of 2.20 mm/H 2 O and offers a max. air flow of 154.1 m³/h. The PWM control allows the fan to be controlled over a wide speed range. In addition, it offers a zero control. It can therefore be regulated down to 0 rpm and then starts with approx. 350 rpm. Of course all Digital RGB LEDs can be controlled at will. Depending on the controller almost all effects are possible. How to connect everything The fans are normally controlled via a 4-pin PWM connector. An included Y-adapter for the fans makes it easy to connect them to the mainboard. This allows all fans to be controlled and regulated via one connector. Each fan has a 3-pin JST connector including Y-adapter for the LED illumination. This allows the fans to be connected directly together and can also be controlled simultaneously via a controller. For the connection to a typical 3-pin 5V connector a corresponding adapter is included. Alternatively, the included Digital RGB controller can be used. The pump of the Eisbaer Aurora uses a 3-pin Molex connector. This can also be connected to the mainboard. The Eisbaer Pro Aurora is a true multi-talent. Expandable, fully compatible with DIY water cooling components and it is the optimal solution for the most powerful processors on the market. Technical data radiator L x W x H 316 x 144 x 30 mm (+/- 3% in the range of the pre-chambers) Material fins, chambers & channels copper Material threads brass Material outer housing stainless steel G 1/4“ threads 2 x for tubes For fan size 140 mm Fan mounting options 2 x one-sided / 4 x both-sided Technical data cooler and pump L x W x H 64 x 79 x 54,3 mm Number of LEDs 10x Digital RGB LEDs Material cooler bottom Nickel plated copper Material cooler top PMMA Threads 2 x G1/4“ (+ 1x Fillport G1/4“) Pump typ DC-LT 2 Pump speed 2600 rpm (+/- 10%) Head of delivery 0,95 m Maximum flow rate 75 L/h Technical data fans Speed 0 - 2000 RPM Static pressure 2,20 mm H 2 O Air flow rate 154,1 m³/h Fan connector 4-Pin PWM Connection Digital aRGB 3-Pin JST + 3-Pin 5V Dimensions 140 x 140 x 25 mm Compatibility list: - Intel: 1700 / 2011 / 2011-3 / 2066 / 3647 Narrow & Square / LGA 4189 - AMD: AM4 / TR4 / sTRX4 / SP3 / sWRX8
Fan speed (max): 2000 Fan speed (min): 500 Air flow rates: 73.11 Number of fans: 1 Noise: 36 Dimensions: Radiator length 152 mm Radiator width 120 mm Radiator height 32 mm Pump length 66 mm Pump width 66 mm Pump height 43 mm Other features: Static pressure 2.93 InchH2O Rated voltage 12 VDC Material Plastic, Nylon, Copper, Rubber, Aluminium Noise level 21 - 36 dB Bearing type FDB(Fluid Dynamic Bearing) Lifetime 60 000 h Fan diameter 120 mm Illumination Yes Connectors 4-PIN, 3-PIN Illumination color RGB Backlight parts Pump Fan lifetime 60000 h
Suurus:120 L x 120 W x 25 H mm tööpinge:3,5-13,8 V testitud:12V õhuvool:124 m3/h õhusurve:2,140 mm/H20 müratase:27,1 dBA kiirus:1800 RPM võimsustarve:2,16 W tootjalehel:http://www.blacknoise.com/en/products/it/7/Noiseblocker-NB_Multiframe_S_Series_120mm
The new premium fan series is based on the NB-Blacksilent-Chassis and is equipped with the excellent electronics module NB-EKA Plus and NB-NanoSLI bearings. Both are features that were so far used only in the more complex Multiframe series. Besides the technologically advanced components this fan is also equipped with an individually adaptive cable management. The fan is shipped with a newly developed mounting kit for vibration-free mounting which consists of an optimized "NB-Silentframe" silicone frame with suitable counter-pieces and knurled nuts for tool-free installation. Technical specifications: Dimensions: 140x140x25mm Colour: Black Weight: 135g Nominal voltage: 12V Starting voltage: 4,5V Current draw: 0,06A Nominal speed: 700rpm (+/-10%) Airflow: 49m³/h / 28,841CFM Noise emission: 9 dB(A) MTBF (25°C): 180000hrs Connector: 3-Pin Molex plug with rpm lead Extent of delivery: 1x Noiseblocker NB-BlackSilentPRO PK1 ( 140x140x25mm ) 1x Fan decoupling 1x 3 PIN fan extension 20cm 1x 3 PIN fan extension 50cm 4x Mounting screws 4x Knurled nuts This product has been reviewed for you: Tech-Review Hardware-academy
If you always desire the best... With the new Multiframe® technology the peak of fan design is set again! The Multiframe® is patented by us and offers a whole new dimension of possibilities for noise reduction in PCs and Media appliances of all kind. Noise level readings by the TÜV Nord confirm the extremely low noise level and clear advantage over other fans. The Multiframe® series as a High-end series is equipped with only the best components: An optimized EKA Plus II motor with an extremely low starting voltage, almost inaudible NB-NanoSLI® bearings an the High-End Chassis with Deepsound design all achieve an unprecedented silent operation. The MF8-S3HS is a faster fan for higher cooling needs such as CPU coolers etc. Slightly audible but much more silent that common fans at the same Airflow. NB-Mulitframe® technology: Unique Multi-part Hightech Chassis with integrated vibration absorbers and a vibration-reducing fibre-glass reinforced fame. Extremely low starting voltage of only 4,5V! Powerful yet silent operation: Smooth and extremely quiet operation Highest safety: Inverse polarity protection, overload protection, Restart-function, extremely fail-safe, 6 years warranty Extremely quiet bearing Long-lived and quiet NB-NanoSLI® bearings and much more Great and precise build quality Highly precise manufacturing, massed frame with Deepsound design Technical details: Dimensions: 80 x 80 x 25 mm Nominal speed: 2200 rpm Noise level: 19 dB/A Airflow: max. 59 m³/h / 31,79 CFM Nominal voltage: 12V Starting voltage: 5V Warranty: 6 years Connector: 4-Pin PWM Please note the difference between a 4-Pin power plug (Molex) and a 4-Pin fan connector (PWM). Extent of delivery: 1x Noiseblocker NB-Multiframe M8-P ( 80x80x25mm ) Mounting material Sealing / decoupling frame
