Emaplaat Sapphire NITRO+ X870EA PhantomLink Polar Edition AMD X870E Protsessoripesa AM5 ATX

The SAPPHIRE NITRO+ X870EA WIFI7 Phantom Link Polar is based on the AMD X870E chipset and supports AMD processors for socket AM5. It has four DDR5 slots for up to 256 GB of memory. The SAPPHIRE NITRO+ The SAPPHIRE NITRO+ Mainboard type Color white/black EAN 4895106297425 Manufacturer no. 52122-11-40G Socket AM5 Max. supported CPUs 1 Operating system support Windows 10 ready, Windows 11 ready Processor Supported Models Ryzen 5 7xxx (Raphael), Ryzen 5 7xxxX (Raphael), Ryzen 5 7xxxF (Raphael), Ryzen 5 7xxxX3D (Raphael), Ryzen 5 8xxxF (Phoenix), Ryzen 5 8xxxG (Phoenix), Ryzen 5 9xxx (Granite Ridge), Ryzen 5 9xxxX (Granite Ridge), Ryzen 5 9xxxF (Granite Ridge), Ryzen 7 7xxx (Raphael), Ryzen 7 7xxxX (Raphael), Ryzen 7 7xxxX3D (Raphael), Ryzen 7 8xxxG (Phoenix), Ryzen 7 8xxxF (Phoenix), Ryzen 7 9xxxX (Granite Ridge), Ryzen 7 9xxxX3D (Granite Ridge), Ryzen 9 7xxx (Raphael), Ryzen 9 7xxxX (Raphael), Ryzen 9 7xxxX3D (Raphael), Ryzen 9 9xxxX (Granite Ridge), Ryzen 9 9xxxX3D (Granite Ridge) Chipset AMD X870E Slots PCIe x16 3x (of which: 1x PCIe x16, 2x PCIe x4) Form factor ATX Use PC Power supply ATX12V (24-pin + 2x 8-pin) Memory maximum 256 GB Memory number of sockets 4x DDR5 Memory supported standards DDR5 8400 - 5600 (OC) MT/s / 5600 - 4800 (JEDEC) MT/s Memory channels 2 Memory Maximum memory ranks 8 Memory memory controller in CPU Yes Memory Maximum data density 8192 Mbit Ports (external) USB-A 3.2 Gen 2 (10 Gbit/s) 4 Ports (external) USB-A 3.2 Gen 1 (5 Gbit/s) 4 Connections (external) USB4 2 Ports (external) Note: The designation USB 3.2 Gen 1 corresponds to the previous designations USB 3.1 Gen 1 or USB 3.0. The designation USB 3.2 Gen 2 corresponds to the previous designations USB 3.1 Gen 2 or USB 3.1. Connections (external) USB-A 2.0 2 Connections (external) HDMI-In 1 Connections (external) Microphone 1 Connections (external) Line-Out 1 Connections (external) S/PDIF-Out (optical) 1 Connections (external) RJ-45 1 Connections (external) Bluetooth Yes Connections (external) WLAN Yes Connectors (internal) SATA 4 Connections (internal) M.2 4 Connections (internal) M.2 module Key M Connectors (internal) M.2 Slot 1 PCIe Gen 5.0 Connectors (internal) M.2 Slot 2 PCIe Gen 5.0 Connectors (internal) M.2 Slot 3 PCIe Gen 4.0 Connectors (internal) M.2 Slot 4 PCIe Gen 4.0 Connections (internal) Note: The actual usable speed of your M.2 SSDs depends on the combination of CPU, mainboard slot and chipset. Connectors (internal) M.2 interface PCIe Connections (internal) M.2 length 80 - 80 mm Ports (optional) USB 3.2 Gen 1 (5 Gbit/s) 2 Ports (optional) USB-C 3.2 Gen 2x2 (20 Gbit/s 1 Ports (optional) USB 2.0 4 Connections (optional) TPM Yes RGB Standard Mystic Light SATA controller AMD X870E USB controller AMD X870E Onboard graphics The graphics connections on the mainboard can only be used when using a CPU with an integrated graphics chip. Sound Realtek ALC897 Codec LAN Realtek 8126 5G LAN Wi-Fi 7, Bluetooth 5.4 Features 2x USB4 DisplayPort Alt mode Video outputs & 15W Power Delivery Further information In order to support the latest processor cores, a BIOS update may be required. Dimensions Width: 244mm x Height: 305mm
