EK-Quantum Vector FE RTX 3080 Backplate - Black is a CNC machined retention backplate made from black anodized aluminum for the EK-Quantum Vector FE RTX 3080 - Special Edition water block. The backplate covers the backside of the graphics card's PCB and serves as an aesthetic add-on. It provides additional passive cooling for the GPU core and rear of the printed circuit board VRM section. Due to the small size of both the card and the water block, the backplate boasts a ribbed design for additional passive cooling power. Enclosed EK-Quantum Vector FE RTX 3080 Backplate - Black Mounting screws Thermal pads
120 mm großer PWM-Lüfter, digital adressierbare RGB-LED-Beleuchtung (3-Pin), Drehzahl von max. 1.500 U/min, transparenter Rahmen und Lüfterblätter, inklusive Schrauben
EK-Quantum Vector Strix RX 6800/6900 is a 2nd generation Vector GPU water block from the EK® Quantum Line. It is made for ROG Strix RX 6800, 6800XT, 6900XT graphics cards based on the latest AMD® RDNA2™ architecture. EK-Quantum Vector Strix RX 6800/6900 water block for ROG Strix GAMING RX 6800 and 6900 GPUs EK-Quantum Vector RX 6800/6900 water block is compatible with ASUS® ROG Strix GAMING Radeon RX 6800, RX 6800XT, and 6900XT graphics cards. The Vector water block directly cools the GPU, VRAM, and the VRM (voltage regulation module) as a cooling liquid is channeled right over these critical areas. The water block is in contact with power stages as well as Inductor chokes to maximize cooling and minimize the chances of coil whine. These newly developed water blocks feature optimized flow paths that reduce hydrodynamic instabilities and vortexing (dead spots) inside of them. The EK-Quantum Vector Series water blocks use an Open Split-Flow cooling engine design, which proved to be a superior solution for GPU water blocks. It is characterized by low hydraulic flow restriction, meaning it can be used with weaker water pumps or pumps running on low-speed settings, and still achieve top performance. The jet plate and fin structure geometry have been optimized to provide even flow distribution with minimal losses and optimal performance when used in any given coolant flow orientation. The base of the block is CNC-machined out of high-grade nickel-plated electrolytic copper, while its top is CNC-machined out of glass-like cast Acrylic. These 2nd generation Vector GPU water blocks also feature acetal terminals. The watertight sealing is ensured by high-quality EPDM O-rings, while brass standoffs are already pre-installed and allow for a safe and easy installation procedure. D-RGB lighting on EK-Quantum Vector Strix RX 6800/6900 D-RGB water block The aesthetic end-piece is housing the addressable D-RGB LED strip. These water blocks boast a total of 9 individually addressable RGB LEDs, and a LED-lit terminal. They are compatible with popular RGB sync technologies from all major motherboard manufacturers. The arrow marking on the 3-pin D-RGB LED connector is to be aligned with the +5V marking on the D-RGB (addressable) header. Backplate for the Strix 6800/6900 water block EK recommends the purchase of a retention backplate, which improves the overall aesthetics of your graphics cards, and also provides additional passive cooling for the GPU core and backside of the printed circuit board VRM and VRAM sections. Technical Specification Dimensions: (LxHxW) - 300.5x157x19.5mm Enclosed EK-Quantum Vector Strix RX 6800/6900 series high-performance water block Mounting mechanism with screw-in brass standoffs Necessary mounting screws, nuts, and washers 2x Nickel plated brass plug G1/4” EK-Loop Multi Allen Key (6mm, 8mm, 9mm) Thermal pads Thermal grease EK-TIM Ectotherm (1g)
EK-Quantum Vector Strix RX 6800/6900 is a 2nd generation Vector GPU water block from the EK® Quantum Line. It is made for ROG Strix RX 6800, 6800XT, 6900XT graphics cards based on the latest AMD® RDNA2™ architecture. EK-Quantum Vector Strix RX 6800/6900 water block for ROG Strix GAMING RX 6800 and 6900 GPUs EK-Quantum Vector RX 6800/6900 water block is compatible with ASUS® ROG Strix GAMING Radeon RX 6800, RX 6800XT, and 6900XT graphics cards. The Vector water block directly cools the GPU, VRAM, and the VRM (voltage regulation module) as a cooling liquid is channeled right over these critical areas. The water block is in contact with power stages as well as Inductor chokes to maximize cooling and minimize the chances of coil whine. These newly developed water blocks feature optimized flow paths that reduce hydrodynamic instabilities and vortexing (dead spots) inside of them. The EK-Quantum Vector Series water blocks use an Open Split-Flow cooling engine design, which proved to be a superior solution for GPU water blocks. It is characterized by low hydraulic flow restriction, meaning it can be used with weaker water pumps or pumps running on low-speed settings, and still achieve top performance. The jet plate and fin structure geometry have been optimized to provide even flow distribution with minimal losses and optimal performance when used in any given coolant flow orientation. The base of the block is CNC-machined out of high-grade nickel-plated electrolytic copper, while its top is CNC-machined out of durable black POM acetal. These 2nd generation Vector GPU water blocks also feature acetal terminals. The watertight sealing is ensured by high-quality EPDM O-rings, while brass standoffs are already pre-installed and allow for a safe and easy installation procedure. D-RGB lighting on EK-Quantum Vector Strix RX 6800/6900 D-RGB water block The aesthetic end-piece is housing the addressable D-RGB LED strip. These water blocks boast a total of 9 individually addressable RGB LEDs, and a LED-lit terminal. They are compatible with popular RGB sync technologies from all major motherboard manufacturers. The arrow marking on the 3-pin D-RGB LED connector is to be aligned with the +5V marking on the D-RGB (addressable) header. Backplate for the Strix 6800/6900 water block EK recommends the purchase of a retention backplate, which improves the overall aesthetics of your graphics cards, and also provides additional passive cooling for the GPU core and backside of the printed circuit board VRM and VRAM sections. Technical Specification Dimensions: (LxHxW) - 300.5x157x19.5mm Enclosed EK-Quantum Vector Strix RX 6800/6900 series high-performance water block Mounting mechanism with screw-in brass standoffs Necessary mounting screws, nuts, and washers 2x Nickel plated brass plug G1/4” EK-Loop Multi Allen Key (6mm, 8mm, 9mm) Thermal pads Thermal grease EK-TIM Ectotherm (1g)
Backplate für GPU-Wasserkühlung, für EK-Quantum Vector Strix RX 6800/6900, aus vernickeltem Aluminium, bietet erhöhte Stabilität, mit Wärmeleitpad für passive Kühlung der PCB-Komponenten
Backplate für GPU-Wasserkühlung, für EK-Quantum Vector Strix RX 6800/6900, aus anodisiertem Aluminium, bietet erhöhte Stabilität, mit Wärmeleitpad für passive Kühlung der PCB-Komponenten
This is the 2nd generation Vector GPU water block from the EK® Quantum Line, designed for AORUS® Xtreme and Master RTX 3080 and 3090 graphics cards based on the latest NVIDIA® Ampere™ architecture. An EK water block for Xtreme and Master RTX 3080 and 3090 EK-Quantum Vector Xtreme 3080/3090 D-RGB - Nickel + Acetal water block is compatible with Aorus Xtreme and Master RTX 3080 and RTX 3090 graphics cards. The Vector water block actively cools the GPU, VRAM (on the front), power stages, and chokes in the VRM (voltage regulation module). These newly developed water blocks feature optimized flow paths that reduce hydrodynamic instabilities and vortexing (dead spots) inside of them. The EK-Quantum Vector Series water blocks use an Open Split-Flow cooling engine design, which proved to be a superior solution for GPU water blocks. It is characterized by low hydraulic flow restriction, meaning it can be used with weaker water pumps or pumps running on low-speed settings, and still achieve top performance. The jet plate and fin structure geometry have been optimized to provide even flow distribution with minimal losses and optimal performance when used in any given coolant flow orientation. The base of the block is CNC-machined out of nickel-plated high-grade copper, while its top is CNC-machined out of durable black POM Acetal. These 2nd generation Vector GPU water blocks also feature Acetal terminals. The watertight sealing is ensured by high-quality EPDM O-rings, while brass standoffs are already pre-installed and allow for a safe and easy installation procedure. D-RGB lighting on EK-Quantum Vector Xtreme RTX 3080/3090 D-RGB water block The aesthetic corner end-piece is housing the addressable D-RGB LEDs. This water block boasts a total of 8 individually addressable RGB LEDs, and it is compatible with popular RGB sync technologies from all major motherboard manufacturers. The arrow marking on the 3-pin D-RGB LED connector is to be aligned with the +5V marking on the D-RGB (addressable) header. Backplate for the EK-Quantum Vector Xtreme 3080/3090 water block EK recommends the purchase of a retention backplate, especially for the 3090 models of graphics cards. The backplate improves the overall aesthetics of your graphics cards and also provides additional passive cooling for the GPU core, VRAM on the 3090 cards, and backside of the printed circuit board VRM section. Technical Specification Dimensions: (LxHxW) - 295x150.5x20.5mm Enclosed EK-Quantum Vector Xtreme RTX 3080/3090 D-RGB series high-performance water block Mounting mechanism with screw-in brass standoffs Necessary mounting screws, nuts, and washers 2x Nickel plated brass plug G1/4” EK-Loop Multi Allen Key (6mm, 8mm, 9mm) Thermal pads Thermal grease EK-TIM Ectotherm (1g)
Whether used as a replacement or to modify the tube, the Protium reservoir can be used with all Protium items. Technical Data Length: 150 mm Outer diameter: 60 mm Material: Acrylic Compatibility Protium D5 pump attachment Protium D5/Reservoir Combo Protium reservoir
The Alphacool Eisbaer Pro Aurora offers a much larger cooling surface than the normal Eisbaer Aurora. It was specially developed for extremely large CPU DIEs and fully covers processors such as the AMD Threadripper but also the AMD Ryzen CPUs. The Eisbaer Pro has also been designed for the Intel Socket 3647 to ensure the best possible cooling performance of the entire CPU. The Eisbaer Pro Aurora is a true multi-talent. Expandable, fully compatible with DIY water cooling components and it is the optimal solution for the most powerful processors on the market. Large cooling surface The cold plate bottom covers the entire surface of the respective processors. The area of the cooling fins exceeds all known processor cores with an area of around 55 x 42mm. This ensures that all hotspots of a CPU are directly covered and thus optimally cooled. With the included AM4 bracket, cooling an AMD Ryzen processor is also child's play. The cooling fins are 0.4mm thick and also have an optimal distance of 0.4mm between them. In total there are 58 cooling fins on the bottom of the cooler. The bottom of the cooler is only 3mm thick, which allows the heat to reach the water and be dissipated as quickly as possible. Pump The Eisbaer Pro Aurora cooler uses the very compact and small DC-LT 2 pump. It offers enough power to integrate other components such as a GPU water cooler or radiator into the water circuit. Lighting The entire Eisbaer Pro Aurora cooler is equipped with addressable, digital RGB LEDs. This makes it a real eye-catcher in the case. Of course, all digital RGB LEDs can be controlled as desired. Depending on the controller, almost all effects are possible. Usable fittings Connections that are too large mean that the fill port can no longer be used. We recommend the following: - up to and including 13/10 without restriction - 16/10 only in angled version - Connections larger than 16/10 should not be used Compatibility: Intel: 1700 / 2011 / 2011-3 / 2066 / 3647 Narrow & Square / LGA 4189 AMD: AM4 / TR4 / sTRX4 / SP3 / sWRX8 / AM5 Technical data cooler with pump L x W x H 64 x 79 x 54,3mm Material cooler bottom nickel plated copper Material cooler top acrylic Threads 2x G1/4“ (+ 1x Fillport G1/4“) Pump type DC-LT2 Pump speed 2600 rpm (+/- 10%) Head of delivery 0,95 m Maximum flow 75 L/h Voltage 12V DC Power consumption 4W Pressure tested 0,8 Bar Maximum working temperature 60°C Number of LEDs 10x Digital aRGB LEDs
For more than a decade, Alphacool has dominated the market with the NexXxoS Full Copper radiator series. Our extensive portfolio of radiator variants is unique in the world. Just like our manufacturing process, which allows us to produce all water-carrying parts and the cooling fins out of pure copper. As a result, the NexXxoS series offers the highest thermal conductivity of any radiator on the market. Thanks to their exceptional performance, the radiators can easily dissipate even extremely high waste heat and have become essential in many areas of the cooling industry.The next step in evolution: NexXxoS HPE Full Copper Radiator!The NexXxos Full Copper HPE Radiator uses the same materials as previous NexXxos models, but takes it a step further technically. Due to the condensed internal structure, the number of water channels and copper fins could be increased. Thus, a larger volume of water is in direct contact with the cooling fins and the heat transfer is enormously improved. The higher number of fin rows and their shortening also makes much more efficient use of the cooling surface. Comparison tests* with the conventional NexXxos radiator have shown that a performance increase of 4.5K is possible when using the HPE radiator. At higher ambient temperatures and higher fan speeds, the performance gap with the normal NexXxoS radiators even increases progressively, reaching a possible performance increase of up to 6K.(* Test setup: NexXxos ST30 360mm radiator vs. NexXxos HPE-30 360mm radiator with Eisbaer cooler and 3x 120mm Rise Aurora fans and on Asus Prime x299 motherboard with Intel i9 10900x CPU with 350W waste heat)Connection options & mountingThe NexXxoS HPE radiator has two IN or OUT connections with G1/4" threads in the pre-chamber area. On the opposite side is a fill or drain port, which can be used for filling and draining the water circuit. All screws for mounting in the case and for mounting the fans are included with the radiator. Additional screws are not usually required.Safety firstThe NexXxoS HPE radiator has special protective plates placed under all mounting holes to prevent the screws from being screwed in too deeply. This protects the cooling fins and water channels underneath from damage.Patented screw plugsAll NexXxoS HPE radiators use Alphacool's patented screw plugs. Protruding screw plugs often mean that the radiator cannot be laid flush. Alphacool's screw plugs are fully recessed into the radiator, flush with its surface and allow easy installation in the case. Technical data radiatorL x W x H173,5 x 144 x 30mm (+/- 3%)Material cooling fins, pre-chambers & channelscopperMaterial threadsbrassMaterial outer housingstainless steelThreads4x G1/4" IN/OUT & 1x Fill-/Drainport G1/4" (max. 5mm thread length)Possible fan size140mmPossible fan assembly1x one-sided / 2x both-sidedThread size fan mountingM3Pressure tested0,8 BarMaximum working temperature60°CFin density18 FPIWeight496gColorblackWarranty: 10 years???? Warranty Terms
The Alphacool Rise fan offers a wide range of control as well as superior Digital RGB LED lighting. The individually controllable 5V aRGB LEDs paired with the fan's special design can create some unique effects whilst offering performance. Brilliant illumination There are 20 digitally addressable 5V RGB LEDs built into the frame and hub that illuminate the entire fan. This creates a unique illumination that looks very impressive. Thanks to the recessed light diffusers, the light is distributed evenly, and you will not see sporadic uneven lighting. Wide control range and silent The fan can be controlled from 0 to 2500 rpm via the 4-pin PWM connector. In addition, it offers a silent mode, with which the fan can be regulated down to 0 rpm and then they will only start when they are needed above 350rpm. At 800 rpm, the fan is nearly silent, but still offers a good airflow (118.9m3/h) paired with a high static pressure (3.17mm/H2O). This makes the fan perfect for mounting on radiators of a water cooling system or for alternatively, as a case fan. Decouplers are located directly on the corners of the frame. The soft foam pads reduce the transmission of vibrations to the case, which in turn reduces noise. Tear-off edges on the fan blades also provide a significant reduction in noise. Connectors? The fan is controlled via a 4-pin PWM connector. The cable is 40 cm long. This allows the fan to be connected to the motherboard or a fan controller without the need for additional adapter cables or extensions. The digital aRGB LED illumination is controlled via a JST 3-pin connector and adapters are available to change this into a standard 3 pin aRGB connector if required. Note: The cable for connecting the ARGB LEDs is not included in the scope of delivery, but is optionally available in the shop! (Art. 18604, Alphacool connection cable 3pin to 3pin Digital RGB) Technical Data fan L x W x H 120 x 120 x 25 mm Speed 0—2500 rpm (+/-10%) Bearing Sleeve Bearing Connection 4-Pin PWM Cable length 40 cm Voltage 12V DC Current consumption. 0,65A (0,72 max) Static pressure 3,17 H2O Max. air flow 118,9 m³/h Noise max. 31,5 dB(A) MTBF 50.000h Speedometer signal Yes Auto-Restart Yes Technical data digital RGB LED type 5V aRGB Connection 3-Pin JST Cable length 50cm (Splitter after 40cm) Max. current consumption LEDs 3,5W LED quantity Frame: 12 / Hub: 8 Download Data sheet PDF: Alphacool Rise Aurora 120 mm fan (120x120x25mm)
The CORSAIR RS140 MAX case fan is a high-performance cooling solution designed to meet the demands of enthusiasts and professionals. With its airflow range of 27.5 to 104 cfm, it ensures that your system remains cool under heavy loads. The fan's magnetic dome bearing provides a quiet operation with noise levels between 10 and 31 dBa, ensuring durability and reliability. Its 140 mm diameter is ideal for a wide variety of cases, offering flexibility in system building or upgrades. Additionally, the RS140 MAX features CORSAIR AirGuide technology, which channels airflow in a focused manner to cool critical components more efficiently. Support for Pulse-width modulation (PWM) allows for precise control over fan speed, enabling the balance between cooling and noise. The Zero RPM fan mode can completely stop the fan at low temperatures, eliminating noise for silent operation. Constructed from liquid-crystal polymer (LCP), this fan is built to last and perform at a high level, making it an excellent choice for cooling your system.
Alphacool's Eiszapfen is the high-end version of the already proven connectors and meets all the requirements placed on a connector with its high-flow, shape, processing and colour. Compatibility This adapter has a rotatable ¼” external screw thread on one side and a ¼” internal thread on the other side. This 45° angle connector is mostly useful in cases where ¼” threads are too close to one another and larger hose connections do not fit next to each other. Design With brilliant chrome, deep matt black and decent matt white, three colour variants are available that fit perfectly into any system. Thanks to special processes, the coatings are firmly bonded to the substrate. This ensures a high longevity of the colours and prevents the coating from flaking off. The connector now also has the Alphacool logo, which makes it unique in addition to its special shape! Technical details Material Brass Colour White Length 35 mm Diameter 18 mm Thread G1/4“ Thread length 5 mm Weight 34 g Download Datenblatt PDF: Alphacool Eiszapfen angled adaptor 45° rotatable G1/4 outer thread to G1/4 inner thread - White Fitting Map: You can find an interactive map of all Alphacool fittings here.
Alphacool's Eiszapfen is the high-end version of the already proven connectors and meets all the requirements placed on a connector with its high-flow, shape, processing and colour. Compatibility This 90° angled adapter has a rotatable 1/4" external thread on one side and a 1/4" internal thread on the other. This 90° angled connection is mostly used where space is limited and a special solution is required. For maximum flexibility, the adapter can be rotated on the external thread. Design With brilliant chrome, deep matt black and decent matt white, three colour variants are available that fit perfectly into any system. Thanks to special processes, the coatings are firmly bonded to the substrate. This ensures a high longevity of the colours and prevents the coating from flaking off. The connector now also has the Alphacool logo, which makes it unique in addition to its special shape! Technical details Material Brass Colour White Length 34 mm Diameter 18 mm Thread G1/4“ Thread length 5 mm Weight 38 g Download Datasheet PDF: Alphacool Eiszapfen L-connector rotatable G1/4 outer thread to G1/4 inner thread - White Fitting Map: You can find an interactive map of all Alphacool fittings here.
240-mm-Radiator mit 44 mm Dicke, Finnen und Kanäle aus Kupfer, exklusives Modding-Design, 5x G1/4-Zoll-Anschlüsse, hochwertige Verarbeitung, geeignet für Custom-Loops
240-mm-Radiator mit 44 mm Dicke, Finnen und Kanäle aus Kupfer, exklusives Modding-Design, 8x G1/4-Zoll-Anschlüsse, hochwertige Verarbeitung, geeignet für Custom-Loops
