Lauaarvuti Minis Forum Mini PC N5 Air Ryzen 7 H255 0GB 64GB

MINISFORUM N5 Air Ryzen 7 H255 0GB 64GB mini PCThe MINISFORUM N5 Air is an advanced NAS server designed for users who require vast storage space, high performance, and modern expansion capabilities. Equipped with an AMD Ryzen™ 7 255 processor and the proprietary MinisCloud OS, this model serves as an ideal central hub for file storage, backups, multimedia streaming, virtualization, and Docker containers. The design supports up to 174 TB of total storage, offering immense flexibility for building a robust private data cloud.Powerful computing powerSeamless operation is guaranteed by the AMD Ryzen™ 7 255 processor, featuring 8 cores and 16 threads, with a configurable TDP ranging from 45 W to 55 W. This configuration delivers high performance for running multiple services simultaneously, supporting virtual machines, Docker containers, and efficient video transcoding. The integrated AMD Radeon™ 780M graphics chip enables graphical tasks and the connection of high-resolution monitors, allowing the device to function as a versatile workstation for everyday use.Massive storage capacityThe MINISFORUM N5 Air offers exceptionally flexible storage options. Five SATA 3.0 bays support 3.5" and 2.5" drives with capacities up to 30 TB each, while three M.2 2280/22110 NVMe PCIe 4.0 slots allow for high-speed SSD installation with capacities up to 8 TB each. Together, these allow for a total system capacity of up to 174 TB. Support for RAID 0, RAID 1, RAID 5, and RAID 6 lets you tailor the configuration to your specific needs, whether prioritizing maximum speed or advanced data protection.High-performance memory and expansion capabilitiesThe device features two SO-DIMM slots supporting up to 96 GB of DDR5 Non-ECC memory clocked at 5600 MT/s, ensuring rapid data access even under heavy workloads. Additional expansion possibilities are provided by an internal PCIe 4.0 x16 (electrically x4) connector and an OCuLink port, allowing for the connection of specialized expansion cards and external accessories.Lightning-fast network connectivityDual LAN ports with 10GbE and 5GbE bandwidth provide ultra-fast data transfer across your local network, which is essential when handling large files, creating backups, or streaming high-bitrate media. MinisCloud OS offers advanced data management, including support for the ZFS file system, snapshots for data loss protection, and real-time LZ4 compression. The system also supports Docker containers with user isolation and secure remote access, while also allowing for the installation of Windows 11 Pro or Linux.Extensive port selection and practical designThe chassis includes two USB4 ports with DisplayPort 2.0 support, two USB 3.2 Gen2 ports, a USB 2.0 port, HDMI 2.1, and an OCuLink connector. This allows for the connection of up to three monitors with resolutions up to 8K at 60 Hz. The enclosure, measuring 199 × 202 × 252 mm, features a slide-out design that facilitates easy access for drive and memory upgrades. Two 9225 axial fans provide efficient cooling, while front-panel LEDs indicate the system status, network activity, and the health of each hard drive. Included in the packageMini PCPower supplyPower cableHDMI cableNetwork cableSet of screws for HDD drivesUser manual SpecificationsBrandMINISFORUMModelN5 AirProcessor (CPU)AMD Ryzen™ 7 255 (8 cores, 16 threads)CPU clock speedBase 3.8 GHz; max. Turbo 4.9 GHzTDP45W–55WGraphics card (GPU)Integrated AMD Radeon™ 780MRAM slots2 × SO-DIMMMaximum RAMUp to 96GB DDR5 Non-ECCRAM speed5600MT/sHDD/SATA drive bays5 × 3.5"/2.5" SATA 3.0Maximum HDD capacityUp to 30TBSSD/NVMe drive slots3 × M.2 2280/22110 NVMe PCIe 4.0Max. SSD capacityUp to 8TBTotal storage capacityUp to 174TBSupported RAID modesRAID 0, RAID 1, RAID 5, RAID 6LAN port 15GbE (RTL8126)LAN port 210GbE (RTL8127 or AQC113)Video connectorsHDMI 2.1 (8K@60Hz/4K@144Hz), 2 × USB4 with Alt DP 2.0 (8K@60Hz/4K@144Hz)Front portsUSB4 (with DP 2.0), USB 3.2 Gen2Rear portsUSB4 (with Alt DP 2.0), HDMI 2.1 FRL × 1, OCuLink, 10GbE LAN, 5GbE LAN, USB 3.2 Gen2, USB 2.0Expansion slots (internal)PCIe 4.0 x16 (electrically x4)Operating systemMinisCloud OS, compatible with Windows 11 (not included)DesignSlidingCPU coolingDual heat pipes, PCM, 7515 mm Turbo fan, 2700 RPMHDD cooling2 × 9025 mm axial fans, 3450 RPMNoise level42 dB (measured at 50 cm, Balance mode)Wireless connectivityNoneEnclosurePlasticLEDsStatus × 1, NIC × 2, HDD × 5Dimensions19.9 × 20.2 × 25.2 cmWeight4 kg
