This D-Sub HD (High Density) male connector by Delock is suitable for solder assembly and can be used for cable assembly.   Specification • Connectors:   1 x D-Sub HD 44 pin male (3 rows)   1 x 44 soldering pin • Operating temperature: -40 °C ~ 105 °C • Material: metal • Dimensions (LxWxH): ca. 53.0 x 12.5 x 11.0 mm   Package content • 2 x D-Sub HD 44 pin male

With this adapter by Delock the DisplayPort jack of a device can be angled by 90°. This makes it easier to connect a cable in hard to reach places.   Specification • Connectors:   1 x DisplayPort male >   1 x DisplayPort female • DisplayPort 1.4 specification • Downwards compatible to DisplayPort 1.3, 1.2 and 1.1 • Pin 20 is connected (supports 3.3 V) • Contacts gold-plated • Data transfer rate up to 32.4 Gb/s • Resolution up to:   Display with DSC support: 7680 x 4320 @ 60 Hz   Display without DSC support: 7680 x 4320 @ 30 Hz   (depending on the system and the connected hardware) • Supports Display Stream Compression 1.2 (DSC) • Supports HDR • Supports HDCP 1.4 and 2.2 • Dimensions (LxWxH): ca. 30.3 x 31.6 x 12.0 mm • Colour: black   System requirements • A free DisplayPort female   Package content • DisplayPort adapter

This D-Sub HD (High Density) male connector by Delock is suitable for cable mounting. On the back side there are through holes for inserting crimp contacts.   Specification • Connectors:   1 x D-Sub HD 50 pin male (3 rows)   50 x through hole for crimp contacts • Cable gauge: 28 - 20 AWG • Operating temperature: -40 °C ~ 105 °C • Material: metal • Dimensions (LxWxH): ca. 67.0 x 17.5 x 12.5 mm   Package content • D-Sub HD 50 pin crimp male

This D-Sub male connector by Delock is suitable for cable mounting. On the back side there are through holes for inserting crimp contacts.   Specification • Connectors:   1 x D-Sub 15 pin male (2 rows)   15 x through hole for crimp contacts • Cable gauge: 28 - 20 AWG • Operating temperature: -40 °C ~ 105 °C • Material: metal • Dimensions (LxWxH): ca. 39.1 x 17.5 x 12.5 mm   Package content • 4 x D-Sub 15 pin crimp male

With this adapter by Delock the DisplayPort jack of a device can be angled by 90°. This makes it easier to connect a cable in hard to reach places.   Specification • Connectors:   1 x DisplayPort male >   1 x DisplayPort female • DisplayPort 1.4 specification • Downwards compatible to DisplayPort 1.3, 1.2 and 1.1 • Pin 20 is connected (supports 3.3 V) • Contacts gold-plated • Data transfer rate up to 32.4 Gb/s • Resolution up to:   Display with DSC support: 7680 x 4320 @ 60 Hz   Display without DSC support: 7680 x 4320 @ 30 Hz   (depending on the system and the connected hardware) • Supports Display Stream Compression 1.2 (DSC) • Supports HDR • Supports HDCP 1.4 and 2.2 • Dimensions (LxWxH): ca. 30.3 x 31.6 x 12.0 mm • Colour: black   System requirements • A free DisplayPort female   Package content • DisplayPort adapter

This D-Sub male connector by Delock is suitable for cable mounting. On the back side there are through holes for inserting crimp contacts.   Specification • Connectors:   1 x D-Sub 25 pin male (2 rows)   25 x through hole for crimp contacts • Cable gauge: 28 - 20 AWG • Operating temperature: -40 °C ~ 105 °C • Material: metal • Dimensions (LxWxH): ca. 53.0 x 17.5 x 12.5 mm   Package content • 4 x D-Sub 25 pin crimp male

This D-Sub male connector by Delock is suitable for cable mounting. On the back side there are through holes for inserting crimp contacts.   Specification • Connectors:   1 x D-Sub 37 pin male (2 rows)   37 x through hole for crimp contacts • Cable gauge: 28 - 20 AWG • Operating temperature: -40 °C ~ 105 °C • Material: metal • Dimensions (LxWxH): ca. 69.3 x 17.5 x 12.5 mm   Package content • 2 x D-Sub 37 pin crimp male

These crimp contacts by Delock can be used for crimping on wires and they are suitable for D-Sub HD (High Density) crimp connectors.   Specification • For D-Sub HD female connectors with crimp contacts • Cable gauge: 24 - 20 AWG • Insulation diameter: 1.6 mm • Diameter: ca. 0,7 mm • Contacts gold-plated • Operating temperature: -40 °C ~ 105 °C     Package content • 40 x crimp contacts

This D-Sub HD (High Density) male connector by Delock is suitable for solder assembly and can be used for cable assembly.   Specification • Connectors:   1 x D-Sub HD 50 pin male (3 rows)   1 x 50 soldering pin • Operating temperature: -40 °C ~ 105 °C • Material: metal • Dimensions (LxWxH): ca. 67.0 x 12.5 x 11.0 mm   Package content • 2 x D-Sub HD 50 pin male

These crimp contacts by Delock can be used for crimping on wires and they are suitable for D-Sub HD (High Density) crimp connectors.   Specification • For D-Sub HD connectors with crimp contacts • Cable gauge: 24 - 20 AWG • Insulation diameter: 1.6 mm • Diameter: ca. 0,7 mm • Contacts gold-plated • Operating temperature: -40 °C ~ 105 °C     Package content • 40 x crimp contacts

This D-Sub male connector by Delock is suitable for cable mounting. On the back side there are through holes for inserting crimp contacts.   Specification • Connectors:   1 x D-Sub 9 pin male (2 rows)   9 x through hole for crimp contacts • Cable gauge: 28 - 20 AWG • Operating temperature: -40 °C ~ 105 °C • Material: metal • Dimensions (LxWxH): ca. 30.8 x 17.5 x 12.5 mm   Package content • 4 x D-Sub 9 pin crimp male

This D-Sub female connector by Delock is suitable for cable mounting. On the back side there are through holes for inserting crimp contacts.   Specification • Connectors:   1 x D-Sub 37 pin female (2 rows)   37 x through hole for crimp contacts • Cable gauge: 28 - 20 AWG • Operating temperature: -40 °C ~ 105 °C • Material: metal • Dimensions (LxWxH): ca. 69.3 x 17.5 x 12.5 mm   Package content • 2 x D-Sub 37 pin crimp female   Package • Zip poly bag

This D-Sub HD (High Density) female connector by Delock is suitable for cable mounting. On the back side there are through holes for inserting crimp contacts.   Specification • Connectors:   1 x D-Sub HD 50 pin female (3 rows)   50 x through hole for crimp contacts • Cable gauge: 28 - 20 AWG • Operating temperature: -40 °C ~ 105 °C • Material: metal • Dimensions (LxWxH): ca. 67.0 x 15.7 x 12.5 mm   Package content • D-Sub HD 50 pin crimp female

These crimp contacts by Delock can be used for crimping on wires and they are suitable for D-Sub crimp connectors.   Specification • For D-Sub connectors with crimp contacts • Cable gauge: 24 - 20 AWG • Insulation diameter: 2.1 mm • Diameter: ca. 1.0 mm • Contacts gold-plated • Operating temperature: -40 °C ~ 105 °C     Package content • 40 x crimp contacts

This D-Sub HD (High Density) female connector by Delock is suitable for solder assembly and can be used for cable assembly.   Specification • Connectors:   1 x D-Sub HD 44 pin female (3 rows)   1 x 44 soldering pins • Operating temperature: -40 °C ~ 105 °C • Material: metal • Dimensions (LxWxH): ca. 53.0 x 12.5 x 10.7 mm   Package content • 2 x D-Sub HD 44 pin female

This D-Sub HD (High Density) female connector by Delock is suitable for solder assembly and can be used for cable assembly.   Specification • Connectors:   1 x D-Sub HD 50 pin female (3 rows)   1 x 50 soldering pin • Operating temperature: -40 °C ~ 105 °C • Material: metal • Dimensions (LxWxH): ca. 67.0 x 12.5 x 10.7 mm   Package content • 2 x D-Sub HD 50 pin female

This D-Sub HD (High Density) male connector by Delock is suitable for cable mounting. On the back side there are through holes for inserting crimp contacts.   Specification • Connectors:   1 x D-Sub HD 26 pin male (3 rows)   26 x through hole for crimp contacts • Cable gauge: 28 - 20 AWG • Operating temperature: -40 °C ~ 105 °C • Material: metal • Dimensions (LxWxH): ca. 39.1 x 17.5 x 12.5 mm   Package content • 2 x D-Sub HD 26 pin crimp male

This D-Sub female connector by Delock is suitable for solder assembly and can be used for cable assembly.   Specification • Connectors:   1 x D-Sub 37 pin female (2 rows)   1 x 37 soldering pin • Operating temperature: -40 °C ~ 105 °C • Material: metal • Dimensions (LxWxH): ca. 69.3 x 12.5 x 10.7 mm   Package content • 4 x D-Sub 37 pin female

This high-quality High Speed HDMI cable by Delock can be used to connect devices with an HDMI interface, such as televisions, Blu-ray players, monitors or projectors. By supporting a maximum bandwidth of 48 Gbps, content can be displayed in 8K Ultra HD (7680 x 4320 @ 60 Hz) resolution. Dynamic HDR and Dolby® Vision support Supporting Dynamic HDR and Dolby® Vision, the cable is ideal for home cinema and gaming applications. Colours are realistically displayed with impressive depth, brightness and contrast are optimally reproduced. Perfect sound with eARC support The Delock HDMI cable supports Enhanced ARC (eARC). This allows HDMI devices such as Blu-ray players to be connected directly to the TV. The uncompressed audio signals are then transmitted directly and lossless to the connected sound system via the audio return channel.   Specification • Connectors:   1 x HDMI-A male >   1 x HDMI-A male • Cable gauge: 30 AWG • Cable diameter: ca. 6 mm • Copper conductor • Triple shielded cable • Contacts gold-plated • Transmission of audio and video signals • Data transfer rate up to 48 Gbps • Resolution up to:   7680 x 4320 @ 60 Hz   5120 x 2880 @ 120 Hz   3840 x 2160 @ 240 Hz   (depending on the system and the connected hardware) • 3D support: up to 3840 x 2160 @ 120 Hz   (depending on the system and the connected hardware) • Supports the 21:9 cinema aspect ratio • Supports 1080p HFR (High Frame Rate) 3D • Supports colour sampling in 4:4:4, 4:2:2 and 4:2:0 format • Supports Display Stream Compression 1.2 (DSC) • Supports Dolby® Vision • Supports Dynamic HDR • Supports Game Mode VRR • Supports eARC • Up to 32 audio channels for speakers • Up to 1536 kHz audio sampling rate • Supports Dolby® TrueHD and DTS-HD Master Audio™ • Supports dynamic adjustment of lip synchronicity for audio / video delays • Supports CEC 2.0 control commands • Colour: black • Length incl. connectors (L): ca. 1 m   System requirements • A free HDMI interface   Package content • High Speed HDMI cable

This terminal block adapter by Delock can be used to connect bare wires. The Adapter is suitable for special industrial applications. Protection by enclosure The metal housing protects the PCB against dirt and damage.   Specification • Connectors:   1 x HDMI-A male   1 x 20 pin terminal block • Pin assignment: 1:1 • Pitch: 2.00 mm • Useable for a cable gauge from 30 to 24 AWG • Operating temperature: -15 °C ~ 70 °C • Dimensions (LxWxH): ca. 61.5 x 23.5 x 16.0 mm   Package content • Adapter • 2 x locking screws • 1 x screwdriver

This splice box by Delock can be mounted in a 19″ rack. The cassette is extendable, so that it is possible to work on both sides of the couplers without removing the cover. A wide selection of matching front panels with pre-assembled fibre optic couplers is available as accessory, from SC Simplex to LC Quad   Specification • For mounting in 19″ racks, 1U • For 96 fibers • Extendable tray, 45° angled • Lockable with knurled screws • Cable support bar • 4 rear cable entries • Operating temperature: -20 °C ~ 70 °C • Housing colour: black • Dimensions (LxWxH): ca. 482.6 x 338.5 x 43.7 mm   System requirements • Delock 19″ splice box front panel   Package content • 19″ fiber optic splice box • Cable support bar • 4 x splice cassette for 24 pigtails • 2 x M20 cable gland • 4 x zip-tie • Installation manual

This Easy 45 charging port module by Delock provides a USB Type-A charging port with fast charging technology up to 18 watts for smartphones. The simple snap-in mechanism ensures that the module is firmly in place and can be easily removed if necessary. Easy 45 connects Easy 45 is a variable, modular system that allows components such as sockets, HDMI or USB connections to be added according to your needs. The Easy 45 modules are standardised and can be mounted in various module holder or cable ducts. Easy 45 builds the interface between electrical, network and system installation and many peripheral devices such as TV, monitors, printers, laptops and much more.   Specification • Connectors:   1 x USB Type-A female   1 x 2 pin terminal block N, L • Input: AC 100 ~ 240 V / 50 ~ 60 Hz / 0.5 A • Output: USB-A 5.0 V 3.0 A, 9.0 V 2.0 A, 12.0 V 1.5 A • Output power: max. 18.0 W total • Average active efficiency 85.30 % • Efficiency at low load (10 %) 78.70 % • No-load power consumption 0.141 W • Short circuit protection • LED indicator for power • Material: PC plastic • Suitable for module holder Delock Easy 45 • Suitable for 45 mm cable duct with minimum depth 45 mm • Module size: 45 x 45 mm • Dimensions (LxWxH): ca. 45 x 45 x 39 mm • Colour: white   System requirements • A free module port Delock Easy 45   Package content • Charging port module

This wall outlet by Delock can be installed in-wall or on a back box with 60 mm mounting holes. With its standardized dimensions, it is suitable for easy snap-in mounting of one Keystone module.   Specification • 1 Keystone port 19.2 x 14.9 mm • 45° angle of Keystone modules • Dust cover • Integrated name plate • Design suitable central plate 50 x 50 mm • Mounting holes 60 mm • Colour: pure white RAL 9010 • Dimensions (LxWxH): ca. 80 x 80 x 26 mm   Package content • Keystone wall outlet   Package • Poly bag

This module by Delock can be used to extend fiber optic cables. With its standardised dimensions it can be used for easy snap-in mounting in e.g. a Keystone patch panel, face plate or surface-mount box.   Specification • Connectors:   1 x LC Duplex female >   1 x LC Duplex female • Colour: violet • For multi-mode fiber • Insertion loss < 0.3 dB • Dust covers • For Keystone ports with 19.2 x 14.9 mm • Housing colour: black • Dimensions (LxWxH): ca. 29.2 x 16.5 x 21.9 mm   System requirements • A free LC Duplex plug   Package content • Keystone module

This USB memory stick by Delock can be used to save and transport data, e.g. photos, videos or music. The USB stick can be connected optionally via the USB Type-C™ or USB Type-A plug, the inner part is simply turned and then latch into place. Due to the stylish design with eyelet, the small USB memory stick can be easily attached to the key ring for transport. Small sturdy helper Due to its small dimensions and its sturdy housing, this Delock USB stick is particularly suitable for travelling. Due to its tiny size, the USB stick fits into any trouser pocket. Downwards compatible The USB 3.2 Gen 1 Type-A connector is compatible to its forerunners USB 3.0, USB 2.0 and USB 1.1. Thus the memory stick can be connected to a USB 2.0 or USB 1.1 port too. The data transfer rate complies with the respective specification.   Specification • Connectors:   1 x SuperSpeed USB (USB 3.2 Gen 1) Type-A male   1 x SuperSpeed USB (USB 3.2 Gen 1) USB Type-C™ male • Capacity: 16 GB • Maximum read speed: 117 MB/s • Maximum write speed: 43 MB/s • Maximum write cycles: 3000 • Operating temperature: 0 °C ~ 70 °C • Storage temperature: -25 °C ~ 85 °C • Power consumption: max. 5 W • Field of application: consumer • Plug & Play • Dimensions (LxWxH): ca. 36.8 x 12.1 x 7.1 mm   System requirements • Chrome OS 72.0 or above • Linux Kernel 3.3 or above • Mac OS 10.14.3 or above • Windows 7/7-64/8.1/8.1-64/10/10-64 • PC or laptop with a free USB Type-A port or • PC or laptop with a free USB Type-C™ port   Package content • USB 3.0 memory stick

This high quality standoff mounting set by Delock contains different thread sizes which can be used for secure mounting of PCBs to create a fixed distance between a printed circuit board and other components. By separating the PCBs from other components, the spacers allow a better ventilation and offer an optimal resistance to high temperatures, e.g. inside of a PC case.   Specification • Content:   4 x M2.5, inside / inside, length 10 mm   4 x M2.5, inside / inside, length 20 mm   4 x M2.5, inside / inside, length 30 mm   4 x M2.5, inside / outside, length 10 mm   4 x M2.5, inside / outside, length 20 mm   4 x M2.5, inside / outside, length 30 mm   36 x M2.5 screw   12 x M2.5 nut   4 x M3, inside / inside, length 10 mm   4 x M3, inside / inside, length 20 mm   4 x M3, inside / inside, length 30 mm   4 x M3, inside / outside, length 10 mm   4 x M3, inside / outside, length 20 mm   4 x M3, inside / outside, length 30 mm   36 x M3 screw   12 x M3 nut   4 x M4, inside / inside, length 10 mm   4 x M4, inside / inside, length 20 mm   4 x M4, inside / inside, length 30 mm   4 x M4, inside / outside, length 10 mm   4 x M4, inside / outside, length 20 mm   4 x M4, inside / outside, length 30 mm   36 x M4 screw   12 x M4 nut   4 x M5, inside / inside, length 10 mm   4 x M5, inside / inside, length 20 mm   4 x M5, inside / inside, length 30 mm   4 x M5, inside / outside, length 10 mm   4 x M5, inside / outside, length 20 mm   4 x M5, inside / outside, length 30 mm   36 x M5 screw   12 x M5 nut   4 x M6, inside / inside, length 10 mm   4 x M6, inside / inside, length 20 mm   4 x M6, inside / inside, length 30 mm   4 x M6, inside / outside, length 10 mm   4 x M6, inside / outside, length 20 mm   4 x M6, inside / outside, length 30 mm   36 x M6 screw   12 x M6 nut • Material: brass nickel plated / steel • Box dimensions (LxWxH): ca. 250 x 190 x 40 mm   Package content • Standoff mounting set   Package • Box
