When developing the new BioniX P120, special emphasis was placed on a focused air flow and a high static pressure. The fan guarantees extremely efficient cooling, even with increased air resistance. Numerous improvements, such as engine technology and a newly developed fan design, have noticeably increased the performance of P fans. In internal performance tests, the new P fans leveled out to 28 dB (A) left many competitors behind. Technical Details Fan: 120 mm, 200 - 2,100 rpm (PWM controlled) Air flow: 67.56 CFM / 114.79 m3 / h (@ 2,100 rpm) Noise level: 0.45 sone (@ 2,100 rpm) Static pressure: 2.75 mm H2O (@ 2,100 rpm) Typical voltage: 12 V DC Cable length: 400 mm PST cable length: 50 mm
Der P12 PWM PST RGB 0dB besitzt in der Lüfternarbe 12 analoge RGB LEDs. Diese sind einheitlich ansteuerbar und kompatibel zu den gängigen RGB-Standards führender Motherboard Hersteller. Der Lüfter kann somit direkt über den RGB-Mainboard-Anschluss oder über einen externen Controller vollumfänglich illuminiert und mit der Beleuchtung anderer Hardware synchronisiert werden. Das Betriebsgeräusch des neu entwickelten ARCTIC Motors ist selbst bei geringster Drehzahl kaum wahrnehmbar. Zusätzlich besitzt der P12 PWM PST RGB 0dB gummierte Auflageflächen und reduziert so hörbare Schwingungen auf ein Minimum.Dank einer in Deutschland entwickelten Kombination von Legierung/Schmiermittel wird die Reibung innerhalb des Lagers reduziert und eine höhere Effizienz erzielt. Auf diese Weise entwickelt sich weniger Wärme, es entstehen weniger Lagergeräusche und die Lebensdauer des Lüfters wird verlängert. Technische Daten: Geschwindigkeit: 0 - 2000 rpm Luftstrom: 48.8 CFM/ 82.91 m³/h Statischer Druck: 1.85 mm H₂O Geräuschpegel: 0.3 Sone Betriebsumgebungstemperatur: 0 - 40 °C Lüfterrahmen: Standard Kontrolltyp: PWM PST Anschluss: 4-Pin-Connector + 4-Pin-Socket Lüfterlager: Fluid Dynamic Bearing Typische Spannung: 12 V DC Anlaufspannung: 5 V Stromstärke/ Spannung: 0.11 A / 12 V Kabellänge: 400 mm Länge: 120 mm Breite: 120 mm Höhe: 25mm Gewicht: 131g
dimensions 120x120x25mm, revolutions 200-1800rpm, Air flow 95.7m³ / h, Air pressure 2.2mmH₂O, Fan bearing hydrodynamic plain bearing (FDB), Connection 4-pin PWM, Voltage range 12V, power consumption 0.96W, ACFAN00133A
IDEAL WHERE SPACE IS LIMITED Unlike normal case fans, which are 25 mm thick, the P12 Slim PWM PST has an installation depth of only 15 mm. This makes it a predestined fan for small form factor builds. OPTIMISED FOR STATIC PRESSURE During the development of the new P12 Slim PWM PST, special emphasis was placed on a focused airstream and thus a high static pressure. The fan guarantees extremely efficient cooling, even with increased air resistance. Therefore, the P12 Slim PWM PST is particularly suitable for use on covered case vents or inlets with filters. MORE EFFICIENT TECHNOLOGY The motor is powered by a Neodym-Iron-Boron-Magnet ring of the newest generation, which allows the new P12 Slim PWM PST to run much more efficiently than its predecessors. This saves energy and lowers the coil temperature without comprimising the performance. MAXIMUM QUIETNESS, MINIMUM VIBRATION Even at low speeds the operating sound of the new ARCTIC motor is barely noticeable. Due to a sinus-magnetizing the new motor only creates about 5 % of the vibration from commutation of a regular DC-motor without filter. Consequently, there is no need for rubber spacers due to the steady and smooth torque of the new motor. EXTENDED LIFE SPAN A 10 °C lower motor temperature roughly doubles the life span of a fan. The new ARCTIC motor has a four times longer service life through its low coil temperature. Consequently, we have extended the warranty to 10 years. 300 TO 2100 RPM REGULATED VIA PWM PST With a wide range of regulation and the PWM Sharing Technology (PST), the P12 Slim PWM PST fan speed can be controlled synchronously with all your other fans together. This keeps noise at a minimum while guaranteeing maximum cooling performance when needed. HIGH QUALITY BEARING Thanks to an alloy/lubricant combination developed in Germany, friction within the bearing is reduced and greater efficiency is achieved. As a result, there is less heat development as well as less bearing noise, which means you can enjoy a longer service life from your fan. Technical Data General Fan Speed: 300 - 2100 rpm Airflow: 41.1 CFM/ 71.53 m³/h Static Pressure: 1.45 (mm/H2O) Noise Level: 0.3 Sone Fan Fan Frame: Standard RPM-Controll: PWM Connector: 4-Pin-Connector + 4-Pin-Socket Fan Bearing: Fluid Dynamic Bearing Elektrical Specification Typical Voltage: 12 V DC Startup Voltage: 4 V Current: 0.12 A Cable Length: 400 mm Size & Weight Length: 120 mm Width: 120 mm Heigth: 15 mm Weight: 85 g
OPTIMISED FOR STATIC PRESSURE During the development of the new BioniX P120, special emphasis was placed on a focused airstream and thus a high static pressure. The fan guarantees extremely efficient cooling, even with increased air resistance. Therefore, the BioniX P120 is particularly suitable for use on heatsinks and radiators. STRONG COOLING PERFORMANCE Numerous improvements, such as an updated engine technology and a newly developed fan design, have noticeably increased the performance of P-fans. MORE EFFICIENT TECHNOLOGY The motor is powered by a Neodym-Iron-Boron-Magnet ring of the newest generation, which allows the new BioniX P120 to run much more efficiently than its predecessors. This saves energy and lowers the coil temperature without comprimising the performance. MAXIMUM QUIETNESS, MINIMUM VIBRATION Even at low speeds the operating sound of the new ARCTIC motor is barely noticeable. Due to a sinus-magnetizing the new motor only creates about 5 % of the vibration from commutation of a regular DC-motor without filter. Consequently, there is no need for rubber spacers due to the steady and smooth torque of the new motor. EXTENDED LIFE SPAN A 10 °C lower motor temperature roughly doubles the life span of a fan. The new ARCTIC motor has a four times longer service life through its low coil temperature. Consequently, we have extended the warranty to 10 years. 200 TO 2100 RPM REGULATED VIA PWM PST With a wide range of regulation and the PWM Sharing Technology (PST), the BioniX P120 fan speed can be controlled synchronously with all your other fans together. This keeps noise at a minimum while guaranteeing maximum cooling performance when needed. HIGH QUALITY BEARING Thanks to an alloy/lubricant combination developed in Germany, friction within the bearing is reduced and greater efficiency is achieved. As a result, there is less heat development as well as less bearing noise, which means you can enjoy a longer service life from your fan. Technical Data Performance Fan Speed: 200 - 2100 rpm Airflow: 67.56 CFM/ 114.9 m³/h Static Pressure: 2.75 mm H₂O Noise Level: 0.45 Sone Operating Ambient Temperature: 0 - 40 °C Fan Fan Frame: BioniX Control Type: PWM PST Connector: 4-Pin-Connector + 4-Pin-Socket Fan Bearing: Fluid Dynamic Bearing Electric Characteristics Typical Voltage: 12 V DC Starting Voltage: 4.3 V Current/ Voltage: 0.13 A / 12 V Cable Lenght: 400 mm Size & Weight Lenght: 120 mm Width: 120 mm Height: 27 mm Weight: 140 g
When developing the new BioniX P120, special emphasis was placed on a focused air flow and a high static pressure. The fan guarantees extremely efficient cooling, even with increased air resistance. Numerous improvements, such as engine technology and a newly developed fan design, have noticeably increased the performance of P fans. In internal performance tests, the new P fans leveled out to 28 dB (A) left many competitors behind. Technical Details Fan: 120 mm, 200 - 2,100 rpm (PWM controlled) Air flow: 67.56 CFM / 114.79 m3 / h (@ 2,100 rpm) Noise level: 0.45 sone (@ 2,100 rpm) Static pressure: 2.75 mm H2O (@ 2,100 rpm) Typical voltage: 12 V DC Cable length: 400 mm PST cable length: 50 mm
Set aus drei 120-mm-Gehäuselüftern, max. 2.000 U/min, 4-Pin-PWM-Anschluss, PST-Technologie, langlebiges Fluiddynamik-Lager, adressierbare RGB-Beleuchtung
