The AdderLink XDIP is a compact, easy to install, fanless matrix solution that runs on a standard IP network and enables users to extend and manage their computers with ultra-low latency, HD video and stereo audio. The XDIP is scalable, from simple extension to small matrix. It is very well suited to small and medium sized installations. • Uses IP technology over standard CATx network cable • Point-to-point, switching, sharing or small matrix operation • Local USB and video feed through ports • PoE models are powered by PoE or an optional external PSU • USB2.0 (low & full speed) for keyboard, mouse, tablet and touch screen • Analog audio with headphone support Product Codes XDIP-POE XDIP-IEC XDIP-xx XDIP-RED XDIP-PSU-US* XDIP-PSU-RED* * US market specific Configurable units The XDIP user and computer units are the same and assigned a role at set up. They can transmit/receive up to 1920x1200 video, stereo analog audio and USB2.0 over a single CATx network cable. High quality video, real time control XDIP implements low latency, high quality, 60Hz video compression to deliver an “at the computer” user experience over a standard Gigabit LAN. CATx cable for connection Video, USB2.0 and audio all pass along a single minimum spec of CAT5e cable allowing use of existing infrastructure cables in the building and an immediate ROI. Distance is linked to the IP standard of 100m with a 40% overhead for safety. Longer distances are achieved by routing through your IP infrastructure. Feed through and local computer support Video and USB feed through ports are available. These enable a local console at the source computer. A local computer is also supported at the user station. One solution, many uses XDIP nodes can be configured as a simple extender, distributed KVM switch or KVM sharer or any combination up to 8 computers and 8 users (each user does not necessarily need to be connected to the same 8 computers). EDID management The extender has intelligent EDID management to allow the true characteristics of the monitor to be passed back to the computer or alternatively, a fixed EDID can be specified. Plug and Play There is no need for drivers or software to be installed. A simple wizard takes you through setup at the start of life of the product. CD-quality analog audio CD-quality stereo audio (16-bit sampling at 48kHz) is passed between the local and remote units. Headphones are also supported (16 to 32 Ohms).
The AdderLink XDIP is a compact, easy to install, fanless matrix solution that runs on a standard IP network and enables users to extend and manage their computers with ultra-low latency, HD video and stereo audio. The XDIP is scalable, from simple extension to small matrix. It is very well suited to small and medium sized installations. • Uses IP technology over standard CATx network cable • Point-to-point, switching, sharing or small matrix operation • Local USB and video feed through ports • PoE models are powered by PoE or an optional external PSU • USB2.0 (low & full speed) for keyboard, mouse, tablet and touch screen • Analog audio with headphone support Product Codes XDIP-POE XDIP-IEC XDIP-xx XDIP-RED XDIP-PSU-US* XDIP-PSU-RED* * US market specific Configurable units The XDIP user and computer units are the same and assigned a role at set up. They can transmit/receive up to 1920x1200 video, stereo analog audio and USB2.0 over a single CATx network cable. High quality video, real time control XDIP implements low latency, high quality, 60Hz video compression to deliver an “at the computer” user experience over a standard Gigabit LAN. CATx cable for connection Video, USB2.0 and audio all pass along a single minimum spec of CAT5e cable allowing use of existing infrastructure cables in the building and an immediate ROI. Distance is linked to the IP standard of 100m with a 40% overhead for safety. Longer distances are achieved by routing through your IP infrastructure. Feed through and local computer support Video and USB feed through ports are available. These enable a local console at the source computer. A local computer is also supported at the user station. One solution, many uses XDIP nodes can be configured as a simple extender, distributed KVM switch or KVM sharer or any combination up to 8 computers and 8 users (each user does not necessarily need to be connected to the same 8 computers). EDID management The extender has intelligent EDID management to allow the true characteristics of the monitor to be passed back to the computer or alternatively, a fixed EDID can be specified. Plug and Play There is no need for drivers or software to be installed. A simple wizard takes you through setup at the start of life of the product. CD-quality analog audio CD-quality stereo audio (16-bit sampling at 48kHz) is passed between the local and remote units. Headphones are also supported (16 to 32 Ohms).
This HDMI switch by Delock is a manual bidirectional switch for connecting different devices with HDMI port. This switch offers two different applications. 1. Up to 2 devices can be connected to a monitor, TV or projector. At the push of a button, the device that is displayed on the screen can be selected. 2. An HDMI device can be connected to up to 2 screens. The screen on which the signal is displayed can be selected at the touch of a button. Simultaneous output to multiple screens is not possible. Specification • Connectors: Function 1 Input: 2 x HDMI-A 19 pin female Output: 1 x HDMI-A 19 pin female Function 2 Input: 1 x HDMI-A 19 pin female Output: 2 x HDMI-A 19 pin female • High Speed HDMI specification • HDMI port selection by button • Resolution up to 3840 x 2160 @ 60 Hz (depending on the system and the connected hardware) • No external power supply needed • Plastic housing • Colour: black • Dimensions (LxWxH): ca. 82 x 62 x 17 mm System requirements • One free HDMI female • HDMI cable Package content • Switch bidirectional • User manual Package • Retail Box
Selle Delocki HDMI-switchiga saab kasutada kuni kolme HDMI-seadet ühe HDMI-monitori, teleri või projektoriga. Seadmel oleva nupu või puldi abil saate HDMI-seadmete vahel vahetada. Spetsifikatsioon - Liitmikud: Sisend: HDMI-A 19-pini emasliitmik: 3 x HDMI-A 19-pini emasliitmik 1 x 5 V alalisvoolu toitepistik Väljund: 1 x HDMI-A 19-pini pistikühendusliides: 1 x HDMI-A 19-pini pistikühendus - HDMI-pordi ümberlülitamine: automaatne funktsioon, nupu või infrapunapuldi kaudu - LED-indikaatorid aktiivse HDMI-pordi jaoks - Kiire HDMI spetsifikatsioon - Toetab 3D-ekraane - Toetab HDCP 1.4 ja 2.2 - Toetab HDR - Toetab CEC - Resolutsioon kuni 3840 x 2160 @ 60 Hz (sõltuvalt süsteemist ja ühendatud riistvarast) - Video ribalaius kuni 600 MHz / 6 Gbps, max. 18 Gbps - Energiatarve: max. 2.0 W - Metallist korpus - Värv: must - Mõõtmed (LxSxK): ca. 80 x 51 x 20 mm Toiteallika spetsifikatsioon - Seina toiteallikas - Sisend: V / 50 ~ 60 Hz / 0,3 A - Väljund: 5 V / 1 A - Maandus väljastpoolt, pluss seestpoolt - Mõõdud: ø ca. 2,1 mm, seestpoolt: ø ca. 2,1 mm väljast: ø ca. 5,5 mm pikkus: ca. 9 mm Süsteeminõuded - Vaba HDMI-liitmik - HDMI-kaabel Pakendi sisu - HDMI switch - Kaugjuhtimispult - USB toitejuhe, pikkus: ca. 0,5 m - Väline toiteallikas - Kasutusjuhend
Live production switcher designed for live streaming with 4 HDMI inputs, front panel control, transitions, DVE, keyers, full 1080 HD webcam output and more!
Extends uncompressed HDMI or DVI-D signals up to 100m via its HDBaseT connection Supports HDTV resolutions up to 4K 3840 x 2160p24/30 Full HD 1080p support with 24/36/48 bit colour depth, including 1080p 3D Receiver unit is powered over the Cat6/7 cable from the Transmitter (PoE Function) Supports LPCM, DTS Digital, DTS HD, Dolby Digital & Dolby True HD audio Supports hardware RS232 link function and Infrared remote signal Integrated 3 port 10/100 ethernet hubs in both the transmitter and receiver units Simple plug and play installation 2 Year Warranty Important: The HDBaseT RJ-45 ports must never be connected to a LAN as this will cause the extender to fail. The LINDY HDMI C6 Extender supports uncompressed Full HD 1080p and UHD 4K HDMI signal transmissions for high resolution computer graphics and fluent video transmission, at distances up to 100m (4K
2 Port KVM Switch with HDMI, USB 2.0 and Audio SupportAdditional USB accessories can be attached using a USB Hub (not included)Integrated computer connection cables with HDMI, USB and Audio interfacesHDMI, USB 2.0 and 3.5mm Audio In/Out console portsSupports USB 2.0 speeds of up to 480Mbit/secSwitch via the attached desktop switching button, the supplied software or keyboard hot keysLED indicators for each active portSupports HDMI signals up to 1080p, HDCP and 3D - suitable for Mac, PC, Xbox or PS3Can be used with DisplayPort or Mini-DisplayPort equipped computers using a DisplayPort to HDMI or Mini-DisplayPort to HDMI converterCompatible with Windows 2000/XP/Vista/7/8, Linux (Ubuntu 7.10), Mac OS 10.5 and higher2 years warranty
Route 4 Ultra Hi-Def sources to 2 Ultra HD dsiplays with FST, 3DTV and 4K X 2K Ultra Hi-Def support. The matrix is a compact and lightweight alternative to rack-mounted matrixes. It allows up to four Ultra High Definition 4K or 1080p Full HD sources to be routed to up to two Ultra HD displays. Each Hi-Def source can be routed to either of the connected displays using the front panel push-button controls, the included IR remote, RS-232 serial control interface, or through IP, using Telnet, UDP, and the built-in web server interface. LED indicators on the top panel display the current routing status, FST mode, audio configuration, and EDID settings.
Splitter routes one Ultra HD source to two 4K Ultra HD displays. It eliminates the lengthy HDMI authentication process, and allows disconnecting, reconnecting, or powering down HDTV displays without any of these activities causing picture loss in other displays within the same distribution system. The choice between built-in and passed-through EDIDs, and the ability to configure the EDID for 2-channel or multichannel operation help customize your AV system to meet its operational requirements . The Gefen 1:2 Splitter is a high performance and capable choice for any small or large 4K video distribution system. This product features Fast Switching Technology (FST). FST is a Gefen firmware implementation for HDMI products.
The GefenTV 4x1 Switcher for HDMI with RS232 switches between any of four Hi-Def sources to one HDTV display. Resolutions up to 1080p Full HD with multichannel digital audio are supported. The front panel LEDs show the currently selected source. This 4x1 Switcher has an auto-switching feature: If a new source is connected or turned on, the Switcher will automatically switch to that input. The 4x1 Switcher will revert to the previous input once the current device is turned off or disconnected. Any of the four Hi-Def sources can be selected by the push-button, IR remote control, or using the RS-232 control.
This Easy 45 2-gang switch by Delock is designed to switch light sources and power supplies on and off. The simple snap-in mechanism ensures that the switch is firmly in place and can be easily removed if necessary. Easy 45 connects Easy 45 is a variable, modular system that allows components such as sockets, HDMI or USB connections to be added according to your needs. The Easy 45 modules are standardised and can be mounted in various module holder or cable ducts. Easy 45 builds the interface between electrical, network and system installation and many peripheral devices such as TV, monitors, printers, laptops and much more. Specification • Connectors: 2 x screw terminal • Switch type: 1-pole, 1-way • Switching voltage: AC 250 V~ • Switching current: 10 AX • Material: nylon / PC plastic • Suitable for module holder Delock Easy 45 • Suitable for 45 mm cable duct with minimum depth 45 mm • Module size: 45 x 45 mm • Dimensions (LxWxH): ca. 45 x 45 x 37 mm • Colour: white System requirements • A free module port Delock Easy 45 (45 x 45 mm) Package content • Easy 45 switch • User manual
Smart, Portable, All-In-One Live Streaming Encoder & Touchscreen Control Monitor. Incoder, Monitor, Recorder, Multi-Sites Streamer In One Intuitive 5.5" Touchscreen Control on Android OS Stream via Ethernet, Wi-Fi, 4G LTE; Internal Battery Stream at up to 1080p60; Supports H.264, 1 x HDMI, 1 x USB In; 1 x SD Card Input; Mic In, Line In 1 x HDMI Confidence Monitor Out; Audio Out Built-In Lower-Thirds/Scoreboard/Graphic Overlays Built-In Picture in Picture, Side-By-Side, Split-View Add logos/comments to the stream Same QualComm CPU as YoloBox Pro; 8-Core Processor Introducing the most intuitive, multi-use, all-in-one live streaming encoder: YoloBox Mini is an encoder, monitor, recorder and multi-destinations streamer in one. It’s the industry’s first REALLY all-in-one live production system that doesn’t require anything external. With built-in restreaming service, native support integrates directly with YouTube/Facebook/Twitch, adding graphic overlays (logos, lower-thirds, picture in picture, scoreboard, rolling captions) and featuring comments to the stream, Side-By-Side, Split-View and much more. YoloBox Mini brings the professional features and processing power required for the most demanding live broadcasts. The YoloBox Mini is a 320g weight and 5.5" touchscreen display, featuring 1 HDMI input, 1 HDMI output, 1 USB-A input. The Mini supports input resolutions of 720p and 1080i/p, as well as streams of 540p, 720p, and 1080p60 at your choice, using the H.264 codec. With HDMI output, you can display your stream locally on an HDMI device. It also has a line-level audio input, and a separate headphone audio out. You can record your stream directly in the .mp4 format to an optional SD card, up to 128 GB in size, using the built-in SD card slot. The line-in allows you to connect with the synthesizer and mic-in can be connected to the microphone for recording. (Please check out YoloBox Pro if you are looking for more HDMI inputs and video switching features) Touchscreen Control The YoloBox Mini provides you with a touchscreen interface for easy streaming and control. Functions The device works as a switcher, with a variety of picture-in-picture templates as well as graphic layers. It has a built-in encoder that allows for live streaming, and it can record to optional SD cards. Overlays You can brand your live stream by adding logos/watermarks/rolling captions Customized PiP options, including Interview mode, allow you to bring a unique look and feel to your stream Engage with your audience in real time via feature comment overlays The customizable scoreboard feature displays a real-time-controlled scoreboard for professional looking results Built-in lower-thirds templates can be edited or you can add your own Internet You can connect to the internet using the integrated RJ45 (Ethernet) port, Wi-Fi, and via cell service using an optional SIM card. Simultaneous Streaming YoloBox Mini Mini Pro will first push your feed to the YoloLIV platform, from where it automatically forwards your feed to a maximum of 3 destinations simultaneously. Use Only as a Monitor & Recorder Utilize the device even when you are not live streaming. Record, switch, add overlays and transitions to level up your video production efficiency. Streaming Platforms Major streaming platforms such as Facebook live, YouTube, and Twitch are directly integrated, you can simply login your social account and stream. SD Card Input Roll in pre-recorded videos for intro, countdown, B-rolls, or special segments from an SD media card. PDF You can load a PDF as a local source to your YoloBox Mini. Battery Life The internal battery can power your YoloBox Mini Mini for approximately 2 hours. The YoloBox Mini Mini charges via the USB-C connection, which is used for power only. Technical Specifications: Interfaces: HDMI IN 1; USB-A3.0; HDMI OUT; Ethernet; LINE IN (3.5mm); MIC IN (3.5mm); AUDIO OUT (3.5mm); Nano-SIM Card Holder; 1/4´´ Screw Hole；SD Card Holder; USB Type-C (Only for charging) Input Power: DC5V/2.5A, DC9V/2A, DC12V/1.5A Power Consumption: ＜18W Power Supply: USB Type-C USB Rated Output: USB-A: DC5V/1A Battery Capacity: 4700mAh Dimensions (LxWxH): 155x92.6x20mm Net Weight: 320g Monitor Screen Size: 5.5" LCD Resolution: 720*1280 Local Video Inputs: HDMI, USB3.0 Video Over Ethernet: RTMP/RTMPS Video Input Connectors: HDMI,USB-A,RJ-45 Video Input Aspect Ratios: 4:3,16:9 Video Input Deinterlacing: Yes Live Broadcast Video Input Resolution: 480p/720p/1080p (up to 60fps) Video Encoded Format: H.264 Video processing Bitrate control: CQ, VBR, CBR Hardware-Accelerated Video Encoding: Optional Video Output Signal Types: FLV-RTMP, HDMI, UVC Video Output Connectors: HDMI, USB-A Video Output Streaming protocols: RTMP, RTMPS, MJPEG Live Broadcast Video Output Resolution: 480p/720p/1080p (up to 60fps) Analog Audio Input Connectors: Line In, Mic In 3.5mm Digital Audio Inputs: USB, HDMI, RTMP (From internet), Local video (From SD card) Digital Audio Input Connectors: USB-A, HDMI Audio Input Mute: Yes Audio Input Format: 32KHZ / 44.1KHZ / 48KHZ: 16bit Audio Encoded Format:（AAC) 44.1K 2Ch 16bit Analog Audio Output: 3.5mm headphone jack Digital Audio Outputs: HDMI audio (Embedded), USB Audio (Embedded) Record Formats: MP4 Wi-Fi: 2.4G/5G 4G Network: 4G Network Countries & Frequency Band For Users: [NA: Variant for North America（US / Canada / Mexico)］ B2/B4/B5/B7/B12/B13/B14/B17/B25/B26 Notes: Mexico B4 For Non-US / Canada / Mexico Users: (EM: Variant for EMEA / India / Korea / Taiwan / South Asia / Latin / America / Australia / New Zealand） Users: B1/B3/B7 Notes: Thailand B1, B3 Please note that the certification of Yolobox Mini is in line with the mainstream open 4G band requirements of operators in this country or region. For details, please refer to the approval report of this country or region. USB Communication Standard: USB 2.0, and USB 3.0 Ethernet Data Rate: 10/100M, half/full duplex with autodetect SIM Card Size: Nano-SIM Card SDCard format: FAT32 (Under 128G), NTFS, EXFAT Operating Temperature: 0℃-40℃ Operating Humidity: 15%-85%, No Condensation
Laiendab HDMI 4K (3840x2160p60Hz 4:2:0) või VGA (max 1920x1200) videosignaale Gigabit IP-võrgu kaudu Toetab punkt-punkti paigaldamist kuni 100m ja punktpunkti paigaldamist Gigabit Switchi abil (ka video seina loomiseks) Laiendab USB 2.0, USB HID (KVM funktsioonide jaoks), kahesuunaline analoogheli, kahesuunaline IR ja RS232 signaal HDMI 2.0 ja HDCP 2.2/1.4 ühilduvad Vastuvõtja LIN38267
Ühendage ja lülitage kuni 5 UHD HDMI seadet 1 UHD kuvariga või projektoriga. Toetab videoresolutsioone kuni 4K2K@60Hz 8 bit, sealhulgas 3D 1080p Toetab 7.1-kanalilisi LPCM, Dolby TrueHD ja DTS-HD Master Audio digitaalseid helisignaale HDCP 2.2 ühildub uusimate AV-seadmetega kasutamiseks 2-aastane garantii See tipptasemel 4K UHD HDMI 2.0 18G kommutaator on võimeline kuvama kuni 3840 x 2160 resolutsiooni 5 UHD-signaalist sisse 1 UHD-signaali välja. Komplektis on RS232 port, mis võimaldab lülitamist arvuti või juhtimistarkvara kaudu. Lüliti on ka HDR (High Dynamic Range) ühilduv, et reprodutseerida suuremat heleduse dünaamilist ulatust, mis on sarnane pildistamisel ja fotograafias kasutatavale. Telerites kasutatav HDR võimaldab laiemat värvivalikut ja suuremat kontrasti valge ja musta värviga, mille tulemuseks on palju suurema lahutusvõimega pildid, mis on sarnased inimsilmale. Tänu HDCP 2.2 ja HDMI 2.0 täielikule toetusele võite olla kindel, et see toode on täiesti tulevikukindel ja valmis uute ja nõudlike audio- ja videosignaalide jaoks turul. Pakendi sisu 5 portne HDMI 2.0 18G lüliti 5V Multi Country PSU koos Ühendkuningriigi, USA, Austraalia ja Euroopa adapteritega Kaugjuhtimispult koos patareiga IR-vastuvõtja kaabel ~1,2m Lindy kasutusjuhend
4-portiline KVM-lüliti HDMI, USB 2.0 ja audio toega HDMI, USB 2.0 ja 3,5 mm audio sisse/välja konsooli pordid Toetab USB 2.0 kiirust kuni 480Mbit/sek. Toetab HDMI signaale kuni 1080p koos 3D-ga ja DVI kuni 1200p - sobib arvutite, konsoolide ja Blu-Ray mängijate jaoks 2-aastane garantii See KVM-lüliti võimaldab juhtida nelja HDMI-ga varustatud arvutit, mängukonsooli või Blu-Ray-mängijat ühe klaviatuuri, hiire ja monitori abil. Lihtsalt ühendage oma arvuti asjakohaste kaablitega (müüakse eraldi) ning ühendage klaviatuur, hiir ja monitor lüliti külge ja olete valmis. Täiendavad 3,5 mm audiopordid võimaldavad ühendada kõrvaklapid või kõlarid ja mikrofoni, samas kui USB-perifeerseadmeid saab lisada USB-keskuse lisamisega. Pakendi sisu: Komplektis sisalduvad järgmised osad: 1: 4-pordiline KVM-lüliti Kaugjuhtimispult Mitme riigi PSU - 5V ~2A 3,5/1,35mm pistikuga 4 x HDMI & USB 2.0 A/B Combo kaabel ~1,7m LINDY kasutusjuhend
Juhib kahte HDMI-ga varustatud arvutit ühe klaviatuuri, hiire ja monitori abil. Lülitamine seadme nuppude või klaviatuuri kiirklahvide abil Toetab HDMI-signaale, kuni 4K 60 Hz koos 4:4:4 8bitiga Sõltumatu heli ümberlülitamine ja 2 porti USB 2.0 Hub täiendavate USB-perifeeriate jagamiseks 2-aastane garantii KVM-lüliti võimaldab operaatoril mugavalt juhtida ja hallata mitut seadet, näiteks arvutit ja servereid, ühe klaviatuuri, hiire ja ekraanikonsooliga. Lindy 2 Port HDMI 18G, USB 2.0 & Audio KVM Switch on kompaktne lahendus, mis võimaldab juurdepääsu ja kontrolli neljale HDMI-ga varustatud arvutile ühe klaviatuuri, hiire ja monitori komplektist. Kuni 4K Ultra HD 60 Hz resolutsioonide tugi tagab kõrgeima pildikvaliteedi, mis sobib ideaalselt nõudliku graafilise sisu jaoks mängukomplektides, videotöötluses või kahesüsteemi juhtimispunktides. Peaseadme heliväljundipordid võimaldavad kasutajatel ühendada ka kõrvaklapid või kõlarid, et lisada immersiivne 2CH audio ja mikrofon. Täiendavaid USB-perifeerseadmeid saab integreerida 2-pordilise USB 2.0-keskuse abil. Nii heli- kui ka USB-hubisid saab lülitada arvutitest sõltumatult, mis võimaldab kasutajatel näiteks printida ühest arvutist, samal ajal kui nad töötavad teises arvutis. See toetab True Transparent USB-vahetus, täiustatud USB-emulatsioonitehnoloogiat, mis võimaldab KVM-l tuvastada konkreetseid klaviatuuri- ja hiiremudeleid ning emuleerida kõiki nendega seotud spetsiaalseid klahve ja funktsiooniteavet. See tagab ka täiustatud toetuse kombineeritud kasutamiseks koos KVM-laiendajatega. KVM-lülitil on mitu lülitusvõimalust, sealhulgas seadme nupud ja konfigureeritavad kiirklahvid, mis pakuvad kasutajale lihtsat ja usaldusväärset juhtimist, mis sobib suurepäraselt nii professionaalsetele kui ka esmakordsetele kasutajatele. Pange tähele: ühenduskaablid ei kuulu komplekti.
Juhib nelja HDMI-ga varustatud arvutit ühe klaviatuuri, hiire ja monitori abil. Lülitamine seadme nuppude või klaviatuuri kiirklahvide abil Toetab HDMI-signaale, kuni 4K 60 Hz koos 4:4:4 8bitiga Sõltumatu heli ümberlülitamine ja 2 porti USB 2.0 Hub täiendavate USB-perifeeriate jagamiseks 2-aastane garantii KVM-lüliti võimaldab operaatoril mugavalt juhtida ja hallata mitut seadet, näiteks arvutit ja servereid, ühe klaviatuuri, hiire ja ekraanikonsooliga. Lindy 4 Port HDMI 18G & USB KVM Switch Pro on usaldusväärne ja terviklik lahendus nelja host-arvuti juhtimiseks ühe klaviatuuri, hiire ja HDMI-ekraani abil. Kuni 4K Ultra HD 60 Hz resolutsioonide tugi tagab kõrgeima pildikvaliteedi, mis sobib ideaalselt nõudliku graafilise sisu jaoks mängukomplektides, videotöötluses või nelja süsteemi juhtimiseks tööjaamades. Peaseadme heliväljundipordid võimaldavad kasutajatel ühendada ka kõrvaklapid või kõlarid, et lisada immersiivne 2CH audio ja mikrofon. Täiendavaid USB-perifeerseadmeid saab integreerida 2-pordilise USB 2.0-keskuse abil. Nii heli- kui ka USB-hubisid saab lülitada arvutitest sõltumatult, mis võimaldab kasutajatel näiteks printida ühest arvutist, samal ajal kui nad töötavad teises arvutis. See toetab True Transparent USB-vahetus, täiustatud USB-emulatsioonitehnoloogiat, mis võimaldab KVM-l tuvastada konkreetseid klaviatuuri- ja hiiremudeleid ning emuleerida kõiki nendega seotud spetsiaalseid klahve ja funktsiooniteavet. See tagab ka täiustatud toetuse kombineeritud kasutamiseks koos KVM-laiendajatega. KVM-lülitil on mitu lülitusvõimalust, sealhulgas seadme nupud ja konfigureeritavad kiirklahvid, mis pakuvad kasutajale lihtsat ja usaldusväärset juhtimist, mis sobib suurepäraselt nii professionaalsetele kui ka esmakordsetele kasutajatele. Pange tähele: ühenduskaablid ei kuulu komplekti.
Switch between 4 HDMI source devices and 4 HDMI displays connected simultaneouslySupports resolutions up to 4K 60Hz, with additional support for HDRExtract audio from HDMI to SPDIF for connection to amplifiers and speaker systemsEDID Management system for controlling and ensuring the optimum resolution possible2 year warranty Matrix Switches are premium solutions for distributing content from multiple source devices to multiple displays. The Lindy 4x4 HDMI Matrix Switch Pro supports HDMI 2.0 18G signals, allowing for the transmission of clear 4K Ultra HD 60Hz resolutions. Additional support for High Dynamic Range ensures video content is displayed with enhanced brightness, greater contrasts and a much wider colour gamut, perfect for digital signage displays in retail, creating informational multi-display setups in education, or distributing content in commercial installations such as cinemas. HDCP 2.2 support ensures there are no issues with a variety of 4K content when connected to source devices including set top boxes, Blu-Ray players and 4K HDR media players. As well as HDMI audio pass-through, individual SPDIF ports allow for a separate connection of digital speaker systems and amplifiers, creating immersive audio experiences to compliment the video content. This Matrix can be easily controlled via push button switching on the unit, while the included remote control and IR extension also allows the user to have better control over multiple videos and displays, great for trade shows, training presentations or sales demonstrations. DocumentationDriverAsk a question about the productRecommend this product
Secure KVM switch for sharing single or dual head 4K video, USB keyboard and mouse, plus analog audio between four computers spanning multiple security classification levels ADDERView Secure switches enable a KVM plus audio desktop to be shared between different classification level computers. Designed for superior usability, the switches feature configurable LED buttons and a real-time status display. NIAP PP 4.0 Compliant Design Made in America TAA Compliant
ADDERView® CCS-MV 4224 mitmevaatajaJuhtimis- ja kontrollimise mitmevaataja lüliti 4K-video, klaviatuuri ja hiire ning heli jagamiseks nelja arvuti vahel. Uuenduslikud hübriidsed DisplayPort™ ja HDMI® sisendportid paindlikuks ühenduvuseks ühelt arvutilt.ADDERView® CCS-MV on lauaarvuti mitmevaataja lüliti, mis võimaldab ühe tööjaama kaudu samaaegset reaalajas 4K KVMA juurdepääsu kuni neljale arvutile. Kasutajad saavad sihtarvuti juhtimise üle võtta lihtsalt hiirt akende vahel liigutades, mis annab ühe lauaarvuti kasutamise kogemuse.
‘Zero U’ Computer Access Modules (CAMs): Powered by USB, the digital computer access modules sit in-line and are ideal for racks with limited available space. Modules are available in DVI, VGA and DisplayPort options. Product Codes DDX-CAM-DP; DDX-CAM-DVI; DDX-CAM-VGA Zero U A zero U configuration CAM (Computer Access Module) which attaches to your source device/computer and acts as a tranmitter to either the DDX30/DDX10 switch or directly to the DDX USR user station as a point to point extender. DDX CAM requires no specific configuration which means you can simply connect it to a DDX USR or DDX switch. DisplayPort, VGA or DVI Available in DisplayPort, VGA and DVI variants, the DDX CAM supports all common single link digital video resolutions. HDMI is also possible via a passive converter. Mult Function USB Because the DDX CAM is powered by USB, you do not need an external power supply, thus simplifying cable clutter significantly. The same USB power connector also delivers USB data functionality and acts as a USB audio device.
A powerful and flexible Digital KVM over IP product contained within a palm sized unit, the AdderLink Digital ipeps enables computer access from anywhere in the world, securely and remotely via the Internet or corporate network. The AdderLink Digital ipeps uses Real VNC client software that is specifically designed for secure, high performance KVM over IP applications and supports both IPV4 and IPV6 addresses. The AdderLink Digital ipeps can accept video signals from computers equipped with DVI, DisplayPort DP++ (Dual-Mode) or HDMI along with USB for mouse/keyboard control and for virtual media. Product Codes ALD-IPEPS Digital Video Inputs The Adderlink Digital ipeps will accept any single link DVI input up to 1920x1200 resolution. It can also be attached to computers with DisplayPort DP++ (Dual-Mode) or HDMI with converter cables enabling access to any computer with a digital video interface. Independent operation The Digital ipeps gives full control even during boot up, BIOS level or computer crash states, it will even work even if the controlled devices are not operational. High video performance The AdderLink Digital ipeps can be accessed by a standard web browser but for superior graphical performance, a Real VNC viewer should be used. Free of the limitations of HTTPS, Real VNC greatly enhances video performance. Highly secure plus support for IPV6 addresses Employing enterprise grade security (using AES 128 bit encryption and RSA 2048 bit public key authentication) as standard, the AdderLink Digital ipeps is further enhanced by the use of Real VNC that allows for the creation of ciphered user communications. Supports both IPV4 and IPV6 addresses. USB and Virtual media support To transfer files from remote users to controlled computers, the AdderLink Digital ipeps has been engineered to act as a conduit through which data can be passed. Files can be transferred via IP onto the Digital ipeps and onto the target computer by means of a USB virtual media port. Power control through RS232 serial interface The AdderLink Digital ipeps has an RS232 port to allow communication to devices like power switches, allowing remote rebooting of the target computer. Choice of power source The AdderLink Digital ipeps can either be powered from two USB cables or independently from an external 5V power source. User management The AdderLink Digital ipeps can create up to 16 user profiles with defined access rights. The unit can be accessed by up to 4 users at any one time. Remote gateway to AdderLink Infinity The AdderLink Digital ipeps can be used as a remote gateway into the Adderlink Infinity system by connecting it into an AdderLink Infinity reciever unit. This will allow users to access any computer on the Adderlink Infinity network with their normal username and passwords from any location including mobile devices.
Secure KVM switch for sharing single or dual head 4K video, USB keyboard and mouse, plus analog audio between four computers spanning multiple security classification levels ADDERView Secure switches enable a KVM plus audio desktop to be shared between different classification level computers. Designed for superior usability, the switches feature configurable LED buttons and a real-time status display. NIAP PP 4.0 Compliant Design Made in America TAA Compliant Product Features Uni-directional keyboard, video, mouse and audio data paths: Uni-directional optical diodes ensure data paths travel in only one direction, thus preventing data leakage through shared peripherals. A uni-directional structure also protects against timing analysis or forced malfunction attacks and prevents computers influencing the operation of any common circuitry. Channel identification: Reduce the chances of operator error by displaying a name for each channel and its security classification on the E-paper display. The color of the channel LED may also be configured to reflect the security classification. No shared RAM between ports: The keyboard and mouse processor is powered down and reset at each switchover to thwart shared RAM leakages. All data buffers are actively cleared once they have been used. Keyboard locks status: Indicate status of keyboard locks (CAPS-LOCK, NUM-LOCK, SCROLL-LOCK) that are blocked by uni-directional data paths. Automatic switching (configuration option): Free-flow KVM and audio control between ports without the need to press any buttons. Simply move the mouse between windows. Hardware anti-tampering: Holographic anti-tampering labels protect the product’s enclosure, providing a clear visual indication if it has been opened or compromised. Non-reprogrammable firmware: There is no access to the product’s firmware or memory through any port. Firmware is permanently stored in non-reprogrammable Read Only Memory (ROM) to prevent modification. Firmware integrity is verified through a self-test procedure during power up. Detection of a critical failure disables the device and provides a clear visual indication to the user. Restricted USB function: The USB ports will only accept HID (Human Interface Devices), such as keyboards and mice. Other devices, such as USB storage drives, are actively prohibited. Video Performance: Up to UHD 4K video resolution at 60 fps for graphics intensive applications requiring very high quality. Audio hold: Assign the audio port to a specific computer while switching the KVM to other computers. Useful when a user needs to listen to audio from one computer, whilst working on another.
Secure KVM flexi-switch for sharing single or dual head 4K video, USB keyboard and mouse, plus analog audio between eight computers spanning multiple security classification levels. The ADDERView™ Secure Flexi-Switch has been designed for applications that require more functionality than a standard 4-port KVM switch can provide. The Secure Flexi-Switch has eight input computer ports that can be connected to a combination of single and dual-head computers; giving the user real-time control of up to two computers simultaneously. NIAP PP 4.0 Compliant Design Made in America TAA Compliant Product Features Uni-directional keyboard and mouse data paths: Uni-directional optical diodes ensure data paths travel in only one direction, thus preventing data leakage through shared peripherals. A uni-directional structure also protects against timing analysis or forced malfunction attacks and prevents computers influencing the operation of any common circuitry. Keyboard locks status: Indicate status of keyboard locks (CAPS-LOCK, NUM-LOCK, SCROLL-LOCK) that are blocked by uni-directional data paths. No shared RAM between channels: The keyboard and mouse processor is powered down and reset at each switchover to thwart shared RAM leakages. All data buffers are actively cleared once they have been used. Automatic switching (configuration option): Free-flow KVM and audio control between ports without the need to press any buttons. Simply move the mouse between windows. Flexible connections: The user can switch between a combination of single and dual head computers. Two single head computers can be controlled concurrently. Hardware anti-tampering: Holographic anti-tampering labels protect the product’s enclosure, providing a clear visual indication if it has been opened or compromised. Video Performance: Up to UHD 4K video resolution at 60 fps for graphics intensive applications requiring very high quality. Non-reprogrammable firmware: There is no access to the product’s firmware or memory through any port. Firmware is permanently stored in non-reprogrammable Read Only Memory (ROM) to prevent modification. Firmware integrity is verified through a self-test procedure during power up. Detection of a critical failure disables the device and provides a clear visual indication to the user. Restricted USB function: The USB ports will only accept HID (Human Interface Devices), such as keyboards and mice. Other devices, such as USB storage drives, are actively prohibited. Channel identification: Reduce the chances of operator error by displaying a name for each channel and its security classification on the E-paper display. The color of the channel LED may also be configured to reflect the security classification.
Kirjeldus Vahetab 4 HDMI allikaseadme ja 4 HDMI ekraani vahel professionaalse maatriksina Loob klassikalised videoseinad (kuni 2x2) või vertikaalsed videoseinad (4x1) Lülitab seadmete vahel sujuvalt ümber alla 0,1 ms Kontrollib väljundite skaleerimist, et tagada optimaalne või järjepidev resolutsioon 2-aastane garantii Lindy 4x4 HDMI 4K60 Matrix koos videoseina skaleerimisega on professionaalne lahendus sisu levitamiseks mitmest allikaseadmest paljudele HDMI-ekraanidele või pilkupüüdvate videoseina komplektide loomiseks. Toetades kuni 4K@60Hz resolutsiooni, saab sisu näidata suurepärase selgusega, mis sobib suurepäraselt kvaliteetse videokogemuse tagamiseks spordibaarides, jaemüügipoodides või mitmes järjestikuses kohas suuremates installatsioonides. Resolutsioone saab kasutaja hõlpsasti skaleerida ja kontrollida, et tagada alati optimaalse või järjepideva resolutsiooni kuvamine. Lisaks sellele, et see seade pakub professionaalset 4x4-maatrikslülitusfunktsiooni, saab sellega luua kohandatavaid seinakuvasid erinevates paigutustes. See annab kasutajale mitmeid paindlikke kuvamisvõimalusi ning võimaldab seadet kasutada mitmesugustes erikeskkondades, sealhulgas transpordisõlmedes, müügikohtades ja külalislahendusasutustes. Analooghelipordid võimaldavad ka 2-kanalilist heli väljavõtet, et lisada ekraanil olevale sisule kaasahaarav stereoheli. Maatriks võimaldab ka koheselt sujuvat ümberlülitumist allikaseadmete ja kuvarite vahel, mis on oluline funktsioon reaalajas kasutamiseks
The AdderLink XDIP is a compact, easy to install, fanless matrix solution that runs on a standard IP network and enables users to extend and manage their computers with ultra-low latency, HD video and stereo audio. The XDIP is scalable, from simple extension to small matrix. It is very well suited to small and medium sized installations. • Uses IP technology over standard CATx network cable • Point-to-point, switching, sharing or small matrix operation • Local USB and video feed through ports • PoE models are powered by PoE or an optional external PSU • USB2.0 (low & full speed) for keyboard, mouse, tablet and touch screen • Analog audio with headphone support Product Codes XDIP-POE XDIP-IEC XDIP-xx XDIP-RED XDIP-PSU-US* XDIP-PSU-RED* * US market specific Configurable units The XDIP user and computer units are the same and assigned a role at set up. They can transmit/receive up to 1920x1200 video, stereo analog audio and USB2.0 over a single CATx network cable. High quality video, real time control XDIP implements low latency, high quality, 60Hz video compression to deliver an “at the computer” user experience over a standard Gigabit LAN. CATx cable for connection Video, USB2.0 and audio all pass along a single minimum spec of CAT5e cable allowing use of existing infrastructure cables in the building and an immediate ROI. Distance is linked to the IP standard of 100m with a 40% overhead for safety. Longer distances are achieved by routing through your IP infrastructure. Feed through and local computer support Video and USB feed through ports are available. These enable a local console at the source computer. A local computer is also supported at the user station. One solution, many uses XDIP nodes can be configured as a simple extender, distributed KVM switch or KVM sharer or any combination up to 8 computers and 8 users (each user does not necessarily need to be connected to the same 8 computers). EDID management The extender has intelligent EDID management to allow the true characteristics of the monitor to be passed back to the computer or alternatively, a fixed EDID can be specified. Plug and Play There is no need for drivers or software to be installed. A simple wizard takes you through setup at the start of life of the product. CD-quality analog audio CD-quality stereo audio (16-bit sampling at 48kHz) is passed between the local and remote units. Headphones are also supported (16 to 32 Ohms).
