Moxa's terminal servers are equipped with the specialized functions and security features needed to establish reliable terminal connections to a network, and can connect various devices such as terminals, modems, data switches, mainframe computers, and POS devices to make them available to network hosts and process. Memory SD Slot Up to 32 GB (SD 2.0 compatible) Input/Output Interface Alarm Contact Channels Resistive load: 1 A @ 24 VDC Ethernet Interface 10/100BaseT(X) Ports (RJ45 connector) 1 Auto MDI/MDI-X connection Magnetic Isolation Protection 1.5 kV (built-in) Optical Fiber Optical Fiber Ethernet Software Features Configuration Options Web Console (HTTP/HTTPS), Serial Console, Telnet/SSH Console, Windows Utility Management ARP, BOOTP, DHCP Client, DNS, HTTP, ICMP, IPv4/IPv6, PPPOE, SMTP, SNMPv1/v2c/v3, SNTP, TCP/IP, Telnet, UDP Windows Real COM Drivers Windows 95/98/ME/NT/2000, Windows XP/2003/Vista/2008/7/8/8.1/10 (x86/x64), Windows 2008 R2/2012/2012 R2 (x64), Windows Embedded CE 5.0/6.0, Windows XP Embedded Linux Real TTY Drivers Kernel versions: 2.4.x, 2.6.x, 3.x, 4.x, and 5.x Fixed TTY Drivers SCO UNIX, SCO OpenServer, UnixWare 7, QNX 4.25, QNX 6.x, Solaris 10, FreeBSD, AIX 5.x, HP-UX 11i, Mac OS X Android API Android 3.1.x and later MIB MIB-II Time Management SNTP Client Unicast Routing RIPV1/V2, Static Route Authentication Local Account Accessibility, RADIUS, TACACS+ Serial Interface Connector 8-pin RJ45 No. of Ports 32 Serial Standards RS-232 Secure Operation Modes Reverse SSH, Secure Pair Connection, Secure Real COM, Secure TCP Client, Secure TCP Server, SSH Standard Operation Modes Disabled, Ethernet Modem, Pair Connection, PPP, Printer, Real COM, Reverse Telnet, RFC2217, TCP Client, TCP Server, Terminal, UDP Baudrate 50 bps to 921.6 kbps (supports non-standard baudrates) Console Port RS-232 (TxD, RxD, GND), 8-pin RJ45 (19200, n, 8, 1) Data Bits 5, 6, 7, 8 Stop Bits 1, 1.5, 2 Parity None, Even, Odd, Space, Mark Flow Control RTS/CTS, DTR/DSR, XON/XOFF Serial Signals RS-232 TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND Power Parameters Input Current 293 mA @ 48 VDC Input Voltage ±48 VDC, 20 to 72 VDC, -20 to -72 VDC Reliability Automatic Reboot Trigger Built-in WDT Alert Tools Built-in buzzer and RTC (real-time clock) Physical Characteristics Housing Metal Dimensions (with ears) 480 x 195 x 44 mm (18.9 x 7.68 x 1.73 in) Dimensions (without ears) 440 x 195 x 44 mm (17.32 x 7.68 x 1.73 in) Weight 3600 g (7.94 lb) Interactive Interface LCD panel display Push buttons for configuration Installation Rack mounting Environmental Limits Operating Temperature 0 to 55°C (32 to 131°F) Storage Temperature (package included) -40 to 75°C (-40 to 167°F) Ambient Relative Humidity 5 to 95% (non-condensing) Standards and Certifications EMC EN 55032/24 EMI CISPR 32, FCC Part 15B Class A EMS IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV IEC 61000-4-3 RS: 80 MHz to 1 GHz: 3 V/m IEC 61000-4-4 EFT: Power: 1 kV; Signal: 0.5 kV IEC 61000-4-5 Surge: Power: 1 kV IEC 61000-4-6 CS: 150 kHz to 80 MHz: 3 V/m; Signal: 3 V/m IEC 61000-4-8 PFMF Safety UL 60950-1 Traffic Control NEMA TS2 Vibration IEC 60068-2-6 Freefall IEC 60068-2-34 Declaration Green Product RoHS, CRoHS, WEEE MTBF Time 68,707 hrs Standards Telcordia (Bellcore) Standard Warranty Warranty Period 5 years
