Otsing: thermal pad

EK-Quantum Vector Strix RX 5700 +XT Backplate is a CNC machined retention backplate made from black anodized aluminum for EK-Vector Radeon RX 5700 +XT series water blocks. Backplate covers the whole length of graphics cards PCB, serves as an aesthetic add-on and also provides passive cooling for the backside of the voltage regulation module (VRM). This backplate is guaranteed to be compatible with ROG Strix Radeon™ RX 5700 XT series graphics cards. Enclosed: - EK-Quantum Vector Strix RX 5700 +XT Backplate - Black - Mounting mechanism - Thermal pads Made in Slovenia - Europe!

EK-Quantum Vector Strix RX 5700 +XT Backplate is a CNC machined retention backplate made from nickel-plated aluminum for EK-Vector Radeon RX 5700 +XT series water blocks. Backplate covers the whole length of graphics cards PCB, serves as an aesthetic add-on and also provides passive cooling for the backside of the voltage regulation module (VRM). This backplate is guaranteed to be compatible with ROG Strix Radeon™ RX 5700 XT series graphics cards. Enclosed: - EK-Quantum Vector Strix RX 5700 +XT Backplate - Nickel - Mounting mechanism - Thermal pads Made in Slovenia - Europe!

The EK-Quantum Vector FE RTX 3070 backplate is designed for the EK-Quantum Vector RTX FE 3070 graphics card cooler of the same name. A backplate is particularly suitable for giving the graphics card more stability. Since the backplate is kept very simple, it is rounded off by a small but elegant EK logo. Technical Data Material: Nickel-Plated Aluminium Color: Nickel Scope of Delivery EK-Quantum Vector FE RTX 3070 Backplate - Nickel Mounting mechanism (the backplate screws are on the other side - separate compartment) Thermal pads

EK-Quantum Vector Strix RTX 3070 D-RGB from EK is a complete cooler for the ROG Strix RTX 3070 from ASUS. The high-quality workmanship and the nickel-plated copper material used for the heat sink are striking. The nickel-plated copper covers all important areas of the graphics card, such as GPU, memory and voltage converter. The optimised channel structure results in very efficient and reliable cooling. Visually, the cooler is rounded off with a transparent acrylic glass lid and a black end piece. The integrated RGB lighting sets the scene perfectly for the EK Quantum. In addition, the cooler has four G1/4" connections. The graphics card cooler is compatible with the common RGB synchronisation technologies of all major mainboard manufacturers. Technical Data Dimensions: 293 x 154 x 16,5 mm Material Base: Nickel-Plated Copper Material Cover: Acryl Thread: 4x G1/4" D-RGB cable length: 500mm D-RGB LED count: 6 D-RGB connector standard 3-pin (+5V, Data, Blocked, Ground) Compatibility ASUS ROG Strix RTX 3070 Scope of Delivery EK-Quantum Vector Strix RTX 3070 D-RGB series high-performance water block Mounting mechanism with screw-in brass standoffs Necessary mounting screws, nuts, and washers 2x Nickel plated brass plug G1/4” EK-Loop Multi Allen Key (6mm, 8mm, 9mm) Thermal pads Thermal grease EK-TIM Ectotherm (1g)

The EK Quantum Vector RE RTX 3070 from EK is a complete cooler for the Founders Edition of the RTX 3070 from Nvidia. The high-quality workmanship and the nickel-plated copper material used for the heat sink are striking. The nickel-plated copper covers all important areas of the graphics card, such as GPU, memory and voltage converter. The optimised channel structure results in very efficient and reliable cooling. Visually, the black acetal lid stands out, which is rounded off by a metallic trim. In addition, the cooler has four G1/4" connections, which, however, are found on the short side instead of on the upper long side as usual. Technical Data Dimensions: 205 x 98 x 21 mm Material Base: Nickel-Plated Copper Material Cover: Acetal Thread: 4x G1/4" Compatibility NVIDIA GeForce RTX 3070 (Founders Edition) Scope of Delivery EK-Quantum Vector RE RTX 3070 series high-performance water block Mounting mechanism with screw-in brass standoffs Necessary mounting screws, nuts, and washers 2x Nickel plated brass plug G1/4” EK-Loop Multi Allen Key (6mm, 8mm, 9mm) Thermal pads Thermal grease EK-TIM Ectotherm (1g)

The EK-Quantum Vector FE RTX 3070 backplate is designed for the EK-Quantum Vector RTX FE 3070 graphics card cooler of the same name. A backplate is particularly suitable for giving the graphics card more stability. Since the backplate is kept very simple, it is rounded off by a small but elegant EK logo. Technical Data Material: Aluminium Color: Black Scope of Delivery EK-Quantum Vector FE RTX 3070 Backplate - Black Mounting mechanism (the backplate screws are on the other side - separate compartment) Thermal pads

Stannol KS115 electronic solder wire has been designed for the special requirements of lead-free soldering. It is suitable for industrial manufacturing as well as for rework and repair. Stannol solder wire KS115 contains a rosin-free, halide activated synthetic resin. The flux formulation of KS115 is classified to DIN EN 29454-1 Type 1.2.2.B. Due to its high activity (1.5%), the flux is classified as REM1 to IEC 61190-1-3. Alloy: 99% tin, 1% copper Melting point 227°C Active flux for fast wetting of solder pads and pins Bright amber residues with low thermal decomposition at soldering temperatures Solid residues with high softening point Low fuming Low spitting Available in a range of diameters and pack sizes   Seos DIN EN 29454-1 Fluksipitoisuus Fluksikanavien määrä KS100 1.2.3 3,0 % 1 KS110 1.2.2 3,0 % 1 KS115 1.2.2 3,0 % 1

Thermaltake's Pure A14 is a PWM controlled LED fan available in four different colours: blue, green, red and white. Especially radiators benefit from the very quiet operation and low heat generation thanks to the self-lubricating hydraulic bearing. The anti-vibration pads also ensure low noise levels. As the sealing cap prevents the lubricant from escaping, a long service life is also guaranteed. The nine LEDs of the fan impress with a uniform brightness and high colour intensity and give the PC system the final touch. Technical Data: LED colour: White Dimenson: 140 x 140 x 25 mm Interface: 4-Pin PWM Fan Stated Voltage: 9.0 V Fan Rated Voltage: 12 V Rated current: 0.27 A Power Input: 3.24 W Fan Speed: 500 - 1500 rpm Max. Air Pressure: 2.05 mm-H2O Max Air Flow: 93.15 CFM Noise: 32 dB-A Bearing Type: Hydraulic Bearing Life Expectation: 40,000 hrs, 25℃ Weight: 176 g

The EK-Quantum Momentum Aorus Z490 Master D-RGB is the new Quantum Line monoblock designed specifically for the Gigabyte Aorus Z490 master motherboard. The monoblock is simple and elegant due to its black acetal. Based on the EK Momentum series, the CPU cooler has been further optimised in terms of performance and optimal coolant flow. The cooling plate is made of nickel-plated copper and impresses with its dense micro-rib structure. Thanks to the pre-installed nickel-plated brass screw-in spacers, installation is made easy. The supplied thermal pad is used on voltage regulator modules to improve stability and performance and extend the life of the motherboard. Enclosed: EK-Quantum Momentum Aorus Z490 Master D-RGB Monoblock Mounting mechanism Thermal grease EK-TIM Ectotherm Thermal pads

The EK-Quantum Momentum Aorus Z490 Master D-RGB is the new Quantum Line monoblock designed specifically for the Gigabyte Aorus Z490 master motherboard. The top side of the monoblock is made of acrylic glass and the integrated addressable D-RGB lighting sets the block perfectly in scene. Based on the EK Momentum series, the CPU cooler has been further optimised in terms of performance and optimum coolant flow. The cooling plate is made of nickel-plated copper and impresses with its dense micro-rib structure. Thanks to the pre-installed nickel-plated brass screw-in spacers, installation is made easy. The supplied thermal pad is used on voltage regulator modules to improve stability and performance and extend the life of the motherboard. The block is equipped with a 3-pin 5V addressable D-RGB LED strip compatible with the 3-pin 5V D_LED (addressable LED strip) headers of the Aorus Z490 Master. This product is also compatible with D-RGB controllers that support the pin assignment: +5V, D, Blocked, Ground. The arrow marking on the 3-pin LED connector must be aligned with the +5V marking on the D_LED (addressable LED strips). Technical Data D-RGB-Anschluss 3-polige 5V-Digital-LED-Stiftleiste (Pinbelegung: +5V, D, blockiert, Masse) Enclosed: EK-Quantum Momentum Aorus Z490 Master D-RGB Monoblock Mounting mechanism Thermal grease EK-TIM Ectotherm Thermal pads

Buff Thermal müts on valmistatud 100% naturaalsest meriinovillast, kerge ja mitmekülgne. Kergeid meriinovillaseid tooteid kasutatakse külma ilmaga täiendavate kaitsekihtide loomiseks ning need sobivad ka talispordiks. Äärmiselt pehme. Ideaalne kiivri all kandmiseks, pakub aluskihina kaitset külma eest ka selliste tegevuste ajal nagu ronimine ja matkamine.

The Alphacool Eisblock Aurora Acryl GPX-N RTX 3070 DUAL/TUF with Backplate combines style with performance and extensive digital RGB lighting. With experience of over 16 years, Alphacool the ability to create GPU blocks that represent high quality and fantastic performance. This perfectly describes the Aurora Acryl GPX Eisblock More Performance! During the development of the Eisblock Aurora Acryl GPX-N RTX 3070 DUAL/TUF graphic card GPU block, we wanted to further increase the performance. The first step was to move the cooler closer to the individual components by reducing the thermal pads to a thickness of 1 mm. Next, we reduced the thickness of the nickel-plated copper block. Instead of 7 mm, it is now only 5.5 mm thick. The water flow inside the cooler has also been optimized. All important components such as the voltage transformers and the memory are now significantly better and more effectively cooled by the water. All this ensures a significant increase in cooling performance. New Design! The Eisblock Aurora Acryl GPX-N RTX 3070 DUAL/TUF cooler has been designed so that lighting is more important than the previous models. The addressable digital RGB LEDs are embedded directly into the cooling block and run along the entire cooling block. The effect is an illumination of the entire cooling block. No corner or edge remains unlit by the aRGB LEDs. The new design is more angular with all edges bevelled. This promotes better light diffusion in the water cooler due to the reflections on these bevels. In addition, they create various contours, which give the Eisblock Aurora Acryl GPX-N RTX 3070 DUAL/TUF cooler its very own unique identity. Copper or Aluminium? Of course, Alphacool only uses copper for its water coolers. With the Eisblock Aurora Acryl GPX-N RTX 3070 DUAL/TUF, the copper is nickel-plated. Compared to its predecessor models, Alphacool has improved the nickel plating even further, which has considerably increased the acid resistance. This means that the nickel should resist flaking. Why does Alphacool rely on copper instead of aluminium? Simply, copper has almost twice the thermal conductivity of aluminium and is therefore clearly the better material for water cooling. Is There Anything Else New? The Eisblock Aurora Acryl GPX-N RTX 3070 DUAL/TUF also relies on the new patented stop fittings, which sit flush with the surface of the terminal. The Alphacool logo now sits in the corner on the top and is also fully illuminated. On the front of the terminal you can see the corresponding names of the compatible graphic card types. Of course, these are also fully illuminated by the digital LEDs. IN and OUT are now marked by small triangles. They are easily recognizable and fit perfectly into the entire aesthetics of the graphic card water cooler. The Alphacool Eisblock Aurora Acryl GPX-N RTX 3070 DUAL/TUF is a complete redevelopment of the previous Alphacool graphics card water coolers. No technical compromises were made, but the entire technical know-how flowed into the development and implementation. Technical details L x W x H 143 x 240 x 24,5 mm Material cooler Nickle-plated copper Material cooler top POM clear Threads 4 x G1/4“ Thickness cooling fins 0,6 mm Illumination Digital RGB LEDs Power connector Digital RGB LEDs 3-Pin JST Power Digital RGB LEDs 5V Graphics Card Configurator: Click here! List of Compatibility: Nvidia graphic cards Compatibility : - ASUS TUF Gaming GeForce RTX 3070 OC, TUF-RTX3070-O8G-GAMING, 8GB GDDR6, 2x HDMI, 3x DP (90YV0FQ6-M0NA00) - ASUS TUF Gaming GeForce RTX 3070, TUF-RTX3070-8G-GAMING, 8GB GDDR6, 2x HDMI, 3x DP (90YV0FQ7-M0NA00) - ASUS Dual GeForce RTX 3070 OC, DUAL-RTX3070-O8G, 8GB GDDR6, 2x HDMI, 3x DP (90YV0FQ0-M0NA00) - ASUS Dual GeForce RTX 3070, DUAL-RTX3070-8G, 8GB GDDR6, 2x HDMI, 3x DP (90YV0FQ1-M0NA00) Download Datasheet PDF: Alphacool Eisblock Aurora Acryl GPX-N RTX 3070 TUF/DUAL with Backplate Download Manual PDF: Alphacool Eisblock Aurora Acryl GPX-N RTX 3070 TUF/DUAL with Backplate

PessoThermal Pacific tööjakil on ees tõmblukk koos sisemise tormiklapiga. Kapuuts on kootud ja seest fliisiga. Jaki krae on kõrge ja koos lõua kaitsega. Tootel on 2 välist küljetaskut tõmblukuga, rinnatasku tõmblukuga ja 2 sisesmist taskut. Varrukal on tasku tõmblukuga, varruka otsad ja jope alaäär on elastsed. Jaki varrukad on osaliselt kootud ja osaliselt softshellist. Rinna ja selja osa on sooja voodriga. Külgedel on veniv, hingav ja vett hülgav softshell. Keha osa 100% polüester soojustusega, softshell on 2 kihiline.

Detector Type Uncooled microbolometer IR Resolution 320 × 240 pixels List of Contents •Infrared camera •Hard transport case •Battery (inside camera) •USB cable •Power supply/charger with EU, UK, US and Australian plugs •Printed documentation Packaging Size 385 × 165 × 315 mm (15.2 × 6.5 × 12.4 in) Set-up Commands Local adaptation of units, language, date and time formats Spectral Range 7.5–13 µm COMPLIANCE & CERTIFICATIONS Certifications UL, CSA, CE, PSE and CCC CONNECTIONS & COMMUNICATIONS AC Operation AC adapter, 90–260 VAC input, 5 VDC output to camera Interface USB Micro: Data transfer to and from PC and Mac device WiFi •Standard: 802.11 b/g/n •Frequency range: •2400–2480 MHz •5150–5260 MHz •Max. output power: 15 dBm ENVIRONMENTAL EMC •WEEE 2012/19/EC •RoHs 2011/65/EC •C-Tick •EN 61000-6-3 •EN 61000-6-2 •FCC 47 CFR Part 15 Class B Humidity (Operating and Storage) IEC 60068-2-30/24 h 95% relative humidity Operating Temperature Range –15°C to 50°C (+5°F to 122°F) Radio Spectrum •Standard: 802.11 b/g/n •Frequency range: •2400–2480 MHz •5150–5260 MHz •Max. output power: 15 dBm Shock 25 g (IEC 60068-2-27) Storage Temperature Range –40°C to 70°C (–40°F to 158°F) Vibration 2 g (IEC 60068-2-6) Emissivity table/correction Emissivity table of predefined materials/variable from 0.1 to 1.0 Encapsulation/Drop IP 54 (IEC 60529)/2m (6.6 ft.) IMAGING & OPTICAL Camera size (L x W x H) 244 × 95 × 140 mm (9.6 × 3.7 × 5.5 in) Camera weight incl battery 0.575 kg (1.27 lb.) Color Black and gray Color palettes Black & white, iron, and rainbow f-number 1.5 Field of view (FOV) 45° × 34° Focus Focus free Image Adjustment Automatic adjust/lock image Image Frequency 9 Hz Image Modes Thermal MSX, Thermal, Picture-in-Picture, Thermal blending, Digital camera. Minimum Focus Distance 0.5 m (1.6 ft.) Multi Spectral Dynamic Imaging (MSX) IR image enhanced with visible camera detail Picture-in-Picture IR area on visual image Spatial resolution (IFOV) 2.6 mrad Digital Camera Resolution/FOV 640 × 480/55° × 43° MEASUREMENT & ANALYSIS Accuracy ±2°C (±3.6°F) or ±2% of reading, for ambient temperature 10°C to 35°C (50°F to 95°F) and object temperature above 0°C (32°F) Isotherm Above alarm, below alarm Object Temperature Range –20°C to 550°C (-4°F to 1022°F) in two ranges Reflected apparent temperature correction Automatic, based on input of reflected temperature Spot Meter Center spot; box with min./max. Thermal Sensitivity/NETD

EK-Quantum Vector FTW3 RTX 3080/3090 Active Backplate D-RGB - Acryl is a cutting-edge addition to the EK® Quantum Line. It is made to complement the existing EK-Quantum Vector FTW3 RTX 3080/3090 water blocks and actively cool the backside of all EVGA® GeForce RTX™ 3080 and 3090 FTW3 GPU. EK-Quantum Vector FTW3 RTX 3080/3090 Active Backplate The EK-Quantum Vector FTW3 RTX 3080/3090 Active Backplate comes with a new terminal that replaces the stock terminal arriving with the Vector water block and links the water block and Vector Active Backplate into a single unit. This way, the whole enclosure requires only one inlet and one outlet, removing unnecessary additional tubing and reducing clutter. It is the ultimate aesthetic and performance solution that finds your GPU sandwiched between two water blocks, allowing maximum cooling. The Vector Active Backplate directly cools the PCB hotspots that are found on the backside of the GPU core and the VRM (voltage regulation module). On the RX 3090, the VRAM located on the backside is cooled, while the RTX 3080 gets cooling for the PCB located around the front-mounted VRAM. Cooling liquid is channeled over all these critical areas. These newly developed active backplates feature a fin array with 8 wide channels allowing for very low flow restriction. This in turn allows overall lower temperatures, while the active backplate gets more than sufficient surface area for heat transfer. The base of the active backplate is CNC-machined out of nickel-plated electrolytic copper, while its top is CNC-machined out of glass-like cast Acrylic. The rest of the backplate is made of nickel-plated aluminum and it does not come in contact with the liquid. These Vector Active Backplates also feature acrylic terminals that match the top cover. The watertight sealing is ensured by high-quality EPDM O-rings. D-RGB lighting on EK-Quantum Vector FTW3 RTX 3080/3090 Active Backplate D-RGB water block The aesthetic end-piece is housing the addressable D-RGB LED strip. This water block boasts a total of 8 individually addressable RGB LEDs, and it is compatible with popular RGB sync technologies from all major motherboard manufacturers. The arrow marking on the 3-pin D-RGB LED connector is to be aligned with the +5V marking on the D-RGB (addressable) header. Technical Specification Dimensions: (LxHxW) - 303x151x37.8mm D-RGB cable length: 500mm D-RGB LED count: 8 D-RGB connector standard 3-pin (+5V, Data, Blocked, Ground) Enclosed EK-Quantum Vector FTW3 RTX 3080/3090 Active Backplate D-RGB - Acryl Necessary mounting screws, nuts, and washers 1x Nickel plated brass plug G1/4” EK-Loop Multi Allen Key (6mm, 8mm, 9mm) Thermal pads Warning: EK only guarantees compatibility with included EK-brand thermal pads. Installation process, cooling performance and block contacts are tested exclusively with EK-brand thermal pads. Listed thermal pad thicknesses apply only to EK thermal pads which are included in the package. EK does not guarantee compatibility with aftermarket alternatives for thermal interface material.

The EK-Quantum Vector FTW3 RTX 3080/3090 backplate is intended for the EK-Quantum Vector FTW3 RTX 3080/3090 graphics card cooler of the same name. A backplate is particularly suitable for giving the graphics card more stability. As the backplate is kept very simple, it is rounded off by a small but elegant EK logo. Technical Data Material: Nickel-Plated Aluminium Color: Nickel Scope of Delivery EK-Quantum Vector FTW3 RTX 3080/3090 Backplate - Nickel Mounting mechanism (the backplate screws are on the other side - separate compartment) Thermal pads

EK-Quantum Vector Trinity RTX 3080/3090 Active Backplate - Acetal is a cutting-edge addition to the EK® Quantum Line. It is made to complement the existing EK-Quantum Vector Trinity RTX 3080/3090 water blocks and actively cool the backside of all ZOTAC® GeForce RTX™ 3080 and 3090 Trinity GPU. EK-Quantum Vector Trinity RTX 3080/3090 Active Backplate EK-Quantum Vector Trinity RTX 3080/3090 active backplate links the water block and the active backplate part with a new terminal, which replaces the stock terminal coming with your water block. This way the whole enclosure requires only one inlet and one outlet, removing any unneeded additional tubing and reducing clutter. It is the ultimate aesthetic and performance solution that finds your GPU sandwiched between two water blocks allowing maximum cooling. The Vector Active Backplate directly cools the PCB hotspots that are found on the backside of the GPU core and the VRM (voltage regulation module). On the RX 3090, the VRAM located on the backside is cooled, while the RTX 3080 gets cooling for the PCB located around the front-mounted VRAM. Cooling liquid is channeled over all these critical areas. These newly developed active backplates feature a fin array with 6 wide channels allowing for very low flow restriction. This in turn allows overall lower temperatures, while the active backplate gets more than sufficient surface area for heat transfer. The base of this stealthy active backplate is CNC-machined out of nickel-plated electrolytic copper, while its top is CNC-machined out of durable Black POM acetal. The rest of the backplate is made of anodized aluminum and it does not come in contact with the liquid. These Vector Active Backplates also feature acetal terminals that match the top cover. The watertight sealing is ensured by high-quality EPDM O-rings. Technical Specification Dimensions: (LxHxW) - 233x124x15mm Enclosed: EK-Quantum Vector Trinity RTX 3080/3090 Active Backplate - Acetal Necessary mounting screws, nuts, and washers 1x Nickel plated brass plug G1/4” EK-Loop Multi Allen Key (6mm, 8mm, 9mm) Thermal pads Warning: EK only guarantees compatibility with included EK-brand thermal pads. Installation process, cooling performance and block contacts are tested exclusively with EK-brand thermal pads. Listed thermal pad thicknesses apply only to EK thermal pads which are included in the package. EK does not guarantee compatibility with aftermarket alternatives for thermal interface material.

EK-Quantum Vector Master RX 6800XT/6900XT Backplate - Nickel is a CNC machined retention backplate made from nickel-plated aluminum, that fits all EK-Quantum Vector Master RX 6800XT/6900XT water blocks. The backplate covers the whole length of the graphics card's PCB, serves as an aesthetic add-on, and also provides passive cooling for the backside of the voltage regulation module (VRM), VRAM, and the GPU core. Enclosed EK-Quantum Vector RX Master 6800XT/6900XT Backplate - Nickel Mounting mechanism (the backplate screws are on the other side - separate compartment)* Thermal pads

EK-Quantum Vector TUF RX 6800/6900 Backplate - Black is a CNC machined retention backplate made from black anodized aluminum, that fits all EK-Quantum Vector TUF RX 6800/6900 water blocks. The backplate covers the whole length of the graphics card's PCB, serves as an aesthetic add-on, and also provides passive cooling for the backside of the voltage regulation module (VRM), VRAM, and the GPU core. Enclosed EK-Quantum Vector RX TUF 6800/6900 Backplate - Black Mounting mechanism (the backplate screws are on the other side - separate compartment) Thermal pads

This is the 2nd generation Vector GPU water block from the EK® Quantum Line, designed for AORUS® Xtreme and Master RTX 3080 and 3090 graphics cards based on the latest NVIDIA® Ampere™ architecture. An EK water block for Xtreme and Master RTX 3080 and 3090 EK-Quantum Vector Xtreme 3080/3090 D-RGB - Nickel + Acryl water block is compatible with Aorus Xtreme and Master RTX 3080 and RTX 3090 graphics cards. The Vector water block actively cools the GPU, VRAM (on the front), power stages, and chokes in the VRM (voltage regulation module). These newly developed water blocks feature optimized flow paths that reduce hydrodynamic instabilities and vortexing (dead spots) inside of them. The EK-Quantum Vector Series water blocks use an Open Split-Flow cooling engine design, which proved to be a superior solution for GPU water blocks. It is characterized by low hydraulic flow restriction, meaning it can be used with weaker water pumps or pumps running on low-speed settings, and still achieve top performance. The jet plate and fin structure geometry have been optimized to provide even flow distribution with minimal losses and optimal performance when used in any given coolant flow orientation. The base of the block is CNC-machined out of nickel-plated high-grade copper, while its top is CNC-machined out of glass-like cast Acrylic. These 2nd generation Vector GPU water blocks also feature Acetal terminals. The watertight sealing is ensured by high-quality EPDM O-rings, while brass standoffs are already pre-installed and allow for a safe and easy installation procedure. D-RGB lighting on EK-Quantum Vector Xtreme RTX 3080/3090 D-RGB water block The aesthetic corner end-piece is housing the addressable D-RGB LEDs. This water block boasts a total of 8 individually addressable RGB LEDs, and it is compatible with popular RGB sync technologies from all major motherboard manufacturers. The arrow marking on the 3-pin D-RGB LED connector is to be aligned with the +5V marking on the D-RGB (addressable) header. Backplate for the EK-Quantum Vector Xtreme 3080/3090 water block EK recommends the purchase of a retention backplate, especially for the 3090 models of graphics cards. The backplate improves the overall aesthetics of your graphics cards and also provides additional passive cooling for the GPU core, VRAM on the 3090 cards, and backside of the printed circuit board VRM section. Technical Specification Dimensions: (LxHxW) - 295x150.5x20.5mm Enclosed EK-Quantum Vector Xtreme RTX 3080/3090 D-RGB series high-performance water block Mounting mechanism with screw-in brass standoffs Necessary mounting screws, nuts, and washers 2x Nickel plated brass plug G1/4” EK-Loop Multi Allen Key (6mm, 8mm, 9mm) Thermal pads Thermal grease EK-TIM Ectotherm (1g)

EK-Quantum Vector Xtreme RTX 3080/3090 Backplate - Black is a CNC machined retention backplate made from black anodized aluminum, that fits all EK-Quantum Vector Xtreme RTX 3080/3090 water blocks. The backplate covers the whole length of the graphics card's PCB, serves as an aesthetic add-on, and also provides passive cooling for the backside of the voltage regulation module (VRM), the GPU core, and rear-mounted VRAM on the 3090 cards. Enclosed EK-Quantum Vector Xtreme RTX 3080/3090 Backplate - Black Mounting mechanism (the backplate screws are on the other side - separate compartment)* Thermal pads

EK-Quantum Vector Strix RTX 3080/3090 Active Backplate D-RGB - Acetal is a cutting-edge addition to the EK® Quantum Line. It is made to complement the existing EK-Quantum Vector Strix RTX 3080/3090 water blocks and actively cool the backside of a ROG® GeForce RTX™ 3080 and 3090 Strix GPU. EK-Quantum Vector Strix RTX 3080/3090 Active Backplate The EK-Quantum Vector Strix RTX 3080/3090 Active Backplate comes with a new terminal that replaces the stock terminal arriving with the Vector water block and links the water block and Vector Active backplate into a single unit. This way the whole enclosure requires only one inlet and one outlet, removing any unneeded additional tubing and reducing clutter. It is the ultimate aesthetic and performance solution that finds your GPU sandwiched between two water blocks allowing maximum cooling. The Vector Active Backplate directly cools the PCB hotspots that are found on the backside of the GPU core and the VRM (voltage regulation module). On the RX 3090, the VRAM located on the backside is cooled, while the RTX 3080 gets cooling for the PCB located around the front-mounted VRAM. Cooling liquid is channeled over all these critical areas. These newly developed active backplates feature a fin array with 8 wide channels allowing for very low flow restriction. This in turn allows overall lower temperatures, while the active backplate gets more than sufficient surface area for heat transfer. The base of this stealthy active backplate is CNC-machined out of nickel-plated electrolytic copper, while its top is CNC-machined out of durable Black POM acetal. The rest of the backplate is made of anodized aluminum and it does not come in contact with the liquid. These Vector Active Backplates also feature acetal terminals that match the top cover. The watertight sealing is ensured by high-quality EPDM O-rings. Technical Specification Dimensions: (LxHxW) - 281x154x33mm Enclosed EK-Quantum Vector Strix RTX 3080/3090 Active Backplate - Acetal Necessary mounting screws, nuts, and washers 1x Nickel plated brass plug G1/4” EK-Loop Multi Allen Key (6mm, 8mm, 9mm) Thermal pads Warning: EK only guarantees compatibility with included EK-brand thermal pads. Installation process, cooling performance and block contacts are tested exclusively with EK-brand thermal pads. Listed thermal pad thicknesses apply only to EK thermal pads which are included in the package. EK does not guarantee compatibility with aftermarket alternatives for thermal interface material.

EK-Quantum Vector Trinity RTX 3080/3090 Active Backplate D-RGB - Acryl is a cutting-edge addition to the EK® Quantum Line. It is made to complement the existing EK-Quantum Vector Trinity RTX 3080/3090 water blocks and actively cool the backside of all ZOTAC® GeForce RTX™ 3080 and 3090 Trinity GPU. EK-Quantum Vector Trinity RTX 3080/3090 Active Backplate EK-Quantum Vector Trinity RTX 3080/3090 active backplate links the water block and the active backplate part with a new terminal, which replaces the stock terminal coming with your water block. This way the whole enclosure requires only one inlet and one outlet, removing any unneeded additional tubing and reducing clutter. It is the ultimate aesthetic and performance solution that finds your GPU sandwiched between two water blocks allowing maximum cooling. The Vector Active Backplate directly cools the PCB hotspots that are found on the backside of the GPU core and the VRM (voltage regulation module). On the RX 3090, the VRAM located on the backside is cooled, while the RTX 3080 gets cooling for the PCB located around the front-mounted VRAM. Cooling liquid is channeled over all these critical areas. These newly developed active backplates feature a fin array with 6 wide channels allowing for very low flow restriction. This in turn allows overall lower temperatures, while the active backplate gets more than sufficient surface area for heat transfer. The base of the active backplate is CNC-machined out of nickel-plated electrolytic copper, while its top is CNC-machined out of glass-like cast Acrylic. The rest of the backplate is made of nickel-plated aluminum and it does not come in contact with the liquid. These Vector Active Backplates also feature acrylic terminals that match the top cover. The watertight sealing is ensured by high-quality EPDM O-rings. D-RGB lighting on EK-Quantum Vector Trinity RTX 3080/3090 Active Backplate D-RGB water block The aesthetic end-piece is housing the addressable D-RGB LED strip. This water block boasts a total of 8 individually addressable RGB LEDs, and it is compatible with popular RGB sync technologies from all major motherboard manufacturers. The arrow marking on the 3-pin D-RGB LED connector is to be aligned with the +5V marking on the D-RGB (addressable) header. Technical Specification Dimensions: (LxHxW) - 231x124x15mm D-RGB cable length: 500mm D-RGB LED count: 8 D-RGB connector standard 3-pin (+5V, Data, Blocked, Ground) Enclosed EK-Quantum Vector Trinity RTX 3080/3090 Active Backplate D-RGB - Acryl Necessary mounting screws, nuts, and washers 1x Nickel plated brass plug G1/4” EK-Loop Multi Allen Key (6mm, 8mm, 9mm) Thermal pads Warning: EK only guarantees compatibility with included EK-brand thermal pads. Installation process, cooling performance and block contacts are tested exclusively with EK-brand thermal pads. Listed thermal pad thicknesses apply only to EK thermal pads which are included in the package. EK does not guarantee compatibility with aftermarket alternatives for thermal interface material.

This is the 2nd generation Vector GPU water block from the EK® Quantum Line, designed for ASUS® TUF RTX 3070 graphics cards based on the latest NVIDIA® Ampere™ architecture. EK-Quantum Vector TUF 3070 D-RGB water block is compatible with ASUS TUF Gaming RTX 3070 graphics cards.The Vector water block directly cools the GPU, VRAM, and the VRM (voltage regulation module) as a cooling liquid is channeled right over these critical areas. The water block is in contact with the power stages and inductors of the VRM. These newly developed water blocks feature optimized flow paths that reduce hydrodynamic instabilities and vortexing (dead spots) inside of them. Additionally, this new design allows the terminal to be screwed directly onto the copper cold plate of the GPU block, making it more rigid and reducing the chances of damaging the water block. The EK-Quantum Vector Series water blocks use an Open Split-Flow cooling engine design, which proved to be a superior solution for GPU water blocks. It is characterized by low hydraulic flow restriction, meaning it can be used with weaker water pumps or pumps running on low-speed settings, and still achieve top performance. The jet plate and fin structure geometry have been optimized to provide even flow distribution with minimal losses and optimal performance when used in any given coolant flow orientation. The base of the block is CNC-machined out of nickel-plated electrolytic copper, while its top is CNC-machined out of glass-like cast Acrylic. The watertight sealing is ensured by high-quality EPDM O-rings, while brass standoffs are already pre-installed and allow for a safe and easy installation procedure. D-RGB lighting on EK-Quantum Vector TUF RTX 3070 D-RGB water blockThe aesthetic end-piece is housing the addressable D-RGB LED strip. This water block boasts a total of 8 individually addressable RGB LEDs, and it is compatible with popular RGB sync technologies from all major motherboard manufacturers. The arrow marking on the 3-pin D-RGB LED connector is to be aligned with the +5V marking on the D-RGB (addressable) header. Backplate for the EK-Quantum Vector TUF RTX 3070 D-RGB water blockEK recommends the purchase of a retention backplate. The backplate improves the overall aesthetics of your graphics cards and also provides additional passive cooling for the GPU core, VRAM, and backside of the printed circuit board VRM section. Technical Specification Dimensions: (LxHxW) - 255x149x20.5mm D-RGB cable length: 500mm D-RGB LED count: 8 D-RGB connector standard 3-pin (+5V, Data, Blocked, Ground) Enclosed EK-Quantum Vector TUF RTX 3070 D-RGB series high-performance water block Mounting mechanism with screw-in brass standoffs Necessary mounting screws, nuts, and washers 2x Nickel plated brass plug G1/4” EK-Loop Multi Allen Key (6mm, 8mm, 9mm) Thermal pads Thermal grease EK-TIM Ectotherm (1g)

EK-Quantum Vector RE RTX 3080/3090 Active Backplate D-RGB - Acryl is a cutting-edge addition to the EK® Quantum Line. It is made to complement the existing EK-Quantum Vector RE RTX 3080/3090 water blocks and actively cool the backside of a reference design NVIDIA® GeForce RTX™ 3080 and 3090 GPU. EK-Quantum Vector RE RTX 3080/3090 Active Backplate EK-Quantum Vector RE RTX 3080/3090 active backplate links the water block and the active backplate part with a new terminal, which replaces the stock terminal coming with your water block. This way the whole enclosure requires only one inlet and one outlet, removing any unneeded additional tubing and reducing clutter. It is the ultimate aesthetic and performance solution that finds your GPU sandwiched between two water blocks allowing maximum cooling. The Vector Active Backplate directly cools the PCB hotspots that are found on the backside of the GPU core and the VRM (voltage regulation module). On the RX 3090, the VRAM located on the backside is cooled, while the RTX 3080 gets cooling for the PCB located around the front-mounted VRAM. Cooling liquid is channeled over all these critical areas. These newly developed active backplates feature a fin array with 6 wide channels allowing for very low flow restriction. This in turn allows overall lower temperatures, while the active backplate gets more than sufficient surface area for heat transfer. The base of the active backplate is CNC-machined out of nickel-plated electrolytic copper, while its top is CNC-machined out of glass-like cast Acrylic. The rest of the backplate is made of nickel-plated aluminum and it does not come in contact with the liquid. These Vector Active Backplates also feature acrylic terminals that match the top cover. The watertight sealing is ensured by high-quality EPDM O-rings. D-RGB lighting on EK-Quantum Vector RE RTX 3080/3090 Active Backplate D-RGB water block The aesthetic end-piece is housing the addressable D-RGB LED strip. This water block boasts a total of 8 individually addressable RGB LEDs, and it is compatible with popular RGB sync technologies from all major motherboard manufacturers. The arrow marking on the 3-pin D-RGB LED connector is to be aligned with the +5V marking on the D-RGB (addressable) header. Technical Specification Dimensions: (LxHxW) - 223x124x15mm D-RGB cable length: 500mm D-RGB LED count: 8 D-RGB connector standard 3-pin (+5V, Data, Blocked, Ground) Enclosed EK-Quantum Vector RE RTX 3080/3090 Active Backplate D-RGB - Acryl Necessary mounting screws, nuts, and washers 1x Nickel plated brass plug G1/4” EK-Loop Multi Allen Key (6mm, 8mm, 9mm) Thermal pads Warning: EK only guarantees compatibility with included EK-brand thermal pads. Installation process, cooling performance and block contacts are tested exclusively with EK-brand thermal pads. Listed thermal pad thicknesses apply only to EK thermal pads which are included in the package. EK does not guarantee compatibility with aftermarket alternatives for thermal interface material.

This back plate is manufactured from massive aluminum and can be mounted in addition to a kryographics NEXT RTX 3080 Strix / RTX 3090 Strix water block, giving additional stability especially in the voltage regulator area of the graphics card. Additionally, the RAM modules on the back of the RTX 3090 Strix graphics card are cooled effectively. The back plate is anodized in black color. Scope of delivery: One Back plate Thermal conductive pads Mounting material Compatibility: Please check compatibility using the PDF from Aqua Computer under Awards and Documents. Please note: Graphics card and kryographics water block are not included in delivery, please order separately.

Alphacool's Core product series is characterized by high quality, outstanding performance, and a consistent, functional design language.The copper cooler, as well as the end terminal, is milled from a single piece of copper and forms the core of this cooler. The precise workmanship, together with the hard and durable chrome plating that covers the entire copper cooler, meets the highest quality standards. The chrome-plated brass G1/4" threads integrated on both sides are visually distinct from the terminal and represent a central element of the new design language featured throughout the Core series.The aluminum backplate, designed to match, together with the terminal, forms the complete unit and enhances the back of the cooler with a clean and unified look. The lighting features digitally addressable RGB LEDs that evenly and effectively illuminate the entire cooler.Technical innovations are evident in the water delivery to the jet plate as well as the optimization of the jet plate itself. The jet plate has been entirely redesigned based on numerous simulations and practical tests in cooperation with board partners. The fin thickness and spacing have been improved, the cooling surface has been increased, and water flow to the core components with the highest heat generation has been optimized. The included special soft thermal pads, with up to 7 W/mK, adapt perfectly even to the smallest tolerances. Compatibility:- AMD Radeon RX 7900 XTX, 24GB GDDR6- ASRock Radeon RX 7900 XTX, 24GB GDDR6- Asus Radeon RX 7900 XTX, RX7900XTX-24G, 24GB GDDR6 (90YV0IT0-U0NM00)- Biostar Radeon RX 7900 XTX, 24GB GDDR6 (VA7906AEF4)- Gigabyte Radeon RX 7900 XTX 24G, 24GB GDDR6 (GV-R79XTX-24GC-B)- PowerColor Radeon RX 7900 XTX, 24GB GDDR6 (RX 7900 XTX 24G)- XFX Radeon RX 7900 XTX, 24GB GDDR6 (RX-79XMBABF9) Technical data coolerDimensions (L x W x H)269 x 135 x 32.15mmMaterial coolerchrome-plated copperMaterial cooler topacrylicMax working temperature60°CPressure tested0.8 barThreads4 x G1/4"Thickness cooler bottom11.3mmThickness cooling fins0.4mmDistance cooling fins0.4mmIlluminationdigital aRGB LEDsPower connector digital aRGB LEDs3-Pin JSTPower digital aRGB LEDs5VNumber of digital aRGB LEDs15ColortransparentTechnical data backplateDimensions (L x W x H)269 x 221 x 5mmMaterialaluminiumColorblackWarranty: 3 years???? Warranty Terms

The Alphacool Aurora Acryl GPX-A 6800(XT) Eisblock combines style with performance and extensive digital RGB lighting. With experience of over 16 years, Alphacool the ability to create GPU blocks that represent high quality and fantastic performance. This perfectly describes the Aurora Acryl GPX Eisblock More Performance! During the development of the EIsblock Aurora GPX-A 6800(XT) graphic card GPU block, we wanted to further increase the performance. The first step was to move the cooler closer to the individual components by reducing the thermal pads to a thickness of 1 mm. Next, we reduced the thickness of the nickel-plated copper block. Instead of 7 mm, it is now only 5.5 mm thick. The water flow inside the cooler has also been optimized. All important components such as the voltage transformers and the memory are now significantly better and more effectively cooled by the water. All this ensures a significant increase in cooling performance. New Design! The Eisblock Aurora GPX-A 6800(XT) cooler has been designed so that lighting is more important than the previous models. The addressable digital RGB LEDs are embedded directly into the cooling block and run along the entire cooling block. The effect is an illumination of the entire cooling block. No corner or edge remains unlit by the aRGB LEDs. The new design is more angular with all edges bevelled. This promotes better light diffusion in the water cooler due to the reflections on these bevels. In addition, they create various contours, which give the Aurora GPX-A 6800(XT) Eisblock cooler its very own unique identity. Copper or Aluminium? Of course, Alphacool only uses copper for its water coolers. With the Aurora GPX-A 6800(XT) Eisblock, the copper is nickel-plated. Compared to its predecessor models, Alphacool has improved the nickel plating even further, which has considerably increased the acid resistance. This means that the nickel should resist flaking. Why does Alphacool rely on copper instead of aluminium? Simply, copper has almost twice the thermal conductivity of aluminium and is therefore clearly the better material for water cooling. Is There Anything Else New? The Eisblock Aurora GPX-A 6800(XT) also relies on the new patented stop fittings, which sit flush with the surface of the terminal. The Alphacool logo now sits in the corner on the top and is also fully illuminated. On the front of the terminal you can see the corresponding names of the compatible graphic card types. Of course, these are also fully illuminated by the digital LEDs. IN and OUT are now marked by small triangles. They are easily recognizable and fit perfectly into the entire aesthetics of the graphic card water cooler. The Alphacool Aurora GPX-A 6800(XT) Acryl is a complete redevelopment of the previous Alphacool graphics card water coolers. No technical compromises were made, but the entire technical know-how flowed into the development and implementation. Note: - This article is delivered with a backplate Technical data: L x W x B: 130 x 262,5 x 24,5 mm Material cooler: Nickle plated copper Material top: Acryl Thickness cooling fins: 0,6 mm Threads: 4x G1/4“ Power connector Digital RGB: 3-Pin 5V (0,5A) Graphics Card Configurator: Click here! List of Compatibility: AMD graphic cards Compatibility list: - AMD Radeon 6800 Reference Design - AMD Radeon 6800 XT Reference Design - AMD Radeon 6900 XT Reference Design - AMD Radeon 6950 XT Reference Design More compatible models will follow in this list for this cooler. We are currently checking other PCB designs from various manufacturers! Download manual PDF: Alphacool Eisblock Aurora Acryl GPX-A Radeon RX 6800/6800XT/6900XT Reference with Backplate Download data sheet PDF: Alphacool Eisblock Aurora Acryl GPX-A Radeon RX 6800/6800XT/6900XT Reference with Backplate

The Alphacool Aurora Acetal GPX-A 6800/6900(XT) Eisblock combines style with performance. With experience of over 16 years, Alphacool the ability to create GPU blocks that represent high quality and fantastic performance. This perfectly describes the Aurora Acetal GPX Eisblock More Performance! During the development of the EIsblock Aurora GPX-A 6800/6900(XT) graphic card GPU block, we wanted to further increase the performance. The first step was to move the cooler closer to the individual components by reducing the thermal pads to a thickness of 1 mm. Next, we reduced the thickness of the nickel-plated copper block. Instead of 7 mm, it is now only 5.5 mm thick. The water flow inside the cooler has also been optimized. All important components such as the voltage transformers and the memory are now significantly better and more effectively cooled by the water. All this ensures a significant increase in cooling performance. Copper or Aluminium? Of course, Alphacool only uses copper for its water coolers. With the Aurora GPX-A 6800/6900(XT) Eisblock, the copper is nickel-plated. Compared to its predecessor models, Alphacool has improved the nickel plating even further, which has considerably increased the acid resistance. This means that the nickel should resist flaking. Why does Alphacool rely on copper instead of aluminium? Simply, copper has almost twice the thermal conductivity of aluminium and is therefore clearly the better material for water cooling. Is There Anything Else New? The Eisblock Aurora GPX-A 6800/6900(XT) also relies on the new patented stop fittings, which sit flush with the surface of the terminal. On the front of the terminal you can see the corresponding names of the compatible graphic card types. IN and OUT are now marked by small triangles. They are easily recognizable and fit perfectly into the entire aesthetics of the graphic card water cooler. The Alphacool Aurora GPX-A 6800/6900(XT) Acetal is a complete redevelopment of the previous Alphacool graphics card water coolers. No technical compromises were made, but the entire technical know-how flowed into the development and implementation. Note: - This article is delivered with a backplate Technical data: L x W x B: 130 x 262,5 x 24,5 mm Material cooler: Nickle plated copper Material top: Acetal Thickness cooling fins: 0,6 mm Threads: 4x G1/4“ Graphics Card Configurator: Click here! List of Compatibility: AMD graphic cards Compatibility list: - AMD Radeon 6800 Reference Design - AMD Radeon 6800 XT Reference Design - AMD Radeon 6900 XT Reference Design - AMD Radeon 6950 XT Reference Design More compatible models will follow in this list for this cooler. We are currently checking other PCB designs from various manufacturers! Download manual PDF: Alphacool Eisblock Aurora Acetal GPX-A Radeon RX 6800/XT/6900 Reference with Backplate Download data sheet PDF: Alphacool Eisblock Aurora Acetal GPX-A Radeon RX 6800/XT/6900 Reference with Backplate

EK-Quantum Vector TRIO RTX 3080/3090 Active Backplate - Acetal is a state-of-the-art addition to the EK® Quantum Line. It complements the existing EK-Quantum Vector TRIO RTX 3080/3090 water blocks and actively cools the back of all MSI® TRIO and SUPRIM GeForce RTX™ 3080 and 3090 GPUs. The EK-Quantum Vector TRIO RTX 3080/3090 Active Backplate comes with a new connector that replaces the stock connector on the Vector water block, connecting the water block and Vector Active Backplate into one unit. This way, the entire case only needs one inlet and one outlet, eliminating unnecessary extra tubing and reducing clutter. It is the ultimate aesthetic and performance solution where your GPU is sandwiched between two water blocks, allowing for maximum cooling. Technical specification: Dimensions: (LxHxW) - 307x153x38mm Scope of delivery: EK-Quantum Vector TRIO RTX 3080/3090 Active Backplate - Plexi Required mounting screws, nuts and washers 1x nickel-plated brass connector G1/4" EK-Loop Multi Allen key (6mm, 8mm, 9mm) Thermal Pads

Supply includes: PTC heater with fan Quick-connection terminal Assembly parts Note: For precise temperature control inside the enclosure, we recommend the enclosure internal thermostat or the digital enclosure internal temperature display and thermostat. In order to prevent condensation on assemblies, a hygrostat is recommended to regulate heating. In larger enclosures, even heat distribution is best achieved by installing several low-output heaters. The installation of heaters is generally advisable, in order to prevent condensation. Continuous thermal output at 10°C: 800 W - 870 W Note: Continuous thermal output with fan Rated operating voltage: 230 V, 1~, 50 Hz/60 Hz Dimensions: Width: 103 mm Height: 200 mm Depth: 103 mm Miniature circuit-breaker/fuse: 6 A Fans pre-integrated: yes Packs of: 1 pc(s).

The Alphacool Aurora Acetal GPX-N RTX 3080/3090 Eisblock combines style with performance. With experience of over 16 years, Alphacool the ability to create GPU blocks that represent high quality and fantastic performance. This perfectly describes the Aurora Acetal GPX Eisblock. More Performance! During the development of the EIsblock Aurora GPX-N RTX 3080/3090 graphic card GPU block, we wanted to further increase the performance. The first step was to move the cooler closer to the individual components by reducing the thermal pads to a thickness of 1 mm. Next, we reduced the thickness of the nickel-plated copper block. Instead of 7 mm, it is now only 5.5 mm thick. The water flow inside the cooler has also been optimized. All important components such as the voltage transformers and the memory are now significantly better and more effectively cooled by the water. All this ensures a significant increase in cooling performance. Copper or Aluminium? Of course, Alphacool only uses copper for its water coolers. With the Aurora GPX-N RTX 3080/3090 Eisblock, the copper is nickel-plated. Compared to its predecessor models, Alphacool has improved the nickel plating even further, which has considerably increased the acid resistance. This means that the nickel should resist flaking. Why does Alphacool rely on copper instead of aluminium? Simply, copper has almost twice the thermal conductivity of aluminium and is therefore clearly the better material for water cooling. Is There Anything Else New? The Eisblock Aurora GPX-N RTX 3080/3090 also relies on the new patented stop fittings, which sit flush with the surface of the terminal. The Alphacool logo now sits in the corner on the top. On the front of the terminal you can see the corresponding names of the compatible graphic card types. IN and OUT are now marked by small triangles. They are easily recognizable and fit perfectly into the entire aesthetics of the graphic card water cooler. The Alphacool Aurora GPX-N RTX 3080/3090 Acetal is a complete redevelopment of the previous Alphacool graphics card water coolers. No technical compromises were made, but the entire technical know-how flowed into the development and implementation. Note: - The Founders Edition, does NOT correspond to the Reference Design! Technical data cooler L x W x H 224,86 x 121,4 x 25,05 mm Material cooler Nickle-plated copper Material cooler top acetal Threads 4 x G1/4 Thickness cooling fins 0,6 mm Maximum working temperature 60 °C Technical data backplate L x W x H 224,86 x 96,9 x 6 mm Material aluminium Color black Compatibility: RTX 3080 TI Gainward GeForce RTX 3080 Ti 12GB Phoenix INNO3D GEFORCE RTX 3080 TI ICHILL X4 INNO3D GEFORCE RTX 3080 TI ICHILL FROSTBITE INNO3D GEFORCE RTX 3080 TI ICHILL X3 INNO3D GEFORCE RTX 3080 TI X3 INNO3D GEFORCE RTX 3080 TI X3 OC Palit GeForce RTX 3080 Ti GamingPro Zotac Gaming GeForce RTX 3080 Ti AMP Holo Zotac GeForce RTX 3080 Ti AMP HoloBlack Zotac Gaming GeForce RTX 3080 Ti Trinity Zotac Gaming GeForce RTX 3080 Ti Trinity OC RTX 3080 Galakuro NVIDIA GEFORCE RTX 3080 GG-RTX3080-E10GB/TP Galax GeForce RTX 3080 SG 10GB GDDR6X 320-bit DP*3/HDMI Gainward RTX 3080 Phoenix Gainward RTX 3080 Phoenix GS Inno3D GeForce RTX 3080 iChill X3/X4 10240 MB GDDR6X Inno3D GeForce RTX 3080 Twin X2 OC 10240 MB GDDR6X INNO3D GEFORCE RTX 3080 12GB ICHILL FROSTBITE LHR INNO3D GEFORCE RTX 3080 12GB X3 OC LHR INNO3D GEFORCE RTX 3080 12GB ICHILL X3/X4 LHR INNO3D GEFORCE RTX 3080 12GB ICHILL BLACK LHR KFA2 GeForce RTX 3080 SG 10GB GDDR6X 320-bit DP*3/HDMI Palit GeForce RTX™ 3080 GamingPro Palit GeForce RTX™ 3080 GamingPro OC PNY GeForce RTX 3080 XLR8 Gaming EPIC-X RGB 10240 MB GDDR6X (VCG308010TFXMPB) PNY GeForce RTX 3080 XLR8 Gaming EPIC-X RGB 10240 MB GDDR6X (VCG308010TFXPPB) Zotac GAMING GeForce RTX 3080 Trinity Zotac Gaming GeForce RTX 3080 Trinity OC RTX 3090 Galakuro NVIDIA GEFORCE RTX 3090 GG-RTX3090-E24GB/TP Galax GeForce RTX 3090 SG 24GB GDDR6X 320-bit DP*3/HDMI Gainward RTX 3090 Phoenix Gainward RTX 3090 Phoenix GS Inno3D GeForce RTX 3090 iChill X3/X4, 24576 MB GDDR6X Inno3D GeForce RTX 3090 Gaming X3, 24576 MB GDDR6X KFA2 GeForce RTX 3090 SG 24GB GDDR6X 320-bit DP*3/HDMI Palit GeForce RTX™ 3090 GamingPro Palit GeForce RTX™ 3090 GamingPro OC PNY GeForce RTX 3090 XLR8 Gaming EPIC-X RGB, 24576 MB GDDR6X Zotac GeForce RTX 3090 Trinity, 24576 MB GDDR6X

The Alphacool Aurora Plexi GPX-N RTX 3080/3090 Eisblock combines style with performance and extensive digital RGB lighting. With experience of over 16 years, Alphacool the ability to create GPU blocks that represent high quality and fantastic performance. This perfectly describes the Aurora Plexi GPX Eisblock More Performance! During the development of the EIsblock Aurora GPX-N RTX 3080/3090 graphic card GPU block, we wanted to further increase the performance. The first step was to move the cooler closer to the individual components by reducing the thermal pads to a thickness of 1 mm. Next, we reduced the thickness of the nickel-plated copper block. Instead of 7 mm, it is now only 5.5 mm thick. The water flow inside the cooler has also been optimized. All important components such as the voltage transformers and the memory are now significantly better and more effectively cooled by the water. All this ensures a significant increase in cooling performance. New Design! The Eisblock Aurora GPX-N RTX 3080/3090 cooler has been designed so that lighting is more important than the previous models. The addressable digital RGB LEDs are embedded directly into the cooling block and run along the entire cooling block. The effect is an illumination of the entire cooling block. No corner or edge remains unlit by the aRGB LEDs. The new design is more angular with all edges bevelled. This promotes better light diffusion in the water cooler due to the reflections on these bevels. In addition, they create various contours, which give the Aurora GPX-N RTX 3080/3090 Eisblock cooler its very own unique identity. Copper or Aluminium? Of course, Alphacool only uses copper for its water coolers. With the Aurora GPX-N RTX 3080/3090 Eisblock, the copper is nickel-plated. Compared to its predecessor models, Alphacool has improved the nickel plating even further, which has considerably increased the acid resistance. This means that the nickel should resist flaking. Why does Alphacool rely on copper instead of aluminium? Simply, copper has almost twice the thermal conductivity of aluminium and is therefore clearly the better material for water cooling. Is There Anything Else New? The Eisblock Aurora GPX-N RTX 3080/3090 also relies on the new patented stop fittings, which sit flush with the surface of the terminal. The Alphacool logo now sits in the corner on the top and is also fully illuminated. On the front of the terminal you can see the corresponding names of the compatible graphic card types. Of course, these are also fully illuminated by the digital LEDs. IN and OUT are now marked by small triangles. They are easily recognizable and fit perfectly into the entire aesthetics of the graphic card water cooler. The Alphacool Aurora GPX-N RTX 3080/3090 Plexi is a complete redevelopment of the previous Alphacool graphics card water coolers. No technical compromises were made, but the entire technical know-how flowed into the development and implementation. Note: - This article is delivered with a backplate - The Founders Edition, does NOT correspond to the Reference Design! Technical data: L x W x B: 132 x 259 x 25 mm Material cooler: Nickle plated copper Material top: Plexi Thickness cooling fins: 0,6 mm Threads: 4x G1/4“ Power connector Digital RGB: 3-Pin 5V (0,5A) Graphics Card Configurator: Click here! List of Compatibility: Nvidia graphic cards (Note: RTX 3090/3080 cards will be added after their release) Compatibility list: RTX 3080 TI MSI GeForce RTX 3080 Ti Ventus 3X 12G OC RTX 3080 MSI GeForce RTX 3080 Ventus 3X 10G OC, 10GB GDDR6X, HDMI, 3x DP RTX 3090 MSI GeForce RTX 3090 Ventus 3X 24G, 24GB GDDR6X, HDMI, 3x DP MSI GeForce RTX 3090 Ventus 3X 24G OC, 24GB GDDR6X, HDMI, 3x DP Download manual PDF: Alphacool Eisblock Aurora Plexi GPX-N RTX 3090/3080 Ventus with Backplate Download data sheet PDF: Alphacool Eisblock Aurora Plexi GPX-N RTX 3090/3080 Ventus with Backplate

The Alphacool Eisblock Aurora Acrylic GPX graphics card water cooler with backplate combines style with performance. Extreme cooling performance and an extensive digital RGB lighting characterize it. Experience and technical know-how from more than a decade have gone into the development, without making any technical compromises. The Eisblock Aurora Acryl GPX is a significant evolution of the previous Alphacool graphics card water cooler, which has been improved in every area. More performance! During the development of the Eisblock Aurora Acryl GPX graphics card water cooler, emphasis was naturally placed on increasing performance. First, the cooler was brought closer to the individual components by reducing the thickness of the heat conducting pads. Next, the nickel-plated copper block was also made thinner. Step 3 involves the constant optimisation of the water flow within the cooler. The result: All important components such as voltage converters and RAM are cooled much better and more effectively by the water and the cooling performance increases significantly. Brilliant design! The addressable digital aRGB LEDs are embedded directly in the cooling block and run along the sides of the entire cooler. The effect is an illumination that engulfs the entire cooling block. No corner or edge is left unlit by the aRGB LEDs. The new design is more angular, with all edges bevelled. The result is better light diffusion in the water cooler due to the reflections on these bevels. They also create various contours that give the Eisblock Aurora Acryl GPX cooler its very own visual touch. Copper or aluminium? Alphacool only uses copper in its water coolers. In the case of the Eisblock Aurora Acryl GPX, the copper is nickel-plated. Compared to the previous models, however, Alphacool has once again improved the type of nickel plating, which has significantly increased the acid resistance. This should prevent the nickel plating from flaking off. Why does Alphacool use copper instead of aluminium? Copper has almost twice the thermal conductivity of aluminium and is therefore clearly the better material for water cooling. Other special features The Eisblock Aurora Acryl GPX GPU cooler has the patented screw plugs, which sit flush with the surface of the terminal. The Alphacool logo sits in the corner on the top and is also fully illuminated. On the front of the terminal, corresponding designations of the compatible graphics card manufacturers can be seen. Of course, these are also fully illuminated by the adressable digital LEDs. IN and OUT are marked by small discreet triangles. They are easily recognisable and fit perfectly into the overall visual line of the graphics card water cooler. Compatibility: - NVIDIA GeForce RTX 3070 Ti Founders Edition, 8GB GDDR6X, HDMI, 3x DP Technical data cooler L x W x H 187,97 x 123,09 x 33,95 mm Material cooler Nickle-plated copper Material cooler top acrylic Threads 4 x G1/4 Thickness cooling fins 0,6 mm Illumination digital aRGB LEDs Power connector digital aRGB LEDs 3-Pin JST Power digital aRGB LEDs 5V Number of digital aRGB LEDs 11 Technical data backplate L x W x H 187,97 x 98,59 x 6 mm Material aluminium Color black

The Alphacool Eisblock Aurora Acrylic GPX graphics card water cooler with backplate combines style with performance. Extreme cooling performance and an extensive digital RGB lighting characterize it. Experience and technical know-how from more than a decade have gone into the development, without making any technical compromises. The Eisblock Aurora Acryl GPX is a significant evolution of the previous Alphacool graphics card water cooler, which has been improved in every area. More performance! During the development of the Eisblock Aurora Acryl GPX graphics card water cooler, emphasis was naturally placed on increasing performance. First, the cooler was brought closer to the individual components by reducing the thickness of the heat conducting pads. Next, the nickel-plated copper block was also made thinner. Step 3 involves the constant optimisation of the water flow within the cooler. The result: All important components such as voltage converters and RAM are cooled much better and more effectively by the water and the cooling performance increases significantly. Brilliant design! The addressable digital aRGB LEDs are embedded directly in the cooling block and run along the sides of the entire cooler. The effect is an illumination that engulfs the entire cooling block. No corner or edge is left unlit by the aRGB LEDs. The new design is more angular, with all edges bevelled. The result is better light diffusion in the water cooler due to the reflections on these bevels. They also create various contours that give the Eisblock Aurora Acryl GPX cooler its very own visual touch. Copper or aluminium? Alphacool only uses copper in its water coolers. In the case of the Eisblock Aurora Acryl GPX, the copper is nickel-plated. Compared to the previous models, however, Alphacool has once again improved the type of nickel plating, which has significantly increased the acid resistance. This should prevent the nickel plating from flaking off. Why does Alphacool use copper instead of aluminium? Copper has almost twice the thermal conductivity of aluminium and is therefore clearly the better material for water cooling. Other special features The Eisblock Aurora Acryl GPX GPU cooler has the patented screw plugs, which sit flush with the surface of the terminal. The Alphacool logo sits in the corner on the top and is also fully illuminated. On the front of the terminal, corresponding designations of the compatible graphics card manufacturers can be seen. Of course, these are also fully illuminated by the adressable digital LEDs. IN and OUT are marked by small discreet triangles. They are easily recognisable and fit perfectly into the overall visual line of the graphics card water cooler. Compatibility: - KFA² GeForce RTX 3070 Ti SG (1-Click OC), 8GB GDDR6X, HDMI, 3x DP Technical data cooler L x W x H 214,59 x 123,23 x 24,35 mm Material cooler Nickle-plated copper Material cooler top acrylic Threads 4 x G1/4 Thickness cooling fins 0,6 mm Illumination digital aRGB LEDs Power connector digital aRGB LEDs 3-Pin JST Power digital aRGB LEDs 5V Number of digital aRGB LEDs 11 Technical data backplate L x W x H 214,59 x 98,83 x 6 mm Material aluminium Color black

Funktsionaalsed 3-positsioonilised kaaned Ergonoomilistel Kambukka Etna tassidel on väga funktsionaalne kolm-ühes kaas. Valige üks selle kolmest funktsioonist: kaant saab vajutamisel sulgeda, avada või avada. See ainulaadne funktsioon võimaldab teil nautida jooke ja kaitsta neid igas olukorras või kohas. Mugav ja vastupidav Tänu spetsiaalselt kohandatud termokruusi libisemiskindlale alusele, mis tagab hea haarde, seisab Sinu Etna kruus stabiilselt kõikjal, kuhu selle asetad. Samal ajal tagab selle vastupidavuse ja vastupidavuse spetsiaalne 18/8 roostevaba teras, millest on valmistatud termose kahekordsed vaakumisseinad. Tihedus ja Snapclean® tehnoloogia Kas kahtlete, kas vesi termosest ei leki? Kambukka "Etna" seda ei luba. Võtke see endaga kaasa ja hoidke seda turvaliselt seljakotis või pagasis, kartmata, et jook ümberpööramisel maha valgub. Hoolimata täielikult suletud olekust on neid termoseid pärast kaane eemaldamist ülimalt lihtne pesta. Need on ka nõudepesumasinas pestavad. Seda kõike tagab uuenduslik ja patenteeritud Snapclean® tehnoloogia. Kuum jook ei jahuta ja külm mitte Kambukka Etna kruusid on 100% lekkekindlad. Kvaliteetsest roostevabast terasest topeltseinad loovad vaakumi, mis tagab oluliselt parema termoregulatsiooni. Selle tulemusena püsivad teie joogid külmad isegi kuni kella 18-ni. ja palav kella 9ni. Universaalsed kaaned Kambukka tassikaaned on mitmekülgsed. Neid saab hõlpsasti eemaldada ja kohandada kõigi nende kvaliteetsete Belgia toodete mudelitega, muutes nii teie termose stiili. Kaas on nõudepesumasinas pestav. Termokruusi eristavad omadused: • Suletud mittetilkuv süsteem. • Snapclean® tehnoloogia. • Hoiab joogi kuuma kella 9-ni, külmana kella 18-ni. • Ergonoomiline, mugav käes hoida. • Libisemiskindel alus. • Vaakum 18/8 roostevabast terasest kaheseinaline paak. • Sobib teistele Kambukka mudelikatetele. • Snapclean® tehnoloogia. • Valmistatud ilma BPA-ta.

The Alphacool Eisblock Aurora Acryl GPX-N RTX 3070 ROG Strix with Backplate combines style with performance and extensive digital RGB lighting. With experience of over 16 years, Alphacool the ability to create GPU blocks that represent high quality and fantastic performance. This perfectly describes the Aurora Acryl GPX Eisblock More Performance! During the development of the Eisblock Aurora Acryl GPX-N RTX 3070 ROG Strix graphic card GPU block, we wanted to further increase the performance. The first step was to move the cooler closer to the individual components by reducing the thermal pads to a thickness of 1 mm. Next, we reduced the thickness of the nickel-plated copper block. Instead of 7 mm, it is now only 5.5 mm thick. The water flow inside the cooler has also been optimized. All important components such as the voltage transformers and the memory are now significantly better and more effectively cooled by the water. All this ensures a significant increase in cooling performance. New Design! The Eisblock Aurora Acryl GPX-N RTX 3070 ROG Strix cooler has been designed so that lighting is more important than the previous models. The addressable digital RGB LEDs are embedded directly into the cooling block and run along the entire cooling block. The effect is an illumination of the entire cooling block. No corner or edge remains unlit by the aRGB LEDs. The new design is more angular with all edges bevelled. This promotes better light diffusion in the water cooler due to the reflections on these bevels. In addition, they create various contours, which give the Eisblock Aurora Acryl GPX-N RTX 3070 ROG Strix cooler its very own unique identity. Copper or Aluminium? Of course, Alphacool only uses copper for its water coolers. With the Eisblock Aurora Acryl GPX-N RTX 3070 ROG Strix, the copper is nickel-plated. Compared to its predecessor models, Alphacool has improved the nickel plating even further, which has considerably increased the acid resistance. This means that the nickel should resist flaking. Why does Alphacool rely on copper instead of aluminium? Simply, copper has almost twice the thermal conductivity of aluminium and is therefore clearly the better material for water cooling. Is There Anything Else New? The Eisblock Aurora Acryl GPX-N RTX 3070 ROG Strix also relies on the new patented stop fittings, which sit flush with the surface of the terminal. The Alphacool logo now sits in the corner on the top and is also fully illuminated. On the front of the terminal you can see the corresponding names of the compatible graphic card types. Of course, these are also fully illuminated by the digital LEDs. IN and OUT are now marked by small triangles. They are easily recognizable and fit perfectly into the entire aesthetics of the graphic card water cooler. The Alphacool Eisblock Aurora Acryl GPX-N RTX 3070 ROG Strix is a complete redevelopment of the previous Alphacool graphics card water coolers. No technical compromises were made, but the entire technical know-how flowed into the development and implementation. Technical details L x W x H 152 x 267 x 25 mm Material cooler Nickle-plated copper Material cooler top POM clear Threads 4 x G1/4“ Thickness cooling fins 0,6 mm Illumination Digital RGB LEDs Power connector Digital RGB LEDs 3-Pin JST Power Digital RGB LEDs 5V Graphics Card Configurator: Click here! List of Compatibility: Nvidia graphic cards Compatibility : - ASUS ROG Strix GeForce RTX 3070 8GB Advanced (ROG-STRIX-RTX3070-A8G-GAMING) - ASUS ROG Strix GeForce RTX 3070 OC White, ROG-STRIX-RTX3070-O8G-WHITE (90YV0FR5-M0NA00) - ASUS ROG Strix GeForce RTX 3070 White Edition (ROG-STRIX-RTX3070-8G-WHITE) - ASUS ROG Strix RTX 3070 8G Gaming (ROG-STRIX-RTX3070-8G-GAMING) - ASUS ROG Strix RTX 3070 8G Gaming OC - ASUS ROG Strix RTX 3070 8GB TOP (ROG-STRIX-RTX3070-T8G-GAMING) - ASUS ROG Strix RTX 3070 8GB OC (ROG-STRIX-RTX3070-O8G-GAMING) Download Datasheet PDF: Alphacool Eisblock Aurora Acryl GPX-N RTX 3070 ROG Strix with Backplate Datasheet Download Manual PDF: Alphacool Eisblock Aurora Acryl GPX-N RTX 3070 ROG Strix with Backplate Manual

The Alphacool Aurora Acryl GPX-N RTX 3070 Eisblock combines style with performance and extensive digital RGB lighting. With experience of over 16 years, Alphacool the ability to create GPU blocks that represent high quality and fantastic performance. This perfectly describes the Aurora Acryl GPX Eisblock More Performance! During the development of the EIsblock Aurora GPX-N RTX 3070 graphic card GPU block, we wanted to further increase the performance. The first step was to move the cooler closer to the individual components by reducing the thermal pads to a thickness of 1 mm. Next, we reduced the thickness of the nickel-plated copper block. Instead of 7 mm, it is now only 5.5 mm thick. The water flow inside the cooler has also been optimized. All important components such as the voltage transformers and the memory are now significantly better and more effectively cooled by the water. All this ensures a significant increase in cooling performance. New Design! The Eisblock Aurora GPX-N RTX 3070 cooler has been designed so that lighting is more important than the previous models. The addressable digital RGB LEDs are embedded directly into the cooling block and run along the entire cooling block. The effect is an illumination of the entire cooling block. No corner or edge remains unlit by the aRGB LEDs. The new design is more angular with all edges bevelled. This promotes better light diffusion in the water cooler due to the reflections on these bevels. In addition, they create various contours, which give the Aurora GPX-N RTX 3070 Eisblock cooler its very own unique identity. Copper or Aluminium? Of course, Alphacool only uses copper for its water coolers. With the Aurora GPX-N RTX 3070 Eisblock, the copper is nickel-plated. Compared to its predecessor models, Alphacool has improved the nickel plating even further, which has considerably increased the acid resistance. This means that the nickel should resist flaking. Why does Alphacool rely on copper instead of aluminium? Simply, copper has almost twice the thermal conductivity of aluminium and is therefore clearly the better material for water cooling. Is There Anything Else New? The Eisblock Aurora GPX-N RTX 3070 also relies on the new patented stop fittings, which sit flush with the surface of the terminal. The Alphacool logo now sits in the corner on the top and is also fully illuminated. On the front of the terminal you can see the corresponding names of the compatible graphic card types. Of course, these are also fully illuminated by the digital LEDs. IN and OUT are now marked by small triangles. They are easily recognizable and fit perfectly into the entire aesthetics of the graphic card water cooler. The Alphacool Aurora GPX-N RTX 3070 Acryl is a complete redevelopment of the previous Alphacool graphics card water coolers. No technical compromises were made, but the entire technical know-how flowed into the development and implementation. Technical data: L x W x H:128 x 185 x 24,5 mm Material cooler: Nickle-plated copper Material cooler top: Acryl Threads: 4 x G1/4“ Thickness cooling fins: 0,6 mm Illumination: Digital RGB LEDs Power connector Digital RGB LEDs: 3-Pin JST Power Digital RGB LEDs: 5V Graphics Card Configurator: Click here! List of Compatibility: Nvidia graphic cards Compatibility : - Zotac Gaming GeForce RTX 3070 Twin Edge OC, 8GB GDDR6, HDMI, 3x DP (ZT-A30700H-10P) - Zotac Gaming GeForce RTX 3070 Twin Edge, 8GB GDDR6, HDMI, 3x DP (ZT-A30700E-10P) Download data sheet PDF: Alphacool Eisblock Aurora Acryl GPX-N RTX 3070 Gaming Twin Edge with Backplate Download manual PDF: Alphacool Eisblock Aurora Acryl GPX-N RTX 3070 Gaming Twin Edge with Backplate
