UT15B/17B/18B Max True RMS Digital Multimeters UT15B/17B/18B MAX series True RMS multi-meters have a compact and portable design, fast response, strong anti-interference to EMC interference, and come with standard gold-plated test leads and gold-plated fine-tipped test leads.They also feature full-range 1000V input protection, making them the ideal tool for electronic and electrical engineers. Models: UT15B MAX, UT17B MAX, UT18B MAX Features of UT15B/17B/18B Max True RMS Digital Multimeters Certificates: CE, UKCA, cETLus, REACH, RoHS ● True RMS measurement ● Compact design ● V.F.D function ● Fast measurement of Continuity ● Fast measurement of Capacitance ● Two test probes (standard & fine-tipped) ● Strong EMC anti-interference ● Full-range input protection Specifications of UT15B/17B/18B Max True RMS Digital Multimeters Technical Specifications UT15B MAX UT17B MAX UT18B MAX Certificates CE, UKCA, cETLus, REACH, RoHS Voltage (DC) 600.0mV/6.000V/60.00V/600.0V/1000V ±(0.4%+3) ±(0.4%+3) ±(0.4%+3) Voltage (AC) 600.0mV/6.000V/60.00V/600.0V/1000V ±(0.5%+5) ±(0.5%+5) ±(0.5%+5) VFD (Voltage) 600.0V ±(8%) ±(8%) ±(8%) Current (AC) 600.0µA/6000µA/60.00mA/600.0mA/6.000A/10.00A ±(1.2%+3) ±(1.2%+3) ±(1.2%+3) Current (DC) 600.0µA/6000µA/60.00mA/600.0mA/6.000A/10.00A ±(1.2%+3) ±(1.2%+3) ±(1.2%+3) Resistance 600.0Ω/6.000kΩ/60.00kΩ/600.0kΩ/6.000MΩ/60.00MΩ ±(0.5%+2) ±(0.5%+2) ±(0.5%+2) Capacitance 6.000nF/60.00nF~600.0µF/6000µF ±(2.0%+5) ±(2.0%+5) ±(2.0%+5) Frequency(Hz) 10Hz~10MHz ±(0.1%+3) ±(0.1%+3) ±(0.1%+3) Duty cycle 1%~99.9% ±(1.0%+4) ±(1.0%+4) ±(1.0%+4) Temperature(℃/℉) -55℃~500℃/–67°F~932°F – ±2℃/±4℉ ±2℃/±4℉ Main features Display count 6000 6000 6000 Continuity / Diode √ √ √ Data hold √ √ √ MAX/MIN √ √ – Relative mode √ √ √ Backlight (adjustable) √ √ √ Auto range/Manual range √ √ √ Auto power off √ √ √ Low battery indication √ √ √ Audible & Visual alarm √ √ √ LED test – – √ Mis-plug alarm √ √ √ Any-key wake up √ √ √ Overvoltage category CATⅢ 600V CATⅢ 600V CATⅢ 600V General Characteristics Power supply 2*1.5V AA 2*1.5V AA 2*1.5V AA Product color 426U+1797C 426U+1797C 426U+1797C Product weight 455g 455g 455g Product dimension 182mm*91mm*45mm 182mm*91mm*45mm 182mm*91mm*45mm Accessories 1pcs User manual, 2 pair Test lead(normal gold plated probe & Fine-tipped probe),1pcs K-type thermocouple (UT17B/UT18B MAX only), 2pcs battery, Magnetic hanger(optional) SPQ 10 pcs 10 pcs 10 pcs Package dimension 480×370×195mm 480×370×195mm 480×370×195mm Standard package gross weight Around 9kg Around 9kg Around 9kg
UNI-T UT116C SMD Tester.The UNI-T UT116C SMD tester is a versatile and compact measuring device, ideal for electronic service and production facilities. The instrument allows automatic recognition and measurement of parameters of such components as resistors, capacitors (up to 100 mF), diodes, as well as polarity testing of Zener diodes. The UT116C additionally allows measuring DC voltage up to 36 V and checking the state of the battery at 10 mA load. Thanks to its continuity measurement function and built-in LED indicator, the device provides quick and clear results, regardless of the intensity of work. In addition, the product is CE and UKCA certified, confirming high quality and safety standards.Wide range of functions for professionalsThe UT116C tester combines multiple functions in a single, compact device. Automatic component identification simplifies daily work, and the ability to manually check the polarity of LEDs and Zener diodes allows accurate analysis of electronic circuits. In addition, the UT116C provides convenient measurements of DC voltage and battery status, making it an extremely versatile tool in an electronics technician's workshop.Thoughtful design for even greater convenienceThe UT116C's design has been engineered for maximum ergonomics - the tester's movable tip that rotates 180° allows for easy reading of results, even in hard-to-reach places. The integrated LED indicator and compact size make the tester not only functional, but also extremely convenient for everyday use. UNI-T UT116C is an indispensable support in any professional electronic service, ensuring safety and precision during any work.IncludedSMD testerbatteryinstruction manual ManufacturerUNI-TModelUT116CNumber of displayed digits6000Resistance60 MΩCapacitance100 mFDiode test3,2 VLED/stabilivolt testApproximately 21 V / 1 mACircuit continuity test< 50 ΩDC voltage (DCV) measurement36 VBattery/battery testLoad current = 10 mAAutomatic range selectionYesAutomatic component identificationYesAutomatic shutdownYesPower supply2 × 1.5 V battery (R03)Display dimensions39 mm × 20 mmColorRed and grayWeightApproximately 80 gDimensions204 mm × 33 mm × 25 mm
