EK-Quantum Vector FE RTX 3080 Backplate - Black is a CNC machined retention backplate made from black anodized aluminum for the EK-Quantum Vector FE RTX 3080 - Special Edition water block. The backplate covers the backside of the graphics card's PCB and serves as an aesthetic add-on. It provides additional passive cooling for the GPU core and rear of the printed circuit board VRM section. Due to the small size of both the card and the water block, the backplate boasts a ribbed design for additional passive cooling power. Enclosed EK-Quantum Vector FE RTX 3080 Backplate - Black Mounting screws Thermal pads
The connection for 16mm (AD) Hard Tubes from EK Water Blocks, is a compression fitting made of nickel-plated brass. It is silver in colour and comes from the Torque series, which convinces with a simple and timeless design. Originally intended for the EKWB Quantum series, this fitting is also compatible with other EK products. In this fitting, the union nut serves as a compression ring, which presses the sealing ring onto the hard tube. It thus offers a higher level of safety and sealing than, for example, the fittings of the EK-HD series. As a small feature, the union nut has a recess under which coloured rings are placed, which provide a bit of individuality and are available separately. Technical Data: Material: Nickel-Plated Brass Colour: Silver Supported Tube: 16 mm OD Thread: G1/4", male Thread Length: 4,5 mm Outer Diameter (Fitting): 24 mm Installed Height: 15 mm Compatible Solid Tubing: Acrylic, PETG, Copper, Brass, Stainless Steel
The Alphacool Rise fan offers a wide range of control as well as superior Digital RGB LED lighting. The individually controllable 5V aRGB LEDs paired with the fan's special design can create some unique effects whilst offering performance. Brilliant illumination There are 20 digitally addressable 5V RGB LEDs built into the frame and hub that illuminate the entire fan. This creates a unique illumination that looks very impressive. Thanks to the recessed light diffusers, the light is distributed evenly, and you will not see sporadic uneven lighting. Wide control range and silent The fan can be controlled from 0 to 2500 rpm via the 4-pin PWM connector. In addition, it offers a silent mode, with which the fan can be regulated down to 0 rpm and then they will only start when they are needed above 350rpm. At 800 rpm, the fan is nearly silent, but still offers a good airflow (118.9m3/h) paired with a high static pressure (3.17mm/H2O). This makes the fan perfect for mounting on radiators of a water cooling system or for alternatively, as a case fan. Decouplers are located directly on the corners of the frame. The soft foam pads reduce the transmission of vibrations to the case, which in turn reduces noise. Tear-off edges on the fan blades also provide a significant reduction in noise. Connectors? The fan is controlled via a 4-pin PWM connector. The cable is 40 cm long. This allows the fan to be connected to the motherboard or a fan controller without the need for additional adapter cables or extensions. The digital aRGB LED illumination is controlled via a JST 3-pin connector and adapters are available to change this into a standard 3 pin aRGB connector if required. Note: The cable for connecting the ARGB LEDs is not included in the scope of delivery, but is optionally available in the shop! (Art. 18604, Alphacool connection cable 3pin to 3pin Digital RGB) Technical Data fan L x W x H 120 x 120 x 25 mm Speed 0—2500 rpm (+/-10%) Bearing Sleeve Bearing Connection 4-Pin PWM Cable length 40 cm Voltage 12V DC Current consumption. 0,65A (0,72 max) Static pressure 3,17 H2O Max. air flow 118,9 m³/h Noise max. 31,5 dB(A) MTBF 50.000h Speedometer signal Yes Auto-Restart Yes Technical data digital RGB LED type 5V aRGB Connection 3-Pin JST Cable length 50cm (Splitter after 40cm) Max. current consumption LEDs 3,5W LED quantity Frame: 12 / Hub: 8 Download Data sheet PDF: Alphacool Rise Aurora 120 mm fan (120x120x25mm)
Drehbarer 90-Grad-Winkel-Adapter, Teil der EKWB-Quantum-Linie, zur Verbindung von G1/4-Zoll-Außen- mit G1/4-Zoll-Innengewinden, vernickeltem und satiniertem Messing
The Alphacool Eiszapfen is a rotatable 8 mm offset fitting with one internal thread and one external thread that can be easily tied into any water circuit. Integration made easy The offset piece is very compact and can be integrated into any water cooling system thanks to its G1/4" internal and external threads. It is simply screwed onto the corresponding G1/4" connections at the desired position in the water circuit. Design The threads are 5mm deep and 5mm high respectively, thus enabling the very compact design. The offset piece can also be rotated 360°, which provides additional flexibility for integration even in the tightest cases. Coloured O-rings In addition to the standard black O-ring, 3 more O-rings in red, yellow and blue are included.Compatibility:G1/4" OT/IT threads Technical data L x W x H 24 x 22,5 x 18,5mm Material brass Offset 8mm Threads G1/4" IT, G1/4" OT Thread depth 5mm Thread height 5mm Weight 28g Color black
The new Eiszapfen PRO hard tube fittings from Alphacool are the next step in development for the familiar Eiszapfen fittings. In the development of the fittings Alphacool concentrated on a specific problem, deforming PETG hard tubes at high temperatures. PETG can start to deform at 60°C. Although such a temperature is usually rarely reached, it can still occur. The Eiszapfen PRO fittings prevent this problem from the outset and hold the tubes in position. The deformation is prevented by the new nylon inserts inside and stabilizes the hard tubes. Furthermore, the fitting still has an O-ring and a compression seal. However, the contact area is much larger than with normal O-rings, which provides a better grip. With the insert and the compression seal, the tube is strengthened from the inside and outside. Even under heavy loads the HardTube does not slip. Alphacool has tested the tensile strength of up to over 8kg, so there is no need to worry about loose tubing. Technical details: Material: brass Colour: Deep Black Diameter: 22 mm Height: 20 mm Thread: G1/4" Thread length: 5 mm HardTube size: 13 mm Compatibility: PETG, acrylic, brass and glass tubes Weight: 0,023 kg Scope of supply: 1x Alphacool Eiszapfen PRO 13mm HardTube Fitting G1/4 - Deep Black
BLAST FAN SET 3 x 120mm ARGB 3-pin 5V, 4-pin 12V fan Technical specifications: Number of fans included: 3 pcs. Fan size: 120 mm. LED voltage: 5 V. LED connector: 3-pin (male + female). Fan voltage: 12 V. Fan connector: 4-pin (PWM) (male + female). Backlighting: ARGB. Additional power supply for the main fan: SATA. Backlight and speed control: via motherboard, RESET / LED button. Max speed: 800-1800 RPM. Max noise level: 25 dBA. Max possible number of fans connected to the master fan: 9 pcs. Kit contents: 1 × ARGB master fan. 2 × ARGB slave fans. 12 × fan mounting screws. Size and shape The Savio BLAST fan set consists of 3 pieces with a standard 120 mm size and a maximum speed of up to 1800 RPM. They guarantee very effective cooling of your computer. The unique design of the fans rims provides amazing lighting effects inside the case. ARGB backlighting Each BLAST fan features 9 integrated ARGB LEDs that provide impressive lighting effects. You can customize the color of the lighting according to your personal preference, needs and even according to the time of day. The wide variety of colors greatly enhances the gaming experience, which translates into greater gaming satisfaction and builds the mood in the gamers room. Backlight control The backlighting control of the BLAST fans from Savio is done via a 3-pin 5V ARGB connector. Once it is connected to a motherboard equipped with the appropriate slot, it is possible to address individual LEDs for advanced lighting effects. Each of the fans has an integrated adapter. It allows them to be connected in series and powered from a single socket in case the motherboard does not have the required number of them. Speed control (PWM) BLAST features a 4-pin connector that allows infinite speed control via the motherboards built-in PWM controller. Fan speed control can be implemented via UEFI/BIOS and dedicated software. These options give you access to basic settings, where you can determine the fan speed depending on the temperature inside the case or according to your preferences. High operating culture The fans in the Savio kit, thanks to their 9-blade design, provide high airflow inside the computer case. The anti-vibration pads used significantly minimize the generated noise and unwanted vibrations. With BLAST you can be sure that the noise level will not exceed 25 dBA. Effortless installation is facilitated by the included 12 x mounting screws.
An extension cable for 4-pin PWM fans. Available in various lengths. Sleeving provides additional protection, stability and increased lifetime. Technical detailsLength30cmConnections4-pin to 4-pinMaterialPlastic, sleevedColorwhite
The ULTITUBE D5 PRO LEAKSHIELD from Aquacomputer, comes as a combination, consisting of expansion tank and leakshield. The borosilicate glass expansion tank, with a diameter of 65mm, has a very high hardness and scratch resistance, as well as very low thermal expansion and excellent chemical and thermal resistance. The base and the lid of the reservoir are made of acetal. In addition, a filter element is integrated in the base, which is easy to clean under running water, for example. The filter also reduces air bubbles. The ULTITUBE is rounded off with an impressive RGBpx-compatible LED ring, with 13 addressable LEDs. This can be easily connected to the D5 NEXT pump. With the LEAKSHIELD, the user almost no longer needs to worry about the tightness of his water cooling. Thanks to its negative pressure, the LEAKSHIELD actively protects against leaks. This means that no more coolant leaks out of the system. Of course, it does not protect against major damage, such as torn tubes. The air that enters is then pumped out of the system by the integrated vacuum pump. Even before the water cooling system is put into operation for the first time, the LEAKSHIELD checks the system for leaks by creating a vacuum. The system is then checked for pressure changes. It can also simplify filling by drawing the coolant directly from the bottle through a suction line. Technical Data Coolant capacity: approx. 230 ml Connection threads: G1/4" D5 NEXT Supply voltage: 5V, 12V D5 NEXT Maximum power consumption: 65 W (including fan and RGBpx output) D5 NEXT Maximum fan output power: 25 watts D5 NEXT Maximum pump head: 3.7 m / 370 mbar LEAKSHIELD Generated negative pressure: max. -450 mbar LEAKSHIELD Supply voltage: 5 V DC via USB LEAKSHIELD Current consumption: max. 500 mA Dimensions incl. D5 NEXT pump and LEAKSHIELD: approx. 72 x 77 x 227 mm (All dimensions without mounting material) The number 100/150/200 in the Ultitube series product name refers to the length of the glass tube in millimeters. Scope of delivery: One reservoir with integrated pump RGBpx compatible LED ring RGBpx cable, length 50 cm Rubber fixation ring with stainless steel insert Two internal USB cables, length approx. 100 cm Mounting material System requirements Windows 8.1 or newer Internal USB 2.0 port
A water cooling system consists of many different elements: pumps, radiators, cooling blocks, reservoirs, and often other components. To create a functional water cooling system, these parts need to be connected together. The easiest way to do this is with tubing. Here, the Alphacool AlphaTube HF tubing is the best choice.AppearanceAvailable in various vivid colors, transparent, and also UV-active options, the AlphaTube HF tube offers a large selection of colors and styles, making it easy to find the hose that best matches your taste.ApplicationThe AlphaTube HF tubing features ideal flexibility for easy installation. It is flexible enough to be laid effortlessly yet rigid enough so that it does not kink easily, even with tighter bending radii.Available in different sizes.We offer the AlphaTube HF hose in all common sizes.Technical data:Length: 1 mTube size: OD 13 mm / ID 10 mmMaterial: PVCHardness grade: 65-70 A-ShoreWorking temperature: -10 - 80°CBurst pressure: 8 barWorking pressure: 2 bar Download data sheet PDF: Alphacool tubing AlphaTube HF 13/10 (3/8"ID) - Ultra Clear 1m (3,3ft) Retailbox
The FN121-P builds upon the excellent FN121 and FM121 fan designs with optimized 9 blade fan design and frame geometry to improve performance and reduce noise level at the same time.- High performance for system thermal solution- High airflow and less noise with 9-bladed designTüüpVentilaatorVentilaatori läbimõõt12 cmToetatud protsessoripesadEi ole toetatudÜhilduvad protsessoriseeriadEi ole toetatudPöörlemiskiirus (max)1200 RPMMüratase (suur kiirus)25,15 dBMaksimaalne õhuvool58,47 cfmMaksimaalne õhusurve1,12 mmH2OToote värvMustToiteallikas1,32 WPinge13.8Laius120 mmSügavus25 mmKõrgus120 mm
When putting down, nothing beats smooth and easy. That is why we created the PK-2 thermal compound. The PK-2 thermal compound is a high performance thermal bonding agent specially designed for easy application.PK-2's core feature is its low viscosity, allowing for one to quickly and easily apply the thinnest coat of thermal compound possible.This will get your components up close and personal in no time.Soojusjuhtivus10,2 W/m·KKaal5 g
Dust can be a computer system’s worst enemy as it has the potential to lower cooling performance or cause damage when left overly accumulated. But most fan filters are a hassle to install so SilverStone created an easy to use FF143 fan filter.The FF143 has embedded magnet in its frame so it can be effortlessly attached to any steel chassis without tools. Its 140mm size is also compatible with most 120mm fan vents so it can be used in many places that require filtering. For those looking for dust reduction for component longevity with increased cooling efficiency, the FF143 is an excellent buy.- Convenient magnetized design for easy installation- Ultra fine filter provides great dust reduction properties- Compatible with most 140mm fans or ventsSobilikKiibistikVentilaatori läbimõõtEiToetatud protsessoripesadEi ole toetatudÜhilduvad protsessoriseeriadEi ole toetatudToote värvMustLaius140 mmSügavus1,5 mmKõrgus140 mmKaal17 g
