To attach DIN rail adapter to the device: 1. Locate the groove for attaching adapter on the bottom of the device. 2. Line up smaller holes in the middle of DIN rail adapter with the groove on the device. 3. Secure adapter with two self-tapping screws.
The UFiber splitter carries data from a UFiber OLT’s long-haul cable and shares it with multiple UFiber ONUs. Available with 4, 8, 16, or 32 outputs. PLC Splitters UF-SPLITTER-4 UF-SPLITTER-8 UF-SPLITTER-16 UF-SPLITTER-32 Input (1) SC/APC (1) SC/APC (1) SC/APC (1) SC/APC Outputs (4) SC/APC (8) SC/APC (16) SC/APC (32) SC/APC Insertion Loss with Connectors 7.4 dB 10.5 dB 13.7 dB 17.0 dB Uniformity Loss 0.6 dB 0.8 dB 1.2 dB 1.5 dB Polarization Dependent Loss 0.3 dB 0.3 dB 0.3 dB 0.3 dB Wavelength Bandwidth 1260-1650 nm 1260-1650 nm 1260-1650 nm 1260-1650 nm Return Loss (All Ports) 50 dB 50 dB 50 dB 50 dB Directivity 55 dB 55 dB 55 dB 55 dB Fiber Type G657A1 G657A1 G657A1 G657A1 Operating Temperature -40 to 85° C (-40 to 185° F) -40 to 85° C (-40 to 185° F) -40 to 85° C (-40 to 185° F) -40 to 85° C (-40 to 185° F) Total Length 4.06m (13.32') 4.06 m (13.32') 4.06 m (13.32') 4.08 m (13.39') Weight 58 g (2.0 oz) 62 g (2.2 oz) 110 g (3.9 oz) 160 g (5.6 oz)
Kit for mounting RB5009 devices in 1U rackmounts. With this kit you can mount up to four RB5009UG+S+IN routers in a single 1U rackmount space! No more server-room-Tetris just pure productivity.
±48 V DC telecom Open Frame Power supply with 12 V 7 A output for use with Cloud Core Routers since revision "r2" or the new CCR2004-1G-12S+2XS and CRS326-24S+2Q+RM. Simply remove one of the current power supplies and replace with the new PW48V-12V85W for ±48 V installations. Although made specifically for -48V telecom power the supported input range is from 36V to 57V. Note: To use positive terminal must be 36 to 57V higher potential than negative terminal (eg. if negative terminal is -48 V the positive must be -12 to +9 V). Send purchase questions
Vertically and Horizontally AdjustableAvailable now, the Ubiquiti Networks Window/Wall Mounting kit for NanoStation. The kit comes with interchangeable mounting adapters(suction mount for window, wall screws for wall) so the NanoStation can be easily fitted on a window or wall. Vertically and horizontally adjustable.
Using airMAX ac technology, the IsoStation 5AC supports up to 450+ Mbps real TCP/IP throughput. It also offers the following features:Interchangeable horn antennas for enhanced beam shapingHorn feed comes directly from the radio input/output so connectors are eliminatedSingle button release for ease of changing antennasAll metal, shielded radio baseMetal strap for quick pole-mountingThe IsoStation 5AC comes with a 45° isolation antenna. Ubiquiti offer three optional antennas with precise radiation angles for specific beam shaping, so you can customize the IsoStation 5AC for your specific installation requirements:30°60°90°All horn antennas are optimized for co-location. The asymmetrical versions (60° and 90°) narrow the elevation pattern to increase gain where users need it.
CCR1072-1G-8S+ is equipped with two redundant Hot Swap 12v 150W AC/DC power supplies - if one of them goes out of order, second one will take over. Hot Swap 12v 150W AC/DC power supplies for CCR1072-1G-8S+ are now available for purchase separately. You can replace them on the go to ensure zero downtime, no need to even restart the router
Built to Fight Noise With Prism Active RF Filter The Ubiquiti R&D team designed airPrism filtering as a robust solution for tower co-location interference. Requiring no communication between radios – and functioning despite noise from other vendors’ radios (unlike GPS synchronization) – airPrism enables greater system capacity and overall throughput by further reducing out-of-band energy. Using airMAX ac technology, the PrismStationTM delivers throughput speeds up to 500+ Mbps and signal ranges up to 5+ km (3+ miles). It also offers the following features:All horn antennas are optimized for co-location. The asymmetrical versions (60° and 90°) narrow the elevation pattern to increase gain where users need it.Ubiquiti offer three optional antennas with precise radiation angles for specific beam shaping, so you can customize the PrismStation 5AC for your specific installation requirements:Interchangeable horn antennas for enhanced beam shapingHorn feed comes directly from the radio input/output so connectors are eliminatedSingle button release for ease of changing antennasAll metal, shielded radio baseMetal strap for quick pole-mounting30°60°90°Management Wi-Fi Radio The PrismStationTM AC integrates a separate Wi-Fi radio for fast and easy setup using your mobile device.Enhanced Co-Location Asymmetrical horn antenna options (60° and 90°) have naturally attenuated side lobes and extremely low back radiation, and they offer industry-leading front-to-back ratio and low side lobe radiation. Symmetrical horn antennas (30° and 45°, the default) are ideal for cluster sector installations with high co-location requirements.Improved Noise Immunity PrismStationTM AC blocks or spatially filters out noise,so noise immunity is improved.This feature is especially important in an area crowded with other RF signals of the same or similar frequency. Hight MAC Efficiency High MAC efficiency provides ±80% PHY RATE throughput. Modular Design The antenna horn is interchangeable and helps with beam-shaping for specific deployment and environment needs. The PrismStationTM AC also gets maximum gain out of the smallest footprint. Beam Performance Perfected The PrismStationTM can use a variety of horn antenna sectors designed for increased co-location performance without sacrificing gain. Its unique beam performance and superb co-location characteristics allow for a higher density of sectors than traditional sector technology. Now with airOS®8 Sporting an all-new design for improved usability, airOS® 8 is the revolutionary operating system for Ubiquiti® airMAX® ac products
The active GPS antenna is the perfect companion for the LtAP mini, giving you the possibility to get accurate geographical coordinates of your router, even when it is mounted indoors. The long cable allows to bring the antenna outside and mount it with the included magnet, or double sided tape.The ACGPSA is a standalone active GPS antenna, specifically made for the 1575.4 MHz frequency used by GPS. The size of the antenna is 46.5 mm x 26.5 mm x 12.5 mm and is waterproof with IP67 rating. It has a long 5 m cable with an SMA connector, to be connected to LtAP mini via the ACSMAUFL pigtail (available for ordering separately).Specifications: Center frequency1575.42 MhzGain26 dBWater resistance100% waterproof (IP67)ConnectorSMACable5 m RG-174/U (standard)Standard mountingMagnetic baseDC voltages3 V +-0.3 VDC current8 mA maxDimensions46.5 x 46.5 x 12.5 mmWeight35 g, 120 g (with cable and connector)Operating temperature-40°C .. +85°C tested
Ubiquiti Networks set the bar for the world's first low-cost and efficient broadband Customer Premises Equipment (CPE) with the NanoStation® M. The NanoStation AC and NanoStation AC loco take the same concept to the future with sleek form factors, along with integrated airMAX (MIMO TDMA protocol) technology and dedicated Wi-Fi management. The radio and antenna are combined to create a more efficient and compact CPE. The NanoStation AC and NanoStation AC loco get maximum gain out of the smallest footprint. The low cost, high performance, and small form factor of the NanoStation AC and NanoStation AC loco make them extremely versatile and economical to deploy. Sleek Industrial Design The NanoStation AC and NanoStation AC loco represent the next evolution of the iconic CPE design that revolutionized the Wireless ISP industry. Dual Ethernet Connectivity The NanoStation AC provides a secondary Ethernet port with software-enabled PoE. Use this port to conveniently power an external device, such as a PoE security camera, for seamless IP video integration.Management Wi-Fi Radio Each NanoStation AC model integrates a separate Wi-Fi radio for fast and easy setup using your mobile device.Improved Surge Protection The NanoStation AC and NanoStation AC loco feature enhanced protection against ESD events. Now with airOS®8 airOS®8 provides powerful features, including airMAX® ac protocol support, real-time RF analytics, and an all-new design for enhanced usability.
New revision of Gigabit Ethernet Surge Protector in IP67 waterproof enclosureHere’s what a typical use-case would be like. You have a mast with some antennas. And some switches on the ground. Put the GESP surge protectors on each end. They come sealed inside a new and improved IP67 weatherproof enclosure. Your antennas are now safe during a lightning storm.Don’t forget about the grounding wire! Secure it to the rackmount mast or any other structure that is connected to the ground. For maximum protection you should use a surge protector on both ends of long cables.
wAP LR2 kit Our newest out-of-the-box solution for LoRa® technology. Works with the 2.4 GHz frequency for LoRa®. Doesn’t interfere with the 2.4 GHz WLAN signal!
MT48-480095-11DG is 48 V 0.95 A power supply. It's part of Mikrotik GPEN concept that provides all the benefits of GPON but utilizes well-proven simple and inexpensive Ethernet solutions.MT48-480095-11DG allows using long Ethernet cable runs and multiple GPER units - please refer to the table in the last page of GPEN concept brochure.
Hikvision IP Camera | DS-2CD2146G2H-ISU | Dome | 4 MP | 2.8 mm | Power over Ethernet (PoE) | IP67, IK10 | H.265+ | MicroSD/microSDHC/microSDXC card (512 GB)
Kõrge jõudlusega 4MP turvakaamera öörežiimi ja ilmastikukindla disainigaSee kompaktne ja vastupidav turvakaamera on loodud pakkuma töökindlust ja kõrget jõudlust erinevates keskkondades. Täiustatud optika, tugev korpus ja mitmekülgsed funktsioonid tagavad kristallselge 4MP videokvaliteedi koos öörežiimiga, mistõttu sobib see ideaalselt nii sise- kui välistingimustes kasutamiseks.Mehaanilised omadused:Mõõtmed: Ø90 x 71,2 mm (Ø3.5 x 2.8") – kompaktne suurus lihtsaks paigaldamiseks.Kaal: 330 g (11.6 oz), kerge ja vastupidav.Korpuse materjal: Alumiiniumisulamist ja UV-kindel polükarbonaat, tagades pikaealisuse.Ilmastikukindlus: IP66 reitinguga, pakkudes kaitset tolmu ja vee eest.Löögikindlus: IK04 reitinguga, vastupidav füüsilistele löökidele.Kaabli mantli ümbrise mõõtmed: Ø20 x 70,6 mm (0.8 x 2.8").Kaabli mantli materjalid: Termoplastiline elastomeer, polükarbonaat ja silikoonkumm, pakkudes paremat vastupidavust.Kaabli pikkus: 30 cm (1 jalg).Kaabli läbimõõt: 5 mm (0.2").Kaabli mantli materjal: Polükarbonaat.Kaabli pistikutüüp: RJ45 võrguühenduseks.Optika ja pildikvaliteet:Sensor: 1/2.4" CMOS sensor kõrgekvaliteedilise pildi jäädvustamiseks.Objektiiv: Fikseeritud fookuskaugusega objektiiv.Vaatenurgad:Horisontaalne: 102.4°Vertikaalne: 54.9°Diagonaalne: 120.6° – lai vaateväli optimaalseks järelevalveks.Öörežiim: Sisseehitatud infrapuna LED valgustus ja IR lõikefilter, mis tagab selge nähtavuse ka vähese valgusega tingimustes.Video ja pildi seaded:Resolutsioon: 4MP (2688 x 1512) 16:9 kuvasuhtega, pakkudes teravat ja detailset videot.Maksimaalne kaadrisagedus: 30 kaadrit sekundis, sujuvaks liikumise jäädvustamiseks.Pildiseaded: Kohandatavad valikud, sealhulgas värv, heledus, teravus, kontrast, valge tasakaal, särituse kontroll, 2DNR, 3DNR, liikumise järgi müravähendus, maskeerimine ja teksti ülekate.Süsteem ja ühenduvus:Protsessor: Varustatud kahe-tuumalise Arm® Cortex®-A7 kiibiga efektiivseks töötlemiseks.Võrgu liides: 10/100 MbE RJ45 port usaldusväärseks traadiga ühenduseks.Maksimaalne energiatarve: 4W, tagades energiasäästliku töö.Toiteallikas: PoE (Power over Ethernet) kaudu.Toetatud pingevahemik: 37–57V DC, pakkudes mitmekülgseid toitevalikuid.LED indikaatorid: RGB/W LED, mis lihtsustab oleku jälgimist.Lähtestusnupp: Tehase lähtestamise valik kiireks tõrkeotsinguks.Paigaldamine: Pinnale kinnitatav, pakkudes lihtsat ja kindlat paigaldusvõimalust.Keskkonnaomadused:Töötemperatuur: -30 kuni 50º C (-22 kuni 122º F), sobilik ekstreemsetes temperatuurides töötamiseks.Tööniiskus: 0 kuni 90% mitte-kondenseeruv, sobilik erinevates keskkonnatingimustes.Sertifikaadid: FCC, IC, CE sertifitseeritud, tagades vastavuse rahvusvahelistele standarditele.Heli:Mikrofon: Sisseehitatud mikrofon helijälgimiseks (võimalik välja lülitada privaatsuse tagamiseks).
The MikroTik cAP LTE12 ax is a versatile wireless access point designed for performance in various environmental conditions. With an operational temperature range of -40°C to 50°C, it remains reliable in both hot and cold climates. This model features dual-band connectivity, allowing for data transfer rates of up to 1200 Mbps through Wi-Fi 6 capabilities. It supports various IEEE standards, ensuring compatibility with legacy devices while providing robust performance for modern applications.Equipped with 1 GB of RAM and an 1800 MHz processor, this access point manages bandwidth and connectivity. The MikroTik cAP LTE12 ax also offers PoE for streamlined installation, reducing clutter and eliminating the need for additional power outlets. With a flash memory size of 128 MB, it provides space for firmware updates and configuration settings, making it a reliable choice for networking needs.
