ATRM50 on transportimiseks loodud vastupidav 5G-ruuter, millel on 4 x M12 Gigabit Etherneti porti ja M12 toite sisend, mis tagavad püsivad ja turvalised ühendused. See pakub ülisuurt mobiilside kiirust kuni 3,4 Gbps ja toetab kahe SIM-kaardi kasutamist koos eSIM™-iga, mis tagab sujuva ülemineku. ATRM50 on sertifitseeritud standardite EN 45545-2 ja EN 50155 kohaselt ning on konstrueeritud vastama raudteesüsteemide rangetele ohutus- ja töökindlusnõuetele, sobides samas hästi ka muudesse nõudlikesse transpordikeskkondadesse. Ruuter on varustatud GNSS-iga, integreeritud kinnitusklambriga ja ühilduv RMS-iga, mis võimaldab tõhusat kohapealset ja kaugjuhtimist.M12-PISTIKUD4 × M12 X-koodiga Gigabit Etherneti porti, 1 × M12 A-koodiga toite sisend.5GÜlikõrge mobiilside kiirus kuni 3,4 Gbps.DUAL SIM & eSIM™Automaatse ümberlülitamise, varu-WAN-i ja muude ümberlülitamise stsenaariumidega.SertifikaadidEN 45545-2 ja EN 50155MobileMobile module5G Sub-6 GHz SA, NSA 2.4, 3.4Gbps DL (4x4 MIMO) 900, 550Mbps UL (2x2 MIMO); 4G LTE: DL Cat 19 1.6Gbps (4x4 MIMO), UL Cat 18 200Mbps; 3G 42 Mbps (DL)/ 5.76 Mbps(UL) 3GPP ReleaseRelease 16eSIMConsumer type eSIM, profile download and removal operations, up to 7 eSIM profiles; does not include data plansSIM switchDual sim cards and esim, auto-switch cases: weak signal, data limit, SMS limit, roaming, no network, network denied, data connection failStatusIMSI, ICCID, operator, operator state, data connection state, network type, CA indicator, bandwidth, connected band, signal strength (RSSI), SINR, RSRP, RSRQ, EC/IO, RSCP, data sent/received, LAC, TAC, cell ID, ARFCN, UARFCN, EARFCN, MCC, and MNCSMSSMS status, SMS configuration, EMAIL to SMS, SMS to EMAIL, SMS to HTTP, SMS to SMS, scheduled SMS, SMS autoreply, SMPPUSSDSupports sending and reading Unstructured Supplementary Service Data messagesBlock/Allow listOperator block/allow list (by country or separate operators)Multiple PDNPossibility to use different PDNs for multiple network access and servicesBand managementBand lock, Used band status displaySIM idle protection serviceProvides the possibility to configure the router to periodically switch to the unused SIM card and establish a data connection in order to prevent the SIM card from being blockedSIM PIN code managementSIM PIN code management enables setting, changing, or disabling the SIM card's PINAPNAuto APNBridgeDirect connection (bridge) between mobile ISP and device on LANPassthroughRouter assigns its mobile WAN IP address to another device on LANFramed routingFramed routing: support an IP network behind 5G UEWirelessWireless mode802.11b/g/n/ac Wave 2 (Wi-Fi 5) with data transmission rates up to 867 Mbps (Dual Band, MU-MIMO)Wi-Fi securityWPA2-Enterprise: PEAP, WPA2-PSK, WPA-EAP, WPA-PSK, WPA3-SAE, WPA3-EAP, OWE; AES-CCMP, TKIP, Auto-cipher modes, client separation, EAP-TLS with PKCS#12 certificates, disable auto-reconnect, 802.11w Protected Management Frames (PMF)SSID/ESSIDSSID stealth mode and access control based on MAC addressWi-Fi usersUp to 150 simultaneous connectionsWireless Connectivity FeaturesWireless mesh (802.11s), fast roaming (802.11r), Relayd, BSS transition management (802.11v), radio resource measurement (802.11k)Wireless MAC filterAllowlist, blocklistWireless QR code generatorOnce scanned, a user will automatically enter your network without needing to input login informationTravelMateForward Wi-Fi hotspot landing page to a subsequent connected deviceEthernetWAN1 x WAN port 10/100/1000 Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX crossoverLAN3 x LAN ports, 10/100/1000 Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX crossoverNetworkRoutingStatic routing, Dynamic routing (BGP, OSPF v2, RIP v1/v2, EIGRP, NHRP), Policy based routingNetwork protocolsTCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SFTP, FTP, SMTP, SSL/TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SNMP, MQTT, Wake On Lan (WOL), VXLANVoIP passthrough supportH.323 and SIP-alg protocol NAT helpers, allowing proper routing of VoIP packetsConnection monitoringPing Reboot, Wget Reboot, Periodic Reboot, LCP and ICMP for link inspectionFirewallPort forward, traffic rules, custom rules, TTL target customisationFirewall status pageView all your Firewall statistics, rules, and rule countersPorts managementView device ports, enable and disable each of them, turn auto-configuration on or off, change their transmission speed, and so onNetwork topologyVisual representation of your network, showing which devices are connected to which other devicesHotspotCaptive portal (hotspot), internal/external Radius server, Radius MAC authentication, SMS authorisation, SSO authentication, internal/external landing page, walled garden, user scripts, URL parameters, user groups, individual user or group limitations, user management, 9 default customisable themes and optionality to upload and download customised hotspot themesHotspot 2.0Hotspot 2.0 is a Wi-Fi standard that enables seamless, secure, and automatic connection to trusted wireless networksDHCPStatic and dynamic IP allocation, DHCP relay, DHCP server configuration, status, static leases: MAC with wildcardsQoS / Smart Queue Management (SQM)Traffic priority queuing by source/destination, service, protocol or port, WMM, 802.11eDDNSSupported >25 service providers, others can be configured manuallyDNS over HTTPSDNS over HTTPS proxy enables secure DNS resolution by routing DNS queries over HTTPSNetwork backupWi-Fi WAN, Mobile, VRRP, Wired options, each of which can be used as an automatic FailoverLoad balancingBalance Internet traffic over multiple WAN connectionsSSHFSPossibility to mount remote file system via SSH protocolVRF supportInitial virtual routing and forwarding (VRF) supportTraffic ManagementReal-time monitoring, wireless signal charts, traffic usage historySecurityAuthenticationPre-shared key, digital certificates, X.509 certificates, TACACS+, Internal & External RADIUS users authentication, IP & login attempts block, time-based login blocking, built-in random password generatorFirewallPreconfigured firewall rules can be enabled via WebUI, unlimited firewall configuration via CLI, DMZ, NAT, NAT-T, NAT64Attack preventionDDOS prevention (SYN flood protection, SSH attack prevention, HTTP/HTTPS attack prevention), port scan prevention (SYN-FIN, SYN-RST, X-mas, NULL flags, FIN scan attacks)VLANPort and tag-based VLAN separationMobile quota controlMobile data limit, customizable period, start time, warning limit, phone numberWEB filterBlacklist for blocking out unwanted websites, Whitelist for specifying allowed sites onlyAccess controlFlexible access control of SSH, Web interface, CLI and TelnetTPMIdentification and authentication module, TPM 2.0 standardSSL certificate generationLet's Encrypt and SCEP certificate generation methodsVPNOpenVPNMultiple clients and a server can run simultaneously, 27 encryption methodsOpenVPN EncryptionDES-CBC 64, RC2-CBC 128, DES-EDE-CBC 128, DES-EDE3-CBC 192, DESX-CBC 192,BF-CBC 128, RC2-40-CBC 40, CAST5-CBC 128, RC2-64-CBC 64, AES-128-CBC 128, AES-128-CFB 128, AES-128-CFB1 128, AES-128-CFB8 128, AES-128-OFB 128, AES-128-GCM 128, AES-192-CFB 192, AES-192-CFB1 192, AES-192-CFB8 192, AES-192-OFB 192, AES-192-CBC 192, AES-192-GCM 192, AES-256-GCM 256, AES-256-CFB 256, AES-256-CFB1 256, AES-256-CFB8 256, AES-256-OFB 256, AES-256-CBC 256IPsecXFRM, IKEv1, IKEv2, with 14 encryption methods for IPsec (3DES, DES, AES128, AES192, AES256, AES128GCM8, AES192GCM8, AES256GCM8, AES128GCM12, AES192GCM12, AES256GCM12, AES128GCM16, AES192GCM16, AES256GCM16)GREGRE tunnel, GRE tunnel over IPsec supportPPTP, L2TPClient/Server instances can run simultaneously, L2TPv3, L2TP over IPsec supportStunnelProxy designed to add TLS encryption functionality to existing clients and servers without any changes in the program’s codeDMVPNMethod of building scalable IPsec VPNs, Phase 2 and Phase 3 and Dual Hub supportSSTPSSTP client instance supportZeroTierZeroTier VPN client supportWireGuardWireGuard VPN client and server supportTincTinc offers encryption, authentication and compression in it's tunnels. Client and server support.TailscaleTailscale offers speed, stability, and simplicity over traditional VPNs. Encrypted point-to-point connections using the open source WireGuard protocolOPC UASupported modesClient, ServerSupported connection typesTCPMODBUSSupported modesServer, ClientSupported connection typesTCP, USBCustom registersMODBUS TCP custom register block requests, which read/write to a file inside the router, and can be used to extend MODBUS TCP Client functionalitySupported data formats8-bit: INT, UINT; 16-bit: INT, UINT (MSB or LSB first); 32-bit: float, INT, UINT (ABCD (big-endian), DCBA (little-endian), CDAB, BADC), HEX, ASCIIDATA TO SERVERProtocolHTTP(S), MQTT, Azure MQTTData to serverExtract parameters from multiple sources and different protocols, and send them all to a single server; Custom LUA scripting, allowing scripts to utilize the router's Data to server featureMQTT GatewayModbus MQTT GatewayAllows sending commands and receiving data from MODBUS Server through MQTT brokerDNP3Supported modesStation, OutstationSupported connectionTCP, USBDLMS/COSEMDLMS SupportDLMS - standard protocol for utility meter data exchangeSupported modesClientSupported connection typesTCPAPITeltonika Networks Web API (beta) supportExpand your device's possibilities by using a set of configurable API endpoints to retrieve or change data. For more information, please refer to this documentation: https://developers.teltonika-networks.comMonitoring & ManagementWEB UIHTTP/HTTPS, status, configuration, FW update, CLI, troubleshoot, multiple event log servers, firmware update availability notifications, event log, system log, kernel log, Internet statusFOTAFirmware update from server, automatic notificationSSHSSH (v1, v2)SMSSMS status, SMS configurationCallReboot, Status, Mobile data on/off, Output on/off, answer/hang-up with a timer, Wi-Fi on/offEmailReceive email message status alerts of various servicesTR-069OpenACS, EasyCwmp, ACSLite, tGem, LibreACS, GenieACS, FreeACS, LibCWMP, Friendly tech, AVSystemMQTTMQTT Broker, MQTT publisherSNMPSNMP (v1, v2, v3), SNMP Trap, Brute force protectionJSON-RPCManagement API over HTTP/HTTPSRMSTeltonika Remote Management System (RMS)IoT PlatformsThingWorxAllows monitoring of: WAN Type, WAN IP, Mobile Operator Name, Mobile Signal Strength, Mobile Network TypeCumulocity - Cloud of ThingsAllows monitoring of: Device Model, Revision and Serial Number, WAN Type and IP, Mobile Cell ID, ICCID, IMEI, Connection Type, Operator, Signal Strength. Has reboot and firmware upgrade actionsAzure IoT HubCan be configured with Data to Server to send all the available parameters to the cloud. Has Direct method support which allows to execute RutOS API calls on the IoT Hub. Also has Plug and Play integration with Device Provisioning Service that allows zero-touch device provisioning to IoT HubsAWS IoT CoreUtility to interact with the AWS cloud platform. Jobs Support: Call the device's API using AWS Jobs functionalitySystem CharacteristicsCPUMediaTek, Dual-Core, 880 MHz, MIPS1004KcRAM256 MB, DDR3FLASH storage16 MB serial NOR flash, 256 MB serial NAND flashFirmware / ConfigurationWEB UIUpdate FW from file, check FW on server, configuration profiles, configuration backupFOTAUpdate FWRMSUpdate FW/configuration for multiple devices at onceKeep settingsUpdate FW without losing current configurationFactory settings resetA full factory reset restores all system settings, including the IP address, PIN, and user data to the default manufacturer's configurationFIRMWARE CUSTOMISATIONOperating systemRutOS (OpenWrt based Linux OS)Supported languagesBusybox shell, Lua, C, C++, and Python, Java in Package managerDevelopment toolsSDK package with build environment providedGPL customizationYou can create your own custom, branded firmware and web page application by changing colours, logos, and other elements in our firmware to fit your or your clients’ needsPackage ManagerThe Package Manager is a service used to install additional software on the deviceLocation TrackingGNSSGPS, GLONASS, BeiDou, Galileo and QZSSCoordinatesGNSS coordinates via WebUI, SMS, TAVL, RMSNMEANMEA 0183NTRIPNTRIP protocol (Networked Transport of RTCM via Internet Protocol)Server softwareSupported server software TAVL, RMSGeofencingConfigurable multiple geofence zonesUSBData rateUSB 2.0ApplicationsSamba share, USB-to-serialExternal devicesPossibility to connect external HDD, flash drive, additional modem, printer, USB-serial adapterStorage formatsFAT, FAT32, exFAT, NTFS (read-only), ext2, ext3, ext4Input / OutputInput2 x Inputs for Ignition Detection and Low BatteryEventsEmail, RMS, SMSI/O jugglerAllows to set certain I/O conditions to initiate eventSD CARDPhysical sizeMicro SD (internal)Applications Samba shareCapacityUp to 2 TBStorage FormatsFAT32, NTFS, ext2, ext3, ext4PowerConnectorM12 A code 4 pin maleInput voltage range9 - 50 VDC, reverse polarity protection, Overvoltage protection (70V), Surge protection >69 VDC 10us maxPower consumptionIdle: < 5.5 W, Max: < 16 WPhysical InterfacesEthernet4 x M12 X code 8-pin female ports, 10/100/1000 MbpsI/O’s2 x Input (Ignition detection/Low battery)Status LEDs4 x WAN type, 3 x Mobile connection type, 3 x Mobile connection strength, 6 x LAN status, 2 x WAN status, 1 x Power, 2 x 2.4G and 5G Wi-FiSIM2 x SIM slots (Mini SIM - 2FF), 1.8 V/3 VPower1 x M12 A code 4-pin male connectorAntennas4 x SMA for Mobile, 2 x RP-SMA for Wi-Fi, 1 x SMA for GNNSUSB1 x USB A port for external devicesResetReboot/User default reset/Factory reset buttonOther1 x Grounding screwPhysical SpecificationCasing materialAnodized aluminum housing and panelsDimensions (W x H x D)167 x 46.2 x 112.4 mmWeight550 gMounting optionsFlat surfaceOperating EnvironmentOperating temperature-40 °C to 75 °COperating humidity10% to 90% non-condensingIngress Protection RatingIP30Regulatory & Type ApprovalsRegulatoryCE, UKCA, RCM, R-NZ, CB, EAC, UCRF, WEEEVehicleE-mark, RailwayEMC Emissions & ImmunityStandardsEN 55032:2015+ A11:2020 + A1:2020EN 55035:2017+A11:2020EN 61000-3-3:2013+A1:2019+A2:2021EN IEC 61000-3-2:2019+A1:2021EN 301 489-1 V2.2.3EN 301 489-3 V2.3.2EN 301 489-17 V3.2.4EN 301 489-52 V1.2.1AS/NZS CISPR 32:2015+A1:2020ESDEN 61000-4-2:2009Radiated ImmunityEN IEC 61000-4-3:2020EFTEN 61000-4-4:2012Surge Immunity (AC Mains Power Port)EN 61000-4-5:2014+A1:2017CSEN 61000-4-6:2014DIPEN 61000-4-11:2020RFStandardsEN 300 328 V2.2.2EN 301 893 V2.1.1EN 300 440 V2.2.1EN 301 908-1 V15.2.1EN 301 908-2 V13.1.1EN 301 908-13 V13.2.1EN 301 908-25 V15.1.1AS/NZS 4268:2017+A1:2021AS/CA S042.1:2022AS/CA S042.4:2022AS/CA S042.5:2022+A1:2022FCC Part 22SafetyStandardsEN IEC 62311:2020EN IEC 62368-1:2020+A11:2020AS/NZS 2772.2:2016+A1:2018
