See Delocki adapter võimaldab ühendada nt. Displayporti monitor vaba HDMI-liidese kaudu. Spetsifikatsioon • Ühendus: Sisend: 1 x kiire HDMI-A 19 kontaktiga isane 1 x A-tüüpi USB isane (toiteallikas) Väljund: 1 x Displayport 20 kontaktiga emane • Kiibistik: STDP2600 • Displayport 1.2 ja High Speed ​​HDMI spetsifikatsioon • Kiire HDMI-vastuvõtja – lingi kiirus kuni 2,97 Gb/s andmepaari kohta • Toetab 3D-ekraane • Toetab eraldusvõimet kuni 4Kx2K @ 30 Hz; 1920 x 1080 @ 120 Hz (olenevalt süsteem ja ühendatud riistvara) • Toetab Audio 7.1 kanalit kuni 192 kHz diskreetimissagedusega • Toetab HDCP 1.3 • Kullatud pistik • Värvi sügavus: RGB / YCC (4:4:4) – 16-bitine värv YCC (4:2:2 / 4:2:0) – 16-bitine värv • Energiatarve: operatsioon: ca. 500 mW ooterežiim: ca. 25 mW • Värvus: must • Kaabli pikkus: ca. 24,5 cm (koos pistikuga) • OS-ist sõltumatu, draiverite installimine pole vajalik Nõuded süsteemile • Vaba HDMI-A naisport • Vaba USB-A naisport • Vaba Displayport liidesega monitor • Üks Displayport kaabel Pakendi sisu • HDMI-adapter Displayporti • Kasutusjuhend

• Internal • Host interface: U.2 • Output interface: M.2

Original part number 62631 Product name Delock Adapter mini Displayport 1.1 male > VGA / HDMI / DVI female Passive black Producer Delock Class of product Cables - HDMI | DP | Component | DVI | VGA Basic information Basic information Cable type Video HDMI plugs 1x female HDMI A-type (19-pin, Single Link) DisplayPort plugs 1x male Mini DisplayPort DVI plugs 1x DVI-D (Single Link) 24+1 female VGA (D-Sub) plugs 1x female VGA (D-Sub 15-pin) Cable length 0.15 m Other information Other information Gold plated plugs No Cable colour Black Additional information Chipset: PS8312, PTN3392Mini Displayport 1.1a specificationHigh Speed HDMI specificationDVI-D (Single Link) 24+1 port with screw nuts (VGA not wired)Passive converter (level shifter)Supports a resolution up to 1920 x 1200 / 1080p @60 HzPower consumption: ca. 100 mW1 x ferrite core

Original part number 62613 Product name Delock Adapter mini Displayport 1.2 male > HDMI female 4K Passive black Producer Delock Class of product Cables - HDMI | DP | Component | DVI | VGA Basic information Basic information Cable type Video HDMI plugs 1x female HDMI A-type (19-pin, Single Link) DisplayPort plugs 1x male Mini DisplayPort Cable length 0.2 m Other information Other information Gold plated plugs Yes Cable colour Black Net weight no data Gross weight no data Additional information Resolution up to 3840 x 2160 @ 30HzSupports 3D displaysOS independent, no driver installation necessary

Delock 62603

Description This adapter by Delock enables you to connect e.g. a Displayport monitor through a free HDMI interface. Specification • Connector:   Input:     1 x High Speed HDMI-A 19 pin male     1 x USB type A male (power supply)   Output:     1 x Displayport 20 pin female • Chipset: STDP2600 • Displayport 1.2 and High Speed HDMI specification • High Speed HDMI receiver - link rate up to 2.97 Gb/s per data pair • Supports 3D displays • Supports a resolution up to 4Kx2K @ 30 Hz; 1920 x 1080 @ 120 Hz (depending on   the system and the connected hardware) • Supports Audio 7.1 channel up to 192 kHz sample rate • Supports HDCP 1.3 • Gold-plated connector • Colour depth:   RGB / YCC (4:4:4) - 16 bit colour   YCC (4:2:2 / 4:2:0) - 16 bit colour • Power consumption:   operation: ca. 500 mW   standby: ca. 25 mW • Colour: black • Cable length: ca. 24.5 cm (incl. connector) • OS independent, no driver installation necessary System requirements • A free HDMI-A female port • A free USB-A female port • Monitor with a free Displayport interface • One Displayport cable Package content • Adapter HDMI to Displayport • User manual Package • Retail Box
