EK-Quantum Vector Master RX 6800XT/6900XT - Nickel + Acetal is a 2nd generation Vector GPU water block from the EK® Quantum Line. It is made for AORUS Master 6800XT and 6900XT graphics cards based on the latest AMD® RDNA2™ architecture. EK-Quantum Vector Master RX 6800XT/6900XT water block for AORUS Master RX 6800 XT and 6900 XT GPUs EK-Quantum Vector Master RX 6800XT/6900XT water block is compatible with AORUS Master Radeon RX 6800XT, and 6900XT graphics cards. The Vector water block directly cools the GPU, VRAM, and the VRM (voltage regulation module) as a cooling liquid is channeled right over these critical areas. The water block is in contact with power stages as well as Inductor chokes to maximize cooling and minimize the chances of coil whine. These newly developed water blocks feature optimized flow paths that reduce hydrodynamic instabilities and vortexing (dead spots) inside of them. The EK-Quantum Vector Series water blocks use an Open Split-Flow cooling engine design, which proved to be a superior solution for GPU water blocks. It is characterized by low hydraulic flow restriction, meaning it can be used with weaker water pumps or pumps running on low-speed settings, and still achieve top performance. The jet plate and fin structure geometry have been optimized to provide even flow distribution with minimal losses and optimal performance when used in any given coolant flow orientation. The base of the block is CNC-machined out of high-grade nickel-plated electrolytic copper, while its top is CNC-machined out of stealthy black POM Acetal. These 2nd generation Vector GPU water blocks also feature acetal terminals. The watertight sealing is ensured by high-quality EPDM O-rings, while brass standoffs are already pre-installed and allow for a safe and easy installation procedure. D-RGB lighting on EK-Quantum Master Vector RX 6800XT/6900XT D-RGB water block The aesthetic end-piece is housing the addressable D-RGB LED strip. These water blocks boast a total of 7 individually addressable RGB LEDs, and a LED-lit terminal. They are compatible with popular RGB sync technologies from all major motherboard manufacturers. The arrow marking on the 3-pin D-RGB LED connector is to be aligned with the +5V marking on the D-RGB (addressable) header. Backplate for the Master 6800XT/6900XT water block EK recommends the purchase of a retention backplate, which improves the overall aesthetics of your graphics cards, and also provides additional passive cooling for the GPU core and backside of the printed circuit board VRM and VRAM sections. Technical Specification Dimensions: (LxHxW) - 303,5x135,5x16,5mm Enclosed EK-Quantum Vector Master RX 6800XT/6900XT series high-performance water block Mounting mechanism with screw-in brass standoffs Necessary mounting screws, nuts, and washers 2x Nickel plated brass plug G1/4” EK-Loop Multi Allen Key (6mm, 8mm, 9mm) Thermal pads Thermal grease EK-TIM Ectotherm (1g)

EK-Quantum Vector TUF RX 6800/6900 is a 2nd generation Vector GPU water block from the EK® Quantum Line. It is made for ASUS TUF RX 6800, 6800XT, 6900XT graphics cards based on the latest AMD® RDNA2™ architecture. EK-Quantum Vector TUF RX 6800/6900 water block for ASUS TUF GAMING RX 6800 and 6900 GPUs EK-Quantum Vector RX 6800/6900 water block is compatible with ASUS TUF GAMING Radeon RX 6800, RX 6800XT, and 6900XT graphics cards. The Vector water block directly cools the GPU, VRAM, and the VRM (voltage regulation module) as a cooling liquid is channeled right over these critical areas. The water block is in contact with power stages as well as Inductor chokes to maximize cooling and minimize the chances of coil whine. These newly developed water blocks feature optimized flow paths that reduce hydrodynamic instabilities and vortexing (dead spots) inside of them. The EK-Quantum Vector Series water blocks use an Open Split-Flow cooling engine design, which proved to be a superior solution for GPU water blocks. It is characterized by low hydraulic flow restriction, meaning it can be used with weaker water pumps or pumps running on low-speed settings, and still achieve top performance. The jet plate and fin structure geometry have been optimized to provide even flow distribution with minimal losses and optimal performance when used in any given coolant flow orientation. The base of the block is CNC-machined out of high-grade nickel-plated electrolytic copper, while its top is CNC-machined out of durable POM acetal. These 2nd generation Vector GPU water blocks also feature acetal terminals. The watertight sealing is ensured by high-quality EPDM O-rings, while brass standoffs are already pre-installed and allow for a safe and easy installation procedure. D-RGB lighting on EK-Quantum TUF Vector RX 6800/6900 D-RGB water block The aesthetic end-piece is housing the addressable D-RGB LED strip. These water blocks boast a total of 9 individually addressable RGB LEDs, and a LED-lit terminal. They are compatible with popular RGB sync technologies from all major motherboard manufacturers. The arrow marking on the 3-pin D-RGB LED connector is to be aligned with the +5V marking on the D-RGB (addressable) header. Backplate for the TUF 6800/6900 water block EK recommends the purchase of a retention backplate, which improves the overall aesthetics of your graphics cards, and also provides additional passive cooling for the GPU core and backside of the printed circuit board VRM and VRAM sections. Technical Specification Dimensions: (LxHxW) - 300x158x16.5mm Enclosed EK-Quantum Vector TUF RX 6800/6900 series high-performance water block Mounting mechanism with screw-in brass standoffs Necessary mounting screws, nuts, and washers 2x Nickel plated brass plug G1/4” EK-Loop Multi Allen Key (6mm, 8mm, 9mm) Thermal pads Thermal grease EK-TIM Ectotherm (1g)

The new generation of Alphacool GPU coolers has arrived! The Alphacool Eisblock Aurora Plexi GPX combines outstanding performance with breath-taking aesthetics. What has changed? This is where Alphacool's 16 years of experience pays off! The already powerful Eisblocks have been further optimized: A new look, thinner thermal pads (1mm), a thinner copper block (5.5mm) and a significantly improved flow rate are just some of the important changes. And the design? This time Alphacool puts the lighting more in the foreground! Along the entire cooling block there are addressable digital RGB LEDs, so that no corner of your case remains in the dark. The more angular design compared to its predecessors further enhances this effect. What else? There have been no compromises with the materials and the cooling block is still 100% copper. Now however, the nickel-plating of the cooler has been further optimised. This increases acid resistance and almost eliminates the risk of chipping the nickel-plating. A further highlight is the use of the patented Alphacool stop plugs: These sit flush with the surface of the cooler and form a flat surface when screwed in. No more annoying protruding stop fittings! Finally, the branding of the Eisblock has been adapted. It is now much more discreet and fits perfectly into the already elegant appearance. With this product Alphacool has once again proven its technical know-how! Check it out for yourself and let your system shine in a new light! Technical Details: W x T x H: 144 x 269,5 x 25 mm Max Working Temperature: 60 °C Material Cooler: Nickel-Plated Copper Material Top: Plexiglass Threads: 4x G1/4“ Power Supply Digital RGB: 3-Pin 5V (0,5A) Pressure Tested: 1,5 bar Compatibility: ASRock Radeon RX 5700 XT TAICHI X 8G OC+, 8GB GDDR6, 2x HDMI, 4x DisplayPort Graphics Card Configurator: Click here! List of Compatibility: AMD Cooler PDF Manual: Eisblock Aurora Plexi GPX-A AMD Radeon RX 5700 XT Asrock Taichi X8 8G OC PDF Data Sheet: Eisblock Aurora Plexi GPX-A AMD Radeon RX 5700 XT Asrock Taichi X8 8G OC

MechanicalDimensionsDevice: 600 x 720 x 650 mm (23.6 x 28.3 x 25.6")With packaging: 900 x 900 x 940 mm (35.4 x 35.4 x 37")WeightDevice: 38 kg (84 lb)With packaging: 51.5 kg (113.5 lb)Enclosure materialSheet metalColorWhiteTreatmentPowder coatingRack FeaturesU height12URack type4 post, enclosed cabinetAdjustable mounting depthDefault 452 mm (17.8")Max. 532 mm (20.9")Min. 72 mm (2.8")Max. weight capacity100 kg (220 lb)Front doorTempered glassRear doorMetalSide panelsRemovableMountingWall mountFan moduleYes (pre-installed)Thermal sensor switchSensor OFF (Switch Pop-Up)The fan module operates continuously when the power cable is connected.Sensor ON (Switch Drop-Down)The fan module activates automatically when the internal cabinet temperature exceeds 35°C.Grounding lugsYes (pre-installed)Security(1) front door lock(1) rear door lock(2) side panel locks(3) keysStandardCE; EIA/ECA-310-E; RoHS

MechanicalDimensionsWithout caster: 600 x 1,000 x 2,000 mm (23.6 x 39.8 x 78.7")With caster: 600 x 1,000 x 2,135 mm (23.6 x 39.8 x 84")With packaging: 850 x 1,200 x 2,320 mm (33.5 x 47.2 x 91.3")WeightDevice: 164 kg (361 lb)With packaging: 209 kg (460 lb)Enclosure materialSheet metalColorWhiteTreatmentPowder coatingRack FeaturesU height42URack type4 post, enclosed cabinetAdjustable mounting depthDefault 658 mm (25.9")Max. 838 mm (33")Min. 138 mm (5.4")Max. weight capacityStatic 1,500 kg (3,307 lb)Rolling 1,000 kg (2,200 lb)Front doorTempered glassRear doorPerforatedSide panelsRemovableMountingFloor standLockable castersYes (pre-installed)Leveling standsYes (pre-installed)Fan moduleYes (pre-installed)Thermal sensor switchSensor OFF (Switch Pop-Up)The fan module operates continuously when the power cable is connected.Sensor ON (Switch Drop-Down)The fan module activates automatically when the internal cabinet temperature exceeds 35°C.Grounding lugsYes (pre-installed)Security(1) front door lock(1) rear door lock(3) keysStandardCE; EIA/ECA-310-E; RoHS

MechanicalDimensionsDevice: 600 x 560 x 650 mm (23.6 x 22 x 25.6")With packaging: 900 x 730 x 940 mm (35.4 x 28.7 x 37")WeightDevice: 32 kg (71 lb)With packaging: 42.5 kg (94 lb)Enclosure materialSheet metalColorWhiteTreatmentPowder coatingRack FeaturesU height12URack type4 post, enclosed cabinetAdjustable mounting depthDefault 446 mm (17.6")Max. 469 mm (18.5")Min. 78 mm (3.1")Max. weight capacity100 kg (220 lb)Front doorTempered glassRear doorNoSide panelsRemovableMountingWall mountFan moduleYes (pre-installed)Thermal sensor switchSensor OFF (Switch Pop-Up)The fan module operates continuously when the power cable is connected.Sensor ON (Switch Drop-Down)The fan module activates automatically when the internal cabinet temperature exceeds 35°C.Grounding lugsYes (pre-installed)Security(1) front door lock(2) side panel locks(3) keysStandardCE; EIA/ECA-310-E; RoHS

The Alphacool Aurora Acryl GPX-A 6800(XT) Eisblock combines style with performance and extensive digital RGB lighting. With experience of over 16 years, Alphacool the ability to create GPU blocks that represent high quality and fantastic performance. This perfectly describes the Aurora Acryl GPX Eisblock More Performance! During the development of the EIsblock Aurora GPX-A 6800(XT) graphic card GPU block, we wanted to further increase the performance. The first step was to move the cooler closer to the individual components by reducing the thermal pads to a thickness of 1 mm. Next, we reduced the thickness of the nickel-plated copper block. Instead of 7 mm, it is now only 5.5 mm thick. The water flow inside the cooler has also been optimized. All important components such as the voltage transformers and the memory are now significantly better and more effectively cooled by the water. All this ensures a significant increase in cooling performance. New Design! The Eisblock Aurora GPX-A 6800(XT) cooler has been designed so that lighting is more important than the previous models. The addressable digital RGB LEDs are embedded directly into the cooling block and run along the entire cooling block. The effect is an illumination of the entire cooling block. No corner or edge remains unlit by the aRGB LEDs. The new design is more angular with all edges bevelled. This promotes better light diffusion in the water cooler due to the reflections on these bevels. In addition, they create various contours, which give the Aurora GPX-A 6800(XT) Eisblock cooler its very own unique identity. Copper or Aluminium? Of course, Alphacool only uses copper for its water coolers. With the Aurora GPX-A 6800(XT) Eisblock, the copper is nickel-plated. Compared to its predecessor models, Alphacool has improved the nickel plating even further, which has considerably increased the acid resistance. This means that the nickel should resist flaking. Why does Alphacool rely on copper instead of aluminium? Simply, copper has almost twice the thermal conductivity of aluminium and is therefore clearly the better material for water cooling. Is There Anything Else New? The Eisblock Aurora GPX-A 6800(XT) also relies on the new patented stop fittings, which sit flush with the surface of the terminal. The Alphacool logo now sits in the corner on the top and is also fully illuminated. On the front of the terminal you can see the corresponding names of the compatible graphic card types. Of course, these are also fully illuminated by the digital LEDs. IN and OUT are now marked by small triangles. They are easily recognizable and fit perfectly into the entire aesthetics of the graphic card water cooler. The Alphacool Aurora GPX-A 6800(XT) Acryl is a complete redevelopment of the previous Alphacool graphics card water coolers. No technical compromises were made, but the entire technical know-how flowed into the development and implementation. Note: - This article is delivered with a backplate Technical data: L x W x B: 130 x 262,5 x 24,5 mm Material cooler: Nickle plated copper Material top: Acryl Thickness cooling fins: 0,6 mm Threads: 4x G1/4“ Power connector Digital RGB: 3-Pin 5V (0,5A) Graphics Card Configurator: Click here! List of Compatibility: AMD graphic cards Compatibility list: - AMD Radeon 6800 Reference Design - AMD Radeon 6800 XT Reference Design - AMD Radeon 6900 XT Reference Design - AMD Radeon 6950 XT Reference Design More compatible models will follow in this list for this cooler. We are currently checking other PCB designs from various manufacturers! Download manual PDF: Alphacool Eisblock Aurora Acryl GPX-A Radeon RX 6800/6800XT/6900XT Reference with Backplate Download data sheet PDF: Alphacool Eisblock Aurora Acryl GPX-A Radeon RX 6800/6800XT/6900XT Reference with Backplate

Alphacool's Core product series is characterized by high quality, outstanding performance, and a consistent, functional design language.The copper cooler, as well as the end terminal, is milled from a single piece of copper and forms the core of this cooler. The precise workmanship, together with the hard and durable chrome plating that covers the entire copper cooler, meets the highest quality standards. The chrome-plated brass G1/4" threads integrated on both sides are visually distinct from the terminal and represent a central element of the new design language featured throughout the Core series.The aluminum backplate, designed to match, together with the terminal, forms the complete unit and enhances the back of the cooler with a clean and unified look. The lighting features digitally addressable RGB LEDs that evenly and effectively illuminate the entire cooler.Technical innovations are evident in the water delivery to the jet plate as well as the optimization of the jet plate itself. The jet plate has been entirely redesigned based on numerous simulations and practical tests in cooperation with board partners. The fin thickness and spacing have been improved, the cooling surface has been increased, and water flow to the core components with the highest heat generation has been optimized. The included special soft thermal pads, with up to 7 W/mK, adapt perfectly even to the smallest tolerances. Compatibility:- AMD Radeon RX 7900 XTX, 24GB GDDR6- ASRock Radeon RX 7900 XTX, 24GB GDDR6- Asus Radeon RX 7900 XTX, RX7900XTX-24G, 24GB GDDR6 (90YV0IT0-U0NM00)- Biostar Radeon RX 7900 XTX, 24GB GDDR6 (VA7906AEF4)- Gigabyte Radeon RX 7900 XTX 24G, 24GB GDDR6 (GV-R79XTX-24GC-B)- PowerColor Radeon RX 7900 XTX, 24GB GDDR6 (RX 7900 XTX 24G)- XFX Radeon RX 7900 XTX, 24GB GDDR6 (RX-79XMBABF9) Technical data coolerDimensions (L x W x H)269 x 135 x 32.15mmMaterial coolerchrome-plated copperMaterial cooler topacrylicMax working temperature60°CPressure tested0.8 barThreads4 x G1/4"Thickness cooler bottom11.3mmThickness cooling fins0.4mmDistance cooling fins0.4mmIlluminationdigital aRGB LEDsPower connector digital aRGB LEDs3-Pin JSTPower digital aRGB LEDs5VNumber of digital aRGB LEDs15ColortransparentTechnical data backplateDimensions (L x W x H)269 x 221 x 5mmMaterialaluminiumColorblackWarranty: 3 years???? Warranty Terms

The Arctic thermal pads are ideal for efficiently exchanging heat between different components. Thanks to the high quality of workmanship and excellent thermal conductivity, the pads are used in many places on computers and electronic components.The thermal pad, which is based on silicone and a special filler, far outperforms generic and performance-oriented pads.In a test by PC Games Hardware (11/2018), the "excellent processability and reusability in every respect" was praised. In combination with the fair price and good performance, our thermal pad was recommended as a "price-performance tip".Thanks to its low hardness and good compression properties, the thermal pad acts as a perfect gap filler and easily bridges uneven surfaces and air gaps.The ARCTIC Thermal Pads are non-adhesive and can therefore be placed precisely. Installation is child's play and therefore perfect for beginners.The pad contains no metal particles, is electrically insulating and not capacitive. Handling is therefore safe since contact with electrical parts does not lead to damage. Technical specifications:Dimensions 145 x 145 mmContents 1 pieceThickness 0.5 mmThermal conductivity 6.0 W / mKHardness 25 shore 00Relative density 3.2 g / cm³colour blueOperating temperature -40 ~ 200 ℃Volume resistance 1 X 1012 Ω-cmInterruption voltage 12 KV / mmDraw resistance 2.5 Kgf / cm²Elongation 45%Dielectric constant14.1816 ε at 60 Hz13.0264 ε at 1K Hz13.0264 ε at 1M HzFlammability V-0

The Alphacool Eisblock Aurora Acrylic GPX graphics card water cooler with backplate combines style with performance. Extreme cooling performance and an extensive digital RGB lighting characterize it. Experience and technical know-how from more than a decade have gone into the development, without making any technical compromises. The Eisblock Aurora Acryl GPX is a significant evolution of the previous Alphacool graphics card water cooler, which has been improved in every area. More performance! During the development of the Eisblock Aurora Acryl GPX graphics card water cooler, emphasis was naturally placed on increasing performance. First, the cooler was brought closer to the individual components by reducing the thickness of the heat conducting pads. Next, the nickel-plated copper block was also made thinner. Step 3 involves the constant optimisation of the water flow within the cooler. The result: All important components such as voltage converters and RAM are cooled much better and more effectively by the water and the cooling performance increases significantly. Brilliant design! The addressable digital aRGB LEDs are embedded directly in the cooling block and run along the sides of the entire cooler. The effect is an illumination that engulfs the entire cooling block. No corner or edge is left unlit by the aRGB LEDs. The new design is more angular, with all edges bevelled. The result is better light diffusion in the water cooler due to the reflections on these bevels. They also create various contours that give the Eisblock Aurora Acryl GPX cooler its very own visual touch. Copper or aluminium? Alphacool only uses copper in its water coolers. In the case of the Eisblock Aurora Acryl GPX, the copper is nickel-plated. Compared to the previous models, however, Alphacool has once again improved the type of nickel plating, which has significantly increased the acid resistance. This should prevent the nickel plating from flaking off. Why does Alphacool use copper instead of aluminium? Copper has almost twice the thermal conductivity of aluminium and is therefore clearly the better material for water cooling. Other special features The Eisblock Aurora Acryl GPX GPU cooler has the patented screw plugs, which sit flush with the surface of the terminal. The Alphacool logo sits in the corner on the top and is also fully illuminated. On the front of the terminal, corresponding designations of the compatible graphics card manufacturers can be seen. Of course, these are also fully illuminated by the adressable digital LEDs. IN and OUT are marked by small discreet triangles. They are easily recognisable and fit perfectly into the overall visual line of the graphics card water cooler. Compatibility: - NVIDIA GeForce RTX 3070 Ti Founders Edition, 8GB GDDR6X, HDMI, 3x DP Technical data cooler L x W x H 187,97 x 123,09 x 33,95 mm Material cooler Nickle-plated copper Material cooler top acrylic Threads 4 x G1/4 Thickness cooling fins 0,6 mm Illumination digital aRGB LEDs Power connector digital aRGB LEDs 3-Pin JST Power digital aRGB LEDs 5V Number of digital aRGB LEDs 11 Technical data backplate L x W x H 187,97 x 98,59 x 6 mm Material aluminium Color black

ASUS Prime Radeon™ RX 9070 XT OC Edition 16GB GDDR6 Experience Primal performance with the Prime Radeon™ RX 9070 XT graphics card featuring a compact 2.5-slot design for expansive compatibility, enhanced by a phase-change GPU thermal pad and a triple-fan setup for supreme cooling.

self-adhesive thermal pad for HDDs Dimendions ca.: 100 x 150 x 0,25mm

This thermally conductive pad is ideally suited to be used with the kryoM.2 Adapter board (between adapter board and M.2 SSD module). It is made from soft, silicone based material. Technical Details Dimensions: ca. 70 x 20 x 1.8 mm Maximum gap to be filled: 1.8 mm Not electrically conductive Scope of delivery One thermally conductive pad

Pads included: 1mm 1x 8x115mm 2x 15x51mm 1x 15x15mm 1x 15x42mm 3x 8x100mm 1x 8x15mm 2x 8x110mm 4x 8x8mm 2mm 2x 8x84mm 3mm 1x 45x45mm (hole in the middle) 2x 15x51mm 1x 15x40mm 1x 15x15mm 1x 8x115mm 4x 8x100mm 1x 8x20mm 1x 8x40mm

The Alphacool Aurora Acryl GPX-N RTX 3070 Eisblock combines style with performance and extensive digital RGB lighting. With experience of over 16 years, Alphacool the ability to create GPU blocks that represent high quality and fantastic performance. This perfectly describes the Aurora Acryl GPX Eisblock More Performance! During the development of the EIsblock Aurora GPX-N RTX 3070 graphic card GPU block, we wanted to further increase the performance. The first step was to move the cooler closer to the individual components by reducing the thermal pads to a thickness of 1 mm. Next, we reduced the thickness of the nickel-plated copper block. Instead of 7 mm, it is now only 5.5 mm thick. The water flow inside the cooler has also been optimized. All important components such as the voltage transformers and the memory are now significantly better and more effectively cooled by the water. All this ensures a significant increase in cooling performance. New Design! The Eisblock Aurora GPX-N RTX 3070 cooler has been designed so that lighting is more important than the previous models. The addressable digital RGB LEDs are embedded directly into the cooling block and run along the entire cooling block. The effect is an illumination of the entire cooling block. No corner or edge remains unlit by the aRGB LEDs. The new design is more angular with all edges bevelled. This promotes better light diffusion in the water cooler due to the reflections on these bevels. In addition, they create various contours, which give the Aurora GPX-N RTX 3070 Eisblock cooler its very own unique identity. Copper or Aluminium? Of course, Alphacool only uses copper for its water coolers. With the Aurora GPX-N RTX 3070 Eisblock, the copper is nickel-plated. Compared to its predecessor models, Alphacool has improved the nickel plating even further, which has considerably increased the acid resistance. This means that the nickel should resist flaking. Why does Alphacool rely on copper instead of aluminium? Simply, copper has almost twice the thermal conductivity of aluminium and is therefore clearly the better material for water cooling. Is There Anything Else New? The Eisblock Aurora GPX-N RTX 3070 also relies on the new patented stop fittings, which sit flush with the surface of the terminal. The Alphacool logo now sits in the corner on the top and is also fully illuminated. On the front of the terminal you can see the corresponding names of the compatible graphic card types. Of course, these are also fully illuminated by the digital LEDs. IN and OUT are now marked by small triangles. They are easily recognizable and fit perfectly into the entire aesthetics of the graphic card water cooler. The Alphacool Aurora GPX-N RTX 3070 Acryl is a complete redevelopment of the previous Alphacool graphics card water coolers. No technical compromises were made, but the entire technical know-how flowed into the development and implementation. Technical data: L x W x H:128 x 185 x 24,5 mm Material cooler: Nickle-plated copper Material cooler top: Acryl Threads: 4 x G1/4“ Thickness cooling fins: 0,6 mm Illumination: Digital RGB LEDs Power connector Digital RGB LEDs: 3-Pin JST Power Digital RGB LEDs: 5V Graphics Card Configurator: Click here! List of Compatibility: Nvidia graphic cards Compatibility : - Zotac Gaming GeForce RTX 3070 Twin Edge OC, 8GB GDDR6, HDMI, 3x DP (ZT-A30700H-10P) - Zotac Gaming GeForce RTX 3070 Twin Edge, 8GB GDDR6, HDMI, 3x DP (ZT-A30700E-10P) Download data sheet PDF: Alphacool Eisblock Aurora Acryl GPX-N RTX 3070 Gaming Twin Edge with Backplate Download manual PDF: Alphacool Eisblock Aurora Acryl GPX-N RTX 3070 Gaming Twin Edge with Backplate

The Alphacool Eisblock Aurora Acrylic GPX graphics card water cooler with backplate combines style with performance. Extreme cooling performance and an extensive digital RGB lighting characterize it. Experience and technical know-how from more than a decade have gone into the development, without making any technical compromises. The Eisblock Aurora Acryl GPX is a significant evolution of the previous Alphacool graphics card water cooler, which has been improved in every area. More performance! During the development of the Eisblock Aurora Acryl GPX graphics card water cooler, emphasis was naturally placed on increasing performance. First, the cooler was brought closer to the individual components by reducing the thickness of the heat conducting pads. Next, the nickel-plated copper block was also made thinner. Step 3 involves the constant optimisation of the water flow within the cooler. The result: All important components such as voltage converters and RAM are cooled much better and more effectively by the water and the cooling performance increases significantly. Brilliant design! The addressable digital aRGB LEDs are embedded directly in the cooling block and run along the sides of the entire cooler. The effect is an illumination that engulfs the entire cooling block. No corner or edge is left unlit by the aRGB LEDs. The new design is more angular, with all edges bevelled. The result is better light diffusion in the water cooler due to the reflections on these bevels. They also create various contours that give the Eisblock Aurora Acryl GPX cooler its very own visual touch. Copper or aluminium? Alphacool only uses copper in its water coolers. In the case of the Eisblock Aurora Acryl GPX, the copper is nickel-plated. Compared to the previous models, however, Alphacool has once again improved the type of nickel plating, which has significantly increased the acid resistance. This should prevent the nickel plating from flaking off. Why does Alphacool use copper instead of aluminium? Copper has almost twice the thermal conductivity of aluminium and is therefore clearly the better material for water cooling. Other special features The Eisblock Aurora Acryl GPX GPU cooler has the patented screw plugs, which sit flush with the surface of the terminal. The Alphacool logo sits in the corner on the top and is also fully illuminated. On the front of the terminal, corresponding designations of the compatible graphics card manufacturers can be seen. Of course, these are also fully illuminated by the adressable digital LEDs. IN and OUT are marked by small discreet triangles. They are easily recognisable and fit perfectly into the overall visual line of the graphics card water cooler.Compatibility:- NVIDIA GeForce RTX 3070 Ti Founders Edition, 8GB GDDR6X, HDMI, 3x DP Technical data cooler L x W x H 187,97 x 123,09 x 33,95 mm Material cooler Nickle-plated copper Material cooler top acrylic Threads 4 x G1/4 Thickness cooling fins 0,6 mm Illumination digital aRGB LEDs Power connector digital aRGB LEDs 3-Pin JST Power digital aRGB LEDs 5V Number of digital aRGB LEDs 11 Technical data backplate L x W x H 187,97 x 98,59 x 6 mm Material aluminium Color black

The Alphacool Eisblock Aurora Acrylic GPX graphics card water cooler with backplate combines style with performance. Extreme cooling performance and an extensive digital RGB lighting characterize it. Experience and technical know-how from more than a decade have gone into the development, without making any technical compromises. The Eisblock Aurora Acryl GPX is a significant evolution of the previous Alphacool graphics card water cooler, which has been improved in every area. More performance! During the development of the Eisblock Aurora Acryl GPX graphics card water cooler, emphasis was naturally placed on increasing performance. First, the cooler was brought closer to the individual components by reducing the thickness of the heat conducting pads. Next, the nickel-plated copper block was also made thinner. Step 3 involves the constant optimisation of the water flow within the cooler. The result: All important components such as voltage converters and RAM are cooled much better and more effectively by the water and the cooling performance increases significantly. Brilliant design! The addressable digital RGB LEDs are embedded directly in the cooling block and run along the sides of the entire cooler. The effect is an illumination that engulfs the entire cooling block. No corner or edge is left unlit by the aRGB LEDs. The new design is more angular, with all edges bevelled. The result is better light diffusion in the water cooler due to the reflections on these bevels. They also create various contours that give the Eisblock Aurora Acryl GPX cooler its very own visual touch. Copper or aluminium? Alphacool only uses copper in its water coolers. In the case of the Eisblock Aurora Acryl GPX, the copper is nickel-plated. Compared to the previous models, however, Alphacool has once again improved the type of nickel plating, which has significantly increased the acid resistance. This should prevent the nickel plating from flaking off. Why does Alphacool use copper instead of aluminium? Copper has almost twice the thermal conductivity of aluminium and is therefore clearly the better material for water cooling. Other special features The Eisblock Aurora Acryl GPX GPU cooler has the patented screw plugs, which sit flush with the surface of the terminal. The Alphacool logo sits in the corner on the top and is also fully illuminated. On the front of the terminal, corresponding designations of the compatible graphics card manufacturers can be seen. Of course, these are also fully illuminated by the digital LEDs. IN and OUT are marked by small discreet triangles. They are easily recognisable and fit perfectly into the overall visual line of the graphics card water cooler. Technical data cooler L x W x H 184,58 x 127,1 x 23,55 mm Material cooler Nickle-plated copper Material cooler top acrylic Threads 4 x G1/4 Thickness cooling fins 0,6 mm Illumination digital RGB LEDs Power connector digital RGB LEDs 3-Pin JST Power digital RGB LEDs 5V Technical data backplate L x W x H 184,58 x 102,6 x 6 mm Material aluminium Color black Compatibility: Zotac Gaming GeForce RTX 3070 Ti AMP Holo (ZT-A30710F-10P) Zotac Gaming GeForce RTX 3070 Ti Trinity OC (ZT-A30710J-10P) Zotac Gaming GeForce RTX 3070 Ti Trinity (ZT-A30710D-10P)

The Alphacool Eisblock Aurora Acrylic GPX graphics card water cooler with backplate combines style with performance. Extreme cooling performance and an extensive digital RGB lighting characterize it. Experience and technical know-how from more than a decade have gone into the development, without making any technical compromises. The Eisblock Aurora Acryl GPX is a significant evolution of the previous Alphacool graphics card water cooler, which has been improved in every area. More performance! During the development of the Eisblock Aurora Acryl GPX graphics card water cooler, emphasis was naturally placed on increasing performance. First, the cooler was brought closer to the individual components by reducing the thickness of the heat conducting pads. Next, the nickel-plated copper block was also made thinner. Step 3 involves the constant optimisation of the water flow within the cooler. The result: All important components such as voltage converters and RAM are cooled much better and more effectively by the water and the cooling performance increases significantly. Brilliant design! The addressable digital aRGB LEDs are embedded directly in the cooling block and run along the sides of the entire cooler. The effect is an illumination that engulfs the entire cooling block. No corner or edge is left unlit by the aRGB LEDs. The new design is more angular, with all edges bevelled. The result is better light diffusion in the water cooler due to the reflections on these bevels. They also create various contours that give the Eisblock Aurora Acryl GPX cooler its very own visual touch. Copper or aluminium? Alphacool uses only copper for all water-bearing parts. Copper has almost twice the thermal conductivity of aluminum and is therefore clearly the better choice of material for water cooling. The nickel-plated copper base is highly resistant to acid, which means that chipping of the nickel plating can be ruled out. Other special features The Eisblock Aurora Acryl GPX GPU cooler has the patented screw plugs, which sit flush with the surface of the terminal. The Alphacool logo sits in the corner on the top and is also fully illuminated. On the front of the terminal, corresponding designations of the compatible graphics card manufacturers can be seen. Of course, these are also fully illuminated by the adressable digital LEDs. IN and OUT are marked by small discreet triangles. They are easily recognisable and fit perfectly into the overall visual line of the graphics card water cooler. Technical data cooler L x W x H 267 x 127,74 x 23mm Material cooler Nickle-plated copper Material cooler top acrylic Threads 4 x G1/4 Thickness cooling fins 0,6 mm Illumination digital aRGB LEDs Power connector digital aRGB LEDs 3-Pin JST Power digital aRGB LEDs 5V Number of digital aRGB LEDs 13 Technical data backplate L x W x H 267 x 127,74 x 6mm Material aluminium Color black Compatibility: - GeForce RTX™ 3090 Ti ROG Strix LC 24GB (90YV0HC2-M0NA00) - GeForce RTX™ 3090 Ti ROG Strix LC OC Edition 24GB (90YV0HC0-M0NA00) - GeForce RTX™ 3090 Ti TUF Gaming 24GB (90YV0HC3-M0NA00) - GeForce RTX™ 3090 Ti TUF Gaming OC 24GB (90YV0HC1-M0NA00)

Orico NVME M.2, 10gbps, USB-A to USB-A/C drive enclosure (gray) The Orico NVME M.2 drive enclosure is the ideal solution for those who value high performance and speed. With transmission speeds of up to 10 Gbps, it allows you to transfer large files in seconds, making it extremely efficient for everyday use. Support for large capacities of up to 8TB makes it the perfect tool for professionals in need of reliable and fast data storage.Innovative cooling and easy installation The Orico enclosure is equipped with an advanced cooling system that includes a thermal pad and cooling vest for fast and efficient heat dissipation. This ensures that the device stays cool even during intensive use, increasing its longevity and reliability. Tool-free installation and plug-and-play functionality make hardware installation fast, simple and convenient.Wide compatibility and mobilityWith a built-in 2-in-1 data cable, the Orico NVME M.2 enclosure is compatible with a wide range of devices, such as tablets, smartphones, PCs, PS4s and NAS network drives. It supports a variety of operating systems, including Mac OS, Windows, Linux and Android, and is compatible with SSDs in 2280, 2260, 2242 and 2230 formats. With a small, lightweight and portable design, the enclosure weighs as much as a pair of headphones, making it ideal for those in need of mobility and convenience. Manufacturer Orico Model NVME M.2 Color black Material Aluminum, ABS Output USB 3.2 Gen2 Type-C Estimated data transfer speed 10Gbps Data cable D/A to C 2-in-1

The Alphacool Eisblock ES Acetal GPX-N RTX 3080/3090 Turbo was specially developed for the Alphacool Enterprise series. The full-cover cooler with aluminium backplate cools the GPU and all important components such as voltage converters and the graphics memory directly with water. Connections to the top? Server cases offer different dimensions than normal PC cases. To save space in width and height, the connections were moved to the top. Another advantage is that it is easier to connect the tubing of a complete server rack with this kind of positioning of the connections. This means that even quick-release fasteners with G1/4" external thread can be screwed directly to the graphics card as already offered by Alphacool. More performance! During the development of the Eisblock ES Acetal GPX-N RTX 3080/3090 Turbo graphics card waterblock, we naturally placed great emphasis on increasing performance. For the first step, the cooler was brought closer to the individual components by reducing the thermal pads to a thickness of 1 mm. Next, the nickel-plated copper block was also made thinner. Instead of 7 mm, it is now only 5.5 mm thick. The water flow within the cooler was also optimized. All important components such as the voltage converters and the RAM are now cooled much better and more effectively by water. All this provides a significant increase in cooling performance. Copper or aluminum? Alphacool, of course, only uses copper in its water coolers. In the Eisblock ES Acetal GPX-N RTX 3080/3090 Turbo the copper is nickel-plated. However, compared to the previous models, Alphacool has improved the type of nickel plating once again. This has significantly increased the acid resistance and is intended to prevent nickel plating from flaking off. Why does Alphacool use copper instead of aluminum? Copper simply has almost twice the thermal conductivity of aluminum and is therefore clearly the better material for water cooling. Technical data cooler L x W x H 266,7 x 97,90 x 14,75 mm Material cooler Nickle-plated copper Material cooler top acetal Threads 2 x G1/4“ Thickness cooling fins 0,6 mm Technical data backplate L x W x H 266,7 x 97,6 x 6 mm Material aluminium Color Black Compatibility list: - ASUS Turbo GeForce RTX 3090 (90YV0FK0-M0NB00) - ASUS Turbo GeForce RTX 3080 10GB (TURBO-RTX3080-10G) - ASUS Turbo GeForce RTX 3080 V2 10GB (TURBO-RTX3080-10G-V2) Downloads:Datasheet PDF | Manual PDF | Nvidia List of Compatibility PDF Links: Graphics Card Configurator

Alphacool's ultimate solution lets you cool your computer with a sheet of ice. Not an ice sheet in the conventional sense, made of frozen water, but a sheet that brings every chip down to freezing. The properties of these new thermal pads speak for themselves.The light version of the Alphacool Eisschicht ("ice sheet") is the "small and weak" version at 7W/mK, but is definitely strong enough. Any hardware components can now be put together neatly and easily with thermal pads. The Alphacool Eisschicht offers all the benefits and typical qualities of a thermal pad: self-adhesive, elastic, flexible, and much more! Just as varied are the options for placement: whether on RAM or motherboard coolers, or graphics card and CPU coolers, any place where chips meet cooler bodies is a good place for an Alphacool Eisschicht.The Eisschicht Light, with a performance level of 7W/mK, is available in 0.5mm, 1mm, and 1.5mm thicknesses. Perfect for levelling height differences. Each thickness is also available in 100x100mm and 120x20mm (suitable for RAM coolers) sizes. These can easily be cut with scissors to get the right size for any component. Technical dataDimensions (L x W x H)100 x 100 x 0,5mmThermal conductivity7W/mKColorpink

Alphacool's ultimate solution lets you cool your computer with a sheet of ice. Not an ice sheet in the conventional sense, made of frozen water, but a sheet that brings every chip down to freezing. The properties of these new thermal pads speak for themselves.The light version of the Alphacool Eisschicht ("ice sheet") is the "small and weak" version at 7W/mK, but is definitely strong enough. Any hardware components can now be put together neatly and easily with thermal pads. The Alphacool Eisschicht offers all the benefits and typical qualities of a thermal pad: self-adhesive, elastic, flexible, and much more! Just as varied are the options for placement: whether on RAM or motherboard coolers, or graphics card and CPU coolers, any place where chips meet cooler bodies is a good place for an Alphacool Eisschicht.The Eisschicht Light, with a performance level of 7W/mK, is available in 0.5mm, 1mm, and 1.5mm thicknesses. Perfect for levelling height differences. Each thickness is also available in 100x100mm and 120x20mm (suitable for RAM coolers) sizes. These can easily be cut with scissors to get the right size for any component. Technical dataDimensions (L x W x H)120 x 20 x 0,5mmThermal conductivity7W/mKColorpink

Alphacool's ultimate solution lets you cool your computer with a sheet of ice. Not an ice sheet in the conventional sense, made of frozen water, but a sheet that brings every chip down to freezing. The properties of these new thermal pads speak for themselves.The light version of the Alphacool Eisschicht ("ice sheet") is the "small and weak" version at 7W/mK, but is definitely strong enough. Any hardware components can now be put together neatly and easily with thermal pads. The Alphacool Eisschicht offers all the benefits and typical qualities of a thermal pad: self-adhesive, elastic, flexible, and much more! Just as varied are the options for placement: whether on RAM or motherboard coolers, or graphics card and CPU coolers, any place where chips meet cooler bodies is a good place for an Alphacool Eisschicht.The Eisschicht Light, with a performance level of 7W/mK, is available in 0.5mm, 1mm, and 1.5mm thicknesses. Perfect for levelling height differences. Each thickness is also available in 100x100mm and 120x20mm (suitable for RAM coolers) sizes. These can easily be cut with scissors to get the right size for any component. Technical dataDimensions (L x W x H)120 x 20 x 1mmThermal conductivity7W/mKColorpink

Alphacool's ultimate solution lets you cool your computer with a sheet of ice. Not an ice sheet in the conventional sense, made of frozen water, but a sheet that brings every chip down to freezing. The properties of these new thermal pads speak for themselves.The light version of the Alphacool Eisschicht ("ice sheet") is the "small and weak" version at 7W/mK, but is definitely strong enough. Any hardware components can now be put together neatly and easily with thermal pads. The Alphacool Eisschicht offers all the benefits and typical qualities of a thermal pad: self-adhesive, elastic, flexible, and much more! Just as varied are the options for placement: whether on RAM or motherboard coolers, or graphics card and CPU coolers, any place where chips meet cooler bodies is a good place for an Alphacool Eisschicht.The Eisschicht Light, with a performance level of 7W/mK, is available in 0.5mm, 1mm, and 1.5mm thicknesses. Perfect for levelling height differences. Each thickness is also available in 100x100mm and 120x20mm (suitable for RAM coolers) sizes. These can easily be cut with scissors to get the right size for any component. Technical dataDimensions (L x W x H)120 x 20 x 1,5mmThermal conductivity7W/mKColorpink

Stannol KS115 electronic solder wire has been designed for the special requirements of lead-free soldering. It is suitable for industrial manufacturing as well as for rework and repair. Stannol solder wire KS115 contains a rosin-free, halide activated synthetic resin. The flux formulation of KS115 is classified to DIN EN 29454-1 Type 1.2.2.B. Due to its high activity (1.5%), the flux is classified as REM1 to IEC 61190-1-3. Alloy: 99% tin, 1% copper Melting point 227°C Active flux for fast wetting of solder pads and pins Bright amber residues with low thermal decomposition at soldering temperatures Solid residues with high softening point Low fuming Low spitting Available in a range of diameters and pack sizes Seos DIN EN 29454-1 Fluksipitoisuus Fluksikanavien määrä KS100 1.2.3 3,0 % 1 KS110 1.2.2 3,0 % 1 KS115 1.2.2 3,0 % 1

Stannol KS115 electronic solder wire has been designed for the special requirements of lead-free soldering. It is suitable for industrial manufacturing as well as for rework and repair. Stannol solder wire KS115 contains a rosin-free, halide activated synthetic resin. The flux formulation of KS115 is classified to DIN EN 29454-1 Type 1.2.2.B. Due to its high activity (1.5%), the flux is classified as REM1 to IEC 61190-1-3. Alloy: 99% tin, 1% copper Melting point 227°C Active flux for fast wetting of solder pads and pins Bright amber residues with low thermal decomposition at soldering temperatures Solid residues with high softening point Low fuming Low spitting Available in a range of diameters and pack sizes Seos DIN EN 29454-1 Fluksipitoisuus Fluksikanavien määrä KS100 1.2.3 3,0 % 1 KS110 1.2.2 3,0 % 1 KS115 1.2.2 3,0 % 1

Stannol KS115 electronic solder wire has been designed for the special requirements of lead-free soldering. It is suitable for industrial manufacturing as well as for rework and repair. Stannol solder wire KS115 contains a rosin-free, halide activated synthetic resin. The flux formulation of KS115 is classified to DIN EN 29454-1 Type 1.2.2.B. Due to its high activity (1.5%), the flux is classified as REM1 to IEC 61190-1-3. Alloy: 99% tin, 1% copper Melting point 227°C Active flux for fast wetting of solder pads and pins Bright amber residues with low thermal decomposition at soldering temperatures Solid residues with high softening point Low fuming Low spitting Available in a range of diameters and pack sizes Seos DIN EN 29454-1 Fluksipitoisuus Fluksikanavien määrä KS100 1.2.3 3,0 % 1 KS110 1.2.2 3,0 % 1 KS115 1.2.2 3,0 % 1

The Alphacool Eisschicht Ultra Soft are the ultimate in thermal pads. Their outstanding properties mean they can almost be compared to thermal paste. The Eisschicht Ultra Soft pads fit much better to components, which contributes to excellent cooling performance.Better than standard thermal pads?The ultra-soft material of the Eisschicht Ultra Soft thermal pads acts in a similar way to thermal paste. While normal thermal pads are simply pressed together by the contact pressure, which can lead to uneven contact pressure on components of different heights, this is almost impossible with the Eisschicht Ultra Soft thermal pads. The material spreads as well as thermal paste and thus prevents the highest components from being subjected to increased contact pressure from the cooler. In the worst case, this can lead to the PCB bending. The soft consistency also fills in any uneven areas much better. The Eisschicht Ultra Soft thermal pads therefore cling much better to the components, which of course benefits heat transfer.But that’s not the only advantage!The special material also cannot dry out. Usually the silicone in thermal pads bleeds over time. This causes them to become hard and the performance of the pads drops rapidly at a certain point. This is not the case with the Eisschicht Ultra Soft thermal pads. They can be used for a much longer period of time without losing any significant performance.A thermal pad with fabric?The consistency of the heat-conducting material is similar to a viscous thermal paste. A special fabric is embedded so that the material remains stable and can be used as a thermal pad. This ensures perfect distribution of the material if the element to be cooled has an uneven shape. Examples of this include voltage converters, VRam and similar electronic components of all kinds that require cooling.Cropping? No problem!When cutting the thermal pads, you should definitely leave the foil on the pads. This means that the pads can be easily cut to size with scissors. It's just as easy as cutting paper. The cut edges stay perfectly clean and don't fray.The Alphacool Eisschicht Ultra Soft thermal pads are superior to the usual thermal pads in many ways and are also used in all new Eisblock Aurora graphics card coolers from Alphacool. Technical dataDimensions (L x W x H)100 x 100 x 3mmThermal conductivity3 W/mKElectrical ConductiveNoColorwhite

Alphacool's performance thermal pad can be used to cool electronic components of all kinds where it is essential to effectively dissipate waste heat. In addition to voltage converters and VRAMs on graphics cards, electronic components of Playstation and Xbox game consoles can also be cooled, greatly improving their performance and durability.Better than standard thermal pads?The silicone-based Soft heat conduction pad is characterized by optimal compressibility. Due to its low hardness and a natural stickiness, the Core thermal pad adapts perfectly to surfaces, compensates for unevenness between components and thus ensures a significant improvement in heat transfer.Increased service life!The special material composition of the Core thermal pad reduces the risk of silicone bleeding. It can be used for a substantially longer period of time than conventional heat conduction pads without significantly losing performance.Versatile use!Due to its excellent electrical insulation (electrically non-conductive), Alphacool's thermal pad can also be used to cool electronic components in electric vehicles, autopilot systems, cell phones, servers, motherboards, power supplies, LCD TVs, notebooks, telecommunication devices, access points, memory modules, etc. Technical data thermal padDimensions (L x W x H)100 x 100 x 1mmThermal Conductivity (ASTM D5470)6.2 W/mK (±10%)Hardness (ASTM D412)50 (Shore 00) (±15)Working temperature-50 to ~150°CVolume Resistance (ASTM D257)1×10¹³ Ohm-mDielectric Breakdown Voltage (ASTM D149)6 KV/mm (±10%)Density (ASTM D792)3.1 g/cm³ (±10%)Elongation (ASTM D412)50%Weight Loss (ASTM E595)less than 1%Flame Rating (UL 94)V-0Colorblue

The Alphacool Aurora Acryl GPX Eisblock combines style with performance and extensive digital RGBlighting. With experience of over 16 years, Alphacool the ability to create GPU blocks that represent highquality and fantastic performance. This perfectly describes the Aurora Acryl GPX EisblockMore Performance!During the development of the EIsblock Aurora GPX graphic card GPU block, we wanted to further increase the performance. The first step was to move the cooler closer to the individual components byreducing the thermal pads to a thickness of 1 mm. Next, we reduced the thickness of the nickel-platedcopper block. Instead of 7 mm, it is now only 5.5 mm thick. The water flow inside the cooler has alsobeen optimized. All important components such as the voltage transformers and the memory are nowsignificantly better and more effectively cooled by the water. All this ensures a significant increase in cooling performance.New Design!The Eisblock Aurora GPX cooler has been designed so that lighting is more important than the previousmodels. The addressable digital RGB LEDs are embedded directly into the cooling block and run alongthe entire cooling block. The effect is an illumination of the entire cooling block. No corner or edge remains unlit by the aRGB LEDs. The new design is more angular with all edges bevelled. This promotesbetter light diffusion in the water cooler due to the reflections on these bevels. In addition, they createvarious contours, which give the Aurora GPX Eisblock cooler its very own unique identity.Copper or Aluminium?Of course, Alphacool only uses copper for its water coolers. With the Aurora GPX Eisblock, the copperis nickel-plated. Compared to its predecessor models, Alphacool has improved the nickel plating even further, which has considerably increased the acid resistance. This means that the nickel should resist flaking.Why does Alphacool rely on copper instead of aluminium? Simply, copper has almost twice the thermalconductivity of aluminium and is therefore clearly the better material for water cooling.Is There Anything Else New?The Eisblock Aurora GPX also relies on the new patented stop fittings, which sit flush with the surface ofthe terminal. The Alphacool logo now sits in the corner on the top and is also fully illuminated. On thefront of the terminal you can see the corresponding names of the compatible graphic card types. Ofcourse, these are also fully illuminated by the digital LEDs. IN and OUT are now marked by small triangles. They are easily recognizable and fit perfectly into the entire aesthetics of the graphic card watercooler.The Alphacool Aurora GPX Acryl is a complete redevelopment of the previous Alphacool graphics cardwater coolers. No technical compromises were made, but the entire technical know-how flowed into thedevelopment and implementation. Compatibility:- Sapphire Pulse Radeon RX 5600 XT, 6GB GDDR6 (11296-01-20G)- MSI Radeon RX 5700 Evoke OC, 8GB GDDR6 (V381-024R)- MSI Radeon RX 5700 Evoke, 8GB GDDR6- MSI Radeon RX 5700 Mech OC, 8GB GDDR6 (V381-005R)- MSI Radeon RX 5700 Mech, 8GB GDDR6- Sapphire Pulse Radeon RX 5700 8G, 8GB GDDR6 (11294-01-20G)- MSI Radeon RX 5700 XT Evoke OC, 8GB GDDR6 (V381-001R)- MSI Radeon RX 5700 XT Evoke, 8GB GDDR6- MSI Radeon RX 5700 XT Mech OC, 8GB GDDR6 (V381-003R)- MSI Radeon RX 5700 XT Mech, 8GB GDDR6- Sapphire Pulse Radeon RX 5700 XT 8G, 8GB GDDR6 (11293-01-20G) Technical data GPU coolerDimension (B x T x H)123 x 228 x 30 mmMax working temperature60 °CMaterial coolernickel plated copperMaterial topacrylThikness of fins0,6 mmThreads4 x G1/4“Power supply Digital RGB3-Pin 5VPressure tested1,5 BarColortransparent

The Alphacool Aurora Acryl GPX Eisblock combines style with performance and extensive digital RGBlighting. With experience of over 16 years, Alphacool the ability to create GPU blocks that represent highquality and fantastic performance. This perfectly describes the Aurora Acryl GPX EisblockMore Performance!During the development of the EIsblock Aurora GPX graphic card GPU block, we wanted to further increase the performance. The first step was to move the cooler closer to the individual components byreducing the thermal pads to a thickness of 1 mm. Next, we reduced the thickness of the nickel-platedcopper block. Instead of 7 mm, it is now only 5.5 mm thick. The water flow inside the cooler has alsobeen optimized. All important components such as the voltage transformers and the memory are nowsignificantly better and more effectively cooled by the water. All this ensures a significant increase in cooling performance.New Design!The Eisblock Aurora GPX cooler has been designed so that lighting is more important than the previousmodels. The addressable digital RGB LEDs are embedded directly into the cooling block and run alongthe entire cooling block. The effect is an illumination of the entire cooling block. No corner or edge remains unlit by the aRGB LEDs. The new design is more angular with all edges bevelled. This promotesbetter light diffusion in the water cooler due to the reflections on these bevels. In addition, they createvarious contours, which give the Aurora GPX Eisblock cooler its very own unique identityCopper or Aluminium?Of course, Alphacool only uses copper for its water coolers. With the Aurora GPX Eisblock, the copperis nickel-plated. Compared to its predecessor models, Alphacool has improved the nickel plating even further, which has considerably increased the acid resistance. This means that the nickel should resist flaking.Why does Alphacool rely on copper instead of aluminium? Simply, copper has almost twice the thermalconductivity of aluminium and is therefore clearly the better material for water cooling.Is There Anything Else New?The Eisblock Aurora GPX also relies on the new patented stop fittings, which sit flush with the surface ofthe terminal. The Alphacool logo now sits in the corner on the top and is also fully illuminated. On thefront of the terminal you can see the corresponding names of the compatible graphic card types. Ofcourse, these are also fully illuminated by the digital LEDs. IN and OUT are now marked by small triangles. They are easily recognizable and fit perfectly into the entire aesthetics of the graphic card watercooler. The Alphacool Aurora GPX Acryl is a complete redevelopment of the previous Alphacool graphics cardwater coolers. No technical compromises were made, but the entire technical know-how flowed into thedevelopment and implementation. Compatibility:- MSI Radeon RX 5600 XT Gaming X, 6GB GDDR6 (V381-231R)- MSI Radeon RX 5700 Gaming X, 8GB GDDR6 (V381-031R)- MSI Radeon RX 5700 XT Gaming X, 8GB GDDR6 (V381-032R) Technical data GPU coolerDimension (B x T x H)120,4 x 266,7 x 25,3 mmMax working temperature60 °CMaterial coolernickel plated copperMaterial topacrylglassThikness of fins0,6 mmThreads4 x G1/4“Power supply Digital RGB3-Pin 5VPressure tested1,5 BarColortransparent

Alphacool's performance thermal pad can be used to cool electronic components of all kinds where it is essential to effectively dissipate waste heat. In addition to voltage converters and VRAMs on graphics cards, electronic components of Playstation and Xbox game consoles can also be cooled, greatly improving their performance and durability.Better than standard thermal pads?The silicone-based Soft heat conduction pad is characterized by optimal compressibility. Due to its low hardness and a natural stickiness, the Core thermal pad adapts perfectly to surfaces, compensates for unevenness between components and thus ensures a significant improvement in heat transfer.Increased service life!The special material composition of the Core thermal pad reduces the risk of silicone bleeding. It can be used for a substantially longer period of time than conventional heat conduction pads without significantly losing performance.Versatile use!Due to its excellent electrical insulation (electrically non-conductive), Alphacool's thermal pad can also be used to cool electronic components in electric vehicles, autopilot systems, cell phones, servers, motherboards, power supplies, LCD TVs, notebooks, telecommunication devices, access points, memory modules, etc. Technical data thermal padDimensions (L x W x H)40 x 40 x 0,5mmThermal Conductivity (ASTM D5470)6.2 W/mK (±10%)Hardness (ASTM D412)50 (Shore 00) (±15)Working temperature-50 to ~150°CVolume Resistance (ASTM D257)1×10¹³ Ohm-mDielectric Breakdown Voltage (ASTM D149)6 KV/mm (±10%)Density (ASTM D792)3.1 g/cm³ (±10%)Elongation (ASTM D412)50%Weight Loss (ASTM E595)less than 1%Flame Rating (UL 94)V-0Colorblue

Alphacool's performance thermal pad can be used to cool electronic components of all kinds where it is essential to effectively dissipate waste heat. In addition to voltage converters and VRAMs on graphics cards, electronic components of Playstation and Xbox game consoles can also be cooled, greatly improving their performance and durability.Better than standard thermal pads?The silicone-based Soft heat conduction pad is characterized by optimal compressibility. Due to its low hardness and a natural stickiness, the Core thermal pad adapts perfectly to surfaces, compensates for unevenness between components and thus ensures a significant improvement in heat transfer.Increased service life!The special material composition of the Core thermal pad reduces the risk of silicone bleeding. It can be used for a substantially longer period of time than conventional heat conduction pads without significantly losing performance.Versatile use!Due to its excellent electrical insulation (electrically non-conductive), Alphacool's thermal pad can also be used to cool electronic components in electric vehicles, autopilot systems, cell phones, servers, motherboards, power supplies, LCD TVs, notebooks, telecommunication devices, access points, memory modules, etc. Technical data thermal padDimensions (L x W x H)40 x 40 x 1mmThermal Conductivity (ASTM D5470)6.2 W/mK (±10%)Hardness (ASTM D412)50 (Shore 00) (±15)Working temperature-50 to ~150°CVolume Resistance (ASTM D257)1×10¹³ Ohm-mDielectric Breakdown Voltage (ASTM D149)6 KV/mm (±10%)Density (ASTM D792)3.1 g/cm³ (±10%)Elongation (ASTM D412)50%Weight Loss (ASTM E595)less than 1%Flame Rating (UL 94)V-0Colorblue

Alphacool's performance thermal pad can be used to cool electronic components of all kinds where it is essential to effectively dissipate waste heat. In addition to voltage converters and VRAMs on graphics cards, electronic components of Playstation and Xbox game consoles can also be cooled, greatly improving their performance and durability.Better than standard thermal pads?The silicone-based Soft heat conduction pad is characterized by optimal compressibility. Due to its low hardness and a natural stickiness, the Core thermal pad adapts perfectly to surfaces, compensates for unevenness between components and thus ensures a significant improvement in heat transfer.Increased service life!The special material composition of the Core thermal pad reduces the risk of silicone bleeding. It can be used for a substantially longer period of time than conventional heat conduction pads without significantly losing performance.Versatile use!Due to its excellent electrical insulation (electrically non-conductive), Alphacool's thermal pad can also be used to cool electronic components in electric vehicles, autopilot systems, cell phones, servers, motherboards, power supplies, LCD TVs, notebooks, telecommunication devices, access points, memory modules, etc. Technical data thermal padDimensions (L x W x H)40 x 40 x 1,5mmThermal Conductivity (ASTM D5470)6.2 W/mK (±10%)Hardness (ASTM D412)50 (Shore 00) (±15)Working temperature-50 to ~150°CVolume Resistance (ASTM D257)1×10¹³ Ohm-mDielectric Breakdown Voltage (ASTM D149)6 KV/mm (±10%)Density (ASTM D792)3.1 g/cm³ (±10%)Elongation (ASTM D412)50%Weight Loss (ASTM E595)less than 1%Flame Rating (UL 94)V-0Colorblue
