The Alphacool Eisblock Aurora GPX-N Acrylic Active Backplate for Geforce RTX 3080/3090 graphics cards is the perfect upgrade for Alphacool's Eisblock Aurora Acrylic GPX-N GPU custom water coolers as well as Alphacool's Eiswolf 2 GPU AIOs (see compatibility details). With the help of the backplate, consisting of nickel-plated copper, the back of Geforce RTX 3080/3090 graphics cards can now also be actively water-cooled, thus achieving a significant increase in cooling performance.Connection optionsThere are 2 different ways to incorporate the backplate into your existing watercooling loop: Variant 1The cooler has an inlet and outlet with G1/4" internal thread on the top side respectively. With suitable connections and hoses/hard tubes, the backplate can be easily integrated into the water circuit. Variant 2The cooler has an inlet and outlet on the side suitable for 5/3mm hoses. With the help of Alphacool's MCX 2x manifold with 5/3mm tubing (item 1022250), the active backplate can be easily integrated into the water circuit in a space-saving way. This variant is a sensible choice if there is little space in the PC case and tubing runs will be difficult to do. (Note: Only works with Eisblock Aurora Acryl/ES Acetal GPX-N GPU custom water coolers. Cannot be used in combination with Alphacool Eiswolf 2 AIOs!)The connection options are very flexible for both variants, as the inlet and outlet can be freely selected depending on the design.Brilliant illuminationSix addressable digital RGB LEDs are directly recessed and run along the sides of the entire cooling block. This illuminates the entire cooling block and creates unique lighting effects. The Digital aRGB LED lighting is connected via a JST 3-pin connector and can be controlled with a Digital RGB controller (e.g. Alphacool Aurora Eiscontrol, Art.15360) or a Digital RGB capable motherboard. Compatibility:- Alphacool Eisblock Aurora Acryl GPX-N RTX 3090/3080 Gaming/Eagle with backplate (article number: 11942)- Alphacool Eiswolf 2 AIO - 360mm RTX 3080/3090 Gaming/Eagle with backplate (article number: 14416) Technical dataL x W x H233,5 x 97 x 13,3 mmMaterial backplatecopper, nickel-platedMaterial cooleracrylicThreads Water cooling2x G1/4" | 2x 5/3mm tube connectionIllumination6x digital addressable RGB LEDsPower connector digital aRGB LEDs3-pin JST (male & female switch)Power digital aRGB LEDs5VMaximum working temperature60 °CPressure tested0,8 BarWeight662 g
The Alphacool Eisblock Aurora Acrylic GPX graphics card water cooler with backplate combines style with performance. Extreme cooling performance and an extensive digital RGB lighting characterize it. Experience and technical know-how from more than a decade have gone into the development, without making any technical compromises. The Eisblock Aurora Acryl GPX is a significant evolution of the previous Alphacool graphics card water cooler, which has been improved in every area. More performance! During the development of the Eisblock Aurora Acryl GPX graphics card water cooler, emphasis was naturally placed on increasing performance. First, the cooler was brought closer to the individual components by reducing the thickness of the heat conducting pads. Next, the nickel-plated copper block was also made thinner. Step 3 involves the constant optimisation of the water flow within the cooler. The result: All important components such as voltage converters and RAM are cooled much better and more effectively by the water and the cooling performance increases significantly. Brilliant design! The addressable digital aRGB LEDs are embedded directly in the cooling block and run along the sides of the entire cooler. The effect is an illumination that engulfs the entire cooling block. No corner or edge is left unlit by the aRGB LEDs. The new design is more angular, with all edges bevelled. The result is better light diffusion in the water cooler due to the reflections on these bevels. They also create various contours that give the Eisblock Aurora Acryl GPX cooler its very own visual touch. Copper or aluminium? Alphacool uses only copper for all water-bearing parts. Copper has almost twice the thermal conductivity of aluminum and is therefore clearly the better choice of material for water cooling. The nickel-plated copper base is highly resistant to acid, which means that chipping of the nickel plating can be ruled out. Other special features The Eisblock Aurora Acryl GPX GPU cooler has the patented screw plugs, which sit flush with the surface of the terminal. The Alphacool logo sits in the corner on the top and is also fully illuminated. On the front of the terminal, corresponding designations of the compatible graphics card manufacturers can be seen. Of course, these are also fully illuminated by the adressable digital LEDs. IN and OUT are marked by small discreet triangles. They are easily recognisable and fit perfectly into the overall visual line of the graphics card water cooler. Technical data cooler L x W x H 267 x 127,74 x 23mm Material cooler Nickle-plated copper Material cooler top acrylic Threads 4 x G1/4 Thickness cooling fins 0,6 mm Illumination digital aRGB LEDs Power connector digital aRGB LEDs 3-Pin JST Power digital aRGB LEDs 5V Number of digital aRGB LEDs 13 Technical data backplate L x W x H 267 x 127,74 x 6mm Material aluminium Color black Compatibility: - GeForce RTX™ 3090 Ti ROG Strix LC 24GB (90YV0HC2-M0NA00) - GeForce RTX™ 3090 Ti ROG Strix LC OC Edition 24GB (90YV0HC0-M0NA00) - GeForce RTX™ 3090 Ti TUF Gaming 24GB (90YV0HC3-M0NA00) - GeForce RTX™ 3090 Ti TUF Gaming OC 24GB (90YV0HC1-M0NA00)
The Alphacool Eisblock Aurora GPX-N Acrylic Active Backplate for Geforce RTX 3080/3090 graphics cards is the perfect upgrade for Alphacool's Eisblock Aurora Acrylic GPX-N GPU custom water coolers as well as Alphacool's Eiswolf 2 GPU AIOs (see compatibility details). With the help of the backplate, consisting of nickel-plated copper, the back of Geforce RTX 3080/3090 graphics cards can now also be actively water-cooled, thus achieving a significant increase in cooling performance.Connection optionsThere are 2 different ways to incorporate the backplate into your existing watercooling loop: Variant 1The cooler has an inlet and outlet with G1/4" internal thread on the top side respectively. With suitable connections and hoses/hard tubes, the backplate can be easily integrated into the water circuit. Variant 2The cooler has an inlet and outlet on the side suitable for 5/3mm hoses. With the help of Alphacool's MCX 2x manifold with 5/3mm tubing (item 1022250), the active backplate can be easily integrated into the water circuit in a space-saving way. This variant is a sensible choice if there is little space in the PC case and tubing runs will be difficult to do. (Note: Only works with Eisblock Aurora Acryl/ES Acetal GPX-N GPU custom water coolers. Cannot be used in combination with Alphacool Eiswolf 2 AIOs!)The connection options are very flexible for both variants, as the inlet and outlet can be freely selected depending on the design.Brilliant illuminationSix addressable digital RGB LEDs are directly recessed and run along the sides of the entire cooling block. This illuminates the entire cooling block and creates unique lighting effects. The Digital aRGB LED lighting is connected via a JST 3-pin connector and can be controlled with a Digital RGB controller (e.g. Alphacool Aurora Eiscontrol, Art.15360) or a Digital RGB capable motherboard. Compatibility:- Alphacool Eiswolf 2 AIO - 360mm RTX 3080/3090 FTW3 with backplate (article number: 14414)- Alphacool Eisblock Aurora Acryl GPX-N RTX 3080/3090 FTW3 with backplate (article number: 11943) Technical dataL x W x H289,90 x 125,65 x 13,3 mmMaterial backplatecopper, nickel-platedMaterial cooleracrylicThreads Water cooling2x G1/4" | 2x 5/3mm tube connectionIllumination6x digital addressable RGB LEDsPower connector digital aRGB LEDs3-pin JST (male & female switch)Power digital aRGB LEDs5VMaximum working temperature60 °CPressure tested0,8 BarWeight1032 g
The Alphacool Eisblock Aurora GPX-N Acrylic Active Backplate for Geforce RTX 3080/3090 graphics cards is the perfect upgrade for Alphacool's Eisblock Aurora Acrylic GPX-N GPU custom water coolers as well as Alphacool's Eiswolf 2 GPU AIOs (see compatibility details). With the help of the backplate, consisting of nickel-plated copper, the back of Geforce RTX 3080/3090 graphics cards can now also be actively water-cooled, thus achieving a significant increase in cooling performance.Connection optionsThere are 2 different ways to incorporate the backplate into your existing watercooling loop: Variant 1The cooler has an inlet and outlet with G1/4" internal thread on the top side respectively. With suitable connections and hoses/hard tubes, the backplate can be easily integrated into the water circuit. Variant 2The cooler has an inlet and outlet on the side suitable for 5/3mm hoses. With the help of Alphacool's MCX 2x manifold with 5/3mm tubing (item 1022250), the active backplate can be easily integrated into the water circuit in a space-saving way. This variant is a sensible choice if there is little space in the PC case and tubing runs will be difficult to do. (Note: Only works with Eisblock Aurora Acryl/ES Acetal GPX-N GPU custom water coolers. Cannot be used in combination with Alphacool Eiswolf 2 AIOs!)The connection options are very flexible for both variants, as the inlet and outlet can be freely selected depending on the design.Brilliant illuminationSix addressable digital RGB LEDs are directly recessed and run along the sides of the entire cooling block. This illuminates the entire cooling block and creates unique lighting effects. The Digital aRGB LED lighting is connected via a JST 3-pin connector and can be controlled with a Digital RGB controller (e.g. Alphacool Aurora Eiscontrol, Art.15360) or a Digital RGB capable motherboard. Compatibility:- Alphacool Eiswolf 2 AIO - 360mm RTX 3080/3090 Aorus Master/Xtreme with backplate (article number: 11974)- Alphacool Eisblock Aurora Acryl GPX-N RTX 3080/3090 Aorus Master/Xtreme with backplate (article number: 11952) Technical dataL x W x H269,27 x 120,74 x 13,3 mmMaterial backplatecopper, nickel-platedMaterial cooleracrylicThreads Water cooling2x G1/4" | 2x 5/3mm tube connectionIllumination6x digital addressable RGB LEDsPower connector digital aRGB LEDs3-pin JST (male & female switch)Power digital aRGB LEDs5VMaximum working temperature60 °CPressure tested0,8 BarWeight844 g
The Alphacool Eisblock Aurora GPX-N Acrylic Active Backplate for Geforce RTX 3080/3090 graphics cards is the perfect upgrade for Alphacool's Eisblock Aurora Acrylic GPX-N GPU custom water coolers (see compatibility details). With the help of the backplate, consisting of nickel-plated copper, the back of Geforce RTX 3080/3090 graphics cards can now also be actively water-cooled, thus achieving a significant increase in cooling performance.Connection optionsThere are 2 different ways to incorporate the backplate into your existing watercooling loop: Variant 1The cooler has an inlet and outlet with G1/4" internal thread on the top side respectively. With suitable connections and hoses/hard tubes, the backplate can be easily integrated into the water circuit. Variant 2The cooler has an inlet and outlet on the side suitable for 5/3mm hoses. With the help of Alphacool's MCX 2x manifold with 5/3mm tubing (item 1022250), the active backplate can be easily integrated into the water circuit in a space-saving way. This variant is a sensible choice if there is little space in the PC case and tubing runs will be difficult to do. (Note: Only works with Eisblock Aurora Acryl/ES Acetal GPX-N GPU custom water coolers. Cannot be used in combination with Alphacool Eiswolf 2 AIOs!)The connection options are very flexible for both variants, as the inlet and outlet can be freely selected depending on the design.Brilliant illuminationSix addressable digital RGB LEDs are directly recessed and run along the sides of the entire cooling block. This illuminates the entire cooling block and creates unique lighting effects. The Digital aRGB LED lighting is connected via a JST 3-pin connector and can be controlled with a Digital RGB controller (e.g. Alphacool Aurora Eiscontrol, Art.15360) or a Digital RGB capable motherboard. Compatibility:- Alphacool Eisblock Aurora Acryl GPX-N RTX 3090/3080 TI HOF with backplate (article number: 11967) Technical dataL x W x H295 x 125,25 x 13,3 mmMaterial backplatecopper, nickel-platedMaterial cooleracrylicThreads Water cooling2x G1/4" | 2x 5/3mm tube connectionIllumination6x digital addressable RGB LEDsPower connector digital aRGB LEDs3-pin JST (male & female switch)Power digital aRGB LEDs5VMaximum working temperature60 °CPressure tested0,8 BarWeight1013 g
The Alphacool Eisblock Aurora GPX-N Acrylic Active Backplate for Geforce RTX 3080/3090 graphics cards is the perfect upgrade for Alphacool's Eisblock Aurora Acrylic GPX-N GPU custom water coolers as well as Alphacool's Eiswolf 2 GPU AIOs (see compatibility details). With the help of the backplate, consisting of nickel-plated copper, the back of Geforce RTX 3080/3090 graphics cards can now also be actively water-cooled, thus achieving a significant increase in cooling performance.Connection optionsThere are 2 different ways to incorporate the backplate into your existing watercooling loop: Variant 1The cooler has an inlet and outlet with G1/4" internal thread on the top side respectively. With suitable connections and hoses/hard tubes, the backplate can be easily integrated into the water circuit. Variant 2The cooler has an inlet and outlet on the side suitable for 5/3mm hoses. With the help of Alphacool's MCX 2x manifold with 5/3mm tubing (item 1022250), the active backplate can be easily integrated into the water circuit in a space-saving way. This variant is a sensible choice if there is little space in the PC case and tubing runs will be difficult to do. (Note: Only works with Eisblock Aurora Acryl/ES Acetal GPX-N GPU custom water coolers. Cannot be used in combination with Alphacool Eiswolf 2 AIOs!)The connection options are very flexible for both variants, as the inlet and outlet can be freely selected depending on the design.Brilliant illuminationSix addressable digital RGB LEDs are directly recessed and run along the sides of the entire cooling block. This illuminates the entire cooling block and creates unique lighting effects. The Digital aRGB LED lighting is connected via a JST 3-pin connector and can be controlled with a Digital RGB controller (e.g. Alphacool Aurora Eiscontrol, Art.15360) or a Digital RGB capable motherboard. Compatibility:- Alphacool Eiswolf 2 AIO - 360mm RTX 3080/3090 Ventus with backplate (article number: 14420)- Alphacool Eisblock Aurora Acryl GPX-N RTX 3090/3080 Ventus with backplate (article number: 11937) Technical dataL x W x H260 x 107,25 x 13,3 mmMaterial backplatecopper, nickel-platedMaterial cooleracrylicThreads Water cooling2x G1/4" | 2x 5/3mm tube connectionIllumination6x digital addressable RGB LEDsPower connector digital aRGB LEDs3-pin JST (male & female switch)Power digital aRGB LEDs5VMaximum working temperature60 °CPressure tested0,8 BarWeight718 g
The Alphacool Eisblock Aurora Acrylic GPX graphics card water cooler with backplate combines style with performance. Extreme cooling performance and an extensive digital RGB lighting characterize it. Experience and technical know-how from more than a decade have gone into the development, without making any technical compromises. The Eisblock Aurora Acryl GPX is a significant evolution of the previous Alphacool graphics card water cooler, which has been improved in every area. More performance! During the development of the Eisblock Aurora Acryl GPX graphics card water cooler, emphasis was naturally placed on increasing performance. First, the cooler was brought closer to the individual components by reducing the thickness of the heat conducting pads. Next, the nickel-plated copper block was also made thinner. Step 3 involves the constant optimisation of the water flow within the cooler. The result: All important components such as voltage converters and RAM are cooled much better and more effectively by the water and the cooling performance increases significantly. Brilliant design! The addressable digital aRGB LEDs are embedded directly in the cooling block and run along the sides of the entire cooler. The effect is an illumination that engulfs the entire cooling block. No corner or edge is left unlit by the aRGB LEDs. The new design is more angular, with all edges bevelled. The result is better light diffusion in the water cooler due to the reflections on these bevels. They also create various contours that give the Eisblock Aurora Acryl GPX cooler its very own visual touch. Copper or aluminium? Alphacool only uses copper in its water coolers. In the case of the Eisblock Aurora Acryl GPX, the copper is nickel-plated. Compared to the previous models, however, Alphacool has once again improved the type of nickel plating, which has significantly increased the acid resistance. This should prevent the nickel plating from flaking off. Why does Alphacool use copper instead of aluminium? Copper has almost twice the thermal conductivity of aluminium and is therefore clearly the better material for water cooling. Other special features The Eisblock Aurora Acryl GPX GPU cooler has the patented screw plugs, which sit flush with the surface of the terminal. The Alphacool logo sits in the corner on the top and is also fully illuminated. On the front of the terminal, corresponding designations of the compatible graphics card manufacturers can be seen. Of course, these are also fully illuminated by the adressable digital LEDs. IN and OUT are marked by small discreet triangles. They are easily recognisable and fit perfectly into the overall visual line of the graphics card water cooler.Compatibility: - Colorful iGame GeForce RTX 3080 Advanced 10G - Colorful iGame GeForce RTX 3080 Advanced 10G OC - Colorful iGame GeForce RTX 3090 Advanced - Colorful iGame GeForce RTX 3090 Advanced OC Technical data cooler L x W x H 267 x 122 x 24,55 mm Material cooler Nickle-plated copper Material cooler top acrylic Threads 4 x G1/4 Thickness cooling fins 0,6 mm Illumination digital aRGB LEDs Power connector digital aRGB LEDs 3-Pin JST Power digital aRGB LEDs 5V Number of digital aRGB LEDs 14 Technical data backplate L x W x H 267 x 96,9 x 6 mm Material aluminium Color black
The Alphacool Eiswolf 2 is the first full cover GPU AIO waterblock from Alphacool. It is based on the Alphacool Eisblock Aurora GPX water block, a pump unit and a 360mm NexXxoS ST30 full copper radiator. The latter is equipped with the Alphacool Aurora Rise Digital RGB fans.Fullcover Waterblock?The Eiswolf 2 graphics card AIO water block not only cools the GPU with liquid but also all relevant components that require active cooling. This includes the graphics memory, the VRM and, if necessary, other components that require direct cooling. By using the Eisblock GPX Aurora water cooler, the cooling capacity is identical to that of a DIY graphics card water cooler.PumpThe Eiswolf 2 has a pump unit in place of the normal connection terminal. This pump unit houses the DC-LT 2 pump. An improved and quieter version of the well-known DC-LT Low Noise Ceramic Pump. Despite looking rather large, the pump unit is only 5 mm wider than a normal connection terminal.Fittings and TubingAs with all new AIO units, Alphacool uses only TPV hoses from the Enterprise Solution range for (usually reserved for servers and workstations) in the Eiswolf 2. The tubing is made of EPDM/PP and are extremely heat-resistant, durable, and free of plasticizers. All fittings are also based on the Enterprise Solution range and match the TPV hoses perfectly.ExpandabilityBy using the quick-release fastener, the Eiswolf 2 can be connected to another Alphacool AIO unit to achieve a larger loop in seconds. Alphacool offers various prefilled components with which the loop can be easily extended. For safety reasons, the quick-release fasteners are firmly screwed together and not just plugged together.Lighting and fansThe Eiswolf 2 cooler has a digital RGB LED lighting, also called addressable RGB LEDs. They run along the entire back of the graphics card cooler and provide complete illumination of the water cooler. The pump unit is more discreet and offers a green glowing logo for Nvidia and a red glowing logo for AMD cards. The name "Eiswolf" on the pump unit remains unlit, discreetly in the background. The fan used is the Aurora Rise with 120mm. Due to the special blade design, the fan is extremely quiet and the addressable RGB LEDs provide brilliant illumination. The Alphacool Aurora Rise fan convinces with a max. static pressure of 3.17mm/H2O and offers a max. air flow of 119.8m3/h. The PWM control allows the fan to be controlled over a wide speed range. In addition, it offers a zero control. It can therefore be regulated down to 0 rpm and then starts with approx. 350 rpm.NexXxoS RadiatorAs with all AIO units, Alphacool uses radiators from the world renowned NexXxoS series. The full copper radiators offer a much higher cooling capacity than aluminium radiators and have contributed significantly to Alphacool's worldwide success.The combination of all of the components results in a solution that is as simple as an AIO solution to install, but with the performance of a pre-assembled and prefilled custom loop.Technical note!Due to long storage times and various transport routes, the liquid in the Eiswolf 2 AIO remains still for a long time. The ingredients of the liquid can therefore deposit and lead to a brownish discoloration. As soon as the pump starts operating, the ingredients mix again and the liquid should regain an approximately clear color. This is not a reason for complaint as neither the performance nor the function of the AIO are restricted by this. If the discolouration of the cooling liquid does not disappear after the AIO has been put into operation, please contact our support team via E-Mail (info@alphacool.com). You will receive quick and uncomplicated help there. Compatibility:- MSI GeForce RTX 3090 Ti Gaming Trio 24G, 24GB GDDR6X (V509-029R)- MSI GeForce RTX 3090 Ti Gaming X Trio 24G, 24GB GDDR6X (V509-014R)- MSI GeForce RTX 3090 Ti Suprim 24G, 24GB GDDR6X- MSI GeForce RTX 3090 Ti Suprim X 24G, 24GB GDDR6X (V509-003R) Technical data radiatorL x W x H395 x 124 x 30mm (+/- 3%)Material cooling fins, chambers & channelsCopperMaterial threadsBrassMaterial outer housingstainless steelG 1/4“ threads2 x for tubes (+ 1x Fillport G1/4“)For fan size120 mmPossible fan assembly3 x one-sided / 6 x both-sidedTechnical data cooler and pumpL x W x H265,8 x 162,5 x 46mmMaterial cooler bottomChrome plated copperMaterial cooler topacrylicThreads2 x G1/4“Pump typeDC-LT 2Pump speed2600 rpm (+/- 10%)Head of delivery1 mMaximum flow rate72 L/hVoltage6-13.5V DCPower consumption3.2WMTBF50.000 hTechnical data liquidColorclearIngredient 1Destilled water (CAS-number 7732-18-5)Ingredient 2Glysantin (CAS-number 1017-21-1)Working temperatures-15 C° / +90 °CTechnical data quick fastenersL x D95 x 27mmMaterialNylonFor tube size12,7 / 7,6mmColorBlackTechnical data fittingsL x D straight fitting24 x 18mmQuantity straight fittings2xL x B x H 90° fitting35 x 27 x 17mmQuantity 90° fittings2xFor tube size12,7 / 7,6mmMaterial fittingsBrassTechnical data tubeLength50cmMaterial tubeTPV (EPDM/PP)ColorMatt blackTube size12,7 / 7,6mmHardness grade35 Shore-A to 50 Shore-DWorking temperature-50 to +155 °CTechnical data fanSpeed0 - 2500 RPMStatic pressure3,17 mm H2OAir flow rate119,8 m³/hBearingsSleeve bearingFan connector4-Pin PWMConnection Digital aRGB3-Pin JST + 3-Pin 5VDimensions120 x 120 x 25mmNet weight187gMax working temperature60°C
The Alphacool Aurora Acryl GPX-N RTX 3080/3090 Eisblock combines style with performance and extensive digital RGB lighting. With experience of over 17 years, Alphacool the ability to create GPU blocks that represent high quality and fantastic performance. This perfectly describes the Aurora Plexi GPX Eisblock.More Performance!During the development of the EIsblock Aurora GPX-N RTX 3080/3090 graphic card GPU block, we wanted to further increase the performance. The first step was to move the cooler closer to the individual components by reducing the thermal pads to a thickness of 1 mm. Next, we reduced the thickness of the chrome-plated copper block. Instead of 7 mm, it is now only 5.5 mm thick. The water flow inside the cooler has also been optimized. All important components such as the voltage transformers and the memory are now significantly better and more effectively cooled by the water. All this ensures a significant increase in cooling performance.New Design!The Eisblock Aurora GPX-N RTX 3080/3090 cooler has been designed so that lighting is more important than the previous models. The addressable digital RGB LEDs are embedded directly into the cooling block and run along the entire cooling block. The effect is an illumination of the entire cooling block. No corner or edge remains unlit by the aRGB LEDs. The new design is more angular with all edges bevelled. This promotes better light diffusion in the water cooler due to the reflections on these bevels. In addition, they create various contours, which give the Aurora GPX-N RTX 3080/3090 Eisblock cooler its very own unique identity.Copper or Aluminium? Alphacool uses only copper for all water-bearing parts. Copper has almost twice the thermal conductivity of aluminum and is therefore clearly the better choice of material for water cooling. The cooler is made entirely of chrome-plated copper. A chrome plating is much harder than a nickel plating and therefore less sensitive to acids, scratches and damage. It completely eliminates the risk of chipping nickel plating. Additionally, chrome plating looks much more homogeneous and provides a shine that cannot be achieved by nickel plating.Is There Anything Else New?The Eisblock Aurora GPX-N RTX 3080/3090 also relies on the new patented stop fittings, which sit flush with the surface of the terminal. The Alphacool logo now sits in the corner on the top and is also fully illuminated. On the front of the terminal you can see the corresponding names of the compatible graphic card types. Of course, these are also fully illuminated by the digital LEDs. IN and OUT are now marked by small triangles. They are easily recognizable and fit perfectly into the entire aesthetics of the graphic card water cooler.The Alphacool Aurora GPX-N RTX 3080/3090 Acryl is a complete redevelopment of the previous Alphacool graphics card water coolers. No technical compromises were made, but the entire technical know-how flowed into the development and implementation. Compatibility:RTX 3080 TIMSI GeForce RTX 3080 Ti Suprim XMSI GeForce RTX 3080 Ti Gaming X Trio 12GRTX 3080MSI GeForce RTX 3080 Gaming X Trio 10G, 10GB GDDR6X, HDMI, 3x DPMSI GeForce RTX 3080 Gaming Z Trio 10G, 10GB GDDR6X, HDMI, 3x DP (V389-045R)MSI GeForce RTX 3080 Gaming Z Trio 12G LHR, 12GB GDDR6X, HDMI, 3x DP (V389-402R)MSI GeForce RTX 3080 Suprim X 10G, 10GB GDDR6X, HDMI, 3x DPMSI GeForce RTX 3080 Suprim X 12G LHR, 12GB GDDR6X, HDMI, 3x DPRTX 3090MSI GeForce RTX 3090 Gaming X Trio, 24GB GDDR6X, HDMI, 3x DPMSI GeForce RTX 3090 Suprim X 24G, 24GB GDDR6X, HDMI, 3x DP Technical data coolerL x W x H295 x 152 x 25 mmMaterial coolerchrome-plated copperMaterial cooler topacrylicThreads4 x G1/4Thickness cooling fins0,6 mmMaximum working temperature60 °CIlluminationDigital RGB LEDsPower connector Digital RGB LEDs3-Pin JSTPower Digital RGB LEDs5VNumber of digital aRGB LEDs12Technical data backplateL x W x H295 x 125,75 x 6 mmMaterialaluminiumColorblack
Compatibility: - Alphacool Eisblock Aurora Acryl GPX-N RTX 3090/3080 Suprim X with backplate (article number: 11938) Technical data L x W x H: 295 x 127,25 x 13,3 mm Material backplate: copper, nickel-plated Material cooler: acrylic Threads Water cooling: 2x G1/4" | 2x 5/3mm tube connection Illumination: 6x digital addressable RGB LEDs Power connector: digital aRGB LEDs 3-pin JST (male & female switch) Power: digital aRGB LEDs 5V Maximum working temperature: 60 °C Pressure tested: 0,8 Bar Weight: 1054 g
Tootekood: PH-GB3090ASSRX_CR01_BPGTIN: 886523701637Jahutid ja lisad
Full-Block-GPU-Kühler für Custom-Wasserkühlungen, für ASUS ROG Strix RTX 3080/3090, Deckel aus transparentem Acrylglas, mit silbernem Aluminium-Cover, integrierte digitale RGB-Beleuchtung (3-Pin, 5VDG)
Kühlblock und Backplate mit aktiver Kühlung von EK Water Blocks, für EVGA XC3 RTX 3080 / 3080 Ti und 3090, vernickelter Kupferboden, Acetal-Deckel, adressierbare RGB-Beleuchtung
EK-Quantum Vector TRIO RTX 3080/3090 Active Backplate - Acetal ist eine hochmoderne Ergänzung der EK® Quantum Line. Sie ergänzt die bestehenden EK-Quantum Vector TRIO RTX 3080/3090 Wasserblöcke und kühlt aktiv die Rückseite aller MSI® TRIO und SUPRIM GeForce RTX™ 3080 und 3090 GPUs. Die EK-Quantum Vector TRIO RTX 3080/3090 Active Backplate wird mit einem neuen Anschluss geliefert, der den serienmäßigen Anschluss des Vector Wasserblocks ersetzt und den Wasserblock und die Vector Active Backplate zu einer Einheit verbindet. Auf diese Weise benötigt das gesamte Gehäuse nur einen Zu- und einen Abfluss, wodurch unnötige zusätzliche Schläuche entfallen und das Durcheinander reduziert wird. Es ist die ultimative ästhetische und leistungsfähige Lösung, bei der Ihre GPU zwischen zwei Wasserblöcken eingebettet ist, was eine maximale Kühlung ermöglicht. Technische Spezifikation: Abmessungen: (LxHxB) - 307x153x38mm Lieferumfang: EK-Quantum Vector TRIO RTX 3080/3090 Aktive Backplate - Acetal Erforderliche Befestigungsschrauben, Muttern und Unterlegscheiben 1x vernickelter Messingstecker G1/4" EK-Loop Multi Inbusschlüssel (6mm, 8mm, 9mm) Thermische Pads
Backplate mit aktiver Kühlung von EK Water Blocks, für EVGA XC3 RTX 3080 / 3080 Ti und 3090, vernickelter Kupferboden, Acryl-Deckel, adressierbare RGB-Beleuchtung
Full-Cover-Waterblock von EK Water Blocks, für EVGA XC3 RTX 3080 / 3080 Ti und 3090, vernickelter Kupferboden, Acetal-Deckel, adressierbare RGB-Beleuchtung
Backplate für GPU-Wasserkühlung, für EK-Quantum Vector FTW3 RTX 3080/3090, aus POM Acetal, bietet erhöhte Stabilität, mit Wärmeleitpads, für aktive Kühlung des PCBs
This is the 2nd generation Vector GPU water block from the EK® Quantum Line, designed for AORUS® Xtreme and Master RTX 3080 and 3090 graphics cards based on the latest NVIDIA® Ampere™ architecture. An EK water block for Xtreme and Master RTX 3080 and 3090 EK-Quantum Vector Xtreme 3080/3090 D-RGB - Nickel + Acetal water block is compatible with Aorus Xtreme and Master RTX 3080 and RTX 3090 graphics cards. The Vector water block actively cools the GPU, VRAM (on the front), power stages, and chokes in the VRM (voltage regulation module). These newly developed water blocks feature optimized flow paths that reduce hydrodynamic instabilities and vortexing (dead spots) inside of them. The EK-Quantum Vector Series water blocks use an Open Split-Flow cooling engine design, which proved to be a superior solution for GPU water blocks. It is characterized by low hydraulic flow restriction, meaning it can be used with weaker water pumps or pumps running on low-speed settings, and still achieve top performance. The jet plate and fin structure geometry have been optimized to provide even flow distribution with minimal losses and optimal performance when used in any given coolant flow orientation. The base of the block is CNC-machined out of nickel-plated high-grade copper, while its top is CNC-machined out of durable black POM Acetal. These 2nd generation Vector GPU water blocks also feature Acetal terminals. The watertight sealing is ensured by high-quality EPDM O-rings, while brass standoffs are already pre-installed and allow for a safe and easy installation procedure. D-RGB lighting on EK-Quantum Vector Xtreme RTX 3080/3090 D-RGB water block The aesthetic corner end-piece is housing the addressable D-RGB LEDs. This water block boasts a total of 8 individually addressable RGB LEDs, and it is compatible with popular RGB sync technologies from all major motherboard manufacturers. The arrow marking on the 3-pin D-RGB LED connector is to be aligned with the +5V marking on the D-RGB (addressable) header. Backplate for the EK-Quantum Vector Xtreme 3080/3090 water block EK recommends the purchase of a retention backplate, especially for the 3090 models of graphics cards. The backplate improves the overall aesthetics of your graphics cards and also provides additional passive cooling for the GPU core, VRAM on the 3090 cards, and backside of the printed circuit board VRM section. Technical Specification Dimensions: (LxHxW) - 295x150.5x20.5mm Enclosed EK-Quantum Vector Xtreme RTX 3080/3090 D-RGB series high-performance water block Mounting mechanism with screw-in brass standoffs Necessary mounting screws, nuts, and washers 2x Nickel plated brass plug G1/4” EK-Loop Multi Allen Key (6mm, 8mm, 9mm) Thermal pads Thermal grease EK-TIM Ectotherm (1g)
Backplate mit aktiver Kühlung von EK Water Blocks, für EVGA XC3 RTX 3080 / 3080 Ti und 3090, vernickelter Kupferboden, Acetal-Deckel, adressierbare RGB-Beleuchtung
Full-Cover-Waterblock von EK Water Blocks, für ROG Strix und ASUS TUF RTX 3090 Ti, vernickelter Kupferboden, Acryl-Deckel, adressierbare RGB-Beleuchtung
EK-Quantum Vector Strix RTX 3080/3090 Backplate - Nickel is a CNC-milled backplate made of nickel-plated aluminium that fits all EK-Quantum Vector Strix RTX 3070/3080/3090 water blocks. The backplate covers the full length of the graphics card PCB, serves as an aesthetic addition and also provides passive cooling for the back of the voltage regulator module (VRM), the GPU core and the VRAM on the 3090 cards. Enclosed: EK-Quantum Vector Strix RTX 3070/3080/3090 back plate - nickel Assembly mechanism Thermal pads
Full-Block-Wasserkühler von EK Water Blocks, für RTX 3080 und 3090-Grafikkarten im Referenz-Design, schwarzer Acetal-Deckel, Kühlkörper aus hochreinem Kupfer
Backplate mit aktiver Kühlung von EK Water Blocks, für MSI Trio und Suprim 3080 / 3080 Ti und 3090, vernickelter Kupferboden, Acetal-Deckel, adressierbare RGB-Beleuchtung
The Alphacool ES GPX Copper/Carbon water cooler with backplate was developed for the Alphacool Enterprise Series. Due to the positioning of the connections, the hosing of the cooler in the server rack is significantly simplified. The top of the cooler is made of carbon. This makes the water cooler lighter compared to Alphacool's Eisblocks with acetal or acrylic tops. Thanks to the compact design, only 1 slot is needed to mount the cooler in the server rack instead of 1.5 slots as before. This additional space saving is one more argument for using the ES GPX Copper/Carbon graphics card water cooler. More performance! Alphacool manages to position the cooler as close as possible to the components to be cooled. For this purpose, the heat conducting pads used are reduced to a thickness of 1mm. The maximum possible reduction in the thickness of the copper block and the optimization of the water flow inside the cooler allow all important components such as GPU, voltage converters and VRAMs to be cooled by water much better and more effectively. All of this provides a significant increase in cooling performance. Connections on the back? In order to save space in the width and height during installation, the water input and output have been moved to the back of the cooling block. This positioning of the connections makes hosing much easier. It enables easy integration of the GPU cooler into the water circuit even in the tightest server housings. Copper or aluminum? Alphacool uses only copper for all water-bearing parts. Copper has almost twice the thermal conductivity of aluminum and is therefore clearly the better choice of material for water cooling. The cooler is made entirely of chrome-plated copper. A chrome plating is much harder than a nickel plating and therefore less sensitive to acids, scratches and damage. It completely eliminates the risk of chipping nickel plating. Additionally, chrome plating looks much more homogeneous and provides a shine that cannot be achieved by nickel plating. Thermal paste & thermal pads The included thermal paste is Alphacool's Subzero with a thermal conductivity of 16 W/mk. The electrically non-conductive thermal paste is particularly well suited for high contact pressures, but can still be perfectly applied due to its viscosity of 850000 TF. For the thermal pads, Alphacool uses soft pads that fit perfectly to the components to be cooled and are very durable. The 2mm and 3mm thick pads have a thermal conductivity of 3 W/mk. The 1mm thick pads can dissipate 7 W/mk of heat. Discreet appearance The matte carbon finish gives the cooler a noble appearance. This makes it additionally interesting for private users who want to do without aRGB lighting. Compatibility: - Gainward GeForce RTX 3080 Ti 12GB Phoenix - Gainward RTX 3080 Phoenix - Gainward RTX 3080 Phoenix GS - Gainward RTX 3090 Phoenix - Gainward RTX 3090 Phoenix GS - INNO3D GEFORCE RTX 3080 TI ICHILL X4 - INNO3D GEFORCE RTX 3080 TI ICHILL FROSTBITE - INNO3D GEFORCE RTX 3080 TI ICHILL X3 - INNO3D GEFORCE RTX 3080 TI X3 - INNO3D GEFORCE RTX 3080 TI X3 OC - Inno3D GeForce RTX 3080 iChill X3/X4 10240 MB GDDR6X - Inno3D GeForce RTX 3080 Twin X2 OC 10240 MB GDDR6X - INNO3D GEFORCE RTX 3080 12GB ICHILL FROSTBITE LHR - INNO3D GEFORCE RTX 3080 12GB X3 OC LHR - INNO3D GEFORCE RTX 3080 12GB ICHILL X3/X4 LHR - INNO3D GEFORCE RTX 3080 12GB ICHILL BLACK LHR - Inno3D GeForce RTX 3090 iChill X3/X4, 24576 MB GDDR6X - Inno3D GeForce RTX 3090 Gaming X3, 24576 MB GDDR6X - Palit GeForce RTX 3080 Ti GamingPro - Palit GeForce RTX™ 3080 GamingPro - Palit GeForce RTX™ 3080 GamingPro OC - Palit GeForce RTX™ 3090 GamingPro - Palit GeForce RTX™ 3090 GamingPro OC - Zotac Gaming GeForce RTX 3080 Ti AMP Holo - Zotac GeForce RTX 3080 Ti AMP HoloBlack - Zotac Gaming GeForce RTX 3080 Ti Trinity - Zotac Gaming GeForce RTX 3080 Ti Trinity OC - Zotac GAMING GeForce RTX 3080 Trinity - Zotac Gaming GeForce RTX 3080 Trinity OC - Zotac GeForce RTX 3090 Trinity, 24576 MB GDDR6X - Galakuro NVIDIA GEFORCE RTX 3080 GG-RTX3080-E10GB/TP - Galakuro NVIDIA GEFORCE RTX 3090 GG-RTX3090-E24GB/TP - Galax GeForce RTX 3080 SG 10GB GDDR6X 320-bit DP*3/HDMI - Galax GeForce RTX 3090 SG 24GB GDDR6X 320-bit DP*3/HDMI - KFA2 GeForce RTX 3080 SG 10GB GDDR6X 320-bit DP*3/HDMI - KFA2 GeForce RTX 3090 SG 24GB GDDR6X 320-bit DP*3/HDMI - PNY GeForce RTX 3080 XLR8 Gaming EPIC-X RGB 10240 MB GDDR6X (VCG308010TFXMPB) - PNY GeForce RTX 3080 XLR8 Gaming EPIC-X RGB 10240 MB GDDR6X (VCG308010TFXPPB) - PNY GeForce RTX 3090 XLR8 Gaming EPIC-X RGB, 24576 MB GDDR6X Technical data cooler L x W x H 247,30 x 95,35 x 23,08mm Material cooler chrome-plated copper Material cooler top carbon Threads 2 x G1/4" Thickness cooling fins 0,6mm Maximum working temperature 60 °C Pressure tested 0,8 Bar Technical data backplate L x W x H 237,20 x 95,35 x 6mm Material aluminium Color black
