Emaplaadid

ATX DDR4 Memory slots 4|2xPCI-Express 3.0 1x|1xPCI-Express 4.0 16x|2xM.2|1xHDMI|1xDisplayPort|2xAudio-In|3xAudio-Out|2xUSB 2.0|5xUSB 3.2|1xOptical S/PDIF|1xRJ45

LGA 1700 socket - Supports DDR5 Memory, Dual Channel DDR5 6800+MHz (OC) - Enhanced Power Design: 12+1 Duet Rail Power System with P-PAK, 8-pin + 4-pin CPU power connectors, Core Boost, Memory Boost - Premium Thermal Solution: Extended Heatsink, MOSFET thermal pads rated for 7W/mK, additional choke thermal pads are built for high performance system and non-stop gaming experience - Lightning Fast Game experience: PCIe 4.0 slot, Lightning Gen 4 x4 M.2 with M.2 Shield Frozr, Turbo USB 3.2 Gen 2 10G - 2.5G LAN with Wi-Fi 6E Solution: Upgraded network solution for professional and multimedia use. Delivers a secure, stable and fast network connection - High Quality PCB: 6-layer PCB made by 2oz thickened copper - Audio Boost: Reward your ears with studio grade sound quality for the most immersive gaming experience Intel B760 Express LGA1700, ATX DDR5, 6800/6600/6400/6200/6000/5800/5600/5400/5200/5000/4800 MHz Memory slots 4, 5xPCI-Express 16x 2xM.2, 1xHDMI 1xDisplayPort, 2xUSB 2.0 2xUSB 3.2, 1xUSB-C 1xPS/2, 1xOptical S/PDIF 1xRJ45, 5xAudio port USB 2.0, USB 3.2 Bluetooth, WiFi Video Depending on CPU, LAN 2.5 Gigabit Audio Realtek ALC897, RAID SATA 0, 1, 5, 10 TPM Header

LGA1700 Micro-ATX DDR4 Memory slots 4 1xPCI-Express 3.0 16x 1xPCI-Express 4.0 16x 2xM.2 1xHDMI 1xDisplayPort 5xUSB 2.0 3xUSB 3.0 1xRJ45 3xAudio port

DDR5 WIFI

SAM5 ATX DDR5 Memory slots 4 4xPCI-Express 16x 2xM.2 1xHDMI 1xDisplayPort 7xUSB 3.2 1xUSB-C 1xRJ45 6xAudio port

SAM5, MicroATX, DDR5 Memory slots 4, 1xPCI-Express 3.0 1x, 1xPCI-Express 4.0 16x, 2xM.2, 1xHDMI, 2xDisplayPort, 4xUSB 2.0, 3xUSB 3.2, 1xUSB-C, 1xPS/2, 1xRJ45

4DDR5 HDMI M.2 DP USB3.2 ATX

ATX DDR5 Memory slots 4 1xPCI-Express 3.0 16x 1xPCI-Express 4.0 16x 1xPCI-Express 5.0 16x 4xM.2 1xHDMI 1xDisplayPort 4xUSB 2.0 5xUSB 3.2 1xUSB-C 1xOptical S/PDIF 1xRJ45 2xAudio port

DDR5 ATX WIFI 1xHDMI

LGA1700|Micro-ATX, DDR4 Memory slots 2, 2xPCI-Express 3.0 1x, 1xPCI-Express 4.0 16x|2xM.2|1x15pin D-sub|1xHDMI|1xDisplayPort|2xUSB 2.0|3xUSB 3.2|1xUSB-C|1xPS/2|1xRJ45

Socket AM4, Form factor ATX, Chipset AMD B550, CPU compatibility Ryzen 5000, Ryzen 3000, without TDP restriction (manufacturer list), VRM 4 real phases (4 + 1), 14 virtual phases (12 + 2), ASP1106 (RT8877C, max. 6 phases), MOSFETs CPU 12x 50A SIC639, MOSFETs SoC 2x 50A SIC639, RAM 4x DDR4 DIMM, dual PC4-40800U / DDR4-5100 (OC), max. 128GB (UDIMM), Expansion slots 1x PCIe 4.0 x16, 1x PCIe 3.0 x16 (x4), 3x PCIe 3.0 x1, 1x M.2 / M-Key (PCIe 4.0 x4 / SATA, 22110/2280/2260/2242), 1x M .2 / M-Key (PCIe 3.0 x4 / SATA, 22110/2280/2260/2242), External connections 1x HDMI 2.1 (iGPU), 1x DisplayPort 1.2 (iGPU), 1x USB-C 3.1 (B550), 1x USB-A 3.1 (B550), 4x USB-A 3.0, 2x USB-A 2.0, 1x 2.5GBase- T (Intel I225-V), 5x jack, 1x Toslink, Internal connections 1x USB 3.0 header (2x USB 3.0), 2x USB 2.0 header (4x USB 2.0), 6x SATA 6Gb / s (B550), 1x Thunderbolt header 13-pin, Header cooling 2x CPU fan 4-pin, 3x fan 4-pin, 1x AIO pump 4-pin, 1x thermal sensor, Header lighting 2x 4-pin RGB (+ 12V / G / R / B, max. 3A), 1x 3-pin ARGB (+ 5V / DATA / GND, max. 3A, ASUS Gen2), Buttons / Switches USB BIOS Flashback (external), Audio 7.1 (Realtek ALC1220 / ASUS SupremeFX), DTS Sound Unbound, Onboard graphics iGPU, RAID level 0/1/10 (B550), Multi-GPU AMD 2-Way-CrossFireX (x16 / x4), Power connections 1x 24-pin ATX, 1x 8-pin EPS12V, 1x 4-pin ATX12V, BIOS 1x 32MB (256Mb), Special features audio + solid capacitors, diagnostic LED (LED indicators), integrated I / O cover, 2x M.2 passive cooler, ECC support, 90MB15J0-M0EAY0

LGA1700 ATX DDR5 Memory slots 4 1xPCI-Express 4.0 4x |2xPCI-Express 5.0 16x 5xM.2 1xHDMI 5xUSB 3.2 1xUSB-C 2xUSB-C w/Thunderbolt 1xOptical S/PDIF 1xRJ45 MAXIMUSZ790DARKHERO

Socket AM4, Chipset AMD B550, 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory, Integrated in the New Generation AMD Ryzen™ with Radeon™ Graphics processors, Audio Realtek® ALC1200 codec, Lan, Intel® Wi-Fi 6 AX200, ATX

DDR5 ATX

LGA1700 ATX DDR5 Memory slots 4 1xPCI-Express 3.0 1x 3xPCI-Express 5.0 16x 4xM.2 1xHDMI 1xDisplayPort 2xUSB 2.0 5xUSB 3.2 1xUSB-C 1xOptical S/PDIF 1xRJ45 5xAudio port

Intel LGA1151 ATX motherboard with four PCIe 3.0 x16 slots, dual M.2 and USB 3.1 Gen2 connectors. Four PCIe 3.0 x16 slots for flexible expandability with graphics, RAID and LAN add-on cards. Powerful performance with Intel®Xeon®E processor and ECC memory. Supports up to three independent displays simultaneously via HDMI, DisplayPort, DVI-D and VGA. Next-gen transfer speeds with up to 32Gbps M.2 and 10Gbps USB 3.1 Type-A and Type-C. Dual Intel® Gigabit LAN with teaming support. SafeSlot PCIe x16 to protect your graphics card investment. ASUS Control Center — A software utility that provides convenient, secure and cost-saving centralized IT management for small and medium businesses

DDR5 EATX

AMD Promontory B450 Max memory size: 32 Max. number of SATA devices: 4 Max. number of ATA devices: 0 Detailed data on disk/drive interfaces: 4 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1 and RAID 10), NCQ, AHCI and Hot Plug1 x Ultra M.2 Socket, supports M Key type 2242/2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4 Graphics: Integrated AMD Radeon Vega Series Graphics in Ryzen Series APU DirectX 12, Pixel Shader 5.0 Shared memory default 2GB. Max Shared memory supports up to 16GB. Three graphics output options: D-Sub, DVI-D and HDMI Supports Triple Monitor Supports HDMI with max. resolution up to 4K x 2K (4096x2160) @ 24Hz / (3840x2160) @ 30Hz Supports DVI-D with max. resolution up to 1920x1200 @ 60Hz Supports D-Sub with max. resolution up to 2048x1536 @ 60Hz Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI Port (Compliant HDMI monitor is required) Supports HDCP 1.4 with DVI-D and HDMI Ports Supports 4K Ultra HD (UHD) playback with HDMI Port Sound card: 7.1 CH HD Audio (Realtek ALC887 Audio Codec) Supports Surge Protection ELNA Audio Caps Network interface: PCIE x1 Gigabit LAN 10/100/1000 Mb/s Realtek RTL8111H Supports Wake-On-LAN Supports Lightning/ESD Protection Supports Energy Efficient Ethernet 802.3az Supports PXE USB ports at back panel: 6 USB ports on motherboard: 6 Number of USB 3.0/USB 3.1 gen 1/USB 3.2 gen 1 ports: 6 Number of USB 3.1/USB 3.1 gen 2/USB 3.2 gen 2 ports: 0 Special functions: Software ASRock A-Tuning ASRock XFast LAN UEFI ASRock Full HD UEFI ASRock Instant Flash ASRock Easy RAID Installer BIOS: 128Mb AMI UEFI Legal BIOS with multilingual GUI support Supports "Plug and Play" ACPI 5.1 compliance wake up events Supports jumperfree SMBIOS 2.3 support DRAM Voltage multi-adjustment Dimensions: 23.0 cm x 20.1 cm Accessories included: Quick Installation Guide Support CD I/O Shield SATA Data Cables x 2 Screws for M.2 Sockets x 2

DDR5 mATX

Socket AM4, ATX form factor, Chipset AMD B550, CPU compatibility Ryzen 4000G, Ryzen 3000, TDP limit: 105W, VRM 14 virtual phases (12 + 2), MOSFETs CPU 12x, SoC 2x MOSFETs, RAM 4x DDR4 DIMM, dual PC4-40800U / DDR4-5100 (OC), max. 128GB (UDIMM), Expansion slots 1x PCIe 4.0 x16, 1x PCIe 3.0 x16 (x4), 3x PCIe 3.0 x1, 1x M.2 / M-Key (PCIe 4.0 x4 / SATA, 22110/2280/2260/2242), 1x M .2 / M-Key (PCIe 3.0 x4 / SATA, 22110/2280/2260/2242), External connections 1x HDMI 2.1, 1x DisplayPort 1.2, 1x USB-C 3.1 (B550), 1x USB-A 3.1 (B550), 4x USB-A 3.0, 2x USB-A 2.0, 1x 2.5GBase-T (Intel I225-V ), 5x jack, 1x Toslink, Internal connections 1x USB 3.0 header (2x USB 3.0), 2x USB 2.0 header (4x USB 2.0), 6x SATA 6Gb / s (B550), 1x Thunderbolt header 13-pin, Header cooling 2x CPU fan 4-pin, 3x fan 4-pin, 1x AIO pump 4-pin, 1x thermal sensor, Header lighting 2x 4-pin RGB (+ 12V / G / R / B, max. 3A), 1x 3-pin ARGB (+ 5V / DATA / GND, max. 3A, ASUS Gen2), Buttons / Switches USB BIOS Flashback (external), Audio 7.1 (Realtek ALC1220 / ASUS SupremeFX), DTS Sound Unbound, Graphics CPU, RAID level 0/1/10 (B550), Multi-GPU AMD 2-Way CrossFireX (x16 / x4), Power connections 1x 24-pin ATX, 1x 8-pin EPS12V, 1x 4-pin ATX12V, RGB lighting, 1 zone (I / O cover), BIOS 1x 32MB (256Mb), Special features audio + solid capacitors, diagnostic LED (LED indicators), integrated I / O panel, 2x M.2 passive cooler

DDR5 ATX Memory slots 4|2xPCI-Express 4.0 1x|1xPCI-Express 4.0 16x|3xM.2|1xHDMI|1xDisplayPort|4xUSB 2.0|3xUSB 3.2|2xUSB-C|1xRJ45|5xAudio port

ATX DDR4 Memory slots 4|2xPCI-Express 3.0 1x|1xPCI-Express 3.0 16x|1xPCI-Express 4.0 16x|2xM.2|1xHDMI|1xDisplayPort|1xUSB 2.0|2xUSB 3.2|1xUSB-C|1xPS/2|1xOptical S/PDIF|1xRJ45|5xAudio port

Gigabyte emaplaat AMD B650 sam5 micro-ATX memory Ddr5 memory Slots 4 1xPSIe 3.0 1x 1xPSIe 4.0 16x 2xm.2 1xhdmi 2xdisplayport 2xusb 2.0 3xusb 3.2 1xusb-c 1xps/2 1xrj45 3xaudio Port b650md3hp

SAM4 | ATX | 2xPCI-Express 3.0 1x | 1xPCI-Express 3.0 4x | 1xPCI-Express 4.0 16x | 2xM.2 | DDR4 Memory slots 4 | 1xHDMI | 2xAudio-In | 1xAudio-Out | 6xUSB 3.2 | 1xPS/2 | 1xRJ45 | SATA | Video Depending on CPU | Audio Realtek ALC1200 | LAN Realtek (Gigabit) | RAID SATA 0, 1, 10 | TPM Header

Socket AM4, Form factor MicroATX, Chipset AMD B550, CPU compatibility Ryzen 4000G, Ryzen 3000, without TDP restriction (manufacturer list), VRM 8 real phases (5 + 3), PWM controller: RAA229004 (max. 8 phases), MOSFETs CPU 5x 46A 4C10N / 10x 4C06N, MOSFETs SoC 3x 46A 4C10N / 4C06N, RAM 4x DDR4 DIMM, dual PC4-37866U / DDR4-4733 (OC), max. 128GB (UDIMM), Expansion slots 1x PCIe 4.0 x16, 1x PCIe 3.0 x16 (x4), 1x PCIe 3.0 x1, 1x M.2 / M-Key (PCIe 4.0 x4 / SATA, 22110/2280/2260/2242), 1x M .2 / M-Key (PCIe 3.0 x2 / SATA, 2280/2260/2242), External connections 1x DVI-D (iGPU), 1x HDMI 2.1 (iGPU), 4x USB-A 3.0, 4x USB-A 2.0, 1x Gb LAN (Realtek RTL8118AS), 3x jack, 1x PS / 2 combo, Internal connections 1x USB 3.0 header (2x USB 3.0), 1x USB 2.0 header (2x USB 2.0), 4x SATA 6Gb / s (B550), 1x serial, 1x TPM header, Header cooling 1x CPU fan 4-pin, 2x fan 4-pin, Header lighting 3x 4-pin RGB (+ 12V / G / R / B, max. 2A), 2x 3-pin ARGB (+ 5V / DATA / GND, max. 5A), Buttons / Switches USB BIOS Flashback / Q-Flash Plus (internal), Audio 7.1 (Realtek ALC887), Onboard graphics iGPU, RAID level 0/1/10 (B550), Power connections 1x 24-pin ATX, 1x 8-pin EPS12V, BIOS 1x 32MB (256Mb), Special features audio + solid capacitors, integrated I / O cover

ATX AM4, 4xDDR4, PCIE 4.0x16/PCIE16x(2x)/3xPCIE1x, HDMI/DVI, 4xSATA3 Raid/2xM.2 slot, INT: 2xUSB2.0/USB3.2, BACK: 2xUSB2.0/4xUSB3.2, 7.1 Sound, GLAN, ATX

Socket AM4, Form factor ATX, Chipset AMD X570, CPU compatibility Ryzen 5000, Ryzen 4000G, Ryzen 3000, Ryzen 3000G, Ryzen 2000, Ryzen 2000G, Athlon 3000G, Athlon 200G, without TDP restriction (manufacturer list), RAM 4x DDR4 DIMM, dual PC4-40800U / DDR4-5100 (OC), max. 128GB (UDIMM), Expansion slots 2x PCIe 4.0 x16 (1x x16, 1x x4), 2x PCIe 4.0 x1, 2x M.2 / M-Key, (PCIe 4.0 x4 / SATA, 22110/2280/2260/2242), 1x M. 2 / E-Key (PCIe, 2230, occupied with WiFi + BT module), External connections 1x HDMI 1.4b (iGPU), 1x DisplayPort 1.2 (iGPU), 1x USB-C 3.1 (X570), 2x USB-A 3.1 (X570), 4x USB-A 3.0, 1x 2.5GBase-T (Intel I225- V), 5x jack, 1x Toslink, 1x PS / 2 combo, Internal connections 1x USB-C 3.1 Key-A header (X570), 1x USB 3.0 header (2x USB 3.0), 2x USB 2.0 header (4x USB 2.0), 8x SATA 6Gb / s (X570), 1x serial, 1x TPM- Header, Header cooling 2x CPU fan 4-pin, 3x fan 4-pin, 1x AIO pump 4-pin, Header lighting 2x 4-pin RGB (+ 12V / G / R / B, max. 3A), 1x 3-pin ARGB (+ 5V / DATA / GND, max. 3A, ASUS Gen2), Buttons / Switches USB BIOS Flashback (external), Audio 7.1 (Realtek ALC1200), DTS Custom Audio, Onboard graphics iGPU, Wireless WLAN 802.11a / b / g / n / ac / ax (2x2, Intel AX200), Bluetooth 5.1, RAID level 0/1/10 (X570), Multi-GPU AMD 2-Way-CrossFireX (x16 / x4), Power connections 1x 24-pin ATX, 1x 8-pin EPS12V, 1x 4-pin ATX12V, RGB lighting, 1 zone (accent right), BIOS 1x 32MB (256Mb), Special features AMD Audio + solid capacitors, Diagnostic LED (LED indicators), 1x M.2 passive cooler, ECC support

ATX Supports 3rd Gen AMD AM4 Ryzen™ / Future AMD Ryzen™ Processors; 14 Power Phase Design, Digi Power, Dr. MOS; Supports DDR4 4733+ (OC); 1 PCIe 4.0 x16, 1 PCIe 3.0 x16, 2 PCIe 3.0 x1, 1 M.2 Key E for WiFi; Graphics Output Options: ...

ATX DDR5 1xHDMI 1xDP 4xSATA 6Gb/s ports

LGA1700 ATX Memory DDR5 Memory slots 4 2xPCI-Express 4.0 16x 1xPCI-Express 5.0 16x 5xM.2 1xHDMI 1xDisplayPort 10xUSB 3.2 2xUSB-C 1xOptical S/PDIF 1xRJ45 5xAudio port STRIXZ790-EGAMWIFIII

ATX DDR4 Memory slots 4 5xPCI-Express 5.0 16x 2xM.2 1xHDMI 1xDisplayPort 4xUSB 2.0 2xUSB 3.2 1xUSB-C 1xPS/2 1xOptical S/PDIF 1xRJ45 5xAudio port

DDR5 mATX

DDR4 Mini-ITX

LGA1151 ATX DDR4

Intel Z690 LGA 1700 ATX DDR4

Intel Z590 LGA 1200 Mini ITX

DDR4 mATX

DDR5 E-ATX

Socket AM4, Form factor MicroATX, chipset AMD B550, CPU compatibility Ryzen 5000, Ryzen 4000G, Ryzen 3000, without TDP restriction (manufacturer list), VRM 6 real phases (4 + 2), PWM controller: RT8894 (max. 6 phases) , MOSFETs CPU 8x 46A 4C029N / 4C024N, MOSFETs SoC 4x 46A 4C029N / 4C024N, RAM 2x DDR4 DIMM, dual PC4-36800U / DDR4-4600 (OC), max. 64GB (UDIMM), Expansion slots 1x PCIe 4.0 x16, 2x PCIe 3.0 x1, 1x M.2 / M-Key (PCIe 4.0 x4 / SATA, 2280/2260/2242), external connections 1x VGA (iGPU), 1x HDMI 2.1 (iGPU ), 1x DisplayPort 1.4 (iGPU), 4x USB-A 3.0, 2x USB-A 2.0, 1x Gb LAN (Realtek RTL8111H), 3x jack, 1x PS / 2 combo, internal connections 1x USB 3.0 header (2x USB 3.0) , 2x USB 2.0 header (4x USB 2.0), 4x SATA 6Gb / s (B550), 1x serial, 1x TPM header, 1x chassis intrusion header, header cooling 1x CPU fan 4-pin, 1x fan 4-pin, Header lighting 1x 4-pin RGB (+ 12V / G / R / B, max. 3A), 1x 3-pin ARGB (+ 5V / DATA / GND, max. 3A), audio 7.1 (Realtek ALC892 ), Onboard graphics iGPU, RAID level 0/1/10 (B550), power connections 1x 24-pin ATX, 1x 8-pin EPS12V, BIOS 1x 32MB (256Mb) Special features audio + solid capacitors, diagnostic LED (LED indicators), 1x M.2 passive cooler

LGA1700 ATX DDR4 Memory slots 4|1xHDMI|1xDisplayPort|1xAudio-In|1xAudio-väljund|4xUSB 2.0

ATX soc.1700, 4xDDR4, PCIE16x 5.0/2xPCIE16x(4x), DP 1.2/HDMI 2.1, 6xSATA3 Raid/4xM.2 PCIe 4.0, 8xUSB2.0/7xUSB3.2/3xUSB-C 3.2, 7.1 Sound, 2.5 GLAN

AMD WRX80 Socket sWRX8 E-ATX
